CANDY ICL60 User Manual

0 (0)

FR

Mode d’emploi

IT

Istruzioni per l’uso

ES

Instrucciones para el uso

DE

Bedienungsanleitung

EN

User instructions

ICL 60 T

FR

TOUS NOS

COMPLIMENTS

En achetant cet appareil ménager Candy, vous avez démontré que vous n’acceptez aucun compromis: vous voulez toujours ce qu’il y a de mieux.

Candy a le plaisir de vous proposer cette nouvelle machine à laver qui est le résultat d’années de recherches et d’études des besoins du consommateur. Vous avez fait le choix de la qualité, de la fiabilité et de l’efficacité.

Candy vous propose une large gamme d’appareils électroménagers: machines

àlaver la vaisselle, machines

àlaver et sécher le linge, cuisinières, fours à microondes, fours et tables de cuisson, hottes, réfrigerateurs et congélateurs.

Demandez à votre Revendeur le catalogue complet des produits Candy.

Nous vous prions de lire attentivement les conseils contenus dans ce livret. Il contient d’importantes indications concernant les procédures d’installation, d’emploi, d’entretien et quelques suggestions utiles en vue d’améliorer l’utilisation de la machine à laver.

Conservez avec soin ce livret: vous pourrez le consulter bien souvent.

Quand vous communiquez avec Candy, ou avec ses centres d’assistance, veuillez citer le Modèle, le n° et le numéro G (éventuellement).

2

COMPLIMENTI

Con l’acquisto di questo elettrodomestico Candy; Lei ha dimostrato di non accettare compromessi: Lei vuole il meglio.

Candy é lieta di proporLe questa nuova lavatrice frutto di anni di ricerche e di esperienze maturate sul mercato, a contatto diretto con i Consumatori. Lei ha scelto la qualità, la durata e le elevate prestazioni che questa lavatrice Le offre.

Candy Le propone inoltre una vasta gamma di elettrodomestici: lavatrici, lavastoviglie, lavasciuga, cucine, forni a microonde, forni e piani di cottura, frigoriferi e congelatori.

Chieda al Suo Rivenditore il catalogo completo dei prodotti Candy

La preghiamo di leggere attentamente le avvertenze contenute nel presente libretto in quanto forniscono importanti indicazioni riguardanti la sicurezza di installazione, d’uso, di manutenzione e alcuni utili consigli per il migliore utilizzo della lavatrice.

Conservi con cura questo libretto per ogni ulteriore consultazione.

Quando comunica con la Candy o con i suoi centri di assistenza citi sempre il Modello, il n° e il numero G (se c’è). Praticamente tutto ciò che é citato nel riquadro.

ES

ENHORABUENA

Con la compra de este electrodoméstico Candy; usted ha demostrado no conformarse con cualquier cosa: usted quiero lo mejor.

Candy se complace en ofrecerle esta nueva lavadora, fruto de años de investigación y de experiencia en el marcado y del contacto directo con los Consumidores. Usted ha escogido la calidad, la duración y las enormes prestaciones que esta lavadora le ofrece.

Candy le ofreces además, una amplia gama de electrodomésticos: lavadoras, lavavajillas, lavadoras-secadoras, cocinas, microondas, hornos y encimeras, frigoríficos y congeladores.

Solicite a su vendedor el catálogo completo de la gama de productos Candy.

Le rogamos lea atentamente la información contenida en este manual ya que proporciona importantes instrucciones sobre seguridad en su instalación, uso, mantenimiento y algunos consejos prácticos para que ested saque el mejor provecho de su lavadora.

Conserve este manual para cualquier consulta posterior. Cuando se ponga en contacto con Candy o con sus centros de Asistencia mencione siempre el Modelo, el n° y el número G (si lo tiene).

Es decir todo lo que viene anotado en el recuadro.

DE

HERZLICHEN

GLÜCKWUNSCH!

Mit dem Kauf dieses Candy Elektrogerätes haben Sie bewiesen, daß Sie stets nur das Beste wählen - ohne Kompromisse.

Candy freut sich, Ihnen diese neue Waschmaschine anbieten zu können. Sie ist das Ergebnis jahrelanger Forschung und einer Markterfahrung, die im ständigen direkten Kontakt mit dem Verbraucher gereift ist. Sie haben mit diesem Gerät Qualität, lange Lebensdauer und einen hohen Leistungsstandard gewählt.

Candy bietet Ihnen darüber hinaus eine breite Palette weiterer elektrischer Haushaltsgeräte: Waschmaschinen, Geschirrspüler, Wäschetrockner, Elektroherde, Mikrowellenherde, Backöfen und Kochfelder, Kühl - und Gefrierschränke.

Fragen Sie Ihren Fachhändler nach dem kompletten Candy Katalog.

Lesen Sie bitte aufmerksam die Anweisungen, die Sie in diesem Heft finden. Sie finden dort wichtige Hinweise zur sicheren Installation, zur Bedienung, zur Pflege und zur optimalen Verwendung der Waschmaschine.

Bewahren Sie das Heft für eine spätere Nutzung gut auf.

Geben Sie bitte in allen Mitteilungen an Candy oder an Ihre zuständige Kundendienststelle stets das Modell, die Nummer und die G-Nummer (falls vorhanden),- also praktisch alle Angaben des Typenschildes -, an.

EN

OUR COMPLIMENTS

With the purchase of this Candy household appliance, you have shown that you will not accept compromises: you want only the best.

Candy is happy to present their new washing machine, the result of years of research and market experience through direct contact with Consumers.You have chosen the quality, durability and high performance that this washing machine offers.

Candy is also able to offer a vast range of other household appliances: washing machines, dishwashers, washer-dryers, cookers, microwave ovens. Traditional ovens and hobs, refrigerators and freezers.

Ask your local retailer for the complete catalogue of Candy products.

Please read this booklet carefully as it provides important guide lines for safe installation, use and maintenance and some useful advise for best results when using your washing machine.

Keep this booklet in a safe place for further consultation.

When contacting Candy or a Customer Services Centre always refer to the

Model, No., and G number (if applicable of the appliance see panel).

3

FR



IT



CAPITOLO





INDEX



INDICE











CAPÍTULO









KAPITEL









CHAPTER

Avant-propos



Prefazione





Notes générales à la



Note generali alla consegna



1

livraison









Garantie



Garanzia



2

Mesures de sécurité



Prescrizioni di sicurezza



3

Données techniques



Dati tecnici



4

Mise en place, installation



Messa in opera, installazione



5

Description des commandes



Descrizione comandi



6

Tiroir à lessive



Cassetto detersivo



7

Sélection



Selezione



8

Le produit



Il prodotto



9

Tableau des programmes



Tabella programmi



10

Conseils utiles pour



Consigli utili per gli utenti



11

l’utilisateur/Lavage



/Lavaggio





Nettoyage et entretien



Pulizia e manutenzione



12

ordinaire



ordinaria





Recherche des pannes



Ricerca guasti



13











4

ES









ÍNDICE CAPÍTULO

INHALT

INDEX

Introduccíon

Einleitung

Introduction

Notas generales a la

Allgemeine Hinweise zur

General points on delivery

entrega

Lieferung



Garantía

Garantie

Guarantee

Normas de seguridad

Sicherheitsvorschriften

Safety Measures

Datos técnicos

Technische Daten

Technical Data

Puesta en funcionamiento

Inbetriebnahme, Installation

Setting up and Installation

instalación





Descripción de los mandos

Bedienungsanleitung

Control Description

Cubeta del detergente

Waschmittelbehälter

Detergent drawer

Seleción

Programm/Temperaturwahl

Selection

El producto

Das Produkt

The Product

Tabla de programas

Programmtabelle

Table of Programmes

Consejos útiles para el

Einige nützliche

Customer

usuario/Lavado

hinweise/Waschen

Awareness/Washing

Limpieza y mantenimiento

Reinigung und allgemeine

Cleaning and routine

ordinario

Wartung

maintenance

Causas de averías

Fehlersuche

Faults Search







5

FR

CHAPITRE 1

NOTES GENERALES A LA LIVRAISON

A la livraison veuillez, contrôler que le matériel suivant accompagne la machine:

A)LIVRET D’INSTRUCTIONS

B)ADRESSES DE SERVICE APRES VENTE

C)CERTIFICAT DE GARANTIE

D)VIS DE FIXATION DU PANNEAU ARRIERE

E)BOUCHONS

F)COUDES POUR LE TUBE DE VIDANGE

LES CONSERVER

et contrôler que ce matériel soit en bon état; si tel n’est pas le cas appelez le centre Candy le plus proche.

IT

CAPITOLO 1

NOTE GENERALI ALLA CONSEGNA

Alla consegna controlli che con la macchina ci siano:

A)MANUALE D’ISTRUZIONE

B)INDIRIZZI DI ASSISTENZA

C)CERTIFICATI DI GARANZIA

D)VITI FISSAGGIO PANNELLO POSTERIORE

E)TAPPI

F)CURVA PER TUBO SCARICO

CONSERVATELI

e controlli che non abbia subito danni durante il trasporto, in caso contrario chiami il centro Candy più vicino.



EUROPE



Dovunque



tu sia.

A

B

SPEDIRE

TRATTENERE

C

D

E

F

ES

CAPÍTULO 1

NOTAS GENERALES DE ENTREGA

A la entrega compruebe que con la máquina estén:

A)MANUAL DE INSTRUCCIONES

B)DIRECCIONES DE ASISTENCIA TÉCNICA

C)CERTIFICADOS DE GARANTÍA

D)TORNILLOS DE FIJACIÓN DEL PANEL POSTERIOR

E)TAPONES

F)CURVAS PARA EL TUBO DE DESAGÜE

CONSÉRVELOS

y compruebe que no haya sufrido desperfectos durante el transporte, en caso contrario llame al centro Candy más cercano.

DE

KAPITEL 1

ALLGEMEINE

HINWEISE ZUR

LIEFERUNG

Kontrollieren Sie bei Anlieferung des Gerätes, ob das folgende Zubehör mitgeliefert wurde:

A)BEDIENUNGSANLEITUNG

B)VERZEICHNIS DER KUNDENDIENSTSTELLEN

C)GARANTIESCHEIN

D)BEFESTIGUNGSSCHRAUBEN FÜR DIE RÜCKWAND

E)STÖPSEL

F)ROHRBOGEN FÜR ABLAUFSCHLAUCH

BITTE GUT AUFBEWAHREN

Gerät bei Lieferung auf eventuelle Transportschäden untersuchen und gegebenenfalls beim Händler reklamieren.

EN

CHAPTER 1

GENERAL POINTS ON DELIVERY

On delivery, check that the following are included with the machine:

A)INSTRUCTION MANUAL

B)CUSTOMER SERVICE ADDRESSES

C)GUARANTEE CERTIFICATES

D)SCREWS FOR ASSEMBLY OF REAR PANEL

E)CAPS

F)BEND FOR OUTLET TUBE

KEEP THEM IN A SAFE PLACE

Check that the machine has not incurred damage during transport. If this is the case, contact your nearest Candy Centre.

6

7

CHAPITRE 2

GARANTIE

L’appareil est accompagné par un certificat de gàrantie.

Ne pas oublier d’expédier le coupon B du certificat de garantie afin qu’il soit validé dans les 10 jours à dater de l’achat.

Vous devez conserver le coupon A, dûment rempli, qui sera montré au Service d’Assistance Technique en cas d’intervention; conservez également votre facture d’achat.

CAPITOLO 2

GARANZIA

L’apparecchio é corredatoda un certificato di garanzia che Le permette di usufruire gratuitamente del Servizio di Assistenza Tecnica, salvo l’addebito di un diritto fisso di chiamata, per il periodo di un anno dalla data d’acquisto.

SERVIZIO ASSISTENZA TECNICA

199. 123. 123

Ricordi di spedire la parte A del certificato di garanzia, per la necessaria convalida entro10 giorni dalla data di acquisto.

La parte B dovrà essere da Lei conservata, debitamente compilata, per essere esibita al Servizio Assistenza Tecnica, in caso di necessità di intervento, insieme alla ricevuta fiscale rilasciata dal rivenditore al momento dell’acquisto.

8

ES

CAPÍTULO 2

GARANTIA

El aparato va acompañado de un Certificado de Garantía de 1 año.

En los primeros 6 meses, a partir de la fecha de la compra, la garantía le cubre: piezas, recambios, mano de obra y desplazamientos.

En los 6 meses siguientes, la garantía le cubre piezas y recambios.

SERVICIO POST VENTA

902. 100. 150

No olvide remitir la parte B del Certificado de Garantia para la debida convalidación en los 10 días siguientas a la fecha de compra.

La parte A deberá conservarla, debidamente cumplimentada, para presentarla al Servicio Técnico de Asistencia, en caso de necesitar su intervención junto a la factura legal expedida por el vendedor en el momento de combra.

*Rellenar la garantía que viene en Castellano.

DE

KAPITEL 2

GARANTIE

Der beiliegende Garantieschein ermöglicht die kostenlose Inanspruchnahme des technischen Kundendienstes. Die Garantiezeit beträgt ein Jahr ab Kaufdatum. In den ersten 6 Monaten werden alle Reparaturaufwendungen von Candy getragen, die Übernahme der Anfahrtkosten entfällt 6 Monate nach Anlieferung beim Endverbraucher.

IM SERVICEFALL WENDEN SIE SICH BITTE AN UNSEREN AUTORISIERTEN WERKSKUNDENDIENST.

DIE SERVICE-NUMMER FÜR DEUTSCHLAND 01805-625562 VERBINDET SIE AUTOMATISCH MIT DEM ZUSTÄNDIGEN GIASWERKSKUNDENDIENST IN IHRER NÄHE.

Vergessen Sie nicht, Abschnitt B des Garantiescheines innerhalb von 10 Tagen nach dem Kaufdatum einzusenden.

Abschnitt A bitte ausgefüllt zu Ihren Unterlagen heften, und bei Bedarf dem technischen Kundendienst vorlegen, gemeinsam mit der von Ihrem Händler ausgestellten Kaufquittung.

EN

CHAPTER 2

GUARANTEE

The appliance is supplied with a guarantee certificate which allows free use of the Technical Assistance Service, apart from a fixed call out charge, for a period of one year from the date of purchase.

Remember to post part B of the guarantee certificate within 10 days of the purchase date.

Part A should be filled in and kept by you to be shown if necessary to the technician from the Technical Assistance Service. The sales receipt should also be kept.

9

FR

CHAPITRE

MESURES

SECURITE

ATTENTION:

EN CAS D’INTERVENTION DE NETTOYAGE ET D’ENTRETIEN

Débrancher prise de courant.

Fermer le robinet d’alimentation d’eau.

Toutes les machines Candy

sont

mise à la

terre.



Vérifier que l’installation

électrique

alimentée par

une prise de

en cas

contraire demander

l’intervention

personnel

qualifié.



Cet appareil est conforme directives 89/336/EEC, 73/23/EEC et modifications successives.

Ne pas toucher l’appareil pieds nus.

Autant possible éviter l’usage de rallonges dans les

salles de

les

douches.



ATTENTION: PENDANT LAVAGE L’EAU PEUT ATTEINDRE 90°C.

IT

CAPITOLO 3

PRESCRIZIONI DI SICUREZZA

ATTENZIONE:

PER QUALSIASI INTERVENTO DI PULIZIA E MANUTENZIONE DELLA LAVATRICE

Tolga la spina.

Chiuda il rubinetto dell’acqua.

La Candy correda tutte le sue macchine di messa a terra. Si assicuri che l’impianto elettrico sia provvisto di messa a terra in caso contrario richieda l’intervento di personale qualificato.

Apparecchio conforme alle Direttive Europee 89/336/CEE, 73/23/CEE e successive modifiche.

Non tocchi l’apparecchio con mani, piedi bagnati o umidi.

Non usi l’apparecchio a piedi nudi.

Non usi, se non con particolare cautela, prolunghe in locali adibiti a bagno o doccia.

ATTENZIONE: DURANTE IL LAVAGGIO

L’ACQUA PUO’ ANDARE A 90°C.

Avant

le hublot

Prima di aprire l’oblò si

vérifier que

tambour soit

assicuri che non vi sia

sans eau.



acqua nel cestello.

10

ES

CAPÍTULO 3

NORMAS DE

SEGURIDAD

ATENCION: PARA

CUALQUIER TRABAJO DE LIMPIEZA Y MANTENIMIENTO

Desenchúfela.

Cierre el grifo del agua.

Candy provede a todas sus máquinas de toma de tierra.

Asegúrese de que la instalación electrica tenga toma de tierra, en caso contrario llame a un Servicio cualificado.

Estos aparatos cumplen con las Directivas EEC 89/336, EEC 73/23 y modificaciónes siguientes.

No toque el aparato con las manos, los pies mojados o húmedos.

No use el aparato estando descalzo.

No use, si no es con especial cuidado, alargos en cuartos de baño o aseos.

ATENCION:

DURANTE EL LAVADO EL AGUA PUEDE ALCANZAR LOS 90°C.

Antes de abrir el ojo de buey, asegúrese de que no haya agua en el tambor.

DE

KAPITEL 3

SICHERHEITSVORSCHRIFTEN

ZUR BEACHTUNG: BEI REINIGUNG UND WARTUNG GERÄTES

Netzstecker

.

Wasserzufuhr

.

Alle Candy

sind

geerdet.



Versichern Sie

daß Ihr

Stromnetz geerdet ist. Sollte dies nicht der sein, rufen Sie einen Fachmann.

Das Gerät den europäischen

Richtlinien 89/336/ECC, 73/23/ECC nachträglichen Änderungen

Benutzen

Mögkichkeit

Verlängerungskabel in

Feuchträumen

ACHTUNG:

JE NACH WASCHPROGRAMM KANN SICH

WASSER BIS 90° C AUFHEIZEN

Vor dem Öffnen des Bullauges sicherstellen, daß kein Wasser mehr in der Trommel steht.

EN

CHAPTER 3

SAFETY MEASURES

IMPORTANT:

FOR ALL CLEANING

AND MAINTENANCE

WORK

Remove the plug

Turn off the water inlet tap.

All Candy appliances are earthed.

Ensure that the main electricity circuit is earthed. Contact a qualified electrician if this is not the case.

This appliance complies with Directives 89/336/EEC, 73/23/EEC and following changes.

Do not touch the appliance with wet or damp hands or feet.

Do not use the appliance when bare-footed.

Extreme care should be taken if extension leads are used in bathrooms or shower rooms. Avoid this where possible.

WARNING: DURING THE WASHING CYCLE, THE WATER CAN REACH A TEMPERATURE OF 90°C.

Before opening the washing machine door, ensure that there is no water in the drum.

11

FR

Ne pas utiliser d’adaptateurs ou de prises multiples.

Cet appareil ne doit pas être utilisé sans surveillance.

Pour débrancher la prise, ne pas tirer sur le câble.

Ne pas laisser la machine exposée aux agents atmosphériques (pluie, soleil, etc...).

En cas de déménagement ne jamais soulever la machine par les boutons ou par le tiroir des produits lessiviels.

Pendant le transport ne pas appuyer le hublot sur le chariot.

Important!

Les ouvertures à la base de l’appareil ne doivent en aucun cas être obstruées par des tapis, moquette ou autres objets.

2 personnes pour soulever la machine (voir dessin).

En cas de panne et/ou de mauvais fonctionnement éteindre la machine, fermer le robinet d’alimentation d’eau et ne pas toucher à la machine. Pour toute réparation adressez-vous exclusivement à un centre d’assistance technique Candy en demandant des pièces de rechange certifiées constructeur. Le fait de ne pas respecter les indications susmentionnées peut compromettre la sécurité de l’appareil.

Si le remplacement du câble d’alimentation s’avère nécessaire, il devra être remplacé par un câble special fourni par le service après-vente.

12

Non usi adattatori o spine multiple

Non permetta che l’apparecchio sia usato dai bambini o da incapaci, senza sorveglianza.

Non tiri il cavo di alimentazione, o l’apparecchio stesso, per staccare la spina dalla presa di corrente.

Non lasci esposto l’apparecchio ad agenti atmosferici (pioggia, sole, ecc...).

In caso di trasloco non la sollevi mai dalle manopole o dal cassetto del detersivo.

Durante il trasporto non appoggi mai l’oblò al carrello.

Importante!

Nel caso si installi l’apparecchio su un pavimento ricoperto da tappeti o con moquette, si deve fare attenzione che le aperture di ventilazione alla base dell’apparecchio non vengano ostruite.

Sollevarla in due persone come illustrato in figura.

In caso di guasto e/o di cattivo funzionamento dell’apparecchio, lo spenga, chiuda il rubinetto dell’acqua e non manometta l’elettrodomestico. Per l’eventuale riparazione si rivolga solamente a un centro di Assistenza Tecnica Candy e richieda l’utilizzo di ricambi originali.

Il mancato rispetto di quanto sopra può compromettere la sicurezza dell’apparecchio.

Se il cavo di alimentazione risultasse danneggiato, dovrà essere sostituito da un cavo speciale disponibile presso il servizio di Assistenza Tecnica.

ES

No use adaptadores o enchufes múltiples.

No permita la manipulación del aparato a niños o incapacitados, sin vigilancia.

No tire del cable de alimentación, ni del aparato, para desconectar la toma de corriente.

No deje el aparato a la intemperie o expuesto a la acción de los agentes atmosfericos (lluvia, sol, etc..).

En caso de traslado no la sujete nunca por los mandos ni por la cubeta de detergente.

Durante su transporte no apoye el ojo de buey en la carretilla.

Importante!

Si se va a instalar el aparato sobre una alfombra o moqueta, es necesario tener cuidado para evitar que se obstruyan las rejillas de ventilación situadas en la base de la lavadora.

Levántela ayudado por otra persona tal como aparece en la figura.

En caso de avería y/o mal functionamiento del aparato, desconéctelo, cierre el grifo del agua y no manipule el electrodoméstico. Para su eventual reparación diríjase únicamente a un centro de Asistencia Técnica Candy y solicite el uso de recambios originales. El incumplimiento de estas sugerencias puede comprometer la seguridad del aparato.

Si el cable de alimentación resultase dañado, tendrá que ser sustituido por un cable especiäl disponible en el servicio de asistencia técnica.

DE

Gerät nicht an Adapter oder Mehrfachsteckdosen anschließen.

Achten sie darauf, daß Kinder nicht unbeaufsichtigt am Gerät hantieren.

Ziehen Sie den Stecker immer am Stecker selbst aus der Steckdose.

Setzen Sie das Gerät keinen Witterungseinflüssen (Regen, Sonne usw.) aus.

Das Gerät niemals an den Schaltknöpfen oder am Waschmittelbehälter anheben.

Während des Transportes mit einer Sackkarre das Gerät nicht auf das Bullauge lehnen.

Wichtig!

Falls Sie das Gerät auf einen Teppich oder Teppichboden aufstellen, achten Sie darauf, daß die Lufteinlässe am Boden des Gerätes nicht verstopft werden.

Stets, wie auf der Zeichnung dargestellt, zu zweit anheben.

Bei eventuellen Defekten und Fehlfunktionen das Gerät abschalten, die Wasserzufuhr unterbrechen und die Waschmaschine nicht gewaltsam öffnen. Bei anfallenden Reparaturen wenden Sie sich bitte ausschließlich an die Kundendienststelle der Firma Candy und bestehen Sie auf die Verwendung von Originalersatzteilen. Die Nichtbeachtung der o.a. Vorschriften kann zur Beeinträchtigung der Geräte sicherheit führen.

Wenn das Gerät einmal ausgedient hat, entsorgen Sie es bitte ordnungsgemäß über Ihren Fachhändler oder die kommunalen Entsorgungseinrichtungen.

Sollte das Netzkabel beschädigt sein, muß dieses mit dem speziellen Netzkabel ersetzt werden, das vom Gias-Kundendienst zur Verfügung gestellt werden kann.

EN

Do not use adaptors or multiple plugs.

Do not allow the appliance to be used by children or the incompetent without due supervision.

Do not pull the mains lead or the appliance itself to remove the plug from the socket.

Do not leave the appliance exposed to atmospheric agents (rain, sun etc.)

In the case of removal, never lift the appliance by the knobs or detersive drawer.

During transportation

do not lean the door against the trolley.

Important!

When the appliance location is on carpet floors, attention must be paid so as to ensure that there is no obstruction to the bottom vents.

Lift the appliance in pairs as illustrated in the diagram.

In the case of failure and/or incorrect operation, turn the washing machine off, close the water inlet tap and do not tamper with the appliance. Contact a Candy Technical Assistance Centre for any repairs and ask for original Candy spare parts. Avoidance of these norms may compromise the safety of the appliance.

Should the supply cord (mains cable) be demaged, this is to be replaced by a specific cable available from the after sales service centre.

13

FR

IT

CHAPITRE 4

CAPITOLO 4

52 cm

82 cm

60 cm

CAPACITE DE LINGE

CAPACITA’ DI BIANCHERIA

kg

5

SEC

ASCIUTTA













EAU NIVEAU NORMAL

ACQUA

l

19



LIVELLO NORMALE













NIVEAU ECONOMIQUE

ACQUA LIVELLO

l

15

DE L’AU

ECONOMICO













PUISSANCE

POTENZA

W

2200

ABSORBEE

ASSORBITA















CONSOMMATION ENERGIE

CONSUMO DI ENERGIA

kWh

2,0

(PROG. 2)

(PROG. 2)













AMPERAGE

AMPERE DEL

A

10



FUSIBILE DELLA RETE













ESSORAGE (Tours/min.)

GIRI DI

giri/min.

600



CENTRIFUGA













PRESSION DANS

PRESSIONE NELL’IMPIANTO

MPa

min. 0,05

L’INSTALLATION HYDRAULIQUE

IDRAULICO



max. 0,8









TENSION

TENSIONE

V

230









ES

DE

EN

CAPÍTULO 4

KAPITEL 4

CHAPTER 4

CAPACIDAD DE ROPA

FASSUNGSVERMÖGEN

MAXIMUM WASH

SECA

TROCKENWÄSCHE

LOAD DRY







NIVEL NORMAL DE AGUA

WASSERSTAND NORMAL.

NORMAL WATER LEVEL







AGUA NIVEL

ÖKONOMISCHER

ECONIMIC

ECONOMICO

WASSERSTAND

WATER LEVEL







POTENCIA

GESAMTANSCHLUßWERT

POWER INPUT

ABSORBIDA











CONSUMO DE ENERGÍA

ENERGIEVERBRAUCH

ENERGY CONSUMPTION

(PROG. 2)

(PROGR. 2)

(PROG.2)







AMPERIOS DEL FUSIBLE

ABSICHERUNG

POWER CURRENT FUSE

DE LA RED



AMP







REVOLUCIONES DE

SCHLEUDERDREHZAHL

SPIN

CENTRIFUGADO (rpm/min.)

(U/min.)

r.p.m.







PRESIÓN EN EL CIRCUITO

WASSERDRUCK

WATER PRESSURE

HIDRÁULICO











TENSION

SPANNUNG

SUPPLY VOLTAGE







14

15

FR

CHAPITRE 5

MISE EN PLACE INSTALLATION

Placer la machine sur le lieu d’utilisation sans le socle d’emballage.

Couper les colliers serre-tubes

Extraire les 2 vis et enlever le panneau arrière.

Extraire les 4 vis de l’étrier gauche et l’enlever.

Extraire les 4 vis de l’étrier droit et l’enlever.

Extraire les 4 vis de l’étrier inférieur et l’enlever.

Remonter le panneau arrière en encastrant la zone supérieure, visser les 2 vis enlevées et les 4 vis contenues dans l’enveloppe des instructions.

Fermer les 6 trous par les bouchons livrés avec la machine.

ATTENTION:

NE PAS LAISSER À LA PORTÉE DES ENFANTS DES ELEMENTS D’EMBALLAGE QUI PEUVENT CAUSER DES RISQUES.

IT

CAPITOLO 5

MESSA IN OPERA INSTALLAZIONE

Porti la macchina vicino al luogo di utilizzo senza il basamento dell’imballo.

Tagli le fascette fermatubo

Tolga le due viti e rimuova il pannello posteriore.

Tolga le 4 viti della staffa sinistra e la asporti.

Tolga le 4 viti della staffa destra, e l’asporti.

Tolga le 4 viti della staffa inferiore e l’asporti.

Rimonti il pannello posteriore incastrando la zona superiore, avviti le 2 viti tolte e le 4 viti contenute nella busta istruzioni.

Richiuda i 6 fori con i tappi in dotazione.

ATTENZIONE: NON LASCI ALLA

PORTATA DI BAMBINI GLI ELEMENTI DELL’IMBALLAGGIO IN QUANTO POTENZIALI FONTI DI PERICOLO.

ES

CAPÍTULO 5

PUESTA EN FUNCIONAMIENTO INSTALACIÓN

Ponga la máquina cerca del lugar de uso sin la base del embalaje.

Corte las cintas del tubo

Extraiga los 2 tornillos y retire el panel posterior.

Extraiga los 4 tornillos del soporte de fijación izquierdo y quitélo.

Extraiga los 4 tornillos del soporte de fijación derecho y quitélo.

Extraiga los 4 tornillos del soporte de fijación inferior y quitélo.

Vuelva a colocar el panel posterior encajando la parte superior, enrosque los 2 tornillos extraídos más los 4 tornillos contenidos en el sobre de instrucciones.

Cierre los 6 agujeros con los tapones adjuntos.

ATENCIÓN:

NO DEJE AL ALCANCE DE LOS NIÑOS LOS ELEMENTOS DE EMBALAJE YA QUE PUEDEN SER PELIGROSOS.

DE

KAPITEL 5

INBETRIEBNAHME INSTALLATION

Gerät ohne Verpackungsunterteil in die Nähe des Aufstellungsortes bringen.

Lösen Sie die Klammern der Schlauchbefestigung.

Die beiden Schrauben entfernen und Rückwand abnehmen.

Die vier Schrauben des linken Bügels entfernen und Bügel abnehmen.

Die vier Schrauben des rechten Bügels entfernen und Bügel abnehmen.

Die vier Schrauben des unteren Bügels entfernen und Bügel abnehmen.

Die Rückwand wieder montieren, dabei die obere Fläche einrasten lassen, die beiden vorher entfernten sowie die 4 mitgelieferten Schrauben eindrehen.

Die sechs Öffnungen mit den mitgelieferten Stöpseln abdecken.

ACHTUNG:

DIE VERPACKUNG IST IN DEN HÄNDEN VON KINDERN EINE GEFAHRENQUELLE. BITTE ENTSORGEN SIE DAS VERPACKUNGSMATERIAL ORDNUNGSGEMÄß.

EN

CHAPTER 5

SETTING UP

INSTALLATION

Move the machine near its permanent position without the packaging base.

Cut tube-holding straps.

Unscrew the 2 screws and remove the back panel.

Unscrew the 4 screws on the left bracket and remove.

Unscrew the 4 screws on the right bracket and remove.

Unscrew the 4 screws on the lower bracket and remove.

Remount the back panel by slotting the upper edge in place. Screw in the 2 screws removed previously and the 4 screws from the instruction envelope.

Cover the 6 holes with the caps provided.

WARNING:

DO NOT LEAVE THE PACKAGING IN THE REACH OF CHILDREN AS IT IS A POTENTIAL SOURCE OF DANGER.

16

17

CANDY ICL60 User Manual

FR

Appliquer la feuille supplémentaire sur le fond comme dans la figure.

Raccorder le tube de l’eau aux robinets.

L'appareil doit être relié à l'arrivée d'eau exlusivement avec les tuyaux fournis .

Ne pas réutiliser les anciens tuyaux.

ATTENTION:

NE PAS OUVRIR LE

ROBINET

Approcher la machine contre le mur en faisant attention à ce que le tuyau n’ait ni coudes ni étranglements.

Raccorder le tuyau de vidange au rebord de la baignoire ou, mieux encore, à un dispositif fixe d’évacuation, hauteur mini. 50 cm et de diamètre supérieur au tuyau de la machine à laver.

En cas de besoin, utiliser le coude rigide livré avec la machine.

IT

Applichi il foglio di polionda sul fondo come mostrato in figura.

Allacci il tubo dell’acqua al rubinetto.

L’apparecchio deve essere connesso alla rete idrica solo con i nuovi tubi di carico forniti in dotazione. I vecchi tubi di carico non devono essere riutilizzati.

ATTENZIONE:

NON APRA

IL RUBINETTO

Accosti la lavatrice al muro facendo attenzione che non vi siano curve o strozzature, allacci il tubo di scarico al bordo della vasca.

o meglio a uno scarico fisso; altezza minima 50 cm, di diametro superiore al tubo della lavatrice.

In caso di necessità utilizzare la curva rigida in dotazione.



min 4 cm

100 cm

+2,6 mt max

min 50 cm

max

max 85 cm

ES

Aplique la lamina de polionda como se muestra en la figura.

Conecte el tubo del agua al grifo.

El aparato debe ser conectado a la red hidraulica sólo con los nuevos tubos de carga disponibles en dotación. Los viejos tubos de carga no tienen que ser reutilizados.

ATENCIÓN:

NO ABRA EL GRIFO.

Acerque la lavadora a la pared procurando que no se formen curvas o estrangulamientos, fije el tubo desagüe al borde de la pila.

o mejor aún, a un desagüe fijo, con un diámetro mayor que el del tubo de la lavadora, a una altura mínima de 50 cm.

En caso necesario, utilice la curva rígida adjunta.

DE

Befestigen Sie die gewellte Bodenplatte wie in der Abbildung dargestellt.

Den Zulaufschlauch an den Wasserhahn anschließen.

Das Gerät muß an die Wasserversorgung mit neuen Schläuchen angeschlossen werden.

Alte Schläuche dürfen nicht wiederverwendet werden.

ACHTUNG: WASSERHAHN NOCH NICHT ÖFFNEN.

Die Waschmaschine an die Wand rücken, darauf achten, daß dabei der Schlauch nicht verkrümmt oder eingeengt wird.

Ablaufschlauch am Wannenrand

befestigen, oder an einem festen Abfluß von mindestens 50 cm Höhe anbringen, dessen Durchmesser größer ist als der des Waschmaschinenschlauchs. Falls erforderlich den mitgelieferten starren Rohrbogen benutzen.

EN

Fix the sheet of corrugated material on the bottom as shown in picture.

Connect the fill hose to the tap.

The appliance must be connected to the water mains using new hose-sets. The old hose-sets should not be reused.

IMPORTANT:

DO NOT TURN THE TAP ON AT THIS TIME.

Position the washing machine next to the wall. Hook the outlet tube to the edge of the bath tub, paying attention that there are no bends or contractions along the tube.

It is better to connect the discharge hose to a fixed outlet of a diameter greater than that of the outlet tube and at a height of min. 50 cm. If is necessary to use the plastic sleeve supplied.



min 4 cm

100 cm

+2,6 mt max

min 50 cm

max

max 85 cm

18

19

Loading...
+ 23 hidden pages
