Casio V-R7000 User Manual

User’s Manual Manual del usuario Manuel de l’utilisateur Bedienungsanleitung

V-R7000 V-R7100

Touch Screen Terminal

Terminal de pantalla táctil

Borne de l’écran tactile

Touchscreen-Terminal

English

Español

Français

Deutsch

Thank you very much for purchasing the V-R7000/R7100. Please read this User’s Manual thoroughly and use the product accordingly. Please pay particular attention to the “Safety Precautions”. Please keep the User’s Manual in a safe and convenient place for future reference after reading.

Contents

Safety Precautions . . . . . .	. . . . .	. . . . .		.               E-2
Precautions for Use . . . . .	. . . . .	. . . . .	.	.		E-8
Confirming the Accessories . .	. . . . .	. . . . .	.	.	.	. .       E-10

Basic Operation . . . . . . . . . . . . . . .	. . . . .	. . . .	. .	. .	. .	. . . . . .	. . .E.-11. . . . . .
Name of Parts and What They Do . . . .	. . .	. . .	.	.	. .	. . .	E-12
Power ON/OFF . . . . . . . . . . .	. . .	. . .					E-15
Daily Use . . . . . . . . . . . .	. . . .	.					E-15
Moving and Cleaning . . . . . . . .	. . .	. . .	.	.	.		E-16
Description of the Indicator . . . . . .	. . . .	. .	. .	.	.	.	E-17
Adjusting the Angle of the Display . . . .	. . .	. . .	.	.	. .	. . .	E-18
When the Drawer Does not Open
(if using the optional CASIO drawer) . . .	. . .	. . .	.	.	. .	. . .	. E-18

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. . . . . . .	. . .	. . .	. .	.	. .	. . E-19
Name of Parts and What They Do . . . . . . . .	. . . .	. .	.	. .			E-20
Connecting the Power Supply and Various Devices .	. . . .	. .	. . .			.	. E-22
Connecting the Drawer cable . . . . . . . . .	. . . .	. .	.	.			E-22
Connecting the AC Adaptor . . . . . . . . . .	. . .	. .	. .				E-23
Connecting Other Devices . . . . . . . . . .	. . . .	. .	.				E-23
Preparing the Stand . . . . . . . . . . . . .	. . .	.					E-25
Setting the Stand and the Display . . . . . . .	. . . .	. .	.	. .		.	E-26
Installation features . . . . . . . . . . . . . . . . . . . . . . . . . .	. . . . . . .	. . . .	. . .	. .	.	. .	. . . E-28
MCR Unit (VA-B46MCRE) Installation . . . . . .	. . .	. .	. .	. . . . E-29
Specification . . . . . . . . . . . . . . . . .				E-30

E-1

Safety Precautions

●● Please read this “Safety Precautions” thoroughly and use the product accordingly.

●● Please pay due attention to the following symbols to help you use the product safely and properly and to avoid any personal injury or damage to the product.

*Warning	This symbol indicates the contents that may cause death or serious injury to a
	person when the product is misused ignoring this symbol.
*Caution	This symbol indicates the contents that may cause injury to a person or property
	damage when the product is misused ignoring this symbol.

●● The “pictorial indications” in this manual have the following meanings.

’This symbol means “to be careful = caution”. The example at left is “caution for electrical shock”.

!This symbol means “must not do = prohibited”. The example at left is “prohibited to disassemble”.

This symbol means “something must be done = instruction”. The example at left is $ “disconnect the power plug from the outlet”. The “instructions difficult to express in

picture” are indicated by +.

	*Warning
Using the AC power supply
-	●● Do not twist, pull, heat, modify, or place anything heavy on the power cord. This may
	damage the power cord and result in fire or electrical shock.
’	●● Contact the dealer or the CASIO service representative when the power cord is dam-
	aged (wire is exposed or disconnected). Using the power cord in such condition may
	result in fire or electrical shock.
	●● Securely insert the power plug all the way.
	●● Do not touch the power plug with wet hands. This may result in electrical shock.
	●● Do not use any AC adaptor or the power cord other than the parts included in the
	product. Also, do not use the AC adaptor or the power cord included in the product with
	other product. This may result in fire or electrical shock.
Power supply voltage
-	●● Do not use with any voltage other than the indicated power supply voltage. This may
	result in fire or electrical shock.

●● Do not overload the outlet with wires. This may result in fire or electrical shock.

Do not disassemble or modify

! ●● Do not disassemble or modify the product. There are high voltage parts and sharp parts inside. Touching them may result in injury or electric shock, or cause a malfunction or fire.

E-2

*Warning

Do not let any foreign object or water get inside

-●● Do not insert or drop metal object or flammable object inside from the opening.

●● Do not spill any liquid such as water from a flower vase, coffee, juice, etc., inside this

$	product.
	●● Disconnect the power plug from the outlet and contact the dealer where the product
	was purchased or the CASIO service representative when a foreign object or water
	got inside the product. Using the power cord in such condition may result in fire or
	electrical shock.
Do not use the product in abnormal condition
-	●● It may result in fire or electrical shock when the product is used in abnormal condition
	such as overheating, it is smoking, have strange odor, etc. Immediately disconnect the
	power plug from the outlet and contact the dealer where the product was purchased or
	the CASIO service representative.
	*Caution
Installation location
-	●● Do not place in unstable locations such as on an unsteady table or an inclined location.
	It could fall and cause injure.

●● Do not place in a location with high humidity or dust. This may result in fire or electrical shock.

●● Do not place in a location exposed to oil smoke or humidity such as close to cooking table or humidifier. This may result in fire or electrical shock.

●● Do not place in a location close to heating devices such as a stove or a heater, or location directly exposed to hot air. This may result in fire.

●● Select the outlet where the power cord of this product is easily reached, and plug/ unplug of the power plug can easily be performed.

Do not place anything on top

-●● Do not place flower vase or flower pot, cup or container with liquid, or metal object. ●● Do not place anything that is hot such as cigarette.

●● Do not place anything heavy.

●● Do not place your hands and lean on the product.

When moving the product

$	●● Always disconnect the power plug from the outlet before moving.
	●● Always hold onto the plug when unplugging the power plug.
	●● Pulling on the power cord may damage the cord, resulting to fire or electrical shock.

E-3

*Caution

LCD

-	●● Do not press hard on the LCD or apply strong impact. This may crack the glass on the
	LCD, resulting to injury.
	●● Never touch the liquid from inside when the LCD is cracked. This may result in irritation
	to the skin.
	●● Immediately rinse the mouth and contact the physician when the liquid inside the LCD
	gets inside the mouth.
	●● Rinse for minimum of 15 minutes with clean running water and contact the physician
	when the liquid inside the LCD gets in the eye or on the skin.
Handling of screen and key
-	●● Do not press the touch screen or keys at side with a sharp object or hard object such
	as ballpoint pen. This may result in malfunction.
	●● Press with finger instead of pressing hard with finger nail when operating.
Adjustment of display
-	●● Take care not to pinch finger with the tilt knob and its surrounding when adjusting the
	angle of the display. This may result in injury.

Drawer (If using the optional CASIO drawer)

+●● Take caution with the face of a child or pregnant person when opening a drawer.

●● Do not lean on the drawer when the drawer is opened. It could fall and cause injure.

-

Cleaning

$	●● Unplug the power plug from the outlet for safety when cleaning.
	●● Clean the blades and surrounding of the blades of the power plug with a dry cloth at

+least once a year. Dust accumulation may result in fire. Do not use detergent to clean the power plug.

When not using for a long period

$	●● Unplug the power plug from the outlet for safety when not using this product for a long
	period such as consecutive holidays.

Handling of Wireless Communication Function

*Warning

Interference with the Operation of Other Equipment (Using Wireless Data Communication)

+	●● In hospitals and other facilities where medical equipment is present, follow the
	instructions provided by the facility. In particular, turn OFF the power or the wireless
	communication function in operating theaters, intensive care units, coronary care units
	or any area where use of such products is prohibited by the facility.

E-4

Regulatory Information

The USA and Canada

GUIDELINES LAID DOWN BY FCC RULES FOR USE OF THE UNIT IN THE U.S.A. (Not applicable to other areas)

WARNING: This equipment has been tested and found to comply with the limits for

a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case

the user will be required to correct the interference at his own expense.

FCC WARNING: Changes or modifications not expressly approved by

the party responsible for compliance could void the user’s authority to operate the equipment.

Caution Exposure to radio frequency radiation

To comply with FCC RF exposure compliance requirements, this device must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with the FCC multi-transmitter product procedures or as described in the fi ling.

For Users in Canada

These Class A digital apparatuses comply with Canadian ICES-003.

Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.

Caution Exposure to radio frequency radiation

To comply with FCC/IC RF exposure compliance requirements, this device must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with the FCC/ IC multi-transmitter product procedures or as described in the filing.

Précaution Exposition aux champs de radiofréquences

Pour respecter les normes relatives aux radiofréquences FCC/IC, ce dispositif ne doit pas être situé ou utilisé à proximité d’une autre antenne ou d’un autre émetteur si ce n’est selon les procédures mentionnées pour le multi-transmetteur FCC/IC ou décrites dans la documentation.

E-5

Caution:

Users should also be advised that

(i)the device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems;

(ii)the maximum antenna gain permitted for devices in the bands 5250-5350 MHz and 5470-5725 MHz shall comply with the e.i.r.p. limit; and

(iii)the maximum antenna gain permitted for devices in the band 5725-5825 MHz shall comply with the e.i.r.p. limits specified for point-to-point and non point-to-point operation as appropriate. High-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices.

Les utilisateurs devraient aussi être avisés que

(i)les dispositifs fonctionnant dans la bande 5 150-5 250 MHz sont réservés uniquement pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux;

(ii)le gain maximal d’antenne permis pour les dispositifs utilisant les bandes 5 250-5 350 MHz et 5 470-5 725 MHz doit se conformer à la limite de p.i.r.e.;

(iii)le gain maximal d’antenne permis (pour les dispositifs utilisant la bande 5 725-5 825 MHz) doit se conformer à la limite de p.i.r.e. spécifiée pour l’exploitation point à point et non point à point,

selon le cas.

De plus, les utilisateurs de radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les bandes 5 250-5 350 MHz et 5 650-5 850 MHz et que ces radars pourraient causer du brouillage et/ou des dommages aux dispositifs LAN-EL.

Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.

Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante.

WARNING

THIS IS A CLASS A PRODUCT. IN A DOMESTIC ENVIRONMENT THIS PRODUCT MAY CAUSE RADIO INTERFERENCE IN WHICH CASE THE USER MAY BE REQUIRED TO TAKE ADEQUATE MEASURES.

E-6

Europe

Manufacturer:CASIO COMPUTER CO., LTD.

6-2, Hon-machi 1-chome, Shibuya-ku, Tokyo 151-8543, Japan Responsible within the European Union:CASIO EUROPE GmbH CASIO-Platz 1, 22848 Norderstedt, Germany

Please keep all information for future reference.

The declaration of conformity may be consulted at http://world.casio.com/

V-R7100

Products are for distribution within all member states of the EU.	0984

Laite on liitettävä suojamaadoituskostkettimilla vaurstettuun pistorasiaan

Apparatet må tilkoples jordet stikkontakt

Apparaten skall anslutas till jordat nätuttag.

The main plug on this equipment must be used to disconnect mains power.

Please ensure that the socket outlet is installed near the equipment and shall be easily accessible.

E-7

Precautions for Use

Read the following items thoroughly and use this product properly. CASIO bears no responsibility whatsoever for malfunction or damage caused by handling not following below contents. Please note that it will also result in charged repair, and actual cost required for repair will be charged, even if it is within the warranty period.

Installation Location

Do not place in a hot or dusty location, or in any location exposed to oily smoke or water. Never store or leave in following locations. This could erase the memory and cause a malfunction or result in deformation of the case.

●● Temperature of 0°C or lower

●● Close to air conditioner ●● Under direct sunlight

●● Temperature of 40°C or higher

Avoid using this product in following locations. ●● Outdoor

●● Close to equipment that will become hot such as range, electrical heater, etc. ●● Location exposed to water or steam

●● Location with severe change in environment such as temperature, humidity, etc. ●● Location where corrosive gas or saline matter is generated

●● Location where dirt or dust is generated ●● Location with vibration

●● Location prone to static electricity

Dead Pixels

The LCD panel employed in this product uses high precision and substantial number of components which commonly cause a small number of the pixels not to light or to remain lit all the time. This is due to the characteristics of LCD panel yield in accuracy over 99.99% and permissible.

802.11a/n Restrictions

●● This product is for indoor use only when using channels 36, 40, 44, 48, 52, 56, 60, or 64 (51505250 MHz).

●● To ensure compliance with local regulations, be sure to select the country in which the access point is installed.

Other

●● Do not turn off the power or remove the SD card while writing to or reading from the SD card.

This may result in damage to the SD card or stored data.

●● Prepare separate AC power supply from the power line for motor, ice maker, microwave oven, etc., which may generate noise.

●● Do not touch the power switch with wet hands. This may result in electrical shock. ●● Wipe thoroughly with dry cloth, etc., when there is any water droplet on the device.

●● Do not use any volatile chemical such as thinner, benzine, cosmetics, etc., for cleaning. Wipe with dry soft cloth when this product gets dirty. The display section may be scratched when scuffed strongly with a cloth.

●● The cover or the plastic case for the terminal may discolor or damaged when thinner, gasoline, kerosene, various solvent, grease, any cleaner including them, adhesive, paint, medical agent, cosmetics, etc., are adhered. Please be cautious.

E-8

Take Advance Notice of the Following

●● The content of this manual may be changed without prior notice due to improvement or specification change of the product.

●● Please note that CASIO bears no responsibility for damage, loss of profit, or any claim from third party due to loss or change of data caused by usage, malfunction, or repair of this product.

●● The copyright for this manual and all rights related to the software described in this manual are the property of CASIO Computer Co., Ltd. The unauthorized reproduction of this manual in whole or part is prohibited without the written permission of CASIO.

●● The content of this manual was created with all possible care, but please contact us if there is any unclear point, mistake, omission, etc., in this manual.

●● The screen or illustration used in this manual may be different from the actual product. The keys and icons are described in simplified manner.

●● Weld Line

The line on the exterior of the product is called “weld line”, which is created at the time of plastic forming, and it is not a crack or a scratch. This will not interrupt the usage.

Trademark Registration

SD, SDHC, microSD and microSDHC are trademarks of SD-3C, LLC.

HDMI (High-Definition Multimedia Interface) and the HDMI logo are trademarks of HDMI Licensing, LLC.

Android logo are trademarks or registered trademarks of Google, Inc.

BLUETOOTH is a registered trademark owned by Bluetooth SIG, Inc. and licensed to CASIO Computer Co., Ltd.

E-9
