Cooluli INFINITY-15L Instruction Manual

COOLER &

WARMER

INFINITY-15L
THERMOELECTRIC

Instruction Manual

Page 2

Product Specs & Features

Page 3

Warranty Information

Page 4

Page 5

Page 6

Page 7-8

Page 9

Page 10

Page 11

Characteristics, Applications, & What's in the Box

Getting Started

Optimizing Performance

Frequently Asked Questions

Basic Troubleshooting

Customer Support

Product Warnings

TABLE OF CONTENTS

1

2

INFINITY-15L

COOLER & WARMER

Input/Energy Consumption:

AC 110V/0.6A

DC 12V/5A

60w max

Materials:

Aluminum, Plastic &

Tempered Glass

Cools down to:

35° - 40° below

ambient

temperature

Warms up to:

149° by internal

thermostat

Outer Dimensions:

(W x D x H)

10.5 x 13 x 14.75 in.

267 x 330 x 374.6 mm

Weight:

10.7 lbs/

4.85 kg

FEATURES

Inner Dimensions:

(W x D x H)

8.1 x 8 x 12.75 in.

206 x 203 x 323.8 mm

WARRANTY INFORMATION

1-YEAR LIMITED WARRANTY - REGISTER AT: www.cooluli.com/register

Read all the instructions before attempting to use this product.

This 1-year limited warranty applies to repair or replacement if product, at COOLULI’s
option, is found to be defective in material or workmanship.

1. This warranty only applies to personal, non-commercial use. This warranty is not
applicable to any damage resulting from commercial, abusive, unreasonable use or
supplemental damage. Defects that are the result of normal wear and tear will not be
considered manufacturing defects under this warranty.

COOLULI IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY
NATURE. ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY.

2. This warranty does not cover damage resulting from any unauthorized attempts to repair
or from any use not in accordance with the Instruction Manual.

3. This warranty applies only to the original purchaser of this product from the original date
of purchase. This warranty applies only if the unit is purchased new from an authorized
retailer and is non-transferable from the original purchaser of the item. Any warranties
accompanied with this product is only valid in the country of purchase.

4. Unit is manufactured according to North American voltage specifications. Warranty is void
if unit is plugged into a 220-230 volt outlet.

5. Please read the Instruction Manual carefully before setting up or using this product. If you
believe this product to be suffering from a manufacturing fault, or if you have inquiries about
this product, please contact Customer Support:

COOLULI
ATTN: Customer Support
217 E. Highland Pkwy
Roselle, NJ 07203
Phone: [phone]
Email: [e-mail]

When contacting Customer Support, please have the information below along with the
proof of purchase. All warranty requests must be accompanied by proof of purchase, which is
a copy of the original receipt/invoice.
Model: ________________________________________________________________________
Date of purchase: _______________________________________________________________
Purchased from: ________________________________________________________________

3

Product Characteristics

What’s in the Box

Applications

At home, keep snacks and drinks at hand while enjoying your favorite shows and movies
uninterrupted.

Store on top of your office desk and use it as your own personal mini fridge.

Great for picnics, camping and fishing trips when cold drinks and warm food are a necessity.

Ideal for long road trips, and for commuters, and truck and taxi drivers who want to keep
f

ood and drinks fresh and close by.

Perfect for parents who need to store breast milk at a desired temperature

.

Saf

ely st

or

e medications that need to be kept at a specific temperature.

4

Fig. 2 Fig. 3

INSTRUCTION MANUAL

INFINITY-15L

AC POWER CORD

AC CONNECTOR

AC PLUG

DC CONNECTOR

DC PLUG

DC POWER CORD

Fig. 1

This thermoelectric cooler and warmer is a great way to keep food and drinks cool during
the summer and warm during the winter. Perfect to use at home, in your office, or in your car.
Wherever you are, you can always enjoy fresh food and drinks.

Sleek and easily portable, it makes a stylish choice for any décor or setting.

Shelves and container baskets are removable. To remove shelves: gently push shelves up
and slide out. To remove container baskets: gently push up/slide and lift from slots.

Included AC and DC plugs make it ideal for indoor and outdoor use. This thermoelectric
cooler/warmer unit is ultra-durable, eco-friendly, and safe to use. Its semiconductor operation
consumes minimal power and does not use compressors, cryogen, refrigerants, or Freons.

Fig. 4

Getting Started

Before plugging in the cooler/warmer unit: make sure the switch on the back of the unit is
set to the OFF setting.

A minimum 2" vent clearance is required for proper ventilation.

Plugging in your unit:

Turning on your unit:

1.

2.

3.

4.

5

For home application: use the supplied AC power cord (see Fig. 2) by inserting AC
connector int

o unit’s AC port (see Fig. 5) and inserting AC plug into wall outlet. This
unit ONLY works on 100-120V (in compliance with North American standards). Unit
will sustain damage and warranty will be void if unit is plugged into a 220-230 volt outlet.

For motor vehicle application: Car engine MUST be turned on first before plugging
in the cooler/warmer. This precaution prevents a power surge that can lead to the
unit overheating and/or becoming a potential fire risk. Use the supplied DC power
cord (see Fig. 3) and insert DC connector into unit’s DC port (see Fig. 5) and the DC
plug into the appropriate cigarette-lighter outlet.

For Cooling: Set the power switch to the COLD setting. A green light will turn on to
indicate that the unit is in cooling mode.

For Warming: Set the power switch to the HOT setting. A red light will turn on to
indicate that the unit is in warming mode.

Fig. 5

Vents

HOT/COLD SWITCH

DC/AC SWITCH

DC PORT

AC PORT

Fig. 6

HOT

2

2

HOT

COLD

Optimizing Performance

Pre-chilled food and drinks are recommended to put int

o this unit. If drinks are at room

temperature it will take 2-3 hours to chill them.

This thermoelectric cooler and warmer is not designed to heat cold food; this unit only
preserves hot foods at a warm temperature. However, this unit does have the ability to heat
some foods that are semi-cool if given a minimum of 2 hours.

With proper use, this thermoelectric cooler and warmer unit can preserve the temperature
of food, warm or cold, all day.

NOTE: Ambient temperature refers to the temperature of the surrounding air. For example, if
unit is used for cooling, and your immediate surroundings is 75°F, then the unit will keep
contents cool anywhere between 35°– 40°F.

6

The Infinity-

15L can fit 18 standard soda cans (12 fl. oz./355 ml) in the

following configuration:

• Remove both container baskets on interior door

• Remove topmost interior shelf from unit by gently pushing the shelf up and sliding it out

• Refer to Fig. 7 and Fig. 8 for suggested can configuration

Fig. 8
Can placement: interior,
top and bottom shelf view

Shelf & baskets removed

Fig. 7
Can placement: overhead,
interior view of top shelf

Frequently Asked Questions

Can I keep breast milk in my Cooluli unit?

Yes! Many new parents use our units to store breast milk conveniently in nurseries or nearby
bedrooms.

Can I store insulin in my Cooluli unit?

Yes, many of our customers use our units to store medications and other essentials.

Can my Infinity-15L keep things frozen?

The Infinity-15L should not be used as a freezer. Your Infinity-15L has the ability to keep
things cool (or warm—depending which mode you choose). Frozen items will cool down to
35° to 40°F below ambient temperature. Therefore, if you put a frozen item inside your unit
and your room is 70°F, that item will be kept at a temperature between 30°– 35°F.

What is the cooling temperature of the Infinity-15L?

The Infinity-15L can keep contents (food, drinks, snacks, medications, etc.) cool anywhere
from 35° to 40°F below ambient temperature. Please refer to page 2 of this Instruction
Manual for complete product specifications.

Can I adjust the thermostat on the Infinity-15L?

No, the Infinity-15L does not have a thermostat. ONLY units with a digital display (the
Concord series and Venture series) have a thermostat that can be set.

Does the Infinity-15L have a lock?

The Infinity-15L does not have a lock but it does feature a tight-fitting, magnetic seal that
secures and protects contents.

Are interior shelves removable?

Yes, the shelves and container baskets on the Infinity-15L unit are removable. To remove
shelves, gently push up and slide out. To remove container baskets, gently push/slide
baskets up and remove.

The back of my Infinity-15L feels warm. Is this normal?

Yes, this is normal. While in cooling mode, your Infinity-15L Thermoelectric Cooler/Warmer
moves heat from inside the unit to the back of the unit (vent area). Make sure there is at
least a 2-inch clearance for necessary air flow and circulation. If the back of your Infinity
gets very hot, turn off the unit, and contact Customer Support.

7

FAQ cont.

I hear a slight whirring sound in the back of my Infinity-15L. Is this OK?

The fan makes a slight whirring sound in the Infinity-15L— this sound is normal. The Infinity-15L
features exclusive EcoMax™ Technology—our unique cooling system that makes our
thermoelectric units quiet, yet powerful and efficient. However, if you hear a very loud sound,
turn off the unit, and contact Customer Support.

Can I leave my Infinity-15L plugged in every day, 24 hours per day?

Yes, you can leave your Cooluli unit plugged into an AC outlet in your home or office. For your
car, see the next question/answer below.

If I plug my cooler/warmer unit into my car does the car engine need to be on for the unit
to stay on?

For car or motor vehicle use, we recommend unplugging your cooler/warmer unit when the
car engine is off. Do not have the unit plugged in unless the engine is running.

Can I use my Infinity-15L in a 220V outlet?

The Infinity-15L ONLY works in 100-120V, in compliance with North American standards and
cannot be plugged into a 220V outlet.

Can I use a power bank (portable charger) with my Infinity-15L?

No, a power bank cannot be used with the Infinity-15L.

How much energy does the Infinity-15L consume?

Refer to page 2 of this Instruction Manual for spec details and information.

Does my Infinity-15L come with a warranty?

Yes, the Infinity-15L model comes with a standard 1-year limited warranty. Please refer to
page 3 of this Instruction Manual or go to [e-mail] for more information.

How can I get a replacement cord?

Cooluli r

eplacement cords are available on Amazon and on our website, Cooluli.com.

Where are Cooluli coolers/warmers made?

Cooluli is an American company based in Brooklyn, NY and our products are
custom-manufactured in China.

8

9

BASIC TROUBLESHOOTING

The most common issues experienced by Cooluli users are caused by voltage incompatibility.
T

he following issues give an overview of possible errors and instructions of how to check the

u

nit.

Concern

Possible Reason

Check

Blinking green light in the back

of unit.

Unit fan not rotating.

Contact Customer Support for
assistance. Consult this
Instruction Manual or go to
[e-mail] for contact
information.

Fan making a loud noise.

Check for fan obstruction or

failure.

Check the back to see if there is

at least a 2-inch clearance
around fan and vents. If issue
persists, contact Customer
Support.

Unit doesn’t cool contents as

advertised.

Most Cooluli units cool contents
down anywhere from 35° to 40°F
below ambient temperature.

Consult your unit’s specific
cooling information found in this
Instruction Manual. If cooling
temperature is significantly less
than what is listed for your unit,
contact Customer Support.

Unit not cooling and lights off in

back.

Unit stopped working

Main power source failure.

Check outlets first.

If unit not turning on in your
home/office: Try plugging the

unit into your car using the
included DC power cord.

If unit not turning on in your
car/motor vehicle: Try plugging

the unit into an 100-120 volt
outlet in your home/office using
the included AC power cord.
If issue persists, contact
Customer Support.

Ice is building inside the unit,

around the center screws in the
back.

Water collecting at bottom of
unit.

Water drip or leakage.

Check that the door is clean and
free from obstruction and is
closed securely.

Water condensation. It is normal
for thermoelectric units, while in
cooling mode, to produce water
droplets that may freeze in the
back and then melt.

Water condensation is normal in
thermoelectric units. Check if
water accumulation is due to
condensation.

While the unit is off and at room

temperature, take a soft cloth
and gently wipe down the inside
of your unit to remove any
moisture that may accumulate.
This is recommended once or
twice a week.

If issue persists, contact
Customer Support for further
assistance.

10

COOLULI

ATTN: Customer Support

217 E. Highland Pkwy

Roselle, NJ 07203

Phone: [phone]

Email: [e-mail]

For further assistance please contact

Cooluli Support:

CUSTOMER SUPPORT

WARNING

PLEASE READ THESE DIRECTIONS CAREFULLY BEFORE USING THIS

COOLER/WARMER UNIT TO ENSURE

PROPER OPERATION. IMPROPER USE, INSTALLATION, ADJUSTMENT,

ALTERATION, SERVICE OR

MAINTENANCE CAN CAUSE INJURY OR PROPERTY DAMAGE.

To ensure optimal performance, keep the cooler/warmer unit’s fans clear of dirt
and debris. Stuck fans will overheat the unit and can pose a potential fire hazard.
Do not place any cloth or paper products on the unit.
When plugging in the unit, ensure that the power cord is inserted tightly into the
socket. A loose socket can cause damage or fire.
When using the unit in a car/vehicle with the DC power cord, the vehicle’s engine
must be turned on first. When the engine is running, the unit can then be plugged
into the vehicle's adapter. This prevents a power surge and potential property
damage, injury, and/or fire.
Keep the unit away from flammable items and running water to prevent damage,
injury, and/or fire.
DO NOT attempt to open, break, or refit the appliance.
This unit ONLY works on 100-120V (in compliance with North American standards).
To switch temperature control, the unit must be turned to the OFF setting for 30
minutes before shifting the unit from COLD to HOT.
DO NOT submerge or rinse under running water.
When packing the unit, do not place upside-down.
Avoid dropping or banging the unit.
DO NOT leave the appliance in the rain.
Adult use and supervision only. This is not a toy. Children should not play with this
cooler and warmer unit. For people with reduced physical, sensory, and/or mental
capabilities, use precaution and follow all instructions when operating this unit to
ensure safety.
Always keep ventilation openings clear of obstruction.
DO NOT use other electrical appliances inside the food storage compartments of
the appliance.
If the power cords supplied with the cooler and warmer unit are damaged in any
way—DO NOT attempt to repair them; damaged power cords must be replaced by
the manufacturer.

11

1.

2.

3.

4.

5.

6.

7.

8.

9.

10.

11.

12.

13.

14.

15.

16.

Distributed by Cooluli®

New York, NY 10950

Made in PRC

Cooluli™ is a trademark of

LISSE USA LLC
[phone]

Copyright ©2018 all rights reserved

www.cooluli.com
