Cisco Router and Security Device User Manual

Download

Cisco Router and Security Device Manager User’s Guide

2.5

Americas Headquarters

Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134-1706 USA http://www.cisco.com Tel: 408 526-4000

800 553-NETS (6387)

Fax: 408 527-0883

Customer Order Number: Text Part Number: OL-4015-12

THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS.

THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE OR LIMITED WARRANTY, CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY.

The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California, Berkeley (UCB) as part of UCB’s public domain version of the UNIX operating system. All rights reserved. Copyright © 1981, Regents of the University of California.

NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE PROVIDED “AS IS” WITH ALL FAULTS. CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, THOSE OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF DEALING, USAGE, OR TRADE PRACTICE.

IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING, WITHOUT LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

Any Internet Protocol (IP) addresses used in this document are not intended to be actual addresses. Any examples, command display output, and figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses in illustrative content is unintentional and coincidental.

Cisco Router and Security Device Manager 2.5 User’s Guide

Home Page 1

Creating a New Connection 1

New Connection Reference 2

Create Connection 2

Additional Procedures 3

How Do I Configure a Static Route? 4 How Do I View Activity on My LAN Interface? 4 How Do I Enable or Disable an Interface? 5 How Do I View the IOS Commands I Am Sending to the Router? 5 How Do I Launch the Wireless Application from Cisco SDM? 6 How Do I Configure an Unsupported WAN Interface? 6 How Do I Enable or Disable an Interface? 7 How Do I View Activity on My WAN Interface? 7 How Do I Configure NAT on a WAN Interface? 8 How Do I Configure NAT on an Unsupported Interface? 9 How Do I Configure a Dynamic Routing Protocol? 9 How Do I Configure Dial-on-Demand Routing for My ISDN or Asynchronous

Interface? How Do I Edit a Radio Interface Configuration? 11

OL-4015-12

LAN Wizard 1

Ethernet Configuration 2

LAN Wizard: Select an Interface 2

LAN Wizard: IP Address and Subnet Mask 3

Cisco Router and Security Device Manager 2.5 User’s Guide

iii

Contents

LAN Wizard: Enable DHCP Server 3

LAN Wizard: DHCP Address Pool 4

DHCP Options 4

LAN Wizard: VLAN Mode 5

LAN Wizard: Switch Port 6

IRB Bridge 7

BVI Configuration 8

DHCP Pool for BVI 8

IRB for Ethernet 9

Layer 3 Ethernet Configuration 9

802.1Q Configuration 10 Trunking or Routing Configuration 10 Configure Switch Device Module 10 Configure Gigabit Ethernet Interface 11

Summary 11

802.1x Authentication 1

LAN Wizard: 802.1x Authentication (Switch Ports) 1

Advanced Options 2

LAN Wizard: RADIUS Servers for 802.1x Authentication 4

Edit 802.1x Authentication (Switch Ports) 6

LAN Wizard: 802.1x Authentication (VLAN or Ethernet) 7

802.1x Exception List 8

802.1x Authentication on Layer 3 Interfaces 9 Edit 802.1x Authentication 10

How Do I ... 11

How Do I Configure 802.1x Authentication on More Than One Ethernet Port?

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

Configuring WAN Connections 1

Configuring an Ethernet WAN Connection 1

Ethernet WAN Connection Reference 2

WAN Wizard Interface Welcome Window 2 Select Interface 3 IP Address: Ethernet without PPPoE 3 Encapsulation: PPPoE 4 Summary 5 Advanced Options 5

Configuring a Serial Connection 6

Serial Connection Reference 7

IP Address: Serial with Point-to-Point Protocol 7 IP Address: Serial with HDLC or Frame Relay 8 Authentication 9 Configure LMI and DLCI 10 Configure Clock Settings 11

Contents

OL-4015-12

Configuring a DSL Connection 13

DSL Connection Reference 14

IP Address: ATM or Ethernet with PPPoE/PPPoA 14 IP Address: ATM with RFC 1483 Routing 15 Encapsulation Autodetect 16 PVC 18

Configuring an ISDN Connection 20

ISDN Connection Reference 20

ISDN Wizard Welcome Window 21 IP Address: ISDN BRI or Analog Modem 21 Switch Type and SPIDs 22 Dial String 23

Configuring an Aux Backup Connection 24

Aux Backup Connection Reference 24

Cisco Router and Security Device Manager 2.5 User’s Guide

Contents

Aux Backup Welcome Window 25 Backup Configuration 25 Backup Configuration: Primary Interface and Next Hop IP Addresses 26 Backup Configuration: Hostname or IP Address to Be Tracked 27

Configuring an Analog Modem Connection 27

Analog Modem Connection Reference 28

Analog Modem Welcome 28

Configuring a Cable Modem Connection 29

Cable Modem Connection Reference 29

Cable Modem Connection Wizard Welcome 30 Select Interface 30 Summary 30

Edit Interface/Connection 1

Connection: Ethernet for IRB 5

Connection: Ethernet for Routing 6

Existing Dynamic DNS Methods 7 Add Dynamic DNS Method 7

Wireless 9

Association 9

NAT 11

Edit Switch Port 12

Application Service 13

General 14

Select Ethernet Configuration Type 16

Connection: VLAN 17

Subinterfaces List 17

Add or Edit BVI Interface 18

Add or Edit Loopback Interface 18

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

Connection: Virtual Template Interface 19

Connection: Ethernet LAN 19

Connection: Ethernet WAN 20

Connection: Ethernet Properties 22

Connection: Ethernet with No Encapsulation 24

Connection: ADSL 25

Connection: ADSL over ISDN 28

Connection: G.SHDSL 30

Connection: Cable Modem 34

Configure DSL Controller 35

Add a G.SHDSL Connection 37

Connection: Serial Interface, Frame Relay Encapsulation 40

Connection: Serial Interface, PPP Encapsulation 43

Connection: Serial Interface, HDLC Encapsulation 45

Contents

OL-4015-12

Add or Edit GRE Tunnel 46

Connection: ISDN BRI 48

Connection: Analog Modem 51

Connection: (AUX Backup) 53

Authentication 55

SPID Details 56

Dialer Options 57

Backup Configuration 59

Delete Connection 60

Connectivity Testing and Troubleshooting 62

Wide Area Application Services 1

Configuring a WAAS Connection 2

WAAS Reference 3

Cisco Router and Security Device Manager 2.5 User’s Guide

vii

Contents

NM WAAS 4 Integrated Service Engine 6 WCCP 7 Central Manager Registration 8

Create Firewall 1

Basic Firewall Configuration Wizard 4

Basic Firewall Interface Configuration 4 Configuring Firewall for Remote Access 5

Advanced Firewall Configuration Wizard 5

Advanced Firewall Interface Configuration 5 Advanced Firewall DMZ Service Configuration 6

DMZ Service Configuration 7 Application Security Configuration 8 Domain Name Server Configuration 9 URL Filter Server Configuration 9 Select Interface Zone 9 ZPF Inside Zones 10 Voice Configuration 10 Summary 11

SDM Warning: SDM Access 13

viii

How Do I... 15

How Do I View Activity on My Firewall? 15 How Do I Configure a Firewall on an Unsupported Interface? 17 How Do I Configure a Firewall After I Have Configured a VPN? 17 How Do I Permit Specific Traffic Through a DMZ Interface? 18 How Do I Modify an Existing Firewall to Permit Traffic from a New Network

or Host?

How Do I Configure NAT on an Unsupported Interface? 19 How Do I Configure NAT Passthrough for a Firewall? 20

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

How Do I Permit Traffic Through a Firewall to My Easy VPN Concentrator? 20 How Do I Associate a Rule with an Interface? 22 How Do I Disassociate an Access Rule from an Interface 22 How Do I Delete a Rule That Is Associated with an Interface? 23 How Do I Create an Access Rule for a Java List? 23 How Do I Permit Specific Traffic onto My Network if I Don’t Have a DMZ

Network?

Firewall Policy 1

Edit Firewall Policy/ACL 1

Choose a Traffic Flow 3 Examine the Traffic Diagram and Choose a Traffic Direction 4 Make Changes to Access Rules 6 Make Changes to Inspection Rules 10 Add App-Name Application Entry 12 Add rpc Application Entry 12 Add Fragment application entry 13 Add or Edit http Application Entry 14 Java Applet Blocking 15 Cisco SDM Warning: Inspection Rule 16 Cisco SDM Warning: Firewall 17

Contents

OL-4015-12

Edit Firewall Policy 17

Add a New Rule 21

Add Traffic 22

Application Inspection 23

URL Filter 24

Quality of Service 24

Inspect Parameter 24

Select Traffic 24

Delete Rule 25

Cisco Router and Security Device Manager 2.5 User’s Guide

Contents

Application Security 1

Application Security Windows 1

No Application Security Policy 3

E-mail 4

Instant Messaging 5

Peer-to-Peer Applications 6

URL Filtering 7

HTTP 8

Header Options 9 Content Options 10

Applications/Protocols 12

Timeouts and Thresholds for Inspect Parameter Maps and CBAC 13 Associate Policy with an Interface 16 Edit Inspection Rule 16 Permit, Block, and Alarm Controls 17

Site-to-Site VPN 1

VPN Design Guide 1

Create Site to Site VPN 1

Site-to-Site VPN Wizard 4 View Defaults 5 VPN Connection Information 6 IKE Proposals 8 Transform Set 11 Traffic to Protect 13 Summary of the Configuration 14

Spoke Configuration 15 Secure GRE Tunnel (GRE-over-IPSec) 16 GRE Tunnel Information 16

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

VPN Authentication Information 17 Backup GRE Tunnel Information 18 Routing Information 19 Static Routing Information 20

Select Routing Protocol 22 Summary of Configuration 23

Edit Site-to-Site VPN 23

Add new connection 26 Add Additional Crypto Maps 26 Crypto Map Wizard: Welcome 27 Crypto Map Wizard: Summary of the configuration 28 Delete Connection 28 Ping 29 Generate Mirror... 29 Cisco SDM Warning: NAT Rules with ACL 30

How Do I... 31

How Do I Create a VPN to More Than One Site? 31 After Configuring a VPN, How Do I Configure the VPN on the Peer Router? 33 How Do I Edit an Existing VPN Tunnel? 34 How Do I Confirm That My VPN Is Working? 35 How Do I Configure a Backup Peer for My VPN? 36 How Do I Accommodate Multiple Devices with Different Levels of VPN

Support? How Do I Configure a VPN on an Unsupported Interface? 37 How Do I Configure a VPN After I Have Configured a Firewall? 38 How Do I Configure NAT Passthrough for a VPN? 38

Contents

OL-4015-12

Easy VPN Remote 1

Creating an Easy VPN Remote Connection 2

Create Easy VPN Remote Reference 3

Cisco Router and Security Device Manager 2.5 User’s Guide

Contents

Create Easy VPN Remote 4

Configure an Easy VPN Remote Client 5

Easy VPN Remote Wizard: Network Information 5

Easy VPN Remote Wizard: Identical Address Configuration 6

Easy VPN Remote Wizard: Interfaces and Connection Settings 7

Easy VPN Remote Wizard: Server Information 9

Easy VPN Remote Wizard: Authentication 11

Easy VPN Remote Wizard: Summary of Configuration 13

Administering Easy VPN Remote Connections 14

Editing an Existing Easy VPN Remote Connection 15 Creating a New Easy VPN Remote Connection 15 Deleting an Easy VPN Remote Connection 16 Resetting an Established Easy VPN Remote Connection 16 Connecting to an Easy VPN Server 17 Connecting other Subnets to the VPN Tunnel 17 Administering Easy VPN Remote Reference 18

Edit Easy VPN Remote 18

Add or Edit Easy VPN Remote 23

Add or Edit Easy VPN Remote: General Settings 25

Network Extension Options 28

Add or Edit Easy VPN Remote: Easy VPN Settings 28

Add or Edit Easy VPN Remote: Authentication Information 30

Add or Edit Easy VPN Remote: Easy VPN Client Phase III

Authentication

Add or Edit Easy VPN Remote: Interfaces and Connections 35

Add or Edit Easy VPN Remote: Identical Addressing 37

Easy VPN Remote: Add a Device 39

Enter SSH Credentials 39

XAuth Login Window 40

xii

Other Procedures 40

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

How Do I Edit an Existing Easy VPN Connection? 40 How Do I Configure a Backup for an Easy VPN Connection? 41

Easy VPN Server 1

Creating an Easy VPN Server Connection 1

Create an Easy VPN Server Reference 3

Create an Easy VPN Server 4

Welcome to the Easy VPN Server Wizard 4

Interface and Authentication 4

Group Authorization and Group Policy Lookup 5

User Authentication (XAuth) 6

User Accounts for XAuth 7

Add RADIUS Server 8

Group Authorization: User Group Policies 9

General Group Information 10

DNS and WINS Configuration 11

Split Tunneling 11

Client Settings 12

Choose Browser Proxy Settings 15

Add or Edit Browser Proxy Settings 16

User Authentication (XAuth) 17

Client Update 18

Add or Edit Client Update Entry 19

Cisco Tunneling Control Protocol 20

Summary 21

Browser Proxy Settings 21

Contents

OL-4015-12

Editing Easy VPN Server Connections 23

Edit Easy VPN Server Reference 23

Edit Easy VPN Server 24

Add or Edit Easy VPN Server Connection 25

Cisco Router and Security Device Manager 2.5 User’s Guide

xiii

Contents

Restrict Access 26

Group Policies Configuration 26

IP Pools 29

Add or Edit IP Local Pool 29

Add IP Address Range 30

Enhanced Easy VPN 1

Interface and Authentication 1

RADIUS Servers 2

Group Authorization and Group User Policies 4

Add or Edit Easy VPN Server: General Tab 5

Add or Edit Easy VPN Server: IKE Tab 6

Add or Edit Easy VPN Server: IPSec Tab 8

Create Virtual Tunnel Interface 10

DMVPN 1

Dynamic Multipoint VPN 1

Dynamic Multipoint VPN (DMVPN) Hub Wizard 2

Type of Hub 3

Configure Pre-Shared Key 3

Hub GRE Tunnel Interface Configuration 4

Advanced Configuration for the Tunnel Interface 5

Primary Hub 6

Select Routing Protocol 7

Routing Information 7 Dynamic Multipoint VPN (DMVPN) Spoke Wizard 9

DMVPN Network Topology 9

Specify Hub Information 10

Spoke GRE Tunnel Interface Configuration 10

Cisco SDM Warning: DMVPN Dependency 11

xiv

Edit Dynamic Multipoint VPN (DMVPN) 12

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

General Panel 14 NHRP Panel 15

NHRP Map Configuration 16 Routing Panel 17

How Do I Configure a DMVPN Manually? 19

VPN Global Settings 1

VPN Global Settings: IKE 3 VPN Global Settings: IPSec 4 VPN Global Settings: Easy VPN Server 5 VPN Key Encryption Settings 6

IP Security 1

IPSec Policies 1

Add or Edit IPSec Policy 3 Add or Edit Crypto Map: General 5 Add or Edit Crypto Map: Peer Information 6 Add or Edit Crypto Map: Transform Sets 7 Add or Edit Crypto Map: Protecting Traffic 9

Contents

OL-4015-12

Dynamic Crypto Map Sets 11

Add or Edit Dynamic Crypto Map Set 11 Associate Crypto Map with this IPSec Policy 12

IPSec Profiles 12

Add or Edit IPSec Profile 13 Add or Edit IPSec Profile and Add Dynamic Crypto Map 14

Transform Set 15

Add or Edit Transform Set 18

IPSec Rules 20

Cisco Router and Security Device Manager 2.5 User’s Guide

Contents

Internet Key Exchange 1

Internet Key Exchange (IKE) 1

IKE Policies 2

Add or Edit IKE Policy 4 IKE Pre-shared Keys 6

Add or Edit Pre Shared Key 7 IKE Profiles 8

Add or Edit an IKE Profile 9

Public Key Infrastructure 1

Certificate Wizards 1

Welcome to the SCEP Wizard 2 Certificate Authority (CA) Information 3

Advanced Options 4 Certificate Subject Name Attributes 4

Other Subject Attributes 6

xvi

RSA Keys 7

Summary 8

CA Server Certificate 9

Enrollment Status 9

Cut and Paste Wizard Welcome 9

Enrollment Task 10

Enrollment Request 10

Continue with Unfinished Enrollment 11

Import CA certificate 12

Import Router Certificate(s) 12

Digital Certificates 13

Trustpoint Information 15 Certificate Details 15

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

Revocation Check 15 Revocation Check, CRL Only 16

RSA Keys Window 16

Generate RSA Key Pair 17

USB Token Credentials 18

USB Tokens 19

Add or Edit USB Token 20

Open Firewall 22

Open Firewall Details 23

Certificate Authority Server 1

Create CA Server 1

Prerequisite Tasks for PKI Configurations 2 CA Server Wizard: Welcome 3 CA Server Wizard: Certificate Authority Information 3

Advanced Options 5 CA Server Wizard: RSA Keys 7 Open Firewall 8 CA Server Wizard: Summary 8

Contents

OL-4015-12

Manage CA Server 9

Backup CA Server 11

Manage CA Server Restore Window 11

Restore CA Server 11

Edit CA Server Settings: General Tab 12

Edit CA Server Settings: Advanced Tab 13

Manage CA Server: CA Server Not Configured 13

Manage Certificates 13

Pending Requests 13 Revoked Certificates 15 Revoke Certificate 16

Cisco Router and Security Device Manager 2.5 User’s Guide

xvii

Contents

Cisco IOS SSL VPN 1

Cisco IOS SSL VPN links on Cisco.com 2

Creating an SSL VPN Connection 2

Create an SSL VPN Connection Reference 3

Create SSL VPN 4

Persistent Self-Signed Certificate 6

Welcome 7

SSL VPN Gateways 7

User Authentication 8

Configure Intranet Websites 10

Add or Edit URL 10

Customize SSL VPN Portal 11

SSL VPN Passthrough Configuration 11

User Policy 12

Details of SSL VPN Group Policy: Policyname 12

Select the SSL VPN User Group 13

Select Advanced Features 13

Thin Client (Port Forwarding) 13

Add or Edit a Server 14

Full Tunnel 15

Locating the Install Bundle for Cisco SDM 16

Enable Cisco Secure Desktop 18

Common Internet File System 19

Enable Clientless Citrix 19

Summary 20

xviii

Editing SSL VPN Connections 20

Editing SSL VPN Connection Reference 21

Edit SSL VPN 22

SSL VPN Context 23

Designate Inside and Outside Interfaces 25

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

Select a Gateway 25

Context: Group Policies 26

Group Policy: General Tab 26

Group Policy: Clientless Tab 27

Group Policy: Thin Client Tab 29

Group Policy: SSL VPN Client (Full Tunnel) Tab 29

Advanced Tunnel Options 31

DNS and WINS Servers 33

Context: HTML Settings 33

Select Color 35

Context: NetBIOS Name Server Lists 35

Add or Edit a NBNS Server List 35

Add or Edit an NBNS Server 36

Context: Port Forward Lists 36

Add or Edit a Port Forward List 36

Context: URL Lists 36

Add or Edit a URL List 37

Context: Cisco Secure Desktop 37

SSL VPN Gateways 37

Add or Edit a SSL VPN Gateway 38

Packages 39

Install Package 40

Contents

OL-4015-12

Additional Help Topics 40

Cisco IOS SSL VPN Contexts, Gateways, and Policies 40 Learn More about Port Forwarding Servers 46 Learn More About Group Policies 47 Learn More About Split Tunneling 48 How do I verify that my Cisco IOS SSL VPN is working? 49 How do I configure a Cisco IOS SSL VPN after I have configured a

firewall?

Cisco Router and Security Device Manager 2.5 User’s Guide

xix

Contents

How do I associate a VRF instance with a Cisco IOS SSL VPN context? 50

SSL VPN Enhancements 1

SSL VPN Reference 1

SSL VPN Context: Access Control Lists 1 Add or Edit Application ACL 2 Add ACL Entry 3 Action URL Time Range 4 Add or Edit Action URL Time Range Dialog 5 Add or Edit Absolute Time Range Entry 6 Add or Edit Periodic Time Range Entry 7

VPN Troubleshooting 1

VPN Troubleshooting: Specify Easy VPN Client 3

VPN Troubleshooting: Generate Traffic 4

VPN Troubleshooting: Generate GRE Traffic 5

Cisco SDM Warning: SDM will enable router debugs... 6

Security Audit 1

Welcome Page 4

Interface Selection Page 4

Report Card Page 5

Fix It Page 5

Disable Finger Service 6 Disable PAD Service 7 Disable TCP Small Servers Service 7 Disable UDP Small Servers Service 8 Disable IP BOOTP Server Service 8 Disable IP Identification Service 9

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

Disable CDP 9 Disable IP Source Route 10 Enable Password Encryption Service 10 Enable TCP Keepalives for Inbound Telnet Sessions 11 Enable TCP Keepalives for Outbound Telnet Sessions 11 Enable Sequence Numbers and Time Stamps on Debugs 11 Enable IP CEF 12 Disable IP Gratuitous ARPs 12 Set Minimum Password Length to Less Than 6 Characters 12 Set Authentication Failure Rate to Less Than 3 Retries 13 Set TCP Synwait Time 13 Set Banner 14 Enable Logging 14 Set Enable Secret Password 15 Disable SNMP 15 Set Scheduler Interval 16 Set Scheduler Allocate 16 Set Users 17 Enable Telnet Settings 17 Enable NetFlow Switching 17 Disable IP Redirects 18 Disable IP Proxy ARP 18 Disable IP Directed Broadcast 19 Disable MOP Service 20 Disable IP Unreachables 20 Disable IP Mask Reply 20 Disable IP Unreachables on NULL Interface 21 Enable Unicast RPF on Outside Interfaces 22 Enable Firewall on All of the Outside Interfaces 22 Set Access Class on HTTP Server Service 23

Contents

OL-4015-12

Cisco Router and Security Device Manager 2.5 User’s Guide

xxi

Contents

Set Access Class on VTY Lines 23 Enable SSH for Access to the Router 24 Enable AAA 24

Configuration Summary Screen 25

Cisco SDM and Cisco IOS AutoSecure 25

Security Configurations Cisco SDM Can Undo 27

Undoing Security Audit Fixes 28

Add or Edit Telnet/SSH Account Screen 28

Configure User Accounts for Telnet/SSH Page 29

Enable Secret and Banner Page 30

Logging Page 31

Routing 1

Add or Edit IP Static Route 3

Add or Edit an RIP Route 5

xxii

Add or Edit an OSPF Route 5

Add or Edit EIGRP Route 7

Network Address Translation 1

Network Address Translation Wizards 1

Basic NAT Wizard: Welcome 2 Basic NAT Wizard: Connection 2 Summary 3 Advanced NAT Wizard: Welcome 3 Advanced NAT Wizard: Connection 4

Add IP Address 4 Advanced NAT Wizard: Networks 4

Add Network 5 Advanced NAT Wizard: Server Public IP Addresses 5

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

Add or Edit Address Translation Rule 6 Advanced NAT Wizard: ACL Conflict 7

Details 8

Network Address Translation Rules 8

Designate NAT Interfaces 12 Translation Timeout Settings 12 Edit Route Map 13

Edit Route Map Entry 14 Address Pools 15

Add or Edit Address Pool 16 Add or Edit Static Address Translation Rule: Inside to Outside 17 Add or Edit Static Address Translation Rule: Outside to Inside 20 Add or Edit Dynamic Address Translation Rule: Inside to Outside 23 Add or Edit Dynamic Address Translation Rule: Outside to Inside 26

How Do I . . . 28

How do I Configure Address Translation for Outside to Inside 28 How Do I Configure NAT With One LAN and Multiple WANs? 29

Contents

OL-4015-12

Cisco IOS IPS 1

Create IPS 2

Create IPS: Welcome 3 Create IPS: Select Interfaces 3 Create IPS: SDF Location 3 Create IPS: Signature File 4 Create IPS: Configuration File Location and Category 5

Add or Edit a Config Location 6

Directory Selection 7

Signature File 7 Create IPS: Summary 8 Create IPS: Summary 8

Cisco Router and Security Device Manager 2.5 User’s Guide

xxiii

Contents

Edit IPS 9

Edit IPS: IPS Policies 10

Enable or Edit IPS on an Interface 13 Edit IPS: Global Settings 14

Edit Global Settings 16

Add or Edit a Signature Location 17

Edit IPS: SDEE Messages 18

SDEE Message Text 19 Edit IPS: Global Settings 22

Edit Global Settings 23

Edit IPS Prerequisites 24

Add Public Key 25 Edit IPS: Auto Update 25 Edit IPS: SEAP Configuration 27

Edit IPS: SEAP Configuration: Target Value Rating 28

Add Target Value Rating 29

Edit IPS: SEAP Configuration: Event Action Overrides 29

Add or Edit an Event Action Override 31

Edit IPS: SEAP Configuration: Event Action Filters 32

Add or Edit an Event Action Filter 34 Edit IPS: Signatures 36 Edit IPS: Signatures 42

Edit Signature 46

File Selection 49

Assign Actions 50

Import Signatures 51

Add, Edit, or Clone Signature 53 Cisco Security Center 55 IPS-Supplied Signature Definition Files 55

xxiv

Security Dashboard 56

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

IPS Migration 59

Migration Wizard: Welcome 59 Migration Wizard: Choose the IOS IPS Backup Signature File 60

Signature File 60

Java Heap Size 60

Network Module Management 1

IDS Network Module Management 1

IDS Sensor Interface IP Address 3 IP Address Determination 4 IDS NM Configuration Checklist 5 IDS NM Interface Monitoring Configuration 7

Network Module Login 7

Feature Unavailable 7

Switch Module Interface Selection 7

Contents

OL-4015-12

Quality of Service 1

Creating a QoS Policy 1

Create a QoS Policy Reference 2

Create QoS Policy 2

QoS Wizard 3

Interface Selection 3

Queuing for Outbound Traffic 4

Add a New Traffic Class 5

Policing for Outbound Traffic 7

QoS Policy Generation 7

QoS Configuration Summary 8

Editing QoS Policies 9

Edit QoS Policy Reference 10

Edit QoS Policy 10

Cisco Router and Security Device Manager 2.5 User’s Guide

xxv

Contents

Add Class for the New Policy 13

Add Service Policy to Class 14

Associate or Disassociate the QoS Policy 15

Add or Edit a QoS Class 15

Edit Match DSCP Values 18

Edit Match Protocol Values 19

Add Custom Protocols 19

Edit Match ACL 19

Configure Policing 19

Configure Shaping 20

Configure Queuing 21

Network Admission Control 1

Create NAC Tab 1

Other Tasks in a NAC Implementation 2 Welcome 3 NAC Policy Servers 4 Interface Selection 6 NAC Exception List 7

Add or Edit an Exception List Entry 7

Choose an Exception Policy 8

Add Exception Policy 9 Agentless Host Policy 10 Configuring NAC for Remote Access 10 Modify Firewall 11

Details Window 11 Summary of the configuration 12

xxvi

Edit NAC Tab 13

NAC Components 14 Exception List Window 14

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

Exception Policies Window 15

NAC Timeouts 15

Configure a NAC Policy 17

How Do I... 18

How Do I Configure a NAC Policy Server? 18 How Do I Install and Configure a Posture Agent on a Host? 18

Router Properties 1

Device Properties 1

Date and Time: Clock Properties 2

Date and Time Properties 3 NTP 4

Add or Edit NTP Server Details 5 SNTP 6

Add an NTP Server 7 Logging 8 SNMP 9 Netflow 10

Netflow Talkers 10

Contents

OL-4015-12

Router Access 11

User Accounts: Configure User Accounts for Router Access 11

Add or Edit a Username 12 View Password 14

vty Settings 15

Edit vty Lines 15 Configure Management Access Policies 17 Add or Edit a Management Policy 19 Management Access Error Messages 20 SSH 22

DHCP Configuration 23

Cisco Router and Security Device Manager 2.5 User’s Guide

xxvii

Contents

DHCP Pools 23 Add or Edit DHCP Pool 25 DHCP Bindings 26 Add or Edit DHCP Binding 27

DNS Properties 28

Dynamic DNS Methods 28

Add or Edit Dynamic DNS Method 29

ACL Editor 1

Useful Procedures for Access Rules and Firewalls 3

Rules Windows 3

Add or Edit a Rule 7 Associate with an Interface 10 Add a Standard Rule Entry 11 Add an Extended Rule Entry 13 Select a Rule 16

xxviii

Port-to-Application Mapping 1

Port-to-Application Mappings 1

Add or Edit Port Map Entry 3

Zone-Based Policy Firewall 1

Zone Window 2

Add or Edit a Zone 3 Zone-Based Policy General Rules 3

Zone Pairs 5

Add or Edit a Zone Pair 5 Add a Zone 6 Select a Zone 7

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

Authentication, Authorization, and Accounting 1

Configuring AAA 2

AAA Screen Reference 2

AAA Root Screen 3 AAA Servers and Server Groups 4 AAA Servers 4 Add or Edit a TACACS+ Server 5 Add or Edit a RADIUS Server 6

Edit Global Settings 7 AAA Server Groups 8 Add or Edit AAA Server Group 9 Authentication and Authorization Policies 10 Authentication and Authorization 10 Authentication NAC 11 Authentication 802.1x 12 Add or Edit a Method List for Authentication or Authorization 13

Contents

OL-4015-12

Router Provisioning 1

Secure Device Provisioning 1

Router Provisioning from USB 2

Router Provisioning from USB (Load File) 2

SDP Troubleshooting Tips 2

Cisco Common Classification Policy Language 1

Policy Map 1

Policy Map Windows 1

Add or Edit a QoS Policy Map 3

Associate a Policy Map to Interface 3

Add an Inspection Policy Map 5 Layer 7 Policy Map 5

Cisco Router and Security Device Manager 2.5 User’s Guide

xxix

Contents

Application Inspection 5 Configure Deep Packet Inspection 6

Class Maps 6

Associate Class Map 7

Class Map Advanced Options 7 QoS Class Map 8

Add or Edit a QoS Class Map 9

Select a Class Map 9 Deep Inspection 9 Class Map and Application Service Group Windows 9

Add or Edit an Inspect Class Map 12

Associate Parameter Map 12

Add an HTTP Inspection Class Map 13

HTTP Request Header 13

HTTP Request Header Fields 14

HTTP Request Body 15

HTTP Request Header Arguments 15

HTTP Method 16

Request Port Misuse 16

Request URI 16

Response Header 17

Response Header Fields 18

HTTP Response Body 19

HTTP Response Status Line 19

Request/Response Header Criteria 20

HTTP Request/Response Header Fields 20

Request/Response Body 21

Request/Response Protocol Violation 22

Add or Edit an IMAP Class Map 22

xxx

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

Add or Edit an SMTP Class Map 22

Add or Edit a SUNRPC Class Map 23

Add or Edit an Instant Messaging Class Map 23

Add or Edit a Point-to-Point Class Map 23

Add P2P Rule 24

Add or Edit a POP3 Class Map 24

Parameter Maps 25

Parameter Map Windows 25

Add or Edit a Parameter Map for Protocol Information 25

Add or Edit a Server Entry 26

Add or Edit Regular Expression 26

Add a Pattern 27

Build Regular Expression 28

Regular Expression Metacharacters 30

URL Filtering 1

Contents

OL-4015-12

URL Filtering Window 2

Edit Global Settings 2 General Settings for URL Filtering 3 Local URL List 5

Add or Edit Local URL 6

Import URL List 7 URL Filter Servers 7

Add or Edit a URL Filter Server 8 URL Filtering Precedence 9

Configuration Management 1

Manually Editing the Configuration File 1

Config Editor 2

Reset to Factory Defaults 3

Cisco Router and Security Device Manager 2.5 User’s Guide

xxxi

Contents

This Feature Not Supported 6

More About.... 1

IP Addresses and Subnet Masks 1

Host and Network Fields 3

Available Interface Configurations 4

DHCP Address Pools 5

Meanings of the Permit and Deny Keywords 6

Services and Ports 6

More About NAT 13

Static Address Translation Scenarios 13 Dynamic Address Translation Scenarios 16 Reasons that Cisco SDM Cannot Edit a NAT Rule 17

More About VPN 18

Cisco.com Resources 18 More about VPN Connections and IPSec Policies 19 More About IKE 21 More About IKE Policies 22 Allowable Transform Combinations 23

xxxii

Reasons Why a Serial Interface or Subinterface Configuration May Be Read-Only

Reasons Why an ATM Interface or Subinterface Configuration May Be Read-Only

Reasons Why an Ethernet Interface Configuration May Be Read-Only 26

Reasons Why an ISDN BRI Interface Configuration May Be Read-Only 27

Reasons Why an Analog Modem Interface Configuration May Be Read-Only 28

Firewall Policy Use Case Scenario 29

DMVPN Configuration Recommendations 29

Cisco SDM White Papers 31

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

Getting Started 1

What’s New in this Release? 2

Cisco IOS Versions Supported 4

Viewing Router Information 1

Overview 2

Interface Status 6

Firewall Status 9

Zone-Based Policy Firewall Status 10

VPN Status 12

IPSec Tunnels 12 DMVPN Tunnels 14 Easy VPN Server 15 IKE SAs 17 SSL VPN Components 18

SSL VPN Context 19

User Sessions 19

URL Mangling 20

Port Forwarding 20

CIFS 20

Full Tunnel 21

User List 21

Contents

OL-4015-12

Traffic Status 23

Netflow Top Talkers 23

Top Protocols 23

Top Talkers 24 QoS 25 Application/Protocol Traffic 27

NAC Status 28

Cisco Router and Security Device Manager 2.5 User’s Guide

xxxiii

Contents

Logging 29

Syslog 29 Firewall Log 32 Application Security Log 34 SDEE Message Log 35

IPS Status 37

IPS Signature Statistics 38

IPS Alert Statistics 39

802.1x Authentication Status 40

File Menu Commands 1

Save Running Config to PC 1

Deliver Configuration to Router 1

Write to Startup Config 2

Reset to Factory Defaults 2

xxxiv

File Management 2

Rename 5 New Folder 5

Save SDF to PC 6

Exit 6

Unable to perform squeeze flash 6

Edit Menu Commands 1

Preferences 1

View Menu Commands 1

Home 1

Configure 1

Monitor 1

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

Running Config 2

Show Commands 2

Cisco SDM Default Rules 3

Refresh 4

Tools Menu Commands 1

Ping 1

Telnet 1

Security Audit 1

USB Token PIN Settings 2

Wireless Application 3

Update Cisco SDM 3

CCO Login 4

Help Menu Commands 1

Contents

OL-4015-12

Help Topics 1

Cisco SDM on CCO 1

Hardware/Software Matrix 1

About this router... 2

About Cisco SDM 2

Cisco Router and Security Device Manager 2.5 User’s Guide

xxxv

Contents

xxxvi

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

Home Page

The home page supplies basic information about the router hardware, software, and configuration. This page contains the following sections:

Host Name

The configured name of the router.

About Your Router

Shows basic information about your router hardware and software, and contains the following fields:

Hardware Software

Model Type

Available/Total Memory

Shows the router model number.

Available RAM/Total RAM

IOS Version

Cisco SDM Version

CHAPTER

The version of Cisco IOS software that is currently running on the router.

The version of Cisco Router and Security Device Manager (Cisco SDM) software that is currently running on the router.

OL-4015-12

Cisco Router and Security Device Manager 2.5 User’s Guide

1-1

Hardware Software

Total Flash Capacity

Feature Availability

Flash plus Webflash (if applicable)

The features available in the Cisco IOS image the router is using are designated by a check. The features Cisco SDM checks for are: IP, Firewall, VPN, IPS, and NAC.

More...

The More... link displays a popup window providing additional hardware and software details.

• Hardware Details—In addition to the information presented in the About

Your Router section, this tab displays information about:

–

Where the router boots from–Flash or Configuration File.

–

Whether the router has accelerators, such as VPN accelerators.

–

A diagram of the hardware configuration, including flash memory and installed devices such as USB flash and USB tokens.

• Software Details—In addition to the information presented in the About Your

Router section, this tab displays information about:

Chapter 1 Home Page

Configuration Overview

Note If you do not see feature information described in this help topic on the home

Cisco Router and Security Device Manager 2.5 User’s Guide

1-2

–

The feature sets included in the IOS image.

–

The version of Cisco SDM running.

This section of the home page summarizes the configuration settings that have been made.

page, the Cisco IOS image does not support the feature. For example, if the router is running a Cisco IOS image that does not support security features, the Firewall Policy, VPN, and Intrusion Prevention sections do not appear on the home page.

View Running Config

Click this button to display the router’s running configuration.

OL-4015-12

Chapter 1 Home Page

Double-arrow head: Click to display/hide details.

SDM-supported WAN interfaces that are present on the router.

The total number of Cisco SDM-supported WAN connections that are present on the router.

Interfaces and Connections

Total Supported LAN

Configured LAN Interface

Up (n): The number of LAN and WAN connections that are up.

The total number of LAN interfaces that are present in the router.

The number of supported LAN interfaces currently configured on the

Down (n): The number of LAN and WAN connections that are down.

Total Supported WAN The number of Cisco

Total WAN Connections

router.

DHCP Server

Configured/ Not Configured

DHCP Pool (Detail view)

If one pool is configured, starting

Number of DHCP Clients (Detail view)

Current number of clients

leasing addresses. and ending address of DHCP pool.

If multiple pools are configured, list of configured pool names.

Interface Type IP/Mask Description

Name of configured interface

Interface type IP address and subnet

mask

Description of interface

Firewall Policies

OL-4015-12

Active/Inactive Trusted (n) Untrusted (n)DMZ (n)

Active—A firewall is in place.

Inactive—No

The number of trusted (inside) interfaces.

The number of untrusted (outside) interfaces.

The number of DMZ interfaces.

firewall is in place.

Cisco Router and Security Device Manager 2.5 User’s Guide

1-3

Chapter 1 Home Page

Firewall Policies

Interface Firewall Icon NAT Inspection Rule Access Rule

The name of the interface to which a firewall has been applied

Active/Inactive Trusted (n) Untrusted (n)DMZ (n)

Whether the interface is designated as an inside or an outside interface.

The name or number of the NAT rule applied to this interface.

The names or numbers of the inbound and outbound inspection rules.

The names or numbers of the inbound and outbound access rules.

Up (n)- The number of

VPN

active VPN connections.

IPSec (Site-to-Site)

Xauth Login Required

The number of configured site-to-site VPN connections.

The number of Easy VPN connections awaiting an Xauth

GRE over IPSec

Easy VPN Remote

The number of configured GRE over IPSec connections.

The number of configured Easy VPN Remote connections.

No. of DMVPN Clients

If router is configured as a DMVPN hub, the number of DMVPN clients.

No. of Active VPN clients

If this router is functioning as an Easy VPN Server, the number of Easy VPN clients with active connections.

Interface Type IPSec Policy Description

The name of an interface with a configured VPN

The type of VPN connection configured on the interface.

The name of the IPSec policy associated with the VPN connection.

A description of the connection.

connection

1-4

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

Chapter 1 Home Page

Note • Some VPN servers or concentrators authenticate clients using Extended

Authentication (XAuth). This shows the number of VPN tunnels awaiting an Xauth login. If any Easy VPN tunnel awaits XAuth login, a separate message panel is shown with a Login button. Clicking Login allows you to enter the credentials for the tunnel.

• If Xauth has been configured for a tunnel, it will not begin to function until

the login and password has been supplied. There is no timeout after which it will stop waiting; it will wait indefinitely for this information.

NAC Policies Active or Inactive

Interface Column NAC Policy Column

The name of the interface to which the policy is applied. For example, FastEthernet 0, or Ethernet 0/0.

The name of the NAC policy.

Routing

No. of Static Routes

Dynamic Routing Protocols

OL-4015-12

The number of static routes configured on the router.

Lists any dynamic routing protocols that are configured on the router.

Intrusion Prevention

Active Signatures

The number of active signatures the router is using. These may be built in, or they may be loaded from a remote location.

No. of IPS-enabled interfaces

The number of router interfaces on which IPS has been enabled.

Cisco Router and Security Device Manager 2.5 User’s Guide

1-5

Routing

Intrusion Prevention

SDF Version

Security Dashboard

Chapter 1 Home Page

The version of SDF files on this router.

A link to the IPS Security Dashboard, where the top-ten signatures can be viewed and deployed.

1-6

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

Creating a New Connection

The Cisco SDM connection wizards guide you LAN and WAN configurations, and check the information that you enter against the existing configuration, warning you of any problems.

This chapter contains the following sections:

• Creating a New Connection

• New Connection Reference

• Additional Procedures

Creating a New Connection

Complete these steps to create a new connection:

Step 1 On the Cisco SDM toolbar, click Configure.

CHAPTER

OL-4015-12

Step 2 On the Tasks bar, click Interfaces and Connections.

Step 3 In the Create New Connection box, choose the type of connection that you want

to configure. Information about the type of connection you choose is displayed in the Information box, and the Use Case Scenario area displays a graphic showing the kind of connection that you chose.

Step 4 Click Create New Connection to get started.

Cisco Router and Security Device Manager 2.5 User’s Guide

2-1

New Connection Reference

The following topic describes the screen referred to in this chapter:

• Create Connection

Create Connection

This window allows you to create new LAN and WAN connections.

Note You cannot use Cisco SDM to create WAN connections for Cisco 7000 series

routers.

Field Reference

Table 2-1 describes the fields in this screen.

Table 2-1 Create Connection Fields

Chapter 2 Creating a New Connection

Element Description

Create New Connection Choose a connection type to configure on the physical interfaces

available on your router. Only interfaces that have not been configured are available. If all interfaces have been configured, this area of the window is not displayed.

If the router has Asynchronous Transfer Mode (ATM) or serial interfaces, multiple connections can be configured from a single interface because Cisco Router and Security Device Manager II (Cisco SDM) configures subinterfaces for each interface of that type.

The Other (Unsupported by Cisco SDM) radio button appears if an unsupported logical or physical interface exists, or if a supported interface exists that has been given an unsupported configuration. When you click the Other (Unsupported by Cisco SDM) radio button, the Create New Connection button is disabled.

Cisco Router and Security Device Manager 2.5 User’s Guide

2-2

OL-4015-12

Chapter 2 Creating a New Connection

Additional Procedures

Table 2-1 Create Connection Fields

Element Description

If the router has radio interfaces but you do not see a Wireless radio button, you are not logged on as an Cisco SDM Administrator. If you need to use the wireless application, go to the Cisco SDM Tools menu and choose Wireless Application.

Use Case Scenario When you click the radio button for a connection type, a network

diagram appears illustrating that type of connection.

Information The information area displays more information about the

connection type you choose. For example, if you choose Ethernet LAN, theinformation area may display the text “Configure Ethernet LAN interface for straight routing and 802.1q trunking.”

Create New Connection button Click Create New Connection to start the wizard for the type of

connection you chose.

Additional Procedures

OL-4015-12

This section contains procedures for tasks that the wizard does not help you complete.

This section contains the following topics:

• How Do I Configure a Static Route?

• How Do I View Activity on My LAN Interface?

• How Do I Enable or Disable an Interface?

• How Do I View the IOS Commands I Am Sending to the Router?

• How Do I Configure an Unsupported WAN Interface?

• How Do I Enable or Disable an Interface?

• How Do I View Activity on My WAN Interface?

• How Do I Configure NAT on a WAN Interface?

• How Do I Configure a Static Route?

• How Do I Configure a Dynamic Routing Protocol?

Cisco Router and Security Device Manager 2.5 User’s Guide

2-3

Additional Procedures

• How Do I Configure Dial-on-Demand Routing for My ISDN or

Asynchronous Interface?

How Do I Configure a Static Route?

To configure a static route:

Step 1 From the task bar, click Routing.

Step 2 In the Static Routing group, click Add....

The Add IP Static Route dialog box appears.

Step 3 In the Prefix field, enter the IP address of the static route destination network.

Step 4 In the Prefix Mask field, enter the subnet mask of the destination network.

Step 5 If you want this static route to be the default route, check the Make this as the

Default Route check box.

Step 6 In the Forwarding group, select whether to identify a router interface or the

destination router IP address as the method to forward data, and then choose either the forwarding router interface or enter the destination router IP address.

Step 7 Optionally, in the Distance Metric field, enter the distance metric to be stored in

the routing table.

Chapter 2 Creating a New Connection

Step 8 If you want to configure this static route to be a permanent route, which means

that it will not be deleted even if the interface is shut down or the router is unable to communicate with the next router, check the Permanent Route check box.

Step 9 Click OK.

How Do I View Activity on My LAN Interface?

You can view activity on a LAN interface by using the Monitor mode in Cisco SDM. Monitor mode can display statistics about the LAN interface, including the number of packets and bytes that have been sent or received by the interface, and the number of send or receive errors that have occurred. To display statistics about about a LAN interface:

Cisco Router and Security Device Manager 2.5 User’s Guide

2-4

OL-4015-12

Chapter 2 Creating a New Connection

Step 1 From the toolbar, click Monitor.

Step 2 From the left frame, click Interface Status.

Step 3 In the Select an Interface field, select the LAN interface for which you want to

view statistics.

Step 4 Select the data item(s) you want to view by checking the associated check box(es).

You can view up to four statistics at a time.

Step 5 Click Start Monitoring to see statistics for all selected data items.

The Interface Details screen appears, displaying the statistics you selected. The screen defaults to showing real-time data, for which it polls the router every 10 seconds. If the interface is up and there is data transmitting across it, you should see an increase in the number of packets and bytes transferred across the interface.

How Do I Enable or Disable an Interface?

Additional Procedures

You can disable an interface without removing its configuration, and you can reenable an interface that you have disabled.

Step 1 Click Interfaces and Connections in the task bar.

Step 2 Click the Edit Interfaces and Connections tab.

Step 3 Select the interface that you want to disable or enable.

Step 4 If the interface is enabled, the Disable button appears below the Interface List.

Click that button to disable the interface. If the interface is currently disabled, the Enable button appears below the Interface List. Click that button to disable the interface.

How Do I View the IOS Commands I Am Sending to the Router?

If you are completing a Wizard to configure a feature, you can view the Cisco IOS commands that you are sending to the router when you click Finish.

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

2-5

Chapter 2 Creating a New Connection

Additional Procedures

Step 1 From the Cisco SDM Edit menu, select Preferences.

Step 2 Check Preview commands before delivering to router.

Step 3 Click OK.

The next time you use a wizard to configure the router and click Finish on the Summary window, the Deliver window will appear. In this window you can view the commands that you are delivering to the router’s configuration. Click Deliver when you are finished reviewing the commands.

If you are editing a configuration, the Deliver window is displayed when you click OK in the dialog window. In this window you can view the Cisco IOS commands that you are sending to the router .

How Do I Launch the Wireless Application from Cisco SDM?

Use the following procedure to launch the wireless application from Cisco SDM.

Step 1 Go to the Cisco SDM Tools menu and select Wireless Application. The Wireless

Application launches in a separate browser window.

Step 2 In the left panel, click the title of the configuration screen that you want to work

in. To obtain help for any screen, click the help icon in the upper right corner. This icon looks like an open book with a question mark.

How Do I Configure an Unsupported WAN Interface?

Cisco SDM does not support configuration of every WA N interface that your router might support. If Cisco SDM discovers an interface in your router that it does not support, or a supported interface with an unsupported configuration, Cisco SDM displays a radio button labeled Other (Unsupported by Cisco SDM). The unsupported interface is displayed in the Interfaces and Connections window, but it cannot be configured using Cisco SDM.

Cisco Router and Security Device Manager 2.5 User’s Guide

2-6

OL-4015-12

Chapter 2 Creating a New Connection

To configure an unsupported interface, you must use the router command-line interface (CLI).

How Do I Enable or Disable an Interface?

You can disable an interface without removing its configuration, and you can reenable an interface that you have disabled.

Step 1 Click Configure on the Cisco SDM toolbar.

Step 2 Click Interfaces and Connections in the left frame.

Step 3 Click the interface that you want to disable or enable.

Step 4 If the interface is enabled, the Disable button appears below the Interface List.

Click it to disable the interface. If the interface is currently disabled, the Enable button appears in that location. Click that button to disable the interface.

Additional Procedures

How Do I View Activity on My WAN Interface?

You can view activity on a WA N interface by using the Monitor feature in Cisco SDM. Monitor screens can display statistics about the WAN interface, including the number of packets and bytes that have been sent or received by the interface, and the number of send or receive errors that have occurred. To display statistics about a WAN interface:

Step 1 From the toolbar, click Monitor.

Step 2 From the left frame, click Interface Status.

Step 3 In the Select an Interface field, choose the WAN interface for which you want to

view statistics.

Step 4 Choose the data item(s) you want to view by checking the associated check

box(es). You can view up to four statistics at a time.

Step 5 Click Show Details to see statistics for all selected data items.

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

2-7

Chapter 2 Creating a New Connection

Additional Procedures

How Do I Configure NAT on a WAN Interface?

Step 1 Click Configure on the Cisco SDM toolbar.

Step 2 Click NAT in the left frame.

Step 3 In the NAT window, click Designate NAT interfaces.

Step 4 Find the interface for which you want to configure NAT.

Step 5 Check inside(trusted) next to the interface to designate the interface as an inside,

or trusted interface. An inside designation is typically used to designate an interface serving a LAN whose resources. must be protected. Check outside(untrusted) to designate it as an outside interface. Outside interfaces typically connect to an untrusted network. Click OK.

The interface is added to the pool of interfaces using NAT.

2-8

Step 6 Review the Network Address Translation Rules in the NAT window. If you need

to add, delete, or modify a rule, click the appropriate button on the NAT window to perform the configuration you need.

For more information, click the following links:

• Add or Edit Static Address Translation Rule: Inside to Outside

• Add or Edit Static Address Translation Rule: Outside to Inside

• Add or Edit Dynamic Address Translation Rule: Inside to Outside

• Add or Edit Dynamic Address Translation Rule: Outside to Inside

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

Chapter 2 Creating a New Connection

Additional Procedures

How Do I Configure NAT on an Unsupported Interface?

Cisco SDM can configure Network Address Translation (NAT) on an interface type unsupported by Cisco SDM. Before you can configure the firewall, you must first use the router CLI to configure the interface. The interface must have, at a minimum, an IP address configured, and it must be working. To verify that the connection is working, verify that the interface status is “Up.”

After you have configured the unsupported interface using the CLI, you can configure NAT using Cisco SDM. The unsupported interface will appear as “Other” on the router interface list.

How Do I Configure a Dynamic Routing Protocol?

To configure a dynamic routing protocol:

Step 1 From the toolbar, click Configure.

Step 2 From the left frame, click Routing.

Step 3 In the Dynamic Routing group, click the dynamic routing protocol that you want

to configure.

OL-4015-12

Step 4 Click Edit.

The Dynamic Routing dialog box appears, displaying the tab for the dynamic routing protocol you selected.

Step 5 Using the fields in the Dynamic Routing dialog box, configure the dynamic

routing protocol. If you need an explanation for any of the fields in the dialog box, click Help.

Step 6 When you have finished configuring the dynamic routing protocol, click OK.

Cisco Router and Security Device Manager 2.5 User’s Guide

2-9

Chapter 2 Creating a New Connection

Additional Procedures

How Do I Configure Dial-on-Demand Routing for My ISDN or Asynchronous Interface?

ISDN BRI and asynchronous connections are dial-up connections, meaning that in order to establish a connection, the router must dial a preconfigured phone number. Because the cost of these types of connections is usually determined by the amount of time that a connection was established, and in the case of an asynchronous connection, that a phone line will be tied up, it is often desirable to configure Dial-on-Demand Routing (DDR) for these connection types.

Cisco SDM can help you configure DDR by:

• Letting you associate a rule (or ACL) with the connection, which causes the

router to establish the connection only when it recognizes network traffic that you have identified as interesting with the associated rule.

• Setting idle timeouts, which cause the router to end a connection after a

specified amount of time when there is no activity on the connection.

• Enabling multilink PPP, which causes an ISDN BRI connection to use only

one of the two B channels unless a specified percentage of bandwidth is exceeded on the first B channel. This has the advantage of saving costs when network traffic is low and the second B channel is not needed, but letting you utilize the full bandwidth of your ISDN BRI connection when needed.

2-10

To configure DDR on an existing ISDN BRI or asynchronous connection:

Step 1 Click Configure on the Cisco SDM toolbar.

Step 2 Click Interfaces and Connections in the left frame.

Step 3 Click the ISDN or asynchronous interface on which you want to configure DDR.

Step 4 Click Edit.

The Connection tab appears.

Step 5 Click Options.

The Edit Dialer Option dialog box appears.

Step 6 If you want the router to establish the connection only when it recognizes specific

IP traffic, click the Filter traffic based on selected ACL radio button, and either enter a rule (ACL) number that will identify which IP traffic should cause the router to dial out, or click the ... button to browse the list of rules and choose the rule that you want to use to identify IP traffic from that list.

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

Chapter 2 Creating a New Connection

Step 7 If you want to configure the router to end the connection when the connection is

idle, i.e., no traffic passes across it, for a specified amount of time, in the Idle timeout field, enter the number of seconds the connection can remain idle before

the router ends the connection.

Step 8 If you are editing an ISDN connection, and you would like to use your second B

channel only when the traffic on the first B channel exceeds a certain threshold, check the Enable MultiLink PPP check box, then in the Load Threshold field, enter a number between 1 and 255, where 255 equals 100% of bandwidth, that will determine the threshold on the first B channel. When traffic on that channel exceeds that threshold, it will cause the router to connect the second B channel. In addition, in the Data direction field, you can choose whether this threshold should apply to outbound or inbound traffic.

Step 9 Click OK.

How Do I Edit a Radio Interface Configuration?

Additional Procedures

OL-4015-12

You must use the Wireless Application to edit an existing radio interface configuration.

Step 1 Click Configure on the Cisco SDM toolbar.

Step 2 Click Interfaces and Connections in the left frame, and then click the Edit

Interface/Connection tab.

Step 3 Choose the radio interface and click Edit. In the Connections tab, you can change

the IP address or bridging information. If you want to change other wireless parameters, click Launch Wireless Application.

Cisco Router and Security Device Manager 2.5 User’s Guide

2-11

Additional Procedures

Chapter 2 Creating a New Connection

2-12

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

CHAPTER

LAN Wizard

The Cisco Router and Security Device Manager (Cisco SDM) LAN wizard guides you in the configuration of a LAN interface. The screen lists the LAN interfaces on the router. You can select any of the interfaces shown in the window, and click Configure to make the interface a LAN interface and configure it.

This window lists the router interfaces that were designated as inside interfaces in Startup configuration, and lists the Ethernet interfaces and switch ports that have not been configured as WAN interfaces. The list includes interfaces that have already been configured.

When you configure an interface as a LAN interface, Cisco SDM inserts the description text $ETH-LAN$ in the configuration file so that it recognizes the interface as a LAN interface in the future.

You can return to this screen as often as necessary to configure additional LAN interfaces.

OL-4015-12

Cisco Router and Security Device Manager 2.5 User’s Guide

3-1

Chapter 3 LAN Wizard

Ethernet Configuration

Field Reference

Table 3-1 IP Address and Subnet Mask

Element Description

Interface The name of the interface

Configure To configure an interface you have selected, click Configure. If the

interface has not been configured before, Cisco SDM will take you through the LAN Wizard to help you configure it. If the interface has been given a configuration using Cisco SDM, Cisco SDM displays an Edit window enabling you to change configuration settings.

The Configure button may be disabled if a LAN interface has been given a configuration that Cisco SDM does not support. For a list of such configurations, see Reasons Why an Ethernet Interface Configuration May

Be Read-Only.

Ethernet Configuration

The wizard guides you through the configuration of an Ethernet interface on the LAN. You must provide the following information:

• An IP address and subnet mask for the Ethernet interface

• A DHCP address pool if you decide to use DHCP on this interface

• The addresses of DNS and WINS servers on the WAN

• A domain name

LAN Wizard: Select an Interface

Select the interface on which you want to configure a LAN connection in this window. This window lists interfaces that can support Ethernet LAN configurations.

Cisco Router and Security Device Manager 2.5 User’s Guide

3-2

OL-4015-12

Chapter 3 LAN Wizard

LAN Wizard: IP Address and Subnet Mask

This window lets you configure an IP address and subnet mask for the Ethernet interface that you chose in the first window.

Field Reference

Table 3-2 IP Address and Subnet Mask

Element Description

IP Address Enter the IP address for the interface in dotted decimal format. Your

network administrator should determine the IP addresses of LAN interfaces. For more information, see IP Addresses and Subnet Masks.

Subnet Mask Enter the subnet mask. Obtain this value from your network administrator.

The subnet mask enables the router to determine how much of the IP address is used to define the network and host portions of the address.

Alternatively, select the number of network bits. This value is used to calculate the subnet mask. Your network administrator can tell you the number of network bits to enter.

LAN Wizard: Enable DHCP Server

This screen lets you enable a DHCP server on your router. A DHCP server automatically assigns reusable IP addresses to the devices on the LAN. When a device becomes active on the network, the DHCP server grants it an IP address. When the device leaves the network, the IP address is returned to the pool for use by another device.

Field Reference

Table 3-3 IP Address and Subnet Mask

Element Description

Enable DHCP Server To configure the router as a DHCP server on this interface, click Yes .

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

3-3

Chapter 3 LAN Wizard

LAN Wizard: DHCP Address Pool

This screen lets you configure the DHCP IP address pool. The IP addresses that the DHCP server assigns are drawn from a common pool that you configure by specifying the starting IP address in the range, and the ending address in the range.

For more information, see DHCP Address Pools.

Note If there are discontinuous address pools configured on the router, then the

Starting IP and Ending IP address fields will be read-only.

Field Reference

Table 3-4 DHCP Address Pool

Element Description

Starting IP Enter the beginning of the range of IP addresses for the DHCP server to use

in assigning addresses to devices on the LAN. This is the lowest-numbered IP address in the range.

Ending IP Enter the highest-numbered IP address in the range of IP addresses.

DNS Server and WINS Server Fields

If this window displays DNS Server and WINS Server fields, you can click

DHCP Options for information on them.

DHCP Options

Use this window to configure DHCP options that will be sent to hosts on the LAN that are requesting IP addresses from the router. These are not options for the router that you are configuring; these are parameters that will be sent to the requesting hosts on the LAN. To set these properties for the router, click Additional Tasks on the Cisco SDM category bar, click DHCP, and configure these settings in the DHCP Pools window.

Cisco Router and Security Device Manager 2.5 User’s Guide

3-4

OL-4015-12

Chapter 3 LAN Wizard

LAN Wizard: VLAN Mode

Field Reference

Table 3-5 IP Address and Subnet Mask

Element Description

DNS Server 1 The DNS server is typically a server that maps a known device name with

its IP address. If you have DNS server configured for your network, enter the IP address for that device here.

DNS Server 2 If there is an additional DNS server on the network, you can enter the IP

address for that server in this field.

Domain Name The DHCP server that you are configuring on this router will provide

services to other devices within this domain. Enter the name of the domain.

WINS Server 1 Some clients may require Windows Internet Naming Service (WINS) to

connect to devices on the Internet. If there is a WINS server on the network, enter the IP address for the server in this field.

WINS Server 2 If there is an additional WINS server on the network, enter the IP address

for the server in this field.

LAN Wizard: VLAN Mode

This screen lets you determine the type of VLAN information that will be carried over the switch port. Switch ports can be designated either to be in access mode, in which case they will forward only data that is destined for the VLAN to which they are assigned, or they can be designated to be in trunking mode, in which case they will forward data destined for all VLANs including the VLAN to which they are assigned.

If this switch port will be connected to a single device, such as a single PC or IP phone, or if this device will be connected to a port on a networking device, such as another switch, that is an access mode port, then select Single Device.

If this switch port will be connected to a port on a network device, such as another switch, that is a trunking mode, select Network Device.

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

3-5

Chapter 3 LAN Wizard

LAN Wizard: Switch Port

Field Reference

Table 3-6 IP Address and Subnet Mask

Element Description

Single Device If this switch port will be connected to a single device, such as a single PC

or IP phone, or if this device will be connected to a port on a networking device, such as another switch, that is an access mode port, then choose Single Device.

Network Device If this switch port will be connected to a port on a network device, such as

another switch, that is a trunking mode, choose Network Device.

LAN Wizard: Switch Port

This screen lets you assign an existing VLAN number to the switch port or to create a new VLAN interface to be assigned to the VLAN switch port.

Field Reference

Table 3-7 IP Address and Subnet Mask

Element Description

Existing VLAN If you want to assign the switch port to a VLAN that has already been

defined, such as the default VLAN (VLAN 1), enter the VLAN ID number in the Network (VLAN) Identifier field.

New VLAN If you want to create a new VLAN interface to which the switch port will

be assigned, enter the new VLAN ID number in the New VLAN field, and then enter the IP address and subnet mask of the new VLAN logical interface in the IP Address and Subnet Mask fields.

Include this VLAN in an IRB bridge...

Cisco Router and Security Device Manager 2.5 User’s Guide

3-6

If you want the switch port to form part of a bridge with your wireless network, check this box. The other part of the bridge must be configured using the Wireless Application. The IP address and Subnet mask fields under New VLAN are disabled when this box is checked.

OL-4015-12

Chapter 3 LAN Wizard

Step 1 Select Wireless Application from the Cisco SDM Tools menu. The Wireless

Step 2 In the Wireless Application, click Wireless Express Security, and then click

IRB Bridge

Launching the Wireless Application

After completing this LAN configuration, do the following to launch the Wireless Application and complete the bridging configuration.

Application opens in a separate browser window.

Bridging to provide the information to complete the bridging configuration.

If you are configuring a VLAN to be part of an IRB bridge, the bridge must be a member of a bridge group.

To create a new bridge group that this interface will be part of, click Create a new bridge group and enter a value in the range 1 through 255.

To have this VLAN be a member of an existing bridge group, click Join an existing bridge group, and select a bridge group.

Note When you complete the bridge configuration in the Wireless Application, you

must use the same bridge group number entered in this screen.

Field Reference

Table 3-8 IP Address and Subnet Mask

Element Description

Create a new bridge group

Join an existing bridge group

OL-4015-12

To create a new bridge group that this interface will be part of, click Create a new bridge group and enter a value in the range 1 through 255.

To have this VLAN be a member of an existing bridge group, click Join an existing bridge group, and select a bridge group.

Cisco Router and Security Device Manager 2.5 User’s Guide

3-7

Chapter 3 LAN Wizard

BVI Configuration

Assign an IP address and subnet mask to the BVI interface. If you selected an existing bridge group in the previous screen, the IP address and subnet mask will appear in this screen. You can change it, or leave the values unchanged.

Field Reference

Table 3-9 BVI Configuration

Element Description

IP Address Enter the IP address for the interface in dotted decimal format. Your

network administrator should determine the IP addresses of LAN interfaces. For more information, see IP Addresses and Subnet Masks.

Net Mask Enter the subnet mask. Obtain this value from your network administrator.

The subnet mask enables the router to determine how much of the IP address is used to define the network and host portions of the address.

Net Bits Alternatively, select the number of network bits. This value is used to

calculate the subnet mask. Your network administrator can tell you the number of network bits to enter.

DHCP Pool for BVI

When you configure the router as a DHCP server, you can create a pool of IP addresses that clients on the network can use. When a client logs off the network, the address it was using is returned to the pool for use by another host.

Cisco Router and Security Device Manager 2.5 User’s Guide

3-8

OL-4015-12

Chapter 3 LAN Wizard

IRB for Ethernet

Field Reference

Table 3-10 DHCP Pool for BVI

Element Description

DHCP Server Configuration

Start IP Enter the starting IP address for the pool. Be sure to specify IP addresses in

End IP Enter the ending IP address for the pool. Using the above example, the end

If you want to have the router function as a DHCP server, check DHCP Server Configuration.

the same subnet as the IP address you gave the interface. For example, If you gave the interface an IP address of 10.10.22.1, with a subnet mask of

255.255.255.0, you have over 250 addresses available for the pool, and you might specify a start IP Address of 10.10.22.2.

IP address would be 10.10.22.254.

IRB for Ethernet

If your router has a wireless interface, you can use Integrated Routing and Bridging to have this interface form part of a bridge to the wireless LAN, and enable traffic destined for the wireless network to be routed through this interface. Click Yes if you want to configure this Layer 3 interface for Integrated Routing and Bridging.

If you do not want this interface to be used in bridge to the wireless interface, click No. You will still be able to configure it as a regular routing interface.

Layer 3 Ethernet Configuration

Cisco SDM supports Layer 3 Ethernet configuration on routers with installed 3750 switch modules. You can create VLAN configurations and designate router Ethernet interfaces as DHCP servers.

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

3-9

Chapter 3 LAN Wizard

Layer 3 Ethernet Configuration

802.1Q Configuration

You can configure a VLAN that does not use the 802.1Q encapsulation protocol used for trunking connections. Provide a VLAN ID number, and check Native VLAN if you do not want the VLAN to use 802.1Q tagging.

If you want to use the 802.1Q tagging, leave the Native VLAN box unchecked.

Field Reference

Table 3-11 IP Address and Subnet Mask

Element Description

VLAN ID (1-4094) Enter a VLAN ID number from 1 to 4094. Cisco SDM displays a message

telling you to enter a different VLAN ID if the ID that you enter is already in use.

Native VLAN If you do not want the VLAN to use 802.1Q tagging, check Native VLAN.

If you want the VLAN to use 802.1Q tagging, leave this box unchecked.

Trunking or Routing Configuration

You can configure Layer 3 Ethernet interfaces for 802.1Q trunking or for basic routing. If you configure the interface for 802.1Q trunking, you can configure VLANs on the interface, and you can configure a native VLAN that does not use the 802.1q encapsulation protocol. I f you configure the interface for routing, you cannot configure subinterfraces or additional VLANs on the interface.

Configure Switch Device Module

If you are configuring a Gigabit Ethernet interface for routing, you can provide information about the switch module in this window. It is not required that you provide this information.

You can provide an IP address and subnet mask for the switch module, and login credentials required to log on to the the switch module interface.

Cisco Router and Security Device Manager 2.5 User’s Guide

3-10

OL-4015-12

Chapter 3 LAN Wizard

Check the box at the bottom of the screen if you want to log on to the switch module after providing the information in this wizard and delivering the configuration to the router.

Configure Gigabit Ethernet Interface

Provide IP address and subnet mask information for Gigabit Ethernet interfaces in this window. For more information on IP addresses and subnet masks, see LAN

Wizard: IP Address and Subnet Mask.

Field Reference

Table 3-12 IP Address and Subnet Mask

Element Description

IP Address of Physical Interface

IP Address of VLAN Subinterface

Enter the IP address and subnet mask for the physical Gigabit Ethernet interface in these fields.

Provide the IP address and subnet mask for the VLAN subinterface that you want to create on the physical interface. These fields appear if you are configuring this interface for routing. These fields do not appear if you are configuring this interface for Integrated Routing and Bridging (IRB).

Summary

This window provides a summary of the configuration changes that you made for the interface you selected.

To save this configuration to the router’s running configuration and leave this wizard:

Click Finish. Cisco SDM saves the configuration changes to the router’s running configuration. Although the changes take effect immediately, they will be lost if the router is turned off.

If you checked Preview commands before delivering to router in the User Preferences window, the Deliver window appears. In this window you can view the CLI commands that you are delivering to the router.

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

3-11

Summary

Chapter 3 LAN Wizard

3-12

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

CHAPTER

802.1x Authentication

802.1x authentication allows a remote Cisco IOS router to connect authenticated VPN users to a secure network through a VPN tunnel that is up at all times. The Cisco IOS router will authenticate users through a RADIUS server on the secure network.

802.1x authentication is applied to switch ports or Ethernet (routed) ports, but not to both types of interfaces. If 802.1x authentication is applied to an Ethernet port, non-authenticated users can be routed outside the VPN tunnel to the Internet.

802.1x authentication is configured on interfaces by using the LAN wizard. However, before you can enable 802.1x on any interface, AAA must be enabled on your Cisco IOS router. If you attempt to use the LAN wizard before AAA is enabled, a window appears asking if you want to enable AAA. If you choose to enable AAA, then the 802.1x configuration screens will appear as part of the LAN wizard. If you choose to not enable AAA, then the 802.1x configuration screens will not appear.

LAN Wizard: 802.1x Authentication (Switch Ports)

This window allows you to enable 802.1x authentication on the switch port or ports you selected for configuration using the LAN wizard.

Enable 802.1x Authentication

Check Enable 802.1x Authentication to enable 802.1x authentication on the switch port.

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

4-1

LAN Wizard: 802.1x Authentication (Switch Ports)

Host Mode

Choose Single or Multiple. Single mode allows only one authenticated client to have access. Multiple mode allows for any number of clients to have access once a single client has been authenticated.

Note Ports on Cisco 85x and Cisco 87x routers can be set only to multiple host mode.

Single mode is disabled for these routers.

Guest VLAN

Check Guest VLAN to enable a VLAN for clients lacking 802.1x support. If you enable this option, choose a VLAN form the VLAN drop-down list.

Auth-Fail VLAN

Check Auth-Fail VLAN to enable a VLAN for clients that fail 802.1x authorization. If you enable this option, choose a VLAN form the VLAN drop-down list.

Chapter 4 802.1x Authentication

Periodic Reauthentication

Check Periodic Reauthentication to force reauthentication of 802.1x clients on a regular interval. Choose to configure the interval locally, or to allow the RADIUS server to set the interval. If you choose to configure the reauthentication interval locally, enter a value in the range of 1–65535 seconds. The default setting is 3600 seconds.

Advanced Options

Click Advanced Options to open a window with additional 802.1x authentication parameters.

Advanced Options

This window allows you to change the default values for a number of 802.1x authentication parameters.

Cisco Router and Security Device Manager 2.5 User’s Guide

4-2

OL-4015-12

Chapter 4 802.1x Authentication

Radius Server Timeout

Enter the time, in seconds, that your Cisco IOS router waits before timing out its connection to the RADIUS server. Values must be in the range of 1–65535 seconds. The default setting is 30 seconds.

Supplicant Reply Timeout

Enter the time, in seconds, that your Cisco IOS router waits for a reply from an

802.1x client before timing out its connection to that client. Values must be in the range of 1–65535 seconds. The default setting is 30 seconds.

Supplicant Retries Timeout

Enter the time, in seconds, that your Cisco IOS router retries an 802.1x client before timing out its connection to that client. Values must be in the range of 1–65535 seconds. The default setting is 30 seconds.

Quiet Period

LAN Wizard: 802.1x Authentication (Switch Ports)

Enter the time, in seconds, that your Cisco IOS router will wait between the initial connection to a client and when a login request is sent. Values must be in the range of 1–65535 seconds. The default setting is 60 seconds.

Rate Limit Period

Values must be in the range of 1–65535 seconds. However, the default setting is 0 seconds, which turns off Rate Limit Period.

Maximum Reauthentication Attempts

Enter the maximum number of times your Cisco IOS router tries to reauthenticate an 802.1x client. Values must be in the range 1–10. The default setting is 2.

Maximum Retries

Enter the maximum number of login requests that can be sent to the client. Values must be in the range 1–10. The default setting is 2.

OL-4015-12

Cisco Router and Security Device Manager 2.5 User’s Guide

4-3

Chapter 4 802.1x Authentication

LAN Wizard: RADIUS Servers for 802.1x Authentication

Reset to Defaults

Click Reset to Defaults to reset all advanced options to their default values.

LAN Wizard: RADIUS Servers for 802.1x Authentication

802.1x authentication information is configured and stored in a policy database residing on RADIUS servers running Cisco Secure ACS version 3.3. The router must validate the credentials of 802.1x clients by communicating with a RADIUS server. Use this window to provide the information the router needs to contact one or more RADIUS servers. Each RADIUS server that you specify must have Cisco Secure ACS software version 3.3 installed and configured.

Note All of your Cisco IOS router interfaces enabled with 802.1x authorization will use

the RADIUS servers set up in this window. When you configure a new interface, you will see this screen again. Additions or changes to the RADIUS server information, however, do not have to be made.

Choose the RADIUS client source

Configuring the RADIUS source allows you to specify the source IP address to be sent in RADIUS packets bound for the RADIUS server. If you need more information about an interface, choose the interface and click the Details button.

The source IP address in the RADIUS packets sent from the router must be configured as the NAD IP address in the Cisco ACS version 3.3 or later.

If you choose Router chooses source, the source IP address in the RADIUS packets will be the address of interface through which the RADIUS packets exit the router.

If you choose an interface, the source IP address in the RADIUS packets will be the address of the interface that you chose as the RADIUS client source.

Cisco Router and Security Device Manager 2.5 User’s Guide

4-4

OL-4015-12

Chapter 4 802.1x Authentication

Note Cisco IOS software allows a single RADIUS source interface to be configured on

the router. If the router already has a configured RADIUS source and you choose a different source, the source IP address placed in the packets sent to the RADIUS server changes to the IP address of the new source, and may not match the NAD IP address configured on the Cisco ACS.

Details

If you need a quick snapshot of the information about an interface before choosing it, click Details. The screen shows you the IP address and subnet mask, the access rules and inspection rules applied to the interface, the IPSec policy and QoS policy applied, and whether there is an Easy VPN configuration on the interface.

Server IP, Timeout, and Parameters Columns

The Server IP, Timeout, and Parameters columns contain the information that the router uses to contact a RADIUS server. If no RADIUS server information is associated with the chosen interface, these columns are blank.

LAN Wizard: RADIUS Servers for 802.1x Authentication

Use for 802.1x Check Box

Check this box if you want to use the listed RADIUS server for 802.1x. The server must have the required 802.1x authorization information configured if 802.1x is used successfully.

Add, Edit, and Ping

To provide information for a RADIUS server, click the Add button and enter the information in the screen displayed. Choose a row and click Edit to modify the information for a RADIUS server. Choose a row and click Ping to test the connection between the router and a RADIUS server.

Note When performing a ping test, enter the IP address of the RADIUS source interface

in the source field in the ping dialog. If you chose Router chooses source, you need not provide any value in the ping dialog source field.

OL-4015-12

Cisco Router and Security Device Manager 2.5 User’s Guide

4-5

Chapter 4 802.1x Authentication

Edit 802.1x Authentication (Switch Ports)

The Edit and Ping buttons are disabled when no RADIUS server information is available for the chosen interface.

Edit 802.1x Authentication (Switch Ports)

This window allows you to enable and configure 802.1x authentication parameters.

If a message is displayed indicating that the port is operating in trunk mode instead of the 802.1x authentication parameters, then the switch cannot have

802.1x authentication enabled.

If the 802.1x authentication parameters appear but are disabled, then one of the following is true:

• AAA has not been enabled.

To enable AAA, go to Configure > Additional Tasks > AAA.

• AAA has been enabled, but an 802.1x authentication policy has not been

configured.

To configure an 802.1x authentication policy, go to Configure > Additional Tasks > AAA > Authentication Policies > 802.1x.

Enable 802.1x Authentication

Check Enable 802.1x Authentication to enable 802.1x authentication on this switch port.

Host Mode

Choose Single or Multiple. Single mode allows only one authenticated client to have access. Multiple mode allows for any number of clients to have access once a single client has been authenticated.

Note Ports on Cisco 87x routers can be set only to multiple host mode. Single mode is

disabled for these routers.

Cisco Router and Security Device Manager 2.5 User’s Guide

4-6

OL-4015-12

Chapter 4 802.1x Authentication

Guest VLAN

Check Guest VLAN to enable a VLAN for clients lacking 802.1x support. If you enable this option, choose a VLAN form the VLAN drop-down list.

Auth-Fail VLAN

Check Auth-Fail VLAN to enable a VLAN for clients that fail 802.1x authorization. If you enable this option, choose a VLAN form the VLAN drop-down list.

Periodic Reauthentication

Advanced Options

LAN Wizard: 802.1x Authentication (VLAN or Ethernet)

Click Advanced Options to open a window with additional 802.1x authentication parameters.

LAN Wizard: 802.1x Authentication (VLAN or Ethernet)

This window allows you to enable 802.1x authentication on the Ethernet port you selected for configuration using the LAN wizard. For Cisco 87x routers, this window is available for configuring a VLAN with 802.1x authentication.

Note Before configuring 802.1x on VLAN, be sure that 802.1x is not configured on any

VLAN switch ports. Also be sure that the VLAN is configured for DHCP.

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

4-7

Chapter 4 802.1x Authentication

LAN Wizard: 802.1x Authentication (VLAN or Ethernet)

Use 802.1x Authentication to separate trusted and untrusted traffic on the interface

Check Use 802.1x Authentication to separate trusted and untrusted traffic on the interface to enable 802.1x authentication.

Exception Lists

Click Exception Lists to create or edit an exception list. An exception list exempts certain clients from 802.1x authentication while allowing them to use the VPN tunnel.

Exempt Cisco IP phones from 802.1x authentication

Check Exempt Cisco IP phones from 802.1x authentication to exempt Cisco IP phones from 802.1x authentication while allowing them to use the VPN tunnel.

802.1x Exception List

An exception list exempts certain clients from 802.1x authentication while allowing them to use the VPN tunnel. Exempt clients are identified by their MAC addresses.

Add

4-8

Click Add to open a window where you can add the MAC address of a client. The MAC address must be in the format that matches one of these examples:

• 0030.6eb1.37e4

• 00-30-6e-b1-37-e4

Cisco SDM rejects misformatted MAC addresses, except for MAC addresses shorter than the given examples. Shorter MAC addresses will be padded with a “0” (zero) for each missing digit.

Note Cisco SDM’s 802.1x feature does not support the CLI option that associates

policies with MAC addresses and will not include in the exception list MAC addresses that have a policy associated with them.

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

Chapter 4 802.1x Authentication

802.1x Authentication on Layer 3 Interfaces

Delete

Click Delete to remove a chosen client from the exception list.

802.1x Authentication on Layer 3 Interfaces

This window allows you to configure 802.1x authentication on a Layer 3

Interface. It lists Ethernet ports and VLAN interfaces that have or can be

configured with 802.1x authentication, allows you to choose a Virtual Template interface for untrusted clients, and create an exception list for clients to bypass

802.1x authentication.

Note If policies have been set using the CLI, they will appear as read-only information

in this window. In this case, only enabling or disabling 802.1x is allowed in this window.

Prerequisite Tasks

If a prerequisite task appears in the window, it must be completed before 802.1x authentication can be configured. A message explaining the prerequisite task is displayed, along with a link to the window where the task can be completed.

Enable 802.1x Authentication Globally

Check Enable 802.1x Authentication Globally to enable 802.1x authentication on all Ethernet ports.

Interfaces Table

The Interfaces table has the following columns:

Interface—Displays the name of the Ethernet or VLAN interface.

802.1x Authentication—Indicates whether 802.1x authentication is enabled for

the Ethernet port.

OL-4015-12

Cisco Router and Security Device Manager 2.5 User’s Guide

4-9

802.1x Authentication on Layer 3 Interfaces

Edit

Click Edit to open a window of editable 802.1x authentication parameters. The parameters are the 802.1x authentication settings for the interface chosen in the Interfaces table.

Untrusted User Policy

Choose a Virtual Template interface from the drop-down list. The chosen Virtual Template interface represents the policy applied to clients that fail 802.1x authentication.

Click the Details button to see more information about the chosen Virtual Template interface.

Exception List

For more information about the exception list, see 802.1x Exception List.

Exempt Cisco IP phones from 802.1x authentication

Chapter 4 802.1x Authentication

Check Exempt Cisco IP phones from 802.1x authentication to exempt Cisco IP phones from 802.1x authentication while allowing them to use the VPN tunnel.

Apply Changes

Click Apply Changes for the changes you made to take effect.

Discard Changes

Click Discard Changes to erase the unapplied changes you made.

Edit 802.1x Authentication

This window allows you to enable and change the default values for a number of

802.1x authentication parameters.

Cisco Router and Security Device Manager 2.5 User’s Guide

4-10

OL-4015-12

Chapter 4 802.1x Authentication

Enable 802.1x Authentication

Check Enable 802.1x Authentication to enable 802.1x authentication on the Ethernet port.

Periodic Reauthentication

Advanced Options

Click Advanced Options for descriptions of the fields in the Advanced Options box.

How Do I ...

This section contains procedures for tasks that the wizard does not help you

complete.

How Do I Configure 802.1x Authentication on More Than One Ethernet Port?

Once you configure 802.1x authentication on an interface, the LAN wizard will no longer display any 802.1x options for Ethernet ports because Cisco SDM uses the 802.1x configuration globally.

Note For configuring switches, the LAN wizard will continue to display the 802.1x

options.

If you want to edit the 802.lx authentication configuration on an Ethernet port, go to Configure > Additional Tasks > 802.1x.

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

4-11

How Do I ...

Chapter 4 802.1x Authentication

4-12

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

CHAPTER

Configuring WAN Connections

The WAN wizards enable you to configure WAN connections for all Cisco SDM-supported interfaces.

This chapter contains the following sections:

• Configuring an Ethernet WAN Connection

• Configuring a Serial Connection

• Configuring a DSL Connection

• Configuring an ISDN Connection

• Configuring an Aux Backup Connection

• Configuring an Analog Modem Connection

• Configuring a Cable Modem Connection

Configuring an Ethernet WAN Connection

OL-4015-12

Complete these steps to configure an Ethernet WAN Connection:

Step 1 If you want to review the IOS CLI commands that you send to the router when

you complete the configuration, go to the Cisco SDM toolbar, and click Edit > Preferences > Preview commands before delivering to router.

Step 2 In the Cisco SDM toolbar, click Configure.

Step 3 In the Cisco SDM taskbar, click Interfaces and Connections.

Cisco Router and Security Device Manager 2.5 User’s Guide

5-1

Configuring an Ethernet WAN Connection

Step 4 In the Create Connection tab, click Ethernet WAN.

Step 5 Click Create Connection to start the wizard. The wizard Welcome screen

describes the tasks you will complete.

Step 6 Click Next to go to the subsequent screens to configure the connection.

Step 7 Cisco SDM displays the Summary screen when you have completed the

configuration. Review the configuration. If you need to make changes, click Back to return to the screen in which you need to make changes, then return to the Summary screen.

Step 8 If you want to test the connection after sending the configuration to the router,

check Te st the connectivity after configuring. After you click Finish, Cisco SDM tests the connection and displays the test results in another screen.

Step 9 To send the configuration to the router, click Finish.

The Ethernet WAN Connection Reference describes the screens that Cisco SDM displays.

Chapter 5 Configuring WAN Connections

Ethernet WAN Connection Reference

• WAN Wizard Interface Welcome Window

• Select Interface

• Encapsulation: PPPoE

• IP Address: Ethernet without PPPoE

• IP Address: ATM or Ethernet with PPPoE/PPPoA

• Authentication

• Advanced Options

• Summary

WAN Wizard Interface Welcome Window

This window lists the types of connections you can configure for this interface using Cisco SDM. If you need to configure another type of connection for this interface, you can do so using the CLI.

Cisco Router and Security Device Manager 2.5 User’s Guide

5-2

OL-4015-12

Chapter 5 Configuring WAN Connections

Configuring an Ethernet WAN Connection

Select Interface

This window appears if there is more than one interface of the type you selected in the Create Connection window. Choose the interface that you want to use for this connection.

Field Reference

Table 5-1 describes the fields in this screen.

Table 5-1 Select Interface Fields

Element Description

Check Boxes Check the box next to the interface that you want to use for this

connection.

If you are configuring an Ethernet interface, Cisco SDM inserts the description text $ETH-WAN$ in the configuration file so that it will recognize the interface as a WAN interface in the future.

Enable Dynamic DNS Click Enable Dynamic DNS if you want to update your DNS

servers automatically whenever the WAN interface IP address changes. Click the Dynamic DNS button to configure dynamic DNS.

The Enable Dynamic DNS option is not shown for all connection types.

IP Address: Ethernet without PPPoE

Choose the method that the WAN interface will use to obtain an IP address.

Field Reference

Table 5-2 describes the fields in this screen.

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

5-3

Chapter 5 Configuring WAN Connections

Configuring an Ethernet WAN Connection

Table 5-2 Ethernet without PPPoE IP Address Fields

Element Description

Static IP Address If you choose Static IP Address, enter the IP address and subnet

mask or the network bits in the fields provided. For more information, see IP Addresses and Subnet Masks.

Dynamic (DHCP Client) If you choose Dynamic, the router will lease an IP address from a

remote DHCP server. Enter the name of the DHCP server that will assign addresses.

Dynamic DNS Choose dynamic DNS if you want to update your DNS servers

automatically whenever the WAN interface IP address changes. Click the Dynamic DNS button to configure dynamic DNS.

Encapsulation: PPPoE

This window lets you enable Point-to-Point-Protocol over Ethernet (PPPoE) encapsulation. This is necessary if your service provider or network administrator requires remote routers to communicate using PPPoE.

PPPoE is a protocol used by many asymmetric digital subscriber line (ADSL) service providers. Ask your service provider if PPPoE is used over your connection.

If you choose PPPoE encapsulation, Cisco SDM automatically adds a dialer interface to the configuration, and this is shown in the Summary window.

Field Reference

Table 5-3 describes the fields in this screen.

Table 5-3 PPoE Encapsulation Fields

Element Description

Enable PPPoE Encapsulation If your service provider requires that the router use PPPoE, check

this box to enable PPPoE encapsulation. Uncheck this box if your service provider does not use PPPoE. This check box will not be available if your router is running a version of Cisco IOS that does not support PPPoE encapsulation.

Cisco Router and Security Device Manager 2.5 User’s Guide

5-4

OL-4015-12

Chapter 5 Configuring WAN Connections

Configuring an Ethernet WAN Connection

Summary

This screen displays a summary of the WAN link that you configured.You can review this information, and if you need to change anything, you can click the Back button to return to the screen on which you need to make changes.

Button Reference

Table 5-4 describes the buttons in this screen.

Table 5-4 WAN Summary Buttons

Element Description

Test the connectivity after configuring

To save this configuration to the router’s running configuration and leave this wizard:

Click Finish. Cisco SDM saves the configuration changes to the router’s running configuration. The changes will take effect immediately, but will be lost if the router is turned off.

Check this box if you want Cisco SDM to test the connection you have configured after it delivers the commands to the router. Cisco SDM will test the connection and report results in another window.

Advanced Options

OL-4015-12

If you checked Preview commands before delivering to router in the Cisco SDM Preferences window, the Deliver window appears. In this window, you can view the CLI commands that you are delivering to the router.

There are two advanced options available, based on the router’s configuration: Default static route, and Port Address Translation (PAT). If the Static Route option is not visible in the window, a static route has already been configured on the router. If the PAT option is not visible, PAT has already been configured on an interface.

Field Reference

Table 5-5 describes the fields in this screen.

Cisco Router and Security Device Manager 2.5 User’s Guide

5-5

Chapter 5 Configuring WAN Connections

Configuring a Serial Connection

Table 5-5 Advanced Options Fields

Element Description

Default Static Route Check this box if you want to configure a static route to the outside

interface to which outgoing traffic will be routed. If a static route has already been configured on this router, this box does not appear.

Next Hop Address If your service provider has given you a next-hop IP address to use,

enter the IP address in this field. If you leave this field blank, Cisco SDM will use the WAN interface that you are configuring as the next-hop interface.

Port Address Translation If devices on the LAN have private addresses, you can allow them

to share a single public IP address. You can ensure that traffic goes to its proper destination by using PAT, which represents hosts on a LAN with a single IP address and uses different port numbers to distinguish the hosts. If PAT has already been configured on an interface, the PAT option will not be visible.

Inside Interface to be Translated Choose the inside interface connected to the network whose host IP

addresses you want to be translated.

Configuring a Serial Connection

Complete these steps to configure a Serial connection:

Step 1 If you want to review the IOS CLI commands that you send to the router when

you complete the configuration, go to the Cisco SDM toolbar, and click Edit > Preferences > Preview commands before delivering to router.

Step 2 In the Cisco SDM toolbar, click Configure.

Step 3 In the Cisco SDM taskbar, click Interfaces and Connections.

Step 4 In the Create Connection tab, click Serial.

Step 5 Click Create Connection to start the wizard. The wizard Welcome screen

describes the tasks you will complete.

Step 6 Click Next to go to the subsequent screens to configure the connection.

Cisco Router and Security Device Manager 2.5 User’s Guide

5-6

OL-4015-12

Chapter 5 Configuring WAN Connections

Step 7 Cisco SDM displays the Summary screen when you have completed the

configuration. Review the configuration. If you need to make changes, click Back to return to the screen in which you need to make changes, then return to the Summary screen.

Step 8 If you want to test the connection after sending the configuration to the router,

check Te st the connectivity after configuring. After you click Finish, Cisco SDM tests the connection and displays the test results in another screen.

Step 9 To send the configuration to the router, click Finish.

The Serial Connection Reference describes the screens that Cisco SDM displays.

Serial Connection Reference

• WAN Wizard Interface Welcome Window

• Select Interface

• IP Address: Serial with Point-to-Point Protocol

Configuring a Serial Connection

• IP Address: Serial with HDLC or Frame Relay

• Authentication

• Configure LMI and DLCI

• Configure Clock Settings

• Advanced Options

• Summary

IP Address: Serial with Point-to-Point Protocol

Choose the method that the point-to-point interface will use to obtain an IP address.

Field Reference

Table 5-6 describes the fields in this screen.

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

5-7

Chapter 5 Configuring WAN Connections

Configuring a Serial Connection

Table 5-6 Serial Connection with Point-to-Point Protocol

Element Description

Static IP Address If you choose Static IP Address, enter the IP address and subnet

mask or the network bits in the fields provided. For more information, see IP Addresses and Subnet Masks.

IP Unnumbered Choose IP Unnumbered if you want the interface to share an IP

address that has already been assigned to another interface. Then choose the interface whose IP address you want to use for the interface you are configuring.

Easy IP (IP Negotiated) Choose Easy IP (IP Negotiated) if the router will obtain an IP

address through PPP/IPCP address negotiation.

Dynamic DNS Choose dynamic DNS if you want to update your DNS servers

automatically whenever the WAN interface IP address changes. Click the Dynamic DNS button to configure dynamic DNS.

IP Address: Serial with HDLC or Frame Relay

Choose the method that the WAN interface will use to obtain an IP address. If Frame Relay encapsulation is used, Cisco SDM creates a subinterface, and the IP address is assigned to the subinterface Cisco SDM creates.

Field Reference

Table 5-7 describes the fields in this screen.

Table 5-7 Serial Connection with HDLC or Frame Relay Fields

Element Description

Static IP Address If you choose Static IP Address, enter the IP address and subnet

mask or the network bits in the fields provided. For more information, see IP Addresses and Subnet Masks.

Cisco Router and Security Device Manager 2.5 User’s Guide

5-8

OL-4015-12

Chapter 5 Configuring WAN Connections

Configuring a Serial Connection

Table 5-7 Serial Connection with HDLC or Frame Relay Fields

Element Description

IP Unnumbered Choose IP Unnumbered if you want the interface to share an IP

address that has already been assigned to another interface. Then choose the interface whose IP address you want to use for the interface you are configuring.

Dynamic DNS Choose dynamic DNS if you want to update your DNS servers

automatically whenever the WAN interface IP address changes. Click the Dynamic DNS button to configure dynamic DNS.

Authentication

This page is displayed if you enabled or are configuring:

• PPP for a serial connection

• PPPoE or PPPoA encapsulation for an ATM connection

• PPPoE or PPPoA encapsulation for an Ethernet connection

• An ISDN BRI or analog modem connection

OL-4015-12

Your service provider or network administrator may use a Challenge Handshake Authentication Protocol (CHAP) password or a Password Authentication Protocol (PAP) password to secure the connection between the devices. This password secures both incoming and outgoing access.

Cisco Router and Security Device Manager 2.5 User’s Guide

5-9

Chapter 5 Configuring WAN Connections

Configuring a Serial Connection

Field Reference

Table 5-8 describes the fields in this screen.

Table 5-8 Authentication Fields

Element Description

Authentication Type Check the box for the type of authentication used by your service

provider. If you do not know which type your service provider uses, you can check both boxes: the router will attempt both types of authentication, and one attempt will succeed.

CHAP authentication is more secure than PAP authentication.

Username The username is given to you by your Internet service provider or

network administrator and is used as the username for CHAP or PAP authentication.

Password Enter the password exactly as given to you by your service provider.

Passwords are case sensitive. For example, the password cisco is not the same as Cisco.

Confirm Password Reenter the same password that you entered in the previous box.

Configure LMI and DLCI

If you are configuring a connection with Frame Relay encapsulation, you must specify the protocol used to monitor the connection, called the Local Management Identifier (LMI), and provide a unique identifier for this particular connection, called a data link connection identifier (DLCI).

Field Reference

Table 5-9 describes the fields in this screen.

Table 5-9 LMI and DLCI Fields

Element Description

LMI Type

ANSI Annex D defined by American National Standards Institute (ANSI)

standard T1.617.

Cisco Router and Security Device Manager 2.5 User’s Guide

5-10

OL-4015-12

Chapter 5 Configuring WAN Connections

Configuring a Serial Connection

Table 5-9 LMI and DLCI Fields

Element Description

Cisco LMI type defined jointly by Cisco Systems and three other

companies.

ITU-T Q.933 ITU-T Q.933 Annex A.

Autosense The default. This setting allows the router to detect which LMI type

is being used by communicating with the switch and to then use that type. If autosense fails, the router will use the Cisco LMI type.

DLCI Enter the DLCI in this field. This number must be unique among all

DLCIs used on this interface.

Use IETF Frame Relay Encapsulation

Internet Engineering Task Force (IETF) encapsulation. This option is used with connecting to non-Cisco routers. Check this box if you are connecting to a non-Cisco router on this interface.

Configure Clock Settings

The Clock Settings window is available when you are configuring a T1 or E1 link. The default Frame Relay clock settings are shown in this page. You should not change them unless you know you have different requirements.

Field Reference

Table 5-10 describes the fields in this screen.

Table 5-10 Clock Settings Fields

Element Description

Clock Source Internal specifies that the clock be generated internally. Line

specifies that the clock source be taken from the network. The clock synchronizes data transmission. The default is line.

T1 Framing This field configures the T1 or E1 link for operation with D4 Super

Frame (sf) or Extended Superframe (esf). The default is esf.

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

5-11

Chapter 5 Configuring WAN Connections

Configuring a Serial Connection

Table 5-10 Clock Settings Fields

Element Description

Line Code This field configures the router for operation on binary 8-zeros

substitution (B8ZS) or alternate mark inversion (AMI) T1 lines. The b8zs setting ensures density on a T1 or E1 line by substituting intentional bipolar violations in bit positions 4 and 7 for a sequence of eight zero bits. When the router is configured with the AMI setting, you must use the data-coding inverted setting to ensure density on the T1 line. The default is b8zs.

Data Coding Click inverted if you know that user data is inverted on this link, or

if the Line Code field is set to AMI. Otherwise leave this set to the default value normal. Data inversion is used with bit-oriented protocols such as HDLC, PPP, and Link Access Procedure, Balanced (LAPB) to ensure density on a T1 line with AMI encoding. These bit-oriented protocols perform “zero insertions” after every five “one” bits in the data stream. This has the effect of ensuring at least one zero in every eight bits. If the data stream is then inverted, it ensures that at least one out of every eight bits is a one.

Cisco SDM will set data coding to inverted if the line code is AMI and there are no time slots configured for 56 kbps. If you do not want to use inverted data coding with the AMI line code, you must use the CLI to configure all time slots to 56 kbps.

Facilities Data Link (FDL) This field configures the router behavior on the Facilities Data Link

(FDL) of the Extended Superframe. When configured with att, the router implements AT&T TR 54016. When configured with ansi, it implements ANSI T1.403. When you choose both, the router implements both att and ansi choices.When you choose none, the router ignores the FDL. The default is none. If T1 or E1 framing is set to sf, Cisco SDM will set FDL to none and make this field read-only.

Line Build Out (LBO) This field is used to configure the line build out (LBO) of the T1

link. The LBO decreases the transmit strength of the signal by –7.5 or –15 decibels. It is not likely to be needed on actual T1 or E1 lines. The default is none.

Cisco Router and Security Device Manager 2.5 User’s Guide

5-12

OL-4015-12

Chapter 5 Configuring WAN Connections

Configuring a DSL Connection

Table 5-10 Clock Settings Fields

Element Description

Remote Loopback Requests This field specifies whether the router will go into loopback mode

when a loopback code is received on the line. Choosing full causes the router to accept full loopbacks, while choosing payload-v54 will cause the router to choose payload loopbacks.

Enable Generation/Detection of Remote Alarms

Check this box if you want the router T1 link to generate remote alarms (yellow alarms) and to detect remote alarms being sent from the peer on the other end of the link.

The remote alarm is transmitted by a router when it detects an alarm condition: either a red alarm (loss of signal) or a blue alarm (unframed 1s). The receiving channel service unit/data service unit (CSU/DSU) then knows that there is an error condition on the line.

This setting should only be used when T1 framing is set to esf.

Configuring a DSL Connection

OL-4015-12

Complete these steps to configure an ADSL, or G.SHDSL connection:

Step 1 If you want to review the IOS CLI commands that you send to the router when

you complete the configuration, go to the Cisco SDM toolbar, and click Edit > Preferences > Preview commands before delivering to router.

Step 2 In the Cisco SDM toolbar, click Configure.

Step 3 In the Cisco SDM taskbar, click Interfaces and Connections.

Step 4 The Create Connection tab displays the available DSL connection types, for

example, ADSL (PPPoE or RFC 1483 routing or PPPoA). Choose an available connection type.

Step 5 Click Create Connection to start the wizard. The wizard Welcome screen

describes the tasks you will complete.

Step 6 Click Next to go to the subsequent screens to configure the connection.

Cisco Router and Security Device Manager 2.5 User’s Guide

5-13

Configuring a DSL Connection

Step 7 Cisco SDM displays the Summary screen when you have completed the

configuration. Review the configuration. If you need to make changes, click Back to return to the screen in which you need to make changes, then return to the Summary screen.

Step 8 If you want to test the connection after sending the configuration to the router,

check Te st the connectivity after configuring. After you click Finish, Cisco SDM tests the connection and displays the test results in another screen.

Step 9 To send the configuration to the router, click Finish.

The DSL Connection Reference describes the screens that Cisco SDM displays.

DSL Connection Reference

• WAN Wizard Interface Welcome Window

• Select Interface

• Encapsulation: PPPoE

Chapter 5 Configuring WAN Connections

• Encapsulation Autodetect

• IP Address: ATM or Ethernet with PPPoE/PPPoA

• IP Address: ATM with RFC 1483 Routing

• Authentication

• Advanced Options

• PVC

• Summary

IP Address: ATM or Ethernet with PPPoE/PPPoA

Choose the method that the WAN interface will use to obtain an IP address.

Cisco Router and Security Device Manager 2.5 User’s Guide

5-14

OL-4015-12

Chapter 5 Configuring WAN Connections

Configuring a DSL Connection

Field Reference

Table 5-11 describes the fields in this screen.

Table 5-11 ATM or Ethernet with PPPoE or PPPoA

Element Description

Static IP Address If you choose Static IP Address, enter the IP address and subnet

mask or the network bits in the fields provided.

Dynamic (DHCP Client) If you choose Dynamic, the router will lease an IP address from a

remote DHCP server. Enter the name of the DHCP server that will assign addresses.

IP Unnumbered Choose IP Unnumbered if you want the interface to share an IP

address that has already been assigned to another interface. Then choose the interface whose IP address you want to use for the interface you are configuring.

Easy IP (IP Negotiated) Choose Easy IP (IP Negotiated) if the router will obtain an IP

address through PPP/IPCP address negotiation.

Dynamic DNS Choose dynamic DNS if you want to update your DNS servers

automatically whenever the WAN interface IP address changes. Click the Dynamic DNS button to configure dynamic DNS.

IP Address: ATM with RFC 1483 Routing

Choose the method that the WAN interface will use to obtain an IP address.

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

5-15

Chapter 5 Configuring WAN Connections

Configuring a DSL Connection

Field Reference

Table 5-12 describes the fields in this screen.

Table 5-12 ATM with RFC 1483 Routing

Element Description

Static IP Address If you choose Static IP Address, enter the IP address and subnet

mask or the network bits in the fields provided. For more information, see IP Addresses and Subnet Masks.

Dynamic (DHCP Client) If you choose Dynamic, the router will lease an IP address from a

remote DHCP server. Enter the name of the DHCP server that will assign addresses.

IP Unnumbered Click IP Unnumbered if you want the interface to share an IP

address that has already been assigned to another interface. Then choose the interface whose IP address you want to use for the interface you are configuring.

Dynamic DNS Choose dynamic DNS if you want to update your DNS servers

automatically whenever the WAN interface IP address changes. Click the Dynamic DNS button to configure dynamic DNS.

Encapsulation Autodetect

In this window, choose the type of encapsulation that the WAN link will use. Ask your service provider or network administrator which type of encapsulation is used for this link. The interface type determines the types of encapsulation available.

Cisco Router and Security Device Manager 2.5 User’s Guide

5-16

OL-4015-12

Chapter 5 Configuring WAN Connections

Configuring a DSL Connection

Field Reference

Table 5-13 describes the fields in this screen.

Table 5-13 Encapsulation Fields

Element Description

Autodetect Click Au todete ct to have Cisco SDM discover the encapsulation

type. If Cisco SDM succeeds, it will automatically supply the encapsulation type and other configuration parameters it discovers.

Note Cisco SDM supports autodetect on SB106, SB107, Cisco

836, and Cisco 837 routers. However if you are configuring a Cisco 837 router and the router is running Cisco IOS Release 12.3(8)T or 12.3(8.3)T, the autodetect feature is not supported.

Encapsulations Available for ADSL, G.SHDSL, or ADSL over ISDN

PPPoE Provides Point-to-Point Protocol over Ethernet encapsulation. This

option is available when you have selected an Ethernet interface or an ATM interface. An ATM subinterface and a dialer interface will be created when you configure PPPoE over an ATM interface.

The PPPoE radio button will be disabled if your router is running a version of Cisco IOS that does not support PPPoE encapsulation.

PPPoA Point-to-Point protocol over ATM. This option is available when

you have selected an ATM interface. An ATM subinterface and a dialer interface will be created when you configure PPPoA over an ATM interface.

The PPPoA radio button will be disabled if your router is running a version of Cisco IOS that does not support PPPoA encapsulation.

RFC 1483 routing

with AAL5-SNAP

RFC 1483 routing with AAL5-MUX

This option is available when you have selected an ATM interface. An ATM subinterface will be created when you configure an RFC 1483 connection. This subinterface will be visible in the Summary window.

OL-4015-12

Cisco Router and Security Device Manager 2.5 User’s Guide

5-17

Configuring a DSL Connection

Table 5-13 Encapsulation Fields

Element Description

Encapsulations Available for Serial Interfaces

Frame Relay

Provides Frame Relay encapsulation. This option is available when you have selected a serial interface. A serial subinterface will be created when you create a Frame Relay connection. This subinterface will be visible in the Summary window.

Note If a Frame Relay serial connection has been added to an

interface, only Frame Relay encapsulation will be enabled in this window when subsequent serial connections are configured on the same interface.

Point-to-Point Protocol

Provides PPP encapsulation. This option is available when you have selected a serial interface.

High Level Data Link Control

Provides HDLC encapsulation. This option is available when you have selected a serial interface.

PVC

Chapter 5 Configuring WAN Connections

5-18

ATM routing uses a two-layer hierarchical scheme, virtual paths and virtual channels, denoted by the virtual path identifier (VPI) and virtual channel identifier (VCI), respectively. A particular virtual path may carry a number of different virtual channels corresponding to individual connections. When switching is performed based on the VPI, all cells on that particular virtual path are switched regardless of the VCI. An ATM switch may route according to VCI, VPI, or both VCI and VPI.

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

Chapter 5 Configuring WAN Connections

Configuring a DSL Connection

Field Reference

Table 5-14 describes the fields in this screen.

Table 5-14 PVC Fields

Element Description

VPI Enter the VPI value obtained from your service provider or system

administrator. The virtual path identifier (VPI) is used in ATM switching and routing to identify the path used for a number of connections. Enter the VPI value given to you by your service provider.

VCI Enter the VCI value obtained from your service provider or system

administrator. The virtual circuit identifier (VCI) is used in ATM switching and routing to identify a particular connection within a path that it may share with other connections. Enter the VCI value given to you by your service provider.

Cisco IOS Default Values

The values shown in the following table are Cisco IOS defaults. Cisco SDM will not overwrite these values if they have been changed during a prior configuration, but if your router has not been previously configured, these are the values that will be used

Connection Type Parameter Value

ADSL

G.SHDSL

ADSL over

• Operating mode • Auto

• Operating mode

• Line rate

• Equipment type

• Operating mode • Auto

• Annex A (United States)

• Auto

• CPE

ISDN

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

5-19

Configuring an ISDN Connection

Complete these steps to configure an ISDN connection:

Step 1 If you want to review the IOS CLI commands that you send to the router when

you complete the configuration, go to the Cisco SDM toolbar, and click Edit > Preferences > Preview commands before delivering to router.

Step 2 In the Cisco SDM toolbar, click Configure.

Step 3 In the Cisco SDM taskbar, click Interfaces and Connections.

Step 4 In the Create Connection tab, click ISDN (PPP).

Step 5 Click Create Connection to start the wizard. The wizard Welcome screen

describes the tasks you will complete.

Step 6 Click Next to go to the subsequent screens to configure the connection.

Step 7 Cisco SDM displays the Summary screen when you have completed the

configuration. Review the configuration. If you need to make changes, click Back to return to the screen in which you need to make changes, then return to the Summary screen.

Chapter 5 Configuring WAN Connections

Step 8 If you want to test the connection after sending the configuration to the router,

check Te st the connectivity after configuring. After you click Finish, Cisco SDM tests the connection and displays the test results in another screen.

Step 9 To send the configuration to the router, click Finish.

The ISDN Connection Reference describes the screens that Cisco SDM displays.

ISDN Connection Reference

• ISDN Wizard Welcome Window

• Select Interface

• IP Address: ISDN BRI or Analog Modem

• Switch Type and SPIDs

• Authentication

Cisco Router and Security Device Manager 2.5 User’s Guide

5-20

OL-4015-12

Chapter 5 Configuring WAN Connections

• Advanced Options

• Dial String

• Summary

ISDN Wizard Welcome Window

PPP is the only type of encoding supported over an ISDN BRI by Cisco SDM.

IP Address: ISDN BRI or Analog Modem

Choose the method that the ISDN BRI or analog modem interface will use to obtain an IP address.

Field Reference

Table 5-15 describes the fields in this screen.

Table 5-15 IP Address for ISDN BRI or Analog Modem Fields

Configuring an ISDN Connection

Element Description

Static IP Address If you choose Static IP Address, enter the IP address and subnet

mask or the network bits in the fields provided. For more information, see IP Addresses and Subnet Masks.

IP Unnumbered Choose IP Unnumbered if you want the interface to share an IP

address that has already been assigned to another interface. Then, choose the interface that has the IP address that you want the interface that you are configuring to use.

Easy IP (IP Negotiated) Choose IP Negotiated if the interface will obtain an IP address

from your ISP through PPP/IPCP address negotiation whenever a connection is made.

Dynamic DNS Choose Dynamic DNS if you want to update your DNS servers

automatically whenever the WAN interface IP address changes. Click the Dynamic DNS button to configure dynamic DNS.

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

5-21

Chapter 5 Configuring WAN Connections

Configuring an ISDN Connection

Switch Type and SPIDs

ISDN BRI connections require identification of the ISDN switch type, and in some cases, identification of the B channels using service profile ID (SPID) numbers. This information will be provided to you by your service provider.

Field Reference

Table 5-16 describes the fields in this screen.

Table 5-16 Switch Type and SPIDs Fields

Element Description

ISDN Switch Type Choose the ISDN switch type. Contact your ISDN service provider

for the switch type for your connection.

Cisco SDM supports these BRI switch types:

–

• For North America:

–

basic-5ess—Lucent (AT&T) basic rate 5ESS switch

–

basic-dms100—Northern Telecom DMS-100 basic rate switch

5-22

–

basic-ni—National ISDN switches

• For Australia, Europe, and the UK:

–

basic-1tr6—German 1TR6 ISDN switch

–

basic-net3—NET3 ISDN BRI for Norway NET3, Australia NET3, and New Zealand NET3switch types; ETSI-compliant switch types for Euro-ISDN E-DSS1 signaling system

–

vn3—French ISDN BRI switches

• For Japan:

–

ntt—Japanese NTT ISDN switches

Cisco Router and Security Device Manager 2.5 User’s Guide

OL-4015-12

Cisco Router and Security Device User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
