DIN Rail & Panel Mount Solid State Relays
NOVA22 Solid State Relays were developed combining
technology and innovation to offer high performing solid state
relays in a 22.5mm industrial package.
Highest power available in a 22.5mm wide
package
The advanced design and technology used in NOVA22
products provide greater power density than any other 22.5
mm wide SSR in the market: 35 Amps in DIN Rail mount and
95 Amps in Panel Mount package.
Wide and innovative range of connections
The unique range of terminal options and configurations
makes NOVA22 the most versatile solution. Relay or Contactor
terminal configurations, screw or spring cage plug-in input
terminals, standard or elevator screws, allowing the use of ring
terminals, are all options offered within the NOVA22 family.
NOVA22 Solid state relays are built with high quality
components and Crydom’s technology and innovation
making them the most powerful and versatile solid state
relays in a 22.5mm package on the market today!
Diverse Range of Applications
NOVA22 Solid State Relays can be used in a wide range of AC
and DC applications. Ideal for heating applications, NOVA22s
are also suitable for motion, power and lighting applications;
especially for demanding applications that require higher
levels of reliability including:
Industrial OEMs: Plastic Machinery, Packaging and
Material Handling Equipment, Industrial Ovens, Pumps
Food & Beverage: Baking Ovens, Refrigeration, Food
Processing Equipment
Building Equipment: HVAC&R, Lighting, Access
Control
Energy & Infrastructure: Renewable Energy, Water
and Waste Water Treatments
Transportation: Agricultural Machinery, Railway
Vehicles
50g and 500 Hz, per IEC 60068-2)
(Tested for Shock and Vibration Resistance up to
Power & Versatility in a 22.5mm Package!
2
Rated up to 35 Amps
(DIN Rail Mount) and
95 Amps (Panel Mount)
600 VAC or
200 VDC models
Built-in overvoltage
transient protection
ID marker for easy
identification
High I
breakers (8320 A
t for use with circuit
2
sec)
Zero Voltage or
Instantaneous Turn-On
High resistance to
Shock and Vibration
C-UL-US Listed, CE,
and TUV certified
LED input
status indicator
Input control available in
DC and AC voltage options
Relay or Contactor
configuration
100 kA SCCR
Industry standard Panel Mount
package available
Screws or spring cage
Input terminals
Standard or elevator
innovative output screw
