Carver MSMP, MSMPX User Manual

MSMP / MSMPX

User Manual

This User Manual is made available in Adobe Acrobat format.
In order to view or print the manual, and utilize its enhancements we
recommend that you download Adobe Acrobat Reader 4.0 or
greater. If you do not have this viewer installed on your
computer, or if you have an older version the reader is available
as a free download at http://www.adobe.com.

By going to the table of contents you can directly access any
topic outlined there by simply clicking on the topic heading.

Rev. 11.20.01

© Phoenix Gold International, Inc. November 2001

SAFETY INFORMATION

Caution

The exclamation point within an equilateral triangle is
intended to alert the user of the presence of important
operating and maintenance (servicing) instructions in the

Please read this entire manual, especially the Safety Warnings, before operating
your amplifier.

Table Of Contents

Introduction
Unpacking & Paperwork
Important Paperwork
Features
Configuring the MSMP / MSMPX
JP101
JP100

3
3

3
4

5
5
5

JP3

SW1

Connecting the MSMP / MSMPX
Input Connections
Input Adjustments
MSMPX

5
5
6
6
7
7

8Specifications

(2)

INTRODUCTION

Congratulations on your purchase of a new Carver Professional CV Series Power Amplifier.
The CV Series Amplifiers and Accessory Modules are designed expressly for commercial and
institutional audio applications. The CV Series products are designed and manufactured by
Carver Professional, a division of Phoenix Gold International, Inc. They combine Carver
Professional’s experience in pro audio along with the needs of the system integrator to provide
an uncompromising product for the commercial sound industry. The sonic heritage of Carver
Professional combined with the performance, manufacturing quality and attention to detail that
has defined Phoenix Gold International assures you of the value and integrity you seek in an
amplifier product. Thank you for placing your confidence in Carver Professional and Phoenix
Gold. We know your amplifier will provide many years of dependable service and reliable
sound reproduction.

Please read this entire manual, especially the Safety Warnings, before operating your
amplifier.

UNPACKING AND PAPERWORK

Carefully unpack the module and keep the original carton and packing materials for future
moving, shipment or long-term storage. After opening the box, please check for visible signs
of damage that were not apparent from the outside of the box. If you encounter what appears
to be concealed damage, please contact your Carver Professional Dealer or Carver Professional
before installing unit.

Important Paperwork

Make sure to save your sales receipt. Your receipt is extremely important to establish the
duration of your Limited Warranty and for insurance purposes.

Model: _______________

Purchased at: __________________________ Date: _________________

(3)
