8796 Baby Monitor 100 UG [Vtech 2] 27/5/08 13:02 Page 1
BT Baby Monitor 100 VTECH – Issue 2 – 27.05.08 – 8796
BT Baby Monitor 100
User Guide
8796 Baby Monitor 100 UG [Vtech 2] 27/5/08 13:02 Page 2
BT Baby Monitor 100 VTECH – Issue 2 – 27.05.08 – 8796
Section
Welcome…
to your BT Baby Monitor 100
•Wireless range of up to 300m outdoors and up to 50m indoors (in ideal conditions) - giving you the freedom to move around with clear reception and no interference from other baby monitors.
•Out of range warning.
•Link light provides continuous confidence that the Parent unit is receiving a signal from the Baby unit and will alert
you if the link is lost.
•3 lullabies.
•Talk Back feature lets you instantly reassure and calm your baby.
•Adjustable nightlight brightness on Baby unit.
•Mains or battery operation.
•Rechargeable batteries in Parent unit.
8796 Baby Monitor 100 UG [Vtech 2] 27/5/08 13:02 Page 3
BT Baby Monitor 100 VTECH – Issue 2 – 27.05.08 – 8796
This User Guide provides you with all the information you need to get the most from your BT Baby Monitor 100.
Please read this guide carefully and keep it for future reference.
Need help?
If you have any problems setting up or using your BT Baby Monitor 100 (or would like additional or replacement batteries), call the BT Baby Monitor Helpline 0808 100 6554*.
Alternatively, you may also find the answer in ‘Help’ at the back of this guide.
Section
Got everything?
•Baby unit
•Parent unit
•2 x AA rechargeable batteries for Parent unit
•Parent unit charger
•2 x mains power adapters (item code 045327)
•Travel bag
•Wall mounting bracket for the Baby unit
*Calls made from within the UK mainland network are free. Mobile and international call costs may vary.
8796 Baby Monitor 100 UG [Vtech 2] 27/5/08 13:02 Page 4
BT Baby Monitor 100 VTECH – Issue 2 – 27.05.08 – 8796
4 |
|
In this guide |
|
|
|
|
|
|
|
|
|
|
|
Setting up |
|
General information |
|
|
|
Parent unit . . . . . . . . . . . . . . . . . . . . . . . . . . . |
5 |
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
20 |
|
|
Baby unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
6 |
Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
20 |
|
|
Check the connection . . . . . . . . . . . . . . . . . . |
7 |
Product disposal instructions . . . . . . . . . . . . |
20 |
|
|
|
|
R&TTE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
21 |
|
|
Getting to know your Baby Monitor |
|
Declaration of Conformance . . . . . . . . . . . . . |
21 |
|
|
Parent unit . . . . . . . . . . . . . . . . . . . . . . . . . . . |
8 |
|
|
|
|
Parent unit charger . . . . . . . . . . . . . . . . . . . . |
9 |
|
|
|
|
Baby unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
10 |
|
|
Using the Baby unit
Switching on/off . . . . . . . . . . . . . . . . . . . . . . 12 Changing Baby unit from
battery to mains power . . . . . . . . . . . . . . . . . 12 Adjust speaker volume. . . . . . . . . . . . . . . . . . 13 Talk Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Adjust Talk Back volume . . . . . . . . . . . . . . . . 13 Paging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Nightlight . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Sound level visual indicator. . . . . . . . . . . . . . 16 Alert tone when the loudspeaker is off . . . . 16 Lullaby . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
If you experience any problems, please call the Helpline on 0808 100 6554*
8796 Baby Monitor 100 UG [Vtech 2] 27/5/08 13:02 Page 5
BT Baby Monitor 100 VTECH – Issue 2 – 27.05.08 – 8796
Setting up |
5 |
Parent unit
1.Plug the mains power cable into the socket marked on the back of the Parent unit charger.
Connect the other end to the mains power and switch on.
2.Remove the battery compartment cover and insert the 2 x AA rechargeable batteries into the battery compartment on the Parent unit and replace the battery compartment cover as shown. You should always ensure you have inserted batteries in the Parent unit.
3.Slot the Parent unit into the charger, the red charging light comes on. Charge the batteries for 16 hours before switching on the Parent unit.
IMPORTANT
Your BT Baby Monitor 100 is designed to be an aid and should not be used as a substitute for responsible and proper adult supervision.
Make sure the Baby unit, Parent unit and mains adapter cable are kept out of reach of your baby – at least one metre away.
Never place the Baby unit inside your baby’s cot, bed or playpen.
Never cover your Parent or Baby units (e.g. with clothes, towels or blankets).
Never use or place your Parent or Baby units in moist places or near water.
If travelling abroad, make sure that the voltage shown on the mains power adapter corresponds to the local mains power before connecting to the power supply.
There is a risk of explosion if the batteries are replaced by an incorrect type. Dispose of used batteries according to the instructions.
Always dispose of batteries in accordance with applicable waste disposal regulations, never in your household rubbish.
Battery performance - Parent unit
Rechargeable batteries in the Parent unit give up to 14 hours continuous performance.
Please note however, that new batteries do not reach full capacity until they have been in normal use for several days.
If you experience any problems, please call the Helpline on 0808 100 6554*
8796 Baby Monitor 100 UG [Vtech 2] 27/5/08 13:02 Page 6
BT Baby Monitor 100 VTECH – Issue 2 – 27.05.08 – 8796
6 Setting up
Running rechargeable batteries right down at least once a week will help them last as long as possible. The charge capacity of rechargeable batteries will reduce with time as they wear out, so reducing the performance time of the Parent unit. Eventually they will need to be replaced. New batteries can be obtained from the BT Baby Monitor Helpline 0808 100 6554*.
The Parent unit rechargeable batteries will lose charge over a period of time, even if switched off.
Baby unit
Once your Parent unit has been fully charged:
1.Plug the power cable into the socket marked on the back of the Baby unit.
Connect the other end to the mains power and switch on.
Using batteries
Battery low warning – Parent unit |
Your Baby unit also works on battery power, so that you can |
||||||||||||||
When the batteries are low – |
|||||||||||||||
approximately within 1 hour and 30 |
use it even when you are not near to a mains power socket or |
||||||||||||||
minutes of running out – the Parent |
|||||||||||||||
unit |
|
light will come on. |
during a power cut. |
||||||||||||
If the batteries are completely flat the |
|||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
||||
Parent unit will switch off. |
1. Using your finger or a coin, turn the battery lock on the back |
||||||||||||||
WARNING |
of the Baby unit anticlockwise so the groove is vertical then |
||||||||||||||
The re-chargeable battery icon in the |
lift off the cover. |
||||||||||||||
battery compartment means that only |
|||||||||||||||
re-chargeable batteries can be used. |
2. Insert 4 x AA alkaline batteries (not supplied) as shown. |
||||||||||||||
Never use non-rechargeable batteries |
|||||||||||||||
in your Parent unit. Use only the |
|
|
|
|
|
|
|
|
|
|
|
|
|||
recommended type – 2 x AA |
|
|
|
|
|
|
|
|
|
|
|
|
|||
rechargeable (1300mAh NiMH) |
|
|
|
|
|
|
|
|
|
|
|
|
|||
batteries – using other types could |
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
||||
permanently damage your unit. |
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
||||
Charge the batteries in accordance with |
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
||||
the instructions given in this user guide. |
|
|
|
|
|
|
|
|
|
|
|
|
|||
The Parent unit can still be used when |
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
||||
it is in the charger. |
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
||||
Temperature range |
|
|
|
|
|
|
|
|
|
|
|
Battery lock |
|||
|
|
|
|
|
|
|
|
|
|
|
|||||
The features on your BT Baby Monitor |
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
Child tamper proof lock for |
||||
100 have been designed to work |
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|||||||
normally at any temperature between |
|
|
|
|
|
|
|
|
|
|
|
the battery compartment. |
|||
0oC and 40oC. |
|
|
|
|
|
|
|
|
|
|
|
|
If you experience any problems, please call the Helpline on 0808 100 6554*
8796 Baby Monitor 100 UG [Vtech 2] 27/5/08 13:02 Page 7
BT Baby Monitor 100 VTECH – Issue 2 – 27.05.08 – 8796
|
Setting up |
7 |
||
|
|
|
|
|
3. Replace the battery cover, turning the battery lock into the |
WARNING! |
|
||
vertical position again to lock it. |
Use only the mains power adapter |
|
||
|
supplied. Using an incorrect adapter |
|
||
|
may permanently damage your BT |
|
||
Check the connection |
Baby Monitor 100. |
|
||
The Baby unit will only work from the |
|
|||
When both Units are switched on, the green link lights on both |
batteries if the mains power is off or |
|
||
disconnected. |
|
|||
Units will come on. |
Battery performance – Baby unit |
|
||
|
|
|||
If the link between the Units is broken at any time, the link |
The recommended batteries are 4 x AA |
|
||
alkaline. Not included. |
|
|||
lights will turn red and flash slowly. |
|
|||
With new batteries, your Baby unit will |
|
|||
|
|
|||
At the Parent unit, you will also hear an alert signal (3 beeps |
give up to 14 hours continuous |
|
||
performance with the night lights |
|
|||
every 30 seconds) to warn you that there is no communication |
|
|||
switched off. This will be less if the |
|
|||
between the Units. If this happens, check that the mains |
lights are switched on. |
|
||
power is plugged in and switched on at the Baby Unit. |
When the Baby unit is not being used |
|
||
Also check that the units are within range of one another. |
and is disconnected from the mains |
|
||
power, you should ensure you remove |
|
|||
|
the batteries. This will prevent the |
|
||
During continual use the Baby unit and Parent unit charger |
batteries discharging. |
|
||
power adapters may become warm to the touch. This is |
Battery low warning – Baby unit |
|
||
normal and not something to be concerned about. |
|
|||
When the batteries are low – |
|
|||
In the event of power failure, when the power is restored all |
approximately within 30 minutes of |
|
||
running out – the Baby unit light |
|
|||
your settings will remain unchanged. |
will come on. However, this |
|
|
|
|
will depend on the type of |
|
||
|
batteries used. |
|
If you experience any problems, please call the Helpline on 0808 100 6554*
8796 Baby Monitor 100 UG [Vtech 2] 27/5/08 13:02 Page 8
BT Baby Monitor 100 VTECH – Issue 2 – 27.05.08 – 8796
8 Getting to know your Baby Monitor
Parent unit
From the Parent unit you can listen to your baby and operate the Baby unit by remote control.
Talk (on side of unit) |
LED Link indicator |
|
Press to talk to your baby. |
Green On |
– Linked to Baby unit |
Lullaby LEDs |
Green flashing |
– Not linked to Baby unit |
|
– first 30 seconds |
|
Green on – When the selected |
|
|
|
|
|
lullably is being played. |
Red Flashing |
– Not linked to Baby unit |
|
|
– for longer than 30 seconds. |
Up |
|
|
Increase speaker volume. |
Sensitivity / Volume level LEDs |
|
Increase sensitivity when reviewing |
During use, lights indicate: |
|
the setting. |
– Sensitivity level |
|
Change lullaby when playing. |
– Volume level |
|
|
|
|
|
Battery status LED |
|
Mute LED |
– Red flashing when batteries are low. |
|
Green on – When speaker is muted. |
|
|
|
Lullaby |
|
Mute |
Press to start playing a lullaby, |
|
Press to switch the speaker off, press |
press again to stop. |
|
again to switch it back on. |
|
|
|
Power on/off |
|
Sensitivity |
Press and hold to switch the power |
|
Press to review the sensitivity setting. |
on or off. |
|
Down/Default |
Microphone |
|
Decrease speaker volume. |
|
|
Decrease sensitivity when reviewing the setting.
Change lullaby when playing. Use to restore original settings.
