Datasheet FLC01-200D Datasheet (SGS Thomson Microelectronics)



Application SpecificDiscretes

A.S.D.

FEATURES

SPACESAVING: MONOLITHICFIRE LIGHTER
FUNCTIONINTEGRATION

DEDICATED THYRISTOR STRUCTURE FOR
CAPACITANCE DISCHARGE IGNITION
OPERATION

TM

FLC01-200D

FIRE LIGHTER CIRCUIT

HIGHPULSECURRENT CAPABILITY
190A@ tp = 10µs

DESCRIPTION

The FLC01 is a high performance planar dif-

-

fused technology adapted to high temperature
and rugged environmental conditions.

It has been developed especially for capaci-

-

tance discharge operation. The main applica­tionsare gas lighter orignitor such as :
cookers/ gasboilers/ gas hobs...

Th : Thyristorforswitching operation.
Z :Zener diode to set the thresholdvoltage.
D : Diodefor reverseconduction.
R:2kΩresistor.

1

2

3

SOT82

(Plastic)

FUNCTIONALDIAGRAM

October 1999 Ed: 3A

1/7

FLC01-200D

ABSOLUTERATINGS

(limiting values) : -30°C<T

amb

< 120°C

Symbol Parameter Value Unit

I

TRM Repetitivesurge peak on state currentfor thyristor

I

FRM

di/dt
Tstg

Tj

Toper

T

L Maximumlead temperatureforsolderingduring10s

Note 1 : Test currentwaveform

Repetitivesurge peak on state currentfor diode
Criticalrateof rise time on statecurrent

Storage junction temperaturerange
Maximumjunction temperature

Operatingtemperaturerange

tp =10µs

(note1)

190 A

120 A/µs

- 40 to+ 150
+ 125

-30 + 120 °C
260 °C

°C

m

THERMALRESISTANCE

Symbol Parameter Value Unit

Rth(j-a)

Thermalresistancejunctionto ambient

100

ORDERING INFORMATION

FLC 01 - 200 D

FIRELIGHTERCIRCUIT

PACKAGED : SOT82

°

C/W

2/7

CIRCUITNUMBER: 01 = scr + diode+ zener + resistance
(pin3 not connected)

V

RM

200= 200 V

FLC01-200D

ELECTRICAL CHARACTERISTICS

Symbol Parameters

V

RM

V

BO Breakovervoltage

V

T On-statevoltage

V

F

I

BO

I

RM Leakagecurrent

αT

Stand-offvoltage

Diodevoltage drop
Breakovercurrent

Thermalcoefficientfor V

BO

V

BO

V

RM

I

I

F

V

T

I

RM

I

BO

I

V

F

T

DIODE(D) PARAMETER

Symbol Test Conditions Value Unit

V

F I

=2A tp≤1ms

F

Tj=25°C MAX 1.7 V

THYRISTOR (Th) and ZENER (Z) PARAMETERS

V

Symbol Testconditions Min Typ Max Unit

I

RM

VRM= 200V

Tj=25°C1µA

Tj =125°C10µA

V

BO atI

I

BO

V

T I

α

T 0.27 V/°C

BO

atV

BO

=2A tp≤1ms

T

Tj=25°C 206 220 233 V
Tj=25°C 0.5 mA
Tj=25°C 1.7 V

Fig.1 : Relative variation of breakover current

) versusjunctiontemperature

(I

BO

k = I (Tj) / I (25°C)BO BO

2.5

2

1.5

1

0.5

0

-20 0 20 40 60 80 100

Tj (°C)

3/7

FLC01-200D

BASICAPPLICATION

Rs Ds

AC

Ic

Ic

t

c

Th

Z

MAINS

R

The applications of the lighter using the
capacitance discharge topology operate in 2
phases:

PHASE1

The energy coming from the mains is stored into
thecapacitorC.Forthat,the AC voltageis rectified
bythe diode Ds.

PHASE2

At the end of the phase 1, the voltage across the
capacitorCreachestheavalanchethresholdofthe
zener.Thena currentflowsthroughthegate of the
thyristorTh which fires.

The firing of the thyristor causes an alternating
currentto flowthroughthe capacitorC.

D

ThepositivepartsofthiscurrentflowthroughC,Th
and the primaryof theHVtransformer.

Thenegativepartsof thecurrentflowthroughC, D
and the primatyof the HVtransformer.

RS RESISTORCALCULATION

The Rs resistor allows, in addition with the
capacitor C, to adjust the spark frequency and to
limitate the current fromthe mains. Its value shall
allow thethyristorTh to fireevenin theworstcase.
Inthisborderlinecase thesystemmustfirewiththe
lower RMS mains voltage value while the
breakdown voltage and current of the FLC are at
the maximum.

4/7

Rs

max=

* : seefig 1

The maximumRs value is equal to :

min.

√2)−

[

V

BO

max .(1

V

(

AC

k.I

BO

+α

∗

T

(

T

amb

−25))

]

.

FLC01-200D

Fig. 2 :

Sparkfrequencyversus Rs and C

F (Hz)

20

10

5

3
2

1

4.7 6.8 10 12 15 18 22 27 30

The couple Rs/C can be chosen with the previous
curve. Keep in mind the Rs maximum limit for
which the system would not work when the AC

Vac=220Vrms,Vbo=225V,Tamb=25°C

C=0.47

C=0.47

µ

µ

F

F

C=1

C=1

µ

µ

F

F

µ

µ

F

F

C=3.3

Rs (k )

Ω

C=2.7

µ

F

C=2.2

µ

F

C=1.5

C=1.5

µ

F

mains is minimum. The next curve shows the
behaviorwith Rs=15kΩ and C=1µF.

Fig. 3 :

Voltageacross thecapacitancewith Rs = 15kΩ,C=1µF and V

BO

= 225V

.

5/7

FLC01-200D

PEAK CURRENT LIMIT

This compon ent is designed to withst and
I

= 150A for a pulse duration of 10µs for an

TRM

Fig. 4 : Peak current limit

ITRM (A)
190

180
170
160
150
140
130
120
110

6 8 10 12 14

ambient temperature of 120°C in repetitive surge.
The curve of peak current versus the pulse
duration allows us to verify if the application is
withinthe FLC operatinglimit.

Tjmax =125°C

tp (µs)

POWER LOSSES (For 10µs, seenote 1)

To evaluatethe power losses,pleaseusethefollowing equations:

Forthethyristor: P= 1.18x I
Forthediode: P =0.67 x I

F(AV)

T(AV)

+ 0.106I

+ 0.035I

2

T(RMS)

2

F(RMS)

6/7

PACKAGEMECHANICAL DATA

SOT82(Plastic)

FLC01-200D

DIMENSIONS

REF.

A 7.4 7.8 0.291 0.307

Millimeters Inches

Min. Max. Min. Max.

A

C

B 10.5 10.8 0.413 0.425

b 0.7 0.9 0.395 0.035

F

B

b1 0.49 0.75 0.019 0.029

C 2.4 2.7 0.094 0.106

c1 1.0 1.3 0.039 0.051

D 15.4 16.0 0.606 0.630

e 2.2 typ. 0.086typ.

H2

c1

I

H

e3 4.15 4.65 0.163 0.183

D

V

F 3.8 typ. 0.149typ.
H 2.54 0.100

H2 2.15typ. 0.084typ.

e

I 1.27typ. 0.05 typ.

O 0.3 typ. 0.012typ.

e3 b1 O

b

V10° 10°

Marking

: type number

Weight: 0.72g.
