Bissell Cleanview 8990, Cleanview 3590, Cleanview 3591 User Manual

0 (0)
Safety Instructions
Product View
Assembly
Operations / Special Tools
CleanView
BAGLESS
3590/3591/8990 SERIES
3
4
4-5
6-8
Maintenance
8-11
Troubleshooting
12
Warranty
14
Consumer Services
13
Replacement Parts
13
Reorder Form
15
2
Thanks for buying a BISSELL CleanView
We’re glad you purchased a BISSELL CleanView Vacuum. Everything we know about floor care went into the design and construction of this powerful, high-tech home vacuuming system.
Your BISSELL CleanView is well made, and we back it with a limited comprehensive one-year warranty. We also stand behind it with a knowledgeable, dedicated Consumer Services department, so, should you ever have a problem, you’ll receive fast, considerate assistance.
My great-grandfather invented the floor sweeper in 1876. Today, BISSELL is a global leader in the design, manufacture, and service of high quality homecare products like your BISSELL CleanView.
Thanks again, from all of us at BISSELL.
Mark J. Bissell President and Chief Executive Officer
3
IMPORTANT SAFETY INSTRUCTIONS
Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.
Turn off all controls before plugging or unplugging vacuum cleaner.
Use extra care when cleaning stairs.
Do not pick up flammable materials (lighter fluid, gasoline, kerosene, etc.) or use in the presence of explosive liquids or vapors.
Do not pick up toxic material (chlorine bleach, ammonia, drain cleaner, etc.).
Do not use vacuum cleaner in an enclosed space filled with vapors given off by oil base paint, paint thinner, some moth proofing substances, flammable dust, or other explosive or toxic vapors.
Do not pick up hard or sharp objects such as glass, nails, screws, coins, etc.
Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
Do not use without filters in place.
Use only on dry, indoor surfaces.
Keep appliance on a level surface.
Do not carry the vacuum cleaner while it is running.
SAVE THESE INSTRUCTIONS FOR FUTURE USE.
When using an electrical appliance, basic precautions should be observed, including the following:
READ ALL INSTRUCTIONS BEFORE USING YOUR UPRIGHT VACUUM.
Always connect to a polarized outlet (left slot is wider than right). Unplug from outlet when not in use and before conducting maintenance.
WARNING: To reduce the risk of
fire, electric shock, or injury:
Do not modify the polarized plug to fit a non-polarized outlet or extension cord.
Do not leave vacuum cleaner unattended when it is plugged in.
Unplug from outlet when not in use and before servicing.
Do not use outdoors or on wet surfaces.
Do not allow children to operate vacuum cleaner or use as a toy.
Close attention is necessary when used by or near children.
Do not use for any purpose other than described in this User’s Guide.
Use only manufacturer’s recommended attachments.
Do not use with damaged cord or plug.
If appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, have it repaired at an authorized service center.
Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners. Do not run appliance over cord. Keep cord away from heated surfaces.
Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
Do not handle vacuum cleaner or plug with wet hands.
Do not put any object into openings. Do not use with any opening blocked; keep openings free of dust, lint, hair, and anything that may reduce air flow.
THIS APPLIANCE HAS A POLARIZED PLUG.
To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install a proper outlet. Do not change the plug in any way.
This model is for household use only.
4
CAUTION:
Do not plug in your vacuum cleaner until you are familiar with all instructions and operating procedures.
Power Switch
Carrying Handle
Crevice Tool
Post-Motor Filter
Quick Reach Handle
Handle
Quick Release Cord Wrap
Handle Release Pedal
Powerfoot
Stretch Hose
Extension Wand
Power Cord
Furniture Protection Guard
Height Adjustment Knob
Upper Tank
Dirt Container
Pre-Motor Filter
Lock ’n Seal
Lever
Headlight
Dusting Brush
Hose Wand
Upper Tank Knob
Hose Clip
Power Trak
Furniture Protection Guard
CleanView Window
Optional Hepa Media Filter (Select Models Only)
Power Trak™Models
Hose Wand Base
Louvers
5
This User’s Guide has been designed to help you get the most satisfaction from your BISSELL CleanView. You’ll find assembly and operating instructions, safety precautions, as well as maintenance and troubleshooting instructions. Please read this Guide thoroughly before assembling your vacuum cleaner.
Pay particular attention to the product diagram, assembly instructions, and part names. Locate and organize all parts before assembly. Familiarize yourself with the parts and where they fit. Following this User’s Guide will greatly enhance your ability to get the most performance from your BISSELL CleanView for many years.
The only tool you’ll need to assemble your vacuum cleaner is a screwdriver.
Locate the vacuum Handle and remove the screw packet taped to the base of the Handle.
Stand the vacuum upright and slide the base of the Handle firmly into the grooves at the top of the vacuum body.
Check to be sure the Handle is fitted to the vacuum body. If there is a gap in front, continue to push firmly until the Handle is flush.
Insert one screw provided from the screw packet into the existing hole. Tighten securely with a screwdriver.
Position the Hose Assembly on the back of the vacuum as shown.
Attach the Hose with the remaining two screws from the packet. Tighten securely with a screwdriver.
Grasping the Quick Reach Handle, slide the end of the Hose Wand onto the suction intake opening. Snap the Hose into the Hose Clip.
NOTE: The Powerfoot will not operate effectively unless the hose wand is firmly attached to the suction intake opening.
How To Use This Guide
How To Put It Together
WARNING:
Plastic film can be dangerous. To avoid danger of suffocation, keep away from babies and children.
Attach Handle To Vacuum
1.
2.
3.
4.
Attach Vacuum Hose and Tools
1.
2.
3.
