Bio Bidet Premium i3000 User Manual

•This unit is specially manufactured for household use.

•Please read all operating instructions before installation.

Notes :

1. This product should be installed according to this manual’s directions.

2. Please keep this manual for future reference.

3. Please register the attached Warranty upon purchase of bidet.

4. Observe all precautions as noted on this manual.

Properly installed and maintained, your new bidet should
provide years of optimal operations.
Read this manual before installation.

Contents

IMPORTANT INFORMATION
IDENTIFICATION
GENERAL PRECAUTIONS
OPERATION
INSTALLATION
MAINTENANCE
TROUBLE SHOOTING
CHARACTERISTICS
WARRANTY
WARRANTY REGISTRATION

-------

-------

-------

-------

-------

-------

-------

-------

-------

-------

4
8

9
10
12
14
15
15
16
17

IMPORTANT INFORMATION

The following terms are used to indicate
varying levels of precautions:

WARNING

indicates a potentially hazardous situation which,
if not avoided, may result in serious injury

CAUTION

indicates a potentially hazardous situation which,
if not avoided, may result in minor or moderate
injury or damage to the product or other property.

4

IMPORTANT INFORMATION

WARNING

Keep out of the direct sunlight
and flammable objects.

Low-temperature burn
Usually, a burn or a scald is caused as a result of the skin coming in contact with
something very hot such as fire, boiling water, hot oil, etc. However, even
contact with something of a relatively low temperature (104F-140F) may cause
a low-temperature burn if it is in contact with the skin for an extended period
of time. If there is someone of delicate physical condition, you are requsted to
advice him/her to take the above-mentioned precaution.

Do not disassemble the unit.
It will expire remaining warranty.

5

a insecticide

☞

a benzene

☞

☞

alcohol

IMPORTANT INFORMATION

CAUTION

a detergent

☞

Do not use chemicals.
Use only damp cloth or neutral
detergent to clean.

on the unit.

Take all possible safety precautions
when phsically challenged person,
elderly, or child is using the unit.

Do not step on the unit.Do not slam or apply excessive force

6

IMPORTANT INFORMATION

CAUTION

Do not push or pull connection
tube.

Do not splash water or waste water
directly to the unit.

** Water Temperature **

The human skin may be scalded when high-temperature water
comes into contact with it. Close supervision is necessary when the
user is unstable or a child.

When using the always ensure the usage of water with
lower temperatures when bidet is used by:
* Children
* An unstable or sick person
* A person with particularly sensitive skin
* Physically handicapped person

7

Mild soap or

douche reservoir for

feminine cleaning

IDENTIFICATION

Seat Lid

Operation lever
(Posterior,enema
& Feminine wash

Nozzle cleaning

button

Cold water inlet

Hot water inlet

Water Temperature

Adjustable Lever

Warning Label

Posterior wash &

enema funtion

nozzle

Feminine Wash

Nozzle

Seat

8

IDENTIFICATION

3/8”T-Valve

(2 pc)

Water Supply tubing

(4m)

Cone PackingsMounting Bolts

Bolt Guides Nuts

Simply Guide

Fill valve water supply hose

Manual

GENERAL PRECAUTIONS

1. Water supply should have a water pressure between

2.0 - 7.5kgf/㎠ (28.4psi~ 106.7psi.)

2. Only connect to clean water pipe.

3. Take the protective measures to prevent from freezing.

4. Do not expose to direct sunlight, as it may discolor the plastic.

5. Do not push or pull the connecting tubes, it may cause water leakage.

6. Do not apply excessive force to the shower nozzle.

9

OPERATION

♣Posterior Washing & Enema function.

-Simply sit on the unit, and select posterior/
enema funtion by pulling the lever
backward gradually.

Stop

Posterior

wash

♣Water Pressure Adjustment &

Enema Function.

10

on putting into

on pushing out

-The water pressure can be manually adjusted to
5 levels.

-To activate the enema function, slowly increase the
water pressure by adjusting the level till the washing
water enters the rectum.

-Adjust your body to allow the water to easily enter
your body.

-Once the water fills the rectum, strain your abdomen
to eliminate waste matter from your system.
This action may be repeated 3 or 4 times.

OPERATION

♣Feminine Washing.

-For the feminine wash, slowly push the
lever forward
(away from you).

Stop

Feminine

wash

Cold

♣Warm water adjustment

H
o

t

-Water temperature is adjustable to desired
temperature as illustrated.

(when applicable).

♣Nozzle cleaning function

-Simply push self-cleaning button before and
after using the unit for maximum hygiene.

11

INSTALLATION

1

Removing the existing seat and lid.

-Remove existing seat and lid

12

Close water supply shut off valve.

2

INSTALLATION

3

Connecting the T-Valve (Cold Water / Hot Water)

1. Flush out remaining water in water tank

2. Removing existing fill valve water supply hose.

3. Install supplied T-valve.

4. Connect “Cold”/ “Hot”water suppy tube.

5.

Connect supplied fill valve water supply hose.

(7/8”× 3/8”)

Packing Rubber

(Black)

Tip:
Do not over tighten supplied parts when installing.
Use only hand pressure initially,
then tighten it gradually as checking for leakage.

13

INSTALLATION

Installing .

4

1. Place mounting bolts into mounting
brackets and slide into the mounting
bracket guide rail on the bottom of
the main unit.

2. Securely fasten cone packing
from bottom to secure the unit to toilet.

Connect both hot and cold water supply tube to

5

water inlet on bidet seat.

1

14

2

MAINTAINANCE

Cleaning the nozzle

- Pull out the nozzle and clean the nozzle with toothbrush.

- After cleaning the nozzle, push the nozzle-cleaning
button on the operation lever to activate the
self-cleaning function.

*** CAUTIONS***

15

TROUBLE SHOOTING

♣Before calling the service (A/S) center,

please perform the following checks.

Problem

The washing water is not
spraying properly

There is no hot water pipe
below the wash basin

Water leaking or dripping

1.Check water supply valve.

2.Clean the nozzle.

Connect from another hot water
supplying source.

Check the connection and
securely fasten if loose.
If leakage is from inside of the
main unit, shut water off immediately,
and contact service center.

Remedy Remarks

CHARACTERISTICS & CERTIFICATE

 Enema Function spraying system.

Centralized rotary bubble water streams are made as
water stream from 1 central nozzle and
6 circumferential water streams get together.

(U.S Patent No. US 6526602 B2, Korean Patent No. 0426635 )

 Korean Medical appliance production lisence :

No. 1617 Certified by KOREAN FDA

 Qualification : ISO 9001 &

ISO 14001 Certified.

ISO9001 ISO14001

16

WARRANTY

BBC Innovation Corporation

Limited Warranty

This limited warranty gives you specific legal rights, and you may also have
other rights that may very from state to state or according to other conditions.

General Limited Warranty Covered

The Manufacturer,
buyer only, which fails in normal use and within the applicable periods specified below,
following the terms of this warranty.
be warranted to the original purchaser of the products.

The Parts Warranty

If the parts fail within 12 month after original installation following the installation
manual and normal operation,
replacement part(s).

BBC Innovation Corporation

BBC Innovation Corporation

BBC Innovation Corporation

will warrant to the original retail

replacement will

will furnish a

Will not be Covered by this Warranty

1. Defects and/or malfunctions from failure to properly install, operate and/or maintain
the unit in accordance with the installation manual.

2. Damage from abuse, fire, flood, freeze, and any other act of God.

3. Damage resulting from unauthorized alterations, attachments and/or repairs.

4. If the product was not installed properly to residential water closets.

5. Damage from installing the unit in an environment with animals, mice or insects.

6. Damage caused by excess moisture or from water clogging the water closet.

7. Damage from not being installed in accordance with all applicable local codes,
ordinances and good trade practices.

8. Color fading due to use in wrong environments.

9. Damage from consumable chemicals.

10. The warranty will not be covered without providing the date of purchase with
original receipts.

11. Damage from misuse due to not following the installation manual.

17

WARRANTY REGISTRATION

1 Year Warranty
The Manufacturer carefully tests every Bio Bidet before shipment.
Bio Bidet made with highest quality materials in the highest standard

Ⓡ

Ⓡ

of production and workmanship and guaranteed to be free of defects.
The warranty is good for one year from purchase date.

Only the original purchaser may submit a claim under this limited warranty.

Retain copy of purchase receipt for warranty

Service Center

205 Berg Street, Algonquin, IL 60102, U.S.A

Questions or Service inquiry, call to free

847.458.2334
