INSTRUCTION MANUAL |
Model: DWF-6010 |
TABLE OF CONTENTS |
|
SAFETY INSTRUCTIONS & |
|
SPECIFICATIONS .......................................... |
2 |
PARTS DESCRIPTIONS................................ |
3 |
DIRECTIONS FOR SAFE USE ..................... |
4 |
•How To Install................................................. |
4 |
•Water Connection .......................................... |
6 |
•Drain Hose Setting......................................... |
7 |
HOW TO OPERATE ....................................... |
8 |
• Preparation for Washing ............................... |
8 |
• Descriptions of Control Panel ....................... |
9 |
• General Procedures for Operation ............. |
10 |
• Guides for Basic Washing Programs ......... |
11 |
• Guides for Other Useful Programs............. |
13 |
PERIODIC MAINTENANCE ........................ |
14 |
SPECIAL GUIDES FOR REMOVING STAINS ... |
16 |
TROUBLE SHOOTING GUIDES................. |
17 |
PLEASE READ CAREFULLY THIS INSTRUCTION
MANUAL BEFORE USING YOUR WASHER AND
SAVE THIS FOR FUTURE REFERENCE.
SAFETY INSTRUCTIONS & SPECIFICATIONS
SAFETY INSTRUCTIONS
Your safety is important to us.
Read all instructions before using your washer.
Do not wash items cleaned, washed, soaked in, or spotted with wax, paint, gasoline, oil, or other flammable fluids. The fumes can create a fire hazard or explosion.
Flammable fluids (dry-cleaning solvents, kerosene, gasoline, etc.) should not be used or stored in or near your washer. Do not add flammable fluids to your wash water. These substances give off vapors that can create a fire hazard or explosion.
Do not allow children to operate, play with, or crawl on or inside your washer. Supervise children closely when your washer is used near them.
Do not reach into the wash tub unless START/HOLD button is pressed and all motion stops, while spinning.
Do not use chlorine bleach and ammonia or acids (such as vinegar or rust remover) in the same wash. Hazardous fumes can form.
Unplug power supply cord before attempting to service your washer.
Do not pour water on the control panel.
Remove foreign objects (such as coin, pin, knife, other metallic materials, etc.) inside your wash load. They may damage any fabric.
Do not overload your washer to avoid poor cleaning, wrinkling and/or any abnormal operation.
SPECIFICATIONS
MODEL NO |
DWF-6010 |
|
|
|
|
|
|
|
Power Source |
Please refer to the rating label at the back of your washer. |
|||||||
Power Consumption |
|
|
|
250W |
||||
Width Depth (mm) |
|
|
|
532 542 |
||||
Height (mm) |
855 |
|
|
|
|
|
|
|
Net Weight (Kg) |
32.5 |
|
|
|
|
|
|
|
Maximum Mass of Textile |
|
6.0kg |
|
|
||||
Material of Internal Tub |
Anti-Rust Stainless Steel |
|
|
|||||
Water Consumption |
Approx. 130 Liters/Cycle |
|
|
|||||
Washing Capacity |
Please refer to the rating label at the back of your washer. |
|||||||
Washing Program |
|
|
|
4 Programs |
||||
Water Level |
|
High (55 Liters), Medium (45 Liters), Low (31 Liters) |
||||||
Direction of Inlet Valve |
Backward |
|
|
|
||||
Operating Water Pressure |
|
0.3Kgf/cm2~8Kgf/cm2 (2.94N/cm2~78.4N/cm2) |
||||||
Pulsator |
Provided with 6 Spouting Holes for Powerful Upward Water Stream |
|||||||
|
1. Air Bubble Generator |
|||||||
Optional Features |
2. Reserved Washing with Display for remaining time |
|||||||
|
3. Signal Buzzer for the Operation of Control Button |
|||||||
|
|
|
|
|
|
|
|
|
The above specifications and features are subject to change without prior notice
2
PARTS DESCRIPTIONS
DETERGENT CASE (Symbol)
FABRIC SOFTNER INLET (Symbol, See page 10)
LIQUID BLEACH INLET (Symbol, See page 10)
CONTROL PANEL (88 display and some
buttons may be excluded) WASH TUB
PULSATOR
BASE (Height is
WATER CONNECTOR
(Blue Color: Cold,
Pink Color: Hot)
DOOR
DRAIN HOSE
LINT FILTER
PLUG
GROUND WIRE (This will not be provided in case of 3-wire power cord)
ADJUSTABLE LEG (Optional)
The drawings in this book may vary from your washer model. They are designed to show the different features of all models covered by this book. Your model may not include all features.
ACCESSORIES
Dryten |
Hose Adapter |
Under Cover |
Hose Clamp |
|
(option) |
(option) |
|||
|
|
|||
|
|
UP |
|
|
|
In case of screw-shaped inlet hoses water |
|
|
|
|
tap adapters will not be provided. |
|
|
|
|
Drain Hose |
Inlet Hose |
|
|
|
(option) |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Non-Pump Model |
Pump Model |
|||||||
|
|
|
|
|
|
3
DIRECTIONS FOR SAFE
HOW TO INSTALL
Location
Place your washer on a level and solid floor, considering the length of inlet hose, drain hose and power supply cord.
Do not place or store your washer below 0°C(32°F) to avoid any damage from freezing.
Do not place your washer where it may be splashed during bathing.
If washer is not level, it should be corrected by the adjustable leg (provided optionally) in the front-right side under the base and/or, a thin block or brick.
NOTES:
The opening muse not be obstructed by carpeting when the washing machine is installed on a carpeted floor.
Installation of the Under Base Cover (Option) |
After installing the washing machine, assemble |
|
-DWF-6010 |
||
the under-base cover. |
||
Before installing your washer, remove the |
Push the under-base cover into the end, |
|
åpad from the bottom of the cabinet. |
∫which decrease the noise made by this |
|
Then, separate under cover from rear side |
washer. |
|
of cabinet by unscrewing and insert it into |
|
|
the base. |
|
|
SCREW |
|
Power Supply
*Before plugging the plug into wall receptacle, check the voltage rating is in the range of rating, marked on the label at the back side of your washer.
LABEL
Grounding
•If your water tap or water pipe is not made of metal, connect the ground wire to a copper plate or a metal rod and bury it in the earth.
20Cm
•If both your water tap and water pipe are made of metal, connect the ground wire to the base of the water tap.
•It is of no use connecting the ground wire to the water pipe made of plastic.
•In case of using 3-core cord, there is no need for grounding.
Never Connect the Ground Wire to Such a Thing
• Never connect it to a gas pipe because of danger |
• Never connect it to a telephone wire or a lightning |
of a explosion. |
rod because of os very dangerous at a |
|
thunderbolt. |
Gas Pipe |
|
Telephone Wire |
5
WATER CONNECTION
Be careful not to confuse hot water inlet (pink color) and cold water inlet (blue color), if your washer is provided with dual water inlets.
Also if you have only one water tap, connect the inlet hose with cold water inlet (blue color).
For normal tap
! Pull down the collar of the |
@ Loosen the four screws |
# Fit the hose adapter into the water |
inlet hose to separate it |
properly in fitting into |
tap and tighten the four screws |
from the hose adapter. |
water tap. |
evenly while pushing up the |
|
|
adapter so that the rubber packing |
|
|
can stick to the water tap tightly. |
|
|
TAPE |
$ Remove the tape, and |
% Connect the inlet hose to |
^ Connect the opposite end |
screw connector B into |
the hose adapter, pulling |
of the hose to water inlet |
connector A tightly. |
down the collar of hose |
of your washer tightly. |
|
end. |
• Please check the rubber |
|
|
packing is inside the |
|
|
hose end. |
Connector |
|
|
Connector B |
|
|
*In case that your washer is not provided with collar compartment, procedure # and % is not necessary.
For Thread-Fitting Type
!Connect the inlet hose to the thread of water tap or water pipe by tightening.
Rubber
Connector Packing
Hose
Connector
@For the opposite end, connect it to water inlet as the above procedure ^.
Leak Test
Turn on the water completely to check for any leakage. If any leakage, turn off the water, try again as the above procedures.
For the special tap, call a qualified plumber for the installation.
6
