MO1207-EB © 2012 CASIO COMPUTER CO., LTD.
Operation Guide 5266
ENGLISH
Congratulations upon your selection of this CASIO watch.
Warning !
• The measurement functions built into this watch are not intended for taking measurements that require professional or industrial precision. Values produced by this watch should be considered as reasonable representations only.
• Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any damage or loss suffered by you or any third party arising through the use of this product or its malfunction.
• To ensure correct direction readings by this watch, be sure to perform bidirectional calibration before using it. The watch may produce incorrect direction readings if you do not perform bidirectional calibration. For more information, see “To perform bidirectional calibration” (page E-24).
• Keep the watch away from audio speakers, magnetic necklace, cell phone, and other devices that generate strong magnetism. Exposure to strong magnetism can magnetize the watch and cause incorrect direction readings. If incorrect readings continue even after you perform bidirectional calibration, it could mean that your watch has been magnetized. If this happens, contact your original retailer or an authorized CASIO Service Center.
E-1
|
|
About This Manual |
Things to check before using the watch |
|
|
|
|
|
|
|
|
|
|
•Depending on the model of your watch, digital display text appears either as dark figures on a light background, or light figures on a dark background. All sample displays in this manual are shown using dark figures on a light background.
•Button operations are indicated using the letters shown in the illustration.
•Note that the product illustrations in this manual are intended for reference only, and so the actual product may appear somewhat different than depicted by an illustration.
1. Check the Home City and the daylight saving time (DST) setting.
Use the procedure under “To configure Home City settings” (page E-12) to configure your Home City and daylight saving time settings.
Important!
Proper Hijri calendar, Prayer Time Mode, and Moon Age Mode data depend on correct Home City, time, and date settings in the Timekeeping Mode. Make sure you configure these settings correctly.
2. Configure latitude and longitude settings for your current location.
See “To select a Home City by configuring latitude and longitude settings” (page E-14).
3. Set the current time.
See “Configuring Current Time and Date Settings” (page E-15).
The watch is now ready for use.
E-2 E-3
|
|
Contents |
E-28 Viewing Prayer Names and Prayer Times |
|
|
|
E-29 To display today’s prayer times |
|
|
|
E-2 About This Manual
E-3 Things to check before using the watch
E-7 Mode Reference Guide
E-11 Timekeeping
E-12 Configuring Home City Settings
E-12 To configure Home City settings
E-13 To change the Daylight Saving Time (summer time) setting
E-14 Configure latitude and longitude settings for your current location
E-14 To select a Home City by configuring latitude and longitude settings
E-15 Configuring Current Time and Date Settings
E-15 To change the current time and date settings
E-17 To specify a Hijri date offset
E-19 Hand Home Position Adjustment
E-19 To adjust home positions
E-20 Determining the Direction to Qibla
E-20 To determine Qibla
E-22 To take a direction reading
E-24 To perform bidirectional calibration
E-26 To perform magnetic declination correction
E-30 To view prayer times on a specific date E-31 To turn a prayer alarm on or off
E-32 To stop a sounding prayer alarm
E-33 To select a prayer time calculation method (FAJR, ISHA)
E-36 Using Moon Data
E-36 To look up the Moon age on a specific date
E-37 Thermometer
E-37 To enter and exit the Thermometer Mode E-38 To correct the temperature value
E-40 Specifying Temperature Unit
E-40 To specify the temperature unit
E-41 Using the Alarm
E-41 To enter the Alarm Mode E-42 To set an alarm time E-42 To test the alarm
E-43 To turn an alarm and the Hourly Time Signal on and off E-43 To stop the alarm
E-44 Using the Stopwatch
E-44 To enter the Stopwatch Mode
E-44 To perform an elapsed time operation
E-44 To pause at a split time
E-4 |
E-5 |
Operation Guide 5266
E-45 Using the Countdown Timer
E-45 To enter the Countdown Timer Mode E-45 To specify the countdown start time E-46 To perform a countdown timer operation E-46 To stop the alarm
E-47 Illumination
E-47 To turn on illumination
E-47 To change the illumination duration
E-49 Button Operation Tone
E-49 To turn the button operation tone on and off
E-50 Troubleshooting
E-53 Specifications
Mode Reference Guide
Your watch has 9 “modes”. The mode you should select depends on what you want to do.
To do this: |
Enter this mode: |
See: |
•View the current time and date in the Home City
•Configure Home City and daylight saving time (DST) settings
• Configure current location latitude and longitude settings |
Timekeeping Mode |
E-11 |
• Configure time and date settings |
|
|
• Specify the Hijri calendar offset |
|
|
• View the Qibla |
Qibla Mode |
E-20 |
• Take direction readings and display one of 16 direction |
||
indicators and the angle relative to magnetic north |
|
|
View today’s prayer name and prayer times |
Today’s Salat Time Screen |
E-28 |
View the prayer name and prayer times for a specified date |
SALAT Time Search Mode |
E-28 |
Determine a Moon age value |
Moon Age Mode |
E-36 |
Determine the temperature at your current location |
Thermometer Mode |
E-37 |
Set an alarm time |
Alarm Mode |
E-41 |
Use the stopwatch to measure elapsed time |
Stopwatch Mode |
E-44 |
Use the countdown timer |
Countdown Timer Mode |
E-45 |
E-6 |
E-7 |
|
|
Selecting a Mode
•The illustration below shows which buttons you need to press to navigate between modes.
•To return to the Timekeeping Mode from any other mode, hold down C for about two seconds.
•In any mode, press L to illuminate the display.
Moon Age Mode
Thermometer Mode
• You also can take digital compass readings in the Qibla Mode (page E-22).
SALAT Time Search Mode |
|
Timekeeping Mode |
|
|
Qibla Mode |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Today’s Salat |
|||
Alarm Mode |
Stopwatch Mode |
Countdown Timer Mode |
||||||
Time Screen |
||||||||
E-8 |
E-9 |
|
|
General Functions (All Modes)
The functions and operations described in this section can be used in all of the modes.
Auto Return Features
•If you do not perform any button operation for two or three minutes in the Salat Search Mode, Moon Age Mode, or Alarm Mode, the watch will automatically return to the Timekeeping Mode.
•If you do not perform any button operation for one or two minutes in the Thermometer Mode or Qibla Mode, the watch will automatically return to the Timekeeping Mode.
•If you leave a screen with flashing digits on the digital display for two or three minutes without performing any operation, the watch exits the setting screen automatically.
Initial Screens
When you enter the Alarm Mode, the data you were viewing when you last exited the mode appears first.
Scrolling
The B and D buttons are used on the setting screen to scroll through data on the digital display. In most cases, holding down these buttons during a scroll operation scrolls through the data at high speed.
Timekeeping
Use the Timekeeping Mode to set and view the current time and date.
•Each press of A in the Timekeeping Mode cycles the digital display between the current Gregorian calendar date, the current Hijri calendar date, and the current time.
•The HIJRI indicator on the digital display indicates that the Hijri calendar date is displayed.
Date screen (Gregorian) |
Date screen (Hijri) |
Regular timekeeping |
|
|
screen |
Day Month |
Day Month |
Seconds |
Day of week |
|
Hour : Minutes |
HIJRI indicator
E-10 |
E-11 |
Operation Guide 5266
Configuring Home City Settings
There are two methods you can use to configure Home City settings: selecting a Home City and then selecting standard time or daylight saving time (DST), or selecting CUSTOM and then specifying an UTC offset.
To configure Home City settings
|
|
1. In the Timekeeping Mode, hold down A for at least two seconds |
City Name |
until ADJUST appears on the digital display. This is the setting |
|
|
|
mode. Release A after ADJUST appears. |
|
|
• The city name of the currently selected Home City data will |
|
|
appear on the digital display with an arrow (▲) flashing to the |
|
|
left. |
|
|
• The watch will exit the setting mode automatically if you do not |
|
|
perform any operation for about two or three minutes. |
|
|
• For details about city data, see the “City Data Table” at the back |
|
|
of this manual. |
2. Press D (East) and B (West) to scroll through city names until the one you want to use as your Home City data is displayed.
• If you selected CUSTOM in place of a Home City, press C here to display the UTC offset setting screen. Use D (+) and B (–) change the UTC differential value in 15-minute increments. When you select CUSTOM, the standard time/daylight saving time selection screen does not appear. Jump to step 5 of this procedure.
3. Press C to display the DST setting screen.
4. Press D to toggle between Daylight Saving Time (DST ON) and Standard Time (DST OFF).
• Note that you cannot switch between standard time and daylight saving time (DST) while CUSTOM is selected as your Home City.
E-12
5. When the setting is the way you want, press A twice to return to the
|
|
|
Timekeeping Mode. |
|
|
|
|
• The DST indicator appears to indicate that Daylight Saving Time |
|
|
|
|
is turned on. |
|
|
|
|
||
|
|
|
Note |
|
|
|
|
• After you specify city data, the watch will use UTC* offsets to |
|
|
Setting |
calculate the current time for other time zones based on the |
||
DST indicator |
current time in your Home City. |
|||
* Coordinated Universal Time, the world-wide scientific standard |
||||
|
|
|
||
|
|
|
of timekeeping. |
|
|
|
|
The reference point for UTC is Greenwich, England. |
|
To change the Daylight Saving Time (summer time) setting |
||||
Setting
DST indicator
1.In the Timekeeping Mode, hold down A for at least two seconds until ADJUST appears on the digital display. Release A after ADJUST appears.
•The name of the city currently selected as your Home City will
appear on the digital display with an arrow ( ▲) flashing to the left.
2.Press C to display the DST setting screen.
3.Press D to toggle between Daylight Saving Time (DST ON) and Standard Time (DST OFF).
4.When the setting is the way you want, press A twice to return to the Timekeeping Mode.
•The DST indicator appears to indicate that Daylight Saving Time is turned on.
•Note that you cannot switch between standard time and daylight saving time (DST) while CUSTOM is selected as your Home City.
E-13
Configure latitude and longitude settings for your current location
You can ensure correct display of Qibla, prayer times, and moon ages by configuring latitude and longitude settings for your current location.
To select a Home City by configuring latitude and longitude settings
1. |
In the Timekeeping Mode, hold down A for at least two seconds |
|
until ADJUST appears on the digital display. This is the setting |
|
mode. Release A after ADJUST appears. |
|
• Your current Home City data will appear on the digital display |
|
with an arrow (▲) flashing to the left. |
2. |
Press A to display to the latitude setting screen with the current |
|
latitude setting flashing. |
3. Use D (+) and B (–) to change the flashing value in 0.1° increments.
• Holding down D or B while the latitude or longitude setting screen is displayed will scroll the value to the left of the decimal point (the value to the right does not change) at high speed.
S 62.0°
S 61.9°
S 0.1°
N 0°
N 0.1°
N 61.9°
N 62.0°
4.When the latitude is the value you want, press C to display the longitude setting screen with the current longitude setting flashing.
5.Use D (+) and B (–) to change the flashing value in 0.1° increments.
W 179.9°
W 179.8°
W 0.1°
E 0°
E 0.1°
E 179.9°
E 180°
6. When the settings are the way you want, press A to return to the Timekeeping Mode.
E-14
Configuring Current Time and Date Settings
You can use the procedure below to adjust the current time and date settings if they are off. Changing the digital Home City data should cause the analog time setting to change accordingly. If the analog time does not indicate the digital time, check the home positions of the hands and make adjustments if necessary (page E-19).
This watch displays Hijri calendar months and days. The watch normally calculates and displays Hijri calendar dates automatically. If necessary, you can correct the displayed data by ±3 days.
To change the current time and date settings
1. In the Timekeeping Mode, hold down A for at least two seconds until ADJUST appears on the digital display. This is the setting
mode. Release A after ADJUST appears.
• The name of the city currently selected as your Home City will appear on the digital display with an arrow ( ▲) flashing to the left.
|
2. Use D and B to select the city data you want. |
City name |
• Select your Home City data before changing any other setting. |
• For full information on city data, see the “City Data Table” at the |
|
|
back of this manual. |
3. Press C to move the flashing in the sequence shown below to select the other settings.
City data |
|
DST |
|
|
12/24-Hour Format |
|
|
Seconds |
|
|
Hour |
|
|
Minute |
|
|
Year |
|
|
|
Month |
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||||||||
CUSTOM |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
UTC Offset/GMT Differential |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Date Display Format |
|
|
Illumination Duration |
|
|
Button Operation Tone On/Off |
|
|
|
|
Day |
|||||||||||||||||||
|
|
|
|
|
|
|
|
|||||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
• The following steps explain how to configure timekeeping settings only.
E-15
4.When the timekeeping setting you want to change is flashing, use B and/or D to change it as described below.
Screen |
To do this: |
Do this: |
|
Change the city name |
Use D (East) and B |
|
(West). |
|
|
|
|
|
Toggle between Daylight Saving Time (DST ON) and |
Press D. |
|
Standard Time (DST OFF). |
|
|
Toggle between 12-hour (12H) and 24-hour (24H) |
Press D. |
|
timekeeping. |
|
|
|
|
|
Reset the seconds to 00 |
Press D. |
|
Change the hour or minute |
|
|
Change the year, month, or day |
Use D (+) and B (–). |
|
|
|
|
|
|
|
Select the date display format (DMY, YMD, MDY) |
Press D. |
|
|
|
5. When the settings are the way you want, press A twice to return to the Timekeeping Mode.
Note
•For information about selecting a Home City and configuring the DST setting, see “Configuring Home City Settings” (page E-12).
•The watch’s built-in full automatic calendar makes allowances for different month lengths and leap years. Once you set the date, there should be no reason to change it except after you have the watch’s battery replaced.
•Changing your Home City setting will cause all of the following settings to become initialized: latitude and longitude (to the location of the Home City), the prayer calculation method (Fajr, Isha, Asr), and the Qibla declination (in accordance with the selected Home City). Note that these settings are not initialized when CUSTOM is selected for the Home City setting.
To specify a Hijri date offset
1. In the Timekeeping Mode, hold down A for at least four seconds until HIJRI SET appears on the digital display. This is the setting
mode. Release A after HIJRI SET appears.
• Releasing A will cause the current Hijri date offset to flash on the digital display.
2. Use D (+) and B (–) to change the offset within a range of ±3 days.
|
3. When the setting is the way you want, press A. |
HIJRI indicator |
• This will display the corrected Hijri date. |
|
Note
•The Hijri offset setting is temporary. At the end of each month, the watch automatically corrects the Hijri date and returns the Hijri offset to ±0DAY.
•Note that the Hijri offset also returns to ±0DAY whenever you change the watch’s Gregorian date setting or the latitude and/or longitude settings.
•Changing the watch’s Gregorian date setting can cause an error in the displayed Hijri until the watch performs automatic Hijri date correction at the end of the month (on the 29th or 30th day of the month). If the Hijri date display is wrong, adjust it by changing the Hijri date offset.
Hijri Calendar Precautions
Hijri dates displayed by this calculator are the results of calculations. Actual Hijri dates may be determined by religious authorities based on observations of a New Moon following sundown. This can result in dates calculated by the watch being different from actual Hijri dates.
E-16 |
E-17 |
Loading...
