Installation and User’s

Guide

RIM 857 Wireless

HandheldTM

Installation and User’s Guide

Last revised 07/10/00

Part Number: MAT-03077-001 Rev. 001

At the time of printing, documentation complies with versions: Operating System 2.0, Applications 2.0, and Desktop 2.0.

© 1999-2000 Research In Motion Limited. All rights reserved. RIM, the RIM logo, Research In Motion, RIM 857 Wireless Handheld, and ‘Always On, Always Connected’ are trademarks of Research In Motion Limited. RIM, Research In Motion - Registered U.S. Patent and Trademark Office. © Puma Technology, Inc. Puma Technology, the Puma Technology logo, DSX Technology, the DSX Technology logo, Intellisync, the Intellisync logo and Intellisync Ready logo are trademarks of Puma Technology, Inc. that may be registered in some jurisdictions. DataTAC is a trademark of Motorola Inc., that may be registered in some jurisdictions. Windows 95/98/2000, Exchange and Outlook are either trademarks or registered trademarks of Microsoft Corporation. All other brands, product names, company names, trademarks and service marks used herein are the property of their respective owners.

Warning: This document is for the use of licensed users only. Any unauthorized copying, distribution or disclosure of information is a violation of copyright laws.

While every effort has been made to ensure technical accuracy, information in this document is subject to change without notice and does not represent a commitment on the part of Research In Motion Limited.

For more information on BlackBerry, call 1-877-BLK-BERRY.

Research In Motion Limited

295 Phillip Street,

Waterloo, Ontario, Canada N2L 3W8

Tel. (519) 888-7465 Fax (519) 888-6906 www.rim.net

Printed In Canada KMOct2000/857.book

FCC compliance statement (USA)

FCC Class B Part 15

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

This device may not cause harmful interference, and

This device must accept any interference received, including interference that may cause undesired operation.

WARNING Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instructions, may cause interference harmful to radio communications.

There is no guarantee, however, that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Industry Canada Certification

This device complies with Industry Canada RSS 119, under certification number 2503 195 677A.

IC Class B compliance

This device complies with the Class B limits for radio noise emissions as set out in the interference-causing equipment standard entitled “Digital Apparatus,” ICES-003 of Industry Canada.

Contents



FCC compliance statement (USA) ..........................................

3

Industry Canada Certification ................................................

4

IMPORTANT SAFETY INFORMATION...................................

9

IMPORTANT UL SAFETY INSTRUCTIONS.....................

11

Welcome to your wireless solution ............................................

13

New for version 2.0.................................................................

14

Upgrading to version 2.0 .......................................................

14

Contents of your package ......................................................

15

System Requirements .............................................................

15

About this guide......................................................................

16

About Research In Motion.....................................................

16

Customer support ...................................................................

17

Get to know your handheld.........................................................

19

Handheld components...........................................................

19

Turning on your handheld ....................................................

22

Turning off the handheld.......................................................

23

Description of keys .................................................................

23

Setting the date and time .......................................................

37

Setting message notification..................................................

37

Using password protection ...................................................

38

Summary and tips...................................................................

44

Start sending email........................................................................

45

Turning the radio on and off.................................................

45

Registering with the network................................................

46

Installing the Desktop Software............................................

48

Connect the handheld to your PC ........................................

48

Sending a message..................................................................

50

Reading a message..................................................................

52

Summary ..................................................................................

54

Using the Desktop Software........................................................

55

Installation and setup .............................................................

55

Loading handheld applications ............................................

56

Backing up files from handheld to the PC ..........................

57

Synchronizing PIM .................................................................

59

Summary ..................................................................................

60

Composing and sending messages.............................................

61

Setting message options.........................................................

61

Setting level of importance ....................................................

62

Choosing a send method .......................................................

63

Sending one-time messages...................................................

64

Sending messages to many contacts ....................................

65

Attaching Address Book entries ...........................................

66

Using AutoText .......................................................................

67

Automatic formatting.............................................................

73

Inserting symbols....................................................................

75

Summary and tips...................................................................

76

Receiving and reading messages ................................................

79

Received message options .....................................................

79

Receiving long messages .......................................................

81

Sending file attachments........................................................

82

Managing Address Book attachments .................................

83

Adding contacts to Address Book ........................................

85

Summary and tips...................................................................

86

Managing messages.......................................................................

89

Saving messages......................................................................

89

Searching messages ................................................................

93

Deleting messages...................................................................

99

Editing messages...................................................................

102

Resending a message............................................................

103

Marking a message as unread.............................................

104

Marking all messages read ..................................................

105

Summary and tips.................................................................

106

Using the Address Book .............................................................

109

Setting Address Book options.............................................

109

Adding addresses .................................................................

110

Viewing addresses ................................................................

114

Editing addresses ..................................................................

115

Deleting addresses ................................................................

116

Searching addresses..............................................................

116

Summary and tips.................................................................

117

Managing Tasks and Appointments........................................

119

Using the Tasks function .....................................................

119

Using the Calendar function ...............................................

124

Summary and tips.................................................................

137

Using the MemoPad and Calculator ........................................

139

Using the MemoPad function .............................................

139

Using the Calculator function .............................................

142

Summary and tips.................................................................

146

Customizing your handheld’s options ....................................

149

Setting the alarm ...................................................................

149

Customizing handheld options ..........................................

151

Handheld options .................................................................

152

Summary ................................................................................

160

Frequently asked questions .......................................................

161

Alarm ......................................................................................

161

Battery.....................................................................................

161

Storage ....................................................................................

162

Home screen ..........................................................................

163

LCD screen.............................................................................

163

Messages.................................................................................

164

Punctuation............................................................................

166

Desktop Software..................................................................

166

Resetting the handheld ........................................................

166

Specifications................................................................................

169

Research In Motion Limited Software License Agreement.171

Terms and Conditions..........................................................

171

Limited Warranty.........................................................................

175

Index ...............................................................................................

179

IMPORTANT SAFETY

INFORMATION

Please read these safety instructions and the operation instructions provided in this manual before operating the RIM 857 Wireless Handheld or its charging cradle. Retain these instructions for future use.

Remember to follow any special regulations governing the use of the RIM 857 Wireless Handheld and always switch it off in areas where radio devices are forbidden, or when it may cause interference or danger. Any safety laws and regulations pertaining to the use of cell phones and two-way radios will likely apply to your use of the handheld. We encourage you to follow such laws and regulations at all times. In particular, please observe all restrictions on the use of radio equipment in fuel depots (fuel storage and distribution areas), chemical plants, where blasting operations are in progress or in any other area in which restrictions on radio transmissions are imposed. In addition, the RIM 857 Wireless Handheld should not be used in locations that may be hazardous including, without limitation, locations in which hazardous or combustible gases may be present.

The RIM 857 Wireless Handheld is not an FAA-approved electronic device for use on aircraft. Switch off the handheld when in an aircraft. The effect of the use of the handheld in an aircraft is unknown. Such use may affect aircraft instrumentation, communication and performance, may disrupt the network, and may be illegal.

Operation of any radio transmitting equipment, including the handheld, may interfere with the functionality of inadequately protected medical devices, including pacemakers. Consult a physician or the manufacturer of the medical device if you have any

questions. Additionally, while most modern equipment is adequately shielded from radio signals such that your handheld will not interfere with the operation of such equipment, certain electronic equipment, including automotive systems, may not be shielded against the radio signals from your handheld. You should check with the manufacturer of your motor vehicle or the manufacturer’s representative to determine whether the use of the handheld will present any safety issues.

Avoid using the handheld in any environment requiring your full attention, such as when driving a vehicle. If you need to use your handheld while driving, have a passenger in the vehicle use the handheld for you, or find a safe location to halt your vehicle prior to using the handheld. Do not use the charging cradle as a means of storing your handheld while in a vehicle.

WARNING Do not use any cradle, charging unit, or any other accessory or attachment that is not manufactured or supplied by RIM or an authorized RIM accessories supplier. Use of any accessory or attachment that is not supplied or approved for use by RIM in conjunction with the handheld is not permitted as it may cause hazards.

Do not place the RIM 857 Wireless Handheld or its charging cradle on any unstable surface, such as a cart, stand, tripod, bracket, or table. It may fall, causing serious injury to a child or adult, and serious damage to the handheld.

Discard the handheld properly. As the unit contains a lithium battery, neither the handheld nor the lithium battery should be disposed of in fire. Dispose of the handheld containing the lithium battery in accordance with the laws and regulations in your area governing disposal of such cell types. Contact RIM if you have any questions concerning disposal of the handheld or the lithium cell.

The handheld should be operated only from the type of power source indicated on the marking label. Refer to the operating

instructions starting on page 21 for more information on the battery and power supply. Do not overload wall outlets, extension cords, or integral convenience receptacles as this may result in a risk of fire or electric shock.

Never push objects of any kind into the RIM 857 Wireless Handheld through openings as they may short-out parts and this may result in a fire or electric shock. Never spill liquid of any kind on the handheld or its charging cradle. Unplug the charging cradle from the wall before cleaning. Do not use liquid or aerosol cleaners.

IMPORTANT UL SAFETY

INSTRUCTIONS

Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions.

Do not use this apparatus near water. Clean only with a dry cloth.

Do not install near any heat sources, such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

Only use attachments/accessories specified by the manufacturer.

Unplug this apparatus during lightning storms or when used for long periods of time.

Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as when the power-supply cord or plug has been damaged, liquid has been spilled or objects have fallen into the apparatus, it has been exposed to rain or moisture, does not operate normally, or has been dropped.

WARNING To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.

Adjust only those controls that are covered in this manual. An improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the handheld or charging cradle to its normal operation.

Failure to observe all safety instructions contained in this manual will void the Limited Warranty, and may lead to suspension or denial of services to the offender, or legal action, or both.

Welcome to your wireless solution

The RIM 857 Wireless Handheld is a powerful computer with a fullfeatured Address Book, Appointment Calendar, MemoPad, and Task List. Unlike other PIM products, the RIM 857 Wireless Handheld includes an integrated wireless modem. Your package will also include the RIM 857 Wireless Handheld Charging Cradle and the Desktop Software, which allows you to synchronize with popular desktop personal information management (PIM) software.

Get ready to experience the power of messaging with your handheld using functions such as:

Messages: Receive, read, reply to, compose, forward, save, file, and delete messages.

Compose: Create and send messages to Internet email addresses.

Saved Messages: Store messages for future viewing.

Search Messages: Locate messages in seconds with the powerful search tool.

Address Book: Store your personal directory of contact information, such as multiple phone and fax numbers, and email addresses. Enter notes for individual contacts and search the database to find specific contacts.

Calendar: Keep track of appointments using one of the four calendar views: Day, Week, Month, or Agenda.

Tasks: Add, edit, and delete tasks and mark tasks as complete.

Alarm: Set the alarm on the handheld to sound daily.

MemoPad: Compose, edit, and delete notes, memos and lists.

14Welcome to your wireless solution — New for version 2.0

Calculator: Perform basic mathematical operations and conversions.

Options: Customize the way the handheld notifies you of new messages; set the password; add, edit, and delete AutoText entries; set the current date; program the automatic on/off feature.

Lock: Lock the handheld with a password security screen so that only you can use it. (This function is only visible in the Home screen after you have set a password.)

Turn Wireless Off / Turn Wireless On: Turn the handheld’s radio off when it may interfere with other radio communications, such as during a flight. Turn on the radio again to send and receive messages.

Power Off: Turn off the handheld at night or on weekends.

New for version 2.0

The handheld (pre-installed with version 2.0 software) has an updated Search Messages function, which lets you create and save pre-defined searches on the handheld. You can use these searches in the Messages, Saved Messages, or Search Messages screens to find messages sent to a particular address or containing specific text. (See page 93 for more information.) The expanded Calendar function now supports recurring calendar appointments and offers you one of four views: Day, Week, Month, or Agenda.

For a complete list of new features for version 2.0 of the software, refer to the README.txt file, found on your installation CD-ROM.

Upgrading to version 2.0

If you are currently using a previous version of the Desktop Software, you should upgrade to version 2.0. Before installing the new software on your desktop and your handheld, you should

Installation and User’s Guide

Welcome to your wireless solution — Contents of your package 15

perform a backup to store the contents of your handheld (such as Address Book entries, messages, and calendar items) on your PC. See Chapter 3 or the Backup and Restore online help for instructions on performing a backup.

Once you have backed up your handheld information to your PC, follow the instructions on page 48 to install.

Contents of your package

Your package should contain the following:

Handheld

Charging Cradle

Holster

This Installation and User’s Guide

Handheld Getting Started Card

Installation CD-ROM

If something from this package is missing or not working properly, contact the point of purchase.

System Requirements

The following components are required to install the Desktop Software:

Intel-compatible 486 or higher desktop with an available serial port

Windows 95/98/2000 with 8 Mb of RAM

Installation and User’s Guide

16 Welcome to your wireless solution — About this guide

About this guide

This guide provides information for operating the handheld and for installing the Desktop Software.

Note Notes will appear in this format and will contain additional information to help you perform the task being described.

Tip Tips provide information about performing tasks and offer different options to perform tasks.

A summary, including a list of relevant tips, is included at the end of each chapter.

The ‘Frequently asked questions’ chapter will help you further with your handheld. As well, the Desktop Software offers online help to guide you and answer your questions. To open the online help, select Help from any active window.

About Research In Motion

RIM is a world leader in the mobile communications market. Our current product portfolio includes mobile email solutions, wireless handhelds, and wireless modems.

RIM has a history of developing breakthrough wireless data solutions. Our products are based on industry-leading technologies, providing superior radio coverage, small size, high performance and long battery life. They offer the freedom of mobility and the ability to stay in touch with people and information. And as people discover new uses for wireless data technology, RIM will continue to address their needs and help them discover new frontiers in wireless data.

Installation and User’s Guide

Welcome to your wireless solution — Customer support 17

Customer support

For customer support, contact your service provider.

Installation and User’s Guide

1

Get to know your handheld

This chapter will help you get acquainted with your handheld before you start sending and receiving email.

Handheld components

Figure 1: Front view of handheld

Here are some details on the handheld’s main components:

LCD screen

The LCD screen is your interface with functions such as composing and reading messages, setting tasks and appointments, viewing and editing contact information, customizing device options, and

20Get to know your handheld — Handheld components

performing basic mathematical calculations. The Home screen displays the current signal strength and battery level of the handheld.

In low light conditions, you can increase the readability of the LCD by using the backlighting feature. To activate backlighting, press the silver key once. The backlight will shut off automatically if you do not press any keys or use the trackwheel for more than 20 seconds. (You can manually turn off the backlighting by pressing the silver key again.)

Keyboard and trackwheel

The 33-key QWERTY keyboard provides access to all of the regular alphabetic characters; numeric characters, a symbols library, punctuation, and special characters can be generated using the orange ALT key in combination with the other keys. For easy typing, hold the device in both hands and use your thumbs. Roll and click the trackwheel for navigation and selection.

A trackwheel that clicks!

The trackwheel on the handheld has a unique feature for greater usability and performance: it clicks! Pressing down on the trackwheel with your thumb is comparable to the clicking function of your PC mouse. Click to open menus and to select functions and menu options.

Holster (belt clip)

A holster, equipped with a belt clip, accompanies the handheld. While in the holster, the handheld is protected and wearable. You can choose different forms of message notification based on whether the handheld is in or out of the holster.

When you receive a new message and remove the handheld from the holster within five seconds, notification (based on how you’ve set it) stops and the most recently received message will be open. If

Installation and User’s Guide

Get to know your handheld — Handheld components 21

you pull the handheld out of the holster and quickly replace it, notification stops but the message will remain marked unread. See “Setting message notification” on page 37 for information on notification options.

Serial port

The serial port on the bottom of the handheld fits into the prongs of the docking cradle. You must connect the docking cradle to your PC to use the Desktop Software (provided on the CD with your package).

The Desktop Software supports standard USB-to-serial port converters. See Chapter 3, “Using the Desktop Software”, for more information on installation procedures and serial connection details.

Docking cradle

The docking cradle provides a link between the handheld and your PC, so that you may use the Desktop Software provided with your package. See Chapter 3, “Using the Desktop Software” for more information on the cradle and the capabilities of the Desktop Software.

Charger

The handheld is designed to operate for one week or more on a full charge; exact battery life, however, will depend on factors such as usage and quality of coverage. The handheld contains an internal lithium cell. The docking cradle (see description above) is also used to recharge this cell.

To charge the handheld, connect the AC adapter to the cradle's serial port connector, plug into a wall outlet, and insert the handheld into the cradle. The Desktop Software does not need to be running for charging to occur, nor does the cradle need to be connected to your PC. When the handheld is charging, the battery

Installation and User’s Guide

22Get to know your handheld — Turning on your handheld

icon will change to a charging icon. Once the handheld is fully charged, the battery icon will replace the charging icon. See page 33 for a list of handheld status icons.

The handheld can be kept at a full charge by “topping up” the battery every day for 10-15 minutes. From an empty battery, a full charge can be achieved in approximately 3 hours. It is not necessary to drain the battery completely before recharging.

If the battery level becomes too low, the signal strength bars (located in the top right corner of the Home screen, next to the battery icon) will be replaced by “BAT”. This is an indication that it is time to recharge the handheld. In this state, all radio functions, such as sending and receiving email, will be disabled until the battery is recharged.

Turning on your handheld

When you receive your handheld, you must first insert it into the charging cradle and allow it to charge to full battery power. (You can view the strength of the battery in the top right corner of the Home screen.) See page 48 for more information on connecting your handheld to your PC.

1.Press the silver key to turn on the handheld. From the Home screen you can select any of the handheld’s main functions.

2.Using the trackwheel, scroll through the icons to view the functions. The name of each function appears at the bottom of the screen.

Installation and User’s Guide

Get to know your handheld — Turning off the handheld 23

3.To select a function, scroll to the appropriate icon and click the trackwheel to open that function’s screen.

Tip You can also select a function by pressing the underlined character in the function’s name. For example, press M for Messages.

Turning off the handheld

There are two methods of turning off the handheld:

Press and hold the silver key until the handheld turns off.

In the Home screen, scroll to the POWER OFF icon and click.

Description of keys

The following chart describes special keyboard and trackwheel combinations that will help you navigate, compose messages, and configure options on the handheld.

Key

Function







Power On/Off, Backlight

SILVER KEY

• Press the silver key once to turn on the

handheld.



• When the handheld is on, press the silver



key once to activate backlighting. Press



again to turn off backlighting. (Backlighting



will turn off automatically if you do not



press any keys for 20 seconds.)



• Press and hold the silver key to turn off the



handheld.

Installation and User’s Guide

24 Get to know your handheld — Description of keys

Key

Function







Scrolling and selecting



• Roll the trackwheel with your thumb to



scroll up and down through screen lines,

TRACKWHEEL

fields, and menu items.



• Click (press down) the trackwheel with your



thumb to open menus and select options,



similar to the click function of a mouse used



with your PC.







Scroll through accented characters



• When composing a message or entering text,



press and hold a letter key while rolling the



trackwheel to scroll through international



characters/characters with accents. When



the desired character appears, release the



letter key.







ALT characters

ALT key

The orange ALT key activates the numeric and

symbol characters, printed in orange above the



alphabetic keys.



• Press the ALT key once to affect the next



character you type.



• Press and hold the ALT key while you type to



affect all characters.



An ‘A’ icon appears in the top right corner of



your screen when the ALT key is active.





Installation and User’s Guide





Get to know your handheld —

Description of keys 25











Key



Function













Horizontal scroll and changing options



Hold the ALT key while you roll the





trackwheel to move the cursor horizontally





across screen lines (except in the Home





screen where ALT + ROLL will move the





cursor vertically).







• Hold the ALT key while

you roll the





trackwheel to scroll through field options.











Capitalize alpha characters







• Press the SHIFT key once to capitalize the

SHIFT key

next character that you type.







• Press and hold the SHIFT key while you type





so that all letters are capitalized.



• Press and hold the letter to capitalize it. This





feature only works when Key Rate is set to





Slow or Fast in the Screen/Keyboard screen.

An ‘up arrow’ icon appears in the top right corner of your screen when the SHIFT key is activated.

CAPs lock

• Press ALT + CAP (RIGHT SHIFT) to activate caps lock mode. Any key that you press will be typed in upper case. Press SHIFT again to return to lower case mode.

Installation and User’s Guide

26 Get to know your handheld — Description of keys

Key

Function







NUM lock



• Press ALT + NUM (LEFT SHIFT) to activate num



lock mode. Any key that you press in the



upper row will be typed in its numeric form.



Press SHIFT again to return to regular mode.







Select multiple messages



• Hold the SHIFT key while rolling the



trackwheel in the Messages screen to select



more than one message. You can file, delete,



or save these messages, or mark them read



or unread.







Carriage returns, select highlighted items



• Press the ENTER key to insert a regular

ENTER key

carriage return, moving your cursor to a

new line.





• Press the ENTER key to select the highlighted



item. Instead of clicking the trackwheel to



select the item, you can press the ENTER key



to perform your task.







Delete previous characters

BACKSPACE

• Press the BACKSPACE key to move the cursor

key

backwards and delete characters to the left



of the cursor position.





Installation and User’s Guide



Get to know your handheld — Description of keys 27







Key

Function











Delete characters ahead of cursor, delete



messages



• Press the DEL key to erase characters to the



right of the cursor position.



• Press the DEL key while composing a



message to delete the selected character



only.



• Press the DEL key in the Messages screen to



delete the selected message. If you scroll to a



date in the Messages screen and press DEL, a



message appears asking if you wish to



delete all messages prior to that date.









Esc from screens/menus



• Press the ESC key to hide (close) a menu.

Escape key

• Press the ESC key repeatedly to return to the

Home screen.

(under

• Press the ESC key to cancel an action.

trackwheel)









Insert a space, scroll through field options

SPACE key

• Press the SPACE key to insert a space

between characters while you type.





• Press the SPACE key to insert the ‘@’ and ‘.’



characters in Email fields.



• Press the SPACE key to toggle through field



options.







Installation and User’s Guide

28 Get to know your handheld — Description of keys

Key

Function





Open symbols library for extra characters

Press ALT+SPACE to open the Select Symbol screen, from which you can insert the symbol you need.

Symbols screen

As described in the chart above, you can press ALT+SPACE to open the Select Symbol screen. The following characters are available for you to insert into your message:

To select a symbol, either scroll to a symbol and click, or press the associated alpha key under the desired symbol. You will return to your message with the symbol inserted.

LCD interface

The handheld’s LCD screen is composed of the Home screen, function screens that are launched from the Home screen, and menus within each function. Icons are used throughout for message status, handheld status, and navigational aid. The following

Installation and User’s Guide

Get to know your handheld — Description of keys 29

sections provide details on the handheld’s screens, menus, and icons.

Backlighting

When the handheld is on, press the silver key to activate backlighting.

Backlighting is disabled after 20 seconds if you do not press a key or move the trackwheel. You can manually turn off the backlighting by pressing the silver key again.

Function screens

The functions list appears on the Home screen in rows of icons. To open a function’s screen, scroll to an icon and click the trackwheel (or, press the underlined character in the function name).

Home screen

Installation and User’s Guide

30 Get to know your handheld — Description of keys

The following chart shows each function icon and describes the corresponding function:

Icon

Description





Receive, read, reply to, compose, forward, save, file, and delete messages.

Messages

Type and send messages to Internet email addresses.

Compose

Store important messages for future reference.

Saved

Messages

Locate messages in seconds with the powerful search tool.

Search

Messages

Store your personal directory of contact information, such as multiple phone, fax

numbers, and email addresses. Use the search Address function to locate a specific contact.

Book

Keep track of appointments using one of the four calendar views: Day, Week, Month, or

Agenda.

Calendar

Installation and User’s Guide



Get to know your handheld — Description of keys 31







Icon

Description











Add, edit, and delete tasks and mark tasks as



complete.

Tasks













Set the alarm on the handheld to sound daily.

Alarm













Compose, edit, and delete important notes and



memos.

MemoPad













Perform basic mathematical operations and



conversions.

Calculator













Customize the way the handheld notifies you of



messages; set the password; customize Autotext;

Options

set the date/time; program the automatic on/off

feature.









Lock the handheld with a password security



screen so that only you can gain access to it. This

Lock

icon will only appear on the Home screen after

you have set a password.









Installation and User’s Guide

32 Get to know your handheld — Description of keys

Icon

Description





Turn the handheld’s radio off when it may interfere with other radio communications, such

/as during flight. You will not be able to send or

Turn

receive messages until you turn the radio on

Wireless

again.

On/Turn



Wireless Off









Turn off the handheld whenever you prefer not



to receive email messages or when you wish to

Power Off

conserve battery power. All queued messages

will be delivered to your handheld once you



turn it back on.

Function menus

Menus provide a list of options for the current function. You can open a function screen’s menu by clicking the trackwheel; the menu appears on top and covers approximately half of the screen’s width.

Address Book function menu

Installation and User’s Guide

Get to know your handheld — Description of keys 33

Icons and graphical tools
Home screen components

The Home screen appears when you turn on the handheld. It is your starting point for using the handheld’s functions.

Home screen display

In any of the function screens, press the ESC key to return to this Home screen. For a description of each function, see page 29.

Handheld status icons

These icons appear on the handheld’s LCD screen to indicate battery power, coverage levels, and keyboard modes.

Icon

Description





Battery power indicator

Coverage strength indicator

Installation and User’s Guide

Blackberry RIM 857 User Manual

34 Get to know your handheld — Description of keys

Icon

Description





Charging indicator

Data is being sent

Data is being received

ALT key mode is activated

SHIFT key mode is activated

NUM lock mode is activated

Unread messages waiting

Message status icons

These icons appear on the handheld’s LCD screen to indicate the status of pending, sent, and received messages.

Icon

Description





Message is being sent

Message has been sent out to the network

Message pending (will be sent later)

Installation and User’s Guide



Get to know your handheld — Description of keys 35







Icon

Description











Composed message has been saved (not sent yet)









Unread message transmission error









Message returned, message transmission error









New, unread message has been received









Message has been read.









Status of message is high







Scrolling through options

The handheld provides alternate methods of performing the same function (e.g. using hotkeys instead of the trackwheel). In particular, there are four ways to change the configurable options on your handheld. These alternatives apply to all screens where you can change options, such as in the Date/Time, the New Appointment, or the Daily Alarm screens.

Use the menu. While in an option field, click to view the menu. Scroll to Change Options and click. A dialog box appears where you can scroll through your options. Once you reach the option you prefer, click the trackwheel. After setting all of the options in the screen, click to view the menu. Scroll to Save Options and click.

Installation and User’s Guide

36Get to know your handheld — Description of keys

Use ALT + roll. Hold the ALT key while rolling the trackwheel to scroll through the options. Release the ALT key once you reach your desired setting.

Use the keyboard. You can press the letter or number which represents your choice. For example, if you are in a time field, press the first number of the hour you want to specify.

Use the SPACE key. You can use the SPACE key to scroll through your options. Release the SPACE key once you have set the field to your preference. This method is used throughout the guide.

Navigational icons

These icons appear on the handheld’s LCD screen to indicate positions within fields, lists, menus, and screens.

Icon

Description





Indicates the cursor position

You are at the bottom of a menu or screen; scroll the trackwheel up to view more items.

You are at the top of a menu or screen; scroll the trackwheel down to view more items.

You can scroll the trackwheel up or down to view more screen or menu items.

You can scroll the trackwheel left or right to continue viewing icons on the functions list.

Installation and User’s Guide

Get to know your handheld — Setting the date and time 37

Setting the date and time

1.In the Home screen, scroll to the OPTIONS icon and click.

2.In the Device Options screen, scroll to Date/Time and click. The Date/Time screen appears. Scroll to the field you would like to set, then press the SPACE key to scroll through your options.

3.Click the trackwheel to view the menu. Scroll to Save Options and click.

You return to the Device Options screen.

Setting message notification

You can customize the way the handheld notifies you when you receive a message.

1.In the Home screen, scroll to the OPTIONS icon and click.

Installation and User’s Guide

38Get to know your handheld — Using password protection

2.In the Device Options screen, scroll to Notify and click. The Notify screen appears. Scroll to the field you would like to set, then press the SPACE key to scroll through your options.

3.Click the trackwheel to view the menu. Scroll to Save Options and click.

You return to the Device Options screen. See page 154 for more information on the notification options.

Using password protection

By setting a password for your handheld, you ensure greater security against others using the handheld.

You can specify the length of time that the handheld is idle before the password security screen appears. Once the handheld is left idle for that amount of time, you will need to type your password to use the handheld.

You can also manually activate the password security screen by selecting the Lock function from the Home screen. You should lock your handheld if you leave it unattended.

Installation and User’s Guide

Get to know your handheld — Using password protection 39

If you do not want the password security screen to appear, you must disable your password in the Security screen.

Password security screen

Note If you have entered information in the Owner screen of the Options function, it will appear on the password security screen. We recommend that you include your own (or your company’s) contact information in case the handheld is lost.

If an incorrect password is entered 10 times, all information could be erased from the handheld for security reasons. The handheld’s radio is turned off and the radio icon is removed from the Home screen. You will need to reload the applications before you can use your handheld again. You should regularly backup any information from your handheld that might not have originated on your PC. See Chapter 3 or the Backup and Restore online help for more information.

To enable password protection

You should set a password so that no one can use your handheld without knowing the password.

1.In the Home screen, scroll to the OPTIONS icon and click.

Installation and User’s Guide

40Get to know your handheld — Using password protection

2. In the Device Options screen, scroll to Security and click. The

Security screen appears. While in the Password field, press the SPACE key to enable the password. A dialog box appears, prompting you to enter a minimum 4 character password. Press ENTER when you are finished. You will have to enter your password again to verify it.

3.In the Security Timeout field, set how much idle time should

pass before the password security screen will appear. Press the SPACE key to scroll through your options. Release the SPACE key once you have set the field to your preference.

4.Click the trackwheel to view the menu. Scroll to Save Options and click.

You return to the Device Options screen.

If the password is enabled, you will need to enter it when connecting the handheld to your PC for use with the Desktop

Installation and User’s Guide

Get to know your handheld — Using password protection 41

Manager. With the handheld in the cradle, you must type your password before you can gain access to the Desktop Manager tools.

Note The password security screen will show your contact information (if you have entered it in the Owner screen) or it will prompt you to “Press any key”. Type the first letter of your password to gain access to the Enter Password dialog box. Type the remaining letters of your password to resume using the handheld.

Once you have set a password, you need to enter it to use the Security screen again. In addition, if you turn off the handheld with the password security screen enabled, you will need to enter the password once you turn on the handheld again.

To lock the handheld

Once you have enabled your password in the Security screen, you can lock the handheld whenever you like. A lock icon will appear on the Home screen.

1.In the Home screen, scroll to the LOCK icon and click.

2.The password security screen appears and you will need to enter your password to use the handheld.

Note The information you entered in the Owner screen of the handheld options will appear on the password security screen. If you did not enter any information, default information appears. See page 156 for more information on the Owner screen.

To change your password

1.In the Home screen, scroll to the OPTIONS icon and click.

Installation and User’s Guide

42Get to know your handheld — Using password protection

2.In the Device Options screen, scroll to Security and click. A dialog box appears, asking you to type your password. Once you do so, press ENTER to open the Security screen.

3.Click to view the menu. Scroll to Change Password and click.

4.A dialog box appears, prompting you to enter a new password (minimum 4 characters). Press ENTER when you are finished. You will have to enter your new password again to verify it.

5.Click the trackwheel to view the menu. Scroll to Save Options and click.

You return to the Device Options screen with your password changed.

To disable password protection

Once you disable your password, the password security screen will no longer appear.

1.In the Home screen, scroll to the OPTIONS icon and click.

Installation and User’s Guide

Get to know your handheld — Using password protection 43

2.In the Device Options screen, scroll to Security and click. A dialog box appears, asking you to type your password. Once you do so, press ENTER to open the Security screen.

3.While in the Password field of the Security screen, press the SPACE key to change the Password option to Disabled.

4.Click the trackwheel to view the menu. Scroll to Save Options and click.

You return to the Device Options screen.

Installation and User’s Guide

44 Get to know your handheld — Summary and tips

Summary and tips

In this chapter, you learned about the various components and features of the handheld. You’ve also performed a basic setup including setting the date and time, setting message notification, and enabling password protection. You’re now ready to start sending email.

Getting to know your handheld - Tips

Press the first letter of an item in an options list, menu, or choice list to jump directly to the item.

Press Y to select Yes in a pop-up dialog box.

Press N to select No in a pop-up dialog box.

Press C or ESC to select Cancel in a pop-up dialog box.

Press ALT and click the trackwheel to select an icon. Roll the trackwheel to move the icon to another position, and click the trackwheel to “drop” it into the new position.

Installation and User’s Guide

2

Start sending email

Now that you’re more familiar with the handheld, you can start sending and receiving email! The following steps will help you get started:

1.Turn on the radio.

2.Register with the wireless network (if necessary).

3.Install the Desktop Software on your PC.

4.Connect the handheld to your PC using the cradle.

5.Send a test message.

6.Read the test message.

Turning the radio on and off

When you receive your handheld, you must first insert it into the charging cradle and allow it to recharge to full battery power. The wireless radio will be turned off, and the handheld cannot communicate over the network. You must turn on the radio before you can send and receive messages.

In the Home screen, scroll to the TURN WIRELESS ON icon and click.

46 Start sending email — Registering with the network

You will notice that the TURN WIRELESS ON icon was an antenna, but when you select the icon, the function name changes to TURN WIRELESS OFF and the icon changes to an airplane. The airplane icon is a reminder to turn off your handheld’s radio when on an airplane, in a hospital, or any place where it may interfere with other radio transmissions and frequencies. The icon will change depending on whether the wireless radio is on or off.

Note You should turn off your handheld’s radio if you are going to be out of coverage for an extended period of time. Turning off the radio will greatly improve battery life. See page 161 for more information on saving battery life.

There should be two messages in the Messages screen when you first receive your handheld to introduce you to your handheld and some of its basic features.

Registering with the network

After you turn on the wireless radio, a Registration message should arrive. In the rare case that the Registration message does not arrive, check the Home screen to ensure you are in coverage. (You are in coverage if you have one or more bars beside the coverage indicator

Installation and User’s Guide

Start sending email — Registering with the network 47

in the top right corner of the Home screen.) Register your handheld using this procedure.

1.In the Home screen, scroll to the OPTIONS icon and click.

2.In the Device Options screen, scroll to Network Settings and click.

3.In the Network Settings screen, ensure that the Roaming field is set to your country (U.S. or Canada) and that the Radio field is set to On. Verify that the Status field is set to Active.

4.Click to view the menu. Scroll to Register Now and click.

If you are in coverage, the Registration message should arrive within a few seconds.

Note

If the Status field in the Network Settings screen is not set



to Active, contact customer support.



You may also need to re-register your handheld each time



you load new applications using the Desktop Software’s



Application Loader tool. See Chapter 3 or the Application



Loader online help for more information.

Installation and User’s Guide

48 Start sending email — Installing the Desktop Software

Installing the Desktop Software

You must install the Desktop Software in order to synchronize your Personal Information Management data, and use the other Desktop Software tools.

1.Insert the CD-ROM into the appropriate drive. The Setup program starts automatically. Follow the instructions on your screen, using the default paths and names recommended for the Desktop Software.

2.When Setup is complete, you may choose to open the README file and run the Desktop Software right away.

Connect the handheld to your PC

Note When connecting the handheld to the PC, use only the charging cradle provided by Research In Motion Limited.

When you first receive your handheld, you must insert it into the cradle (with the AC connector plugged into a power outlet) and allow the handheld to fully charge to activate it.

1.Ensure that you have properly installed the Desktop Software. If it is not already open, launch the Desktop Manager by selecting it from the Start>Programs menu.

2.Insert the end of the cradle cable into a COM port on the back of your PC. Connect the AC adapter to the cradle cable as shown below. Plug the AC adapter into an available power outlet.

Installation and User’s Guide

Start sending email — Connect the handheld to your PC 49

3.Secure the handheld in the cradle by inserting the connector port on the bottom edge of the handheld into the connector prongs of the cradle and press firmly in place.

Note If the password is enabled, you must enter it before you can connect to the desktop. See page 38 for more information on the password.

4.In the Desktop Manager, ensure that your PC recognizes a connection with the handheld. Select Options>Serial Settings to open the Settings window. Click Detect.

Note The message “Handheld not found” will appear if the PC cannot detect the handheld on a serial port.

If the handheld and charging cradle cable both appear to be connected securely, ensure that no other devices are sharing the serial port, such as a PCMCIA card or IrDA unit. Ensure that there is no other connectivity software running on your PC, and that you are not using the same port as your mouse.

5.After connection is successful, click OK to exit the Settings window. The Desktop Manager will show the handheld’s PIN and Current Status in the status bar.

Installation and User’s Guide

50 Start sending email — Sending a message

Sending a message

You can send a message to an existing contact or add a new contact while composing your message.

Note You can also compose a message while in the Messages,

Address Book, or Saved Messages screens. Click the trackwheel to view the menu. Scroll to Compose Message and click. Follow steps 2-6 below to compose and send your message.

1.In the Home screen, scroll to the COMPOSE icon and click.

2.In the To: screen, click the trackwheel to view the menu; scroll to New Address and click. (Once you have entries in your Address Book, you can scroll to a name. See page 110 for more information on adding Address Book entries.)

3.In the New Address screen, enter your own email address information and press ENTER after each field.

4.Click the trackwheel to view the menu. Select Save Address by clicking again. You return to the To: screen with your new contact selected. Click the trackwheel to view the menu where you select Email as your send method.

Installation and User’s Guide
