Tower
Fan CTF-P53D
General Safety Precautions
1. Thank you for your purchase of this appliance. Read all
instructions carefully. Keep this User Manual for future reference.
2. Always switch off and unplug the appliance from the electrical
outlet BEFORE cleaning and also when not in use.
3. Never immerse the appliance, power cord or plug into water or
other liquids. Please refer to the section on “Care and Cleaning”.
4. If it is a detachable power cord, always connect the power cord to
the appliance first BEFORE plugging it into the electrical outlet.
To disconnect the appliance, switch off the power on the electrical
outlet before removing the power plug.
5. Close supervision is necessary when operating the appliance
near children. Ensure that the power cord does not hang over the
work surface.
6. Do not operate the appliance with a damaged power cord set or
plug. Any repairs should always be carried out by an authorized
service centre.
7. Do not use the appliance for any purposes other than its intended
use. This appliance is intended for household use only.
8. Do not use the appliance in the outdoors or in a damp area.
9. Do not place the appliance on or near a hot gas or electric burner,
or near easily flammable materials.
10. This appliance should not be used by people who are physically
or mentally impaired (including children) unless proper guidance
is provided during operation.
Parts Identification
Control Panel Display
1
2
3
4
5
6
7
8
9
10
11
12
Front View Back View
1. Control Panel Cover
2. Control Panel
3. LCD Display Panel
4. Remote Control Sensor
5. Wind Outlet
6. Base
7. Remote Control Sensor
8. Handle
9. Screw
10. Remote Control Holder
11. Dustproof Filter
12. Remote Control
Specifications
Model No.
CTF-P53D
Rated Voltage
220-240V~
Rated Power
40W
Frequency
50Hz
Fig. 1 Fig. 2
Fig .3 Fig. 4
Operating Instructions
Assembling Method
1. Unpack the appliance from the gift box.
2. Lay the main body horizontally on the ground.
3. Assemble the front base and rear base.
4. Insert the assembled base to the main body. Use the base screws
(provided) to secure base to the main body.
5. Lift the Tower Fan upright.
6. Do not use this appliance before finish assembling.
Operating Procedure
The appliance is to be operated by selecting the function keys at
the control panel or using the remote control provided.
ON/OFF Key
Turn the fan ON by pressing ON/OFF key. The fan will
automatically operate in low speed and the low speed indicator
light will on.
Press this key again to turn off the fan.
PLASMA / ION Key
Press this key to turn on the plasma/ionizer function and press
again to turn it off.
OSCL Key
To activate the appliance with oscillation, press the OSCL key
once. The fan will oscillate horizontally at 90 degrees and the
corresponding angle will be displayed on LCD. The oscillation
mode can be manually adjusted in sequence at 90 degrees, 180
degrees or 360 degrees.
First Press Oscillates in 90 degrees
Second Press Oscillates in 180 degrees
Third Press Oscillates in 360 degrees
Fourth Press Oscillation function is off
Timer Key
Turn on the fan by pressing the ON/OFF key once.
Press the TIMER key to set the desired time for the fan to operate.
The TIMER indicator light will turn on while the LCD will display
the remaining time. When the set time is reached, the fan will
switch itself OFF automatically. Press the TIMER key continuously
to set the time from 1 to 12 hours.
Mode Key
Press this key for mode selection of either normal, natural or sleep
mode.
Normal Mode: The appliance will operate at selected fan speed of
Low, Medium and High.
Wise Mode: The appliance will operate according to the
temperature automatically as shown on the chart below:
Natural Mode: The appliance will operate in the sequence of high-
mid-low speed, in a repeat manner automatically.
Sleep Mode: The appliance will operate according to
computerized intervals of changing speeds as follow:
High Sleep Mode Operates at high-mid-low natural wind,
each for 30 minutes interval time, in a
repeat manner automatically.
Medium Sleep Mode Operates at mid-low natural wind, each for
30 minutes interval time, in a repeat
manner automatically.
Low Sleep Mode Operates at low natural wind.
“+” & “-” Key
Press “+” or “-” to increase or decrease the wind speed
respectively. The wind speed can be set from the range of 1 to 8
speed level.
The appliance can be stopped any time during any of the above
operation by pressing the ON/OFF key.
Care and Cleaning
1. Always disconnect the appliance from the electrical outlet before
cleaning.
2. Never immerse the appliance, power cord and plug into water or
allow moisture to come in contact with the appliance.
3. Wipe the exterior parts of the appliance with a mild and damp
cloth or cleaner. Never use a corrosive cleaner.
4. For proper storage, always place the appliance in a low humidity
environment.
