Canon 150VP Specification Sheet

Production Systems

Configuration/Platen: Digital, Multifunction Imaging System Imaging System: Electrophotographic Process Developing System: SPD, Two Component Dry Acceptable Originals: Sheets, Transparencies, Tabs, Covers Max. Originals Size: 14.33" x 18.5"* Min. Originals Size: 7" x 8.27"* Max. Print Size: 14" x 18.25" Engine Resolution: 600 x 600 dpi Paper-feeding: 6-drawer Modular Paper Capacity

Standard: 8,000 Sheets

Drawer 1, 4 (Top): 1,000 Sheets (20 lb.) Drawer 2, 5: 1,000 Sheets (20 lb.) Drawer 3, 6: 2,000 Sheets (20 lb.)

Maximum: 12,000 Sheets

▲

Acceptable Paper Weight: 16 lb. Bond to 150 lb. Index (All Cassettes)



Duplexing: Trayless Duplexing (Except Tabs) Warm-up Time: 6 Minutes Maximum Print Speed: 150 ppm (LTR/LGL), 75 ppm (LDG) Dimensions (H x W x D): 64" x 155" x 47"

(163cm x 394cm x 119cm) Weight: 3,240 lb. (1469kg) Power Requirements

(V/Hz/Amps): 208/60/30 Noise Level (Printing): <70dB Duty Cycle: 3 to 5 Million Impressions per Month** Developer: 1.69kg—Estimated Yield:

1,200,000 Prints (LTR)

Toner: 2.5kg—Estimated Yield:

80,000 Prints (LTR, 6% Coverage)

Accessories

Finisher

Number of Trays: 2 Trays Tray Capa city

Top Tray: 500 Sheets (All Sizes) Non-staple Mode

Staple Tray: 3,000 Sheets (Straight or Offset/

85 Sets with Staple)

Paper Size

Top Tray: 7" x 8.27" to 14.33" x 18.5"*

Staple Tray: 7" x 8.27" to 9" x 14"* Staple Position: Multiposition Stapling Stitching Capacity: None, Top, Bottom, Both Document Delivery: Face-down Staples: 50,000 Power Supply: Directly from Main Unit Weight: 650 lb. (294.7kg) Dimensions (H x W x D): 61.5" x 22.5" x 34"

(156cm x 58cm x 86cm)

imageSCANNER 65 Production Scanner

■

(Optional)

Optical Resolution: 600 dpi x 600 dpi Speed (Simplex/

Duplex LTR/A4): 65/36 ppm Paper Feeder Capacity: 100 Sheets(LTR, 20 lb.) Paper Size Ranges: 5.5" x8.5" to 11" x17" Paper Weight Ranges: 16 lb. Bond to 110 lb. Index Weight: 200 lb. (90kg) Dimensions (H x W x D): 15" x 39" x 27"

(38.1cm x 99cm x 66.6cm)

Paper Supply Module (Optional )

Number of Trays: 3 Cassettes Tray Capa city

Drawer 7 (Top): 1,000 Sheets (20 lb.)

Drawer 8: 1,000 Sheets (20 lb.)

Drawer 9: 2,000 Sheets (20 lb.) Paper Size: 16 lb. Bond to 150 lb. Index



Weight: 545 lb. (247.4kg) Dimensions (H x W x D): 45" x 35.5" x 31.5"

(114cm x 90cm x 85cm)

Post-process Inserter (Optional)

Number of Trays: 3 Cassettes Tray Capa city

Drawer 1 (Top): 1,000 Sheets (7" x 8.27" to 9" x 14")*

Drawer 2: 1,000 Sheets (7" x 8.27" to 14.33" x 18.5")*

Drawer 3: 2,000 Sheets (7" x8.27" to 14.33" x 18.5")* Paper Weight:

16 lb. Bond to 150 lb. Index



Weight: 610 lb. (276.7kg) Dimensions (H x W x D): 49.5" x 31" x 33.5"

(125.7cm x 78.7cm x 85.1cm)

Puncher (Optional)

Power Requirements: 120 VAC, 60Hz, 2.5A

100 VAC, 50/60Hz, 2.5A Power Consumption: 320 VA Dimensions (H x W x D): 49.6" x 40.2" x 31.9"

(126cm x 102cm x 81cm) Weight: 595 lb. (270kg) Punch Tools

• Loose-leaf/Office Hole-punch Tool (2-/3-/4-hole)

• Plastic Comb Punch Too l ( Rec ta ngular)

• Wire Comb Punch Tool 2-1 Pitch (Round)

• Wire Comb Punch Tool 3-1 Pitch (Round)

• Wire Comb Punch Tool 2-1 Pitch (Rectangular)

• Wire Comb Punch Tool 3-1 Pitch (Square)

Punch ToolDurability: 12 - 15 Million Actuations

Stacker (Optional)

✝

Number of Trays: 1 Tray Tray Capacity: 5,000 Sheets

(Straight or Offset Non-staple) Paper Size: 7" x 8.27" to 14.33" x 18.5"* Rotator Unit: Rotates 8-1/2" x 11" Portrait Sheets

90 Degrees Document Delivery: Face-down Power Supply: 115V

Weight: 450 lb. (203.7kg) Dimensions (H x W x D): 49.5" x 33" x 31.6"

(125.7cm x 84.8cm x 78.7cm)

Booklet-maker (Optional)

Tray Capa city: Conveyor Belt Output Paper Size: 8" x 10" to 14" x 18" Stitching Capacity: 2 to 22 Sheets Stitching Position

Single-position Stapling: 2 Center Staple Positions

Saddle-stitched Specifications

Folding: V-folding Folding Capacity: 1 to 22 Sheets (20 lb. Bond) Trimming: Edge Trim Folded Booklets

(Adjustable Trim Width) Staple Wire Spool: 40,000 (100-sheet Stitches) Power Supply: 115V Weight: 970 lb. (439.8kg) Dimensions (H x W x D): 58" x 100" x 24"

(147.2cm x 254cm x 58.4cm)

BPRF (Optional)

Power Requirements: 120 VAC, 60Hz Power Consumption: 920 Watts Dimensions (H x W x D): 51" x 64" x 31"

(129cm x 162cm x 78cm) Weight: 562 lb. (255kg)

Perfect Binder (Optional)

Book Thickness: 15 Sheets to 1.5" (40mm)

about 350 Sheets @ 20 lb. Bond Book Size (In-line Binding): 8.5" x 11" Book Size (Off-line Binding): 2.36" x 4" to 12" x 14"

(60mm x 100mm to 305mm x 356mm) Weight (with Input Unit,

Delivery, and Bypass): 1,676 lb. (760kg)

Dimensions with Bypass

(H x W x D): 45" x 8'4" x 5'11"

(1.2m x 2.6m x 1.8m)

Roll Feed Interface Kit (Optional)

Supports Roll Systems DocuSheeter LS Supports Standard Hunkeler SF4-H Sheet Feeder

Multi-stacker Interface Kit(Optional )

Supports up to three Stackers on one device One kit is required for each additionalStacker

Optional Feat ures

MICR printing* Enhanced Feed Mode* Digital Print Quality Adjustments* PCL Interpreter* Extended Paper Size Range*

imageRUNNER Pro 150VP Specifications

*Optional license upgrade is required.

**Depends on customer job stream and number of shifts.

▲

With optional Paper Supply Module.

✝

Stacker is required for Booklet-maker and Perfect Binder.

■

Other optional scanners may be available. Please check with your local Authorized Canon Dealer.



Caliper must fall within 3.5mil to 10mil (0.09mm to 0.25mm)

The PostScript logo is a registered trademark of Adobe Systems Incorporated in the United States and/or other countries. Canon, IMAGERUNNER, and Canon Know How are registered trademarks, and the GENUINE Logo is a trademark of Canon Inc. in the United States and may also be registered trademarks or trademarks in other countries. IMAGEANYWARE isa ser vice mark of Canon U.S.A., Inc. All other terms and product names may be trademarks or registered trademarks of their respective owners and are hereby acknowledged.

Specifications subject to change without notice.

0804-150VP-PDF

1-800-OK-CANON

www.usa.canon.com

Canon U.S.A., Inc. One Canon Plaza Lake Success, NY 11042

The Canon imageRUNNER®Pro 150VP is a high-speed, high-volume net- worked production engine that offers unparalleled flexibility in configuration and design.

Introducing the imageRUNNER Pro 150VP.

A Very Powerful black-and-white

production printer that combines outstanding performance with Variable

Paper and Variable Pitch capabilities.
