Bertazzoni BERERARHDW17 Specs

BERTAZZONI

36” BUILT-IN BOTTOM MOUNT RIGHT SWING DOOR REF36PRR

HIGHLIGHTS

FlexMode Refrigerator-Freezer

Switch bottom compartment between freezer and refrigerator with one touch.

Digital User Interface

Internal LED touch interface with intuitive controls for temperature management and all system functions.

Custom ice maker & water filtration

Integrated water filter connected to water line ensures regular production of ice cubes of customizable size.

Interior LED lighting

Extra-bright LED lighting on top and sides provide optimized interior illumination on all levels

with minimal energy consumption.

FEATURES

Style

bottom mount





Finish

white aluminium interior





Interface

digital display inside





Lighting

6 LED lights recessed into refrigerator



ceiling, 5 side wall flush mounted



individual

Refrigerator shelves

2 full-width





Refrigerator drawers

2





FlexMode drawers

1 large drawer, 1inner drawer + ice tray





Door storage compartment

3 full-width racks





Ice maker

automatic, up to 3lbs/24 hours





U.S. DOE annual energy consumption

580 kWh/yr





Automatic settings

Max Cool Fridge, Vacation, Beverage



Cooler, SuperIce, IceSize, Sabbath



Mode, Water Filter

TECHNICAL SPECIFICATIONS







Voltage , frequency

115V, 60Hz





Max Amp Usage, power rating

4.8A, 552W





DOE compliant

yes





Power connection

back side, length of power cord 6.5ft





Water connection

back side, water supply tube



(female attachment) 3/4’’





Certification

ETL





Warranty

2 years parts and labor





CAPACITY







Refrigerator capacity

14 cu.ft





FlexMode capacity

3.7 cu.ft





Total capacity

17.7 cu.ft





BERTAZZONI

36” BUILT-IN BOTTOM MOUNT RIGHT SWING DOOR REF36PRR

INSTALLATION INSTRUCTIONS

24"

35" 38

6" 38

22"

Clearance 1”

24" 22"

Clearance 14

57" 78

Clearance 1”

83" 12

min 90° max 105°

38 "

24" 22"

35" 38

35" 38

Clearance 14

INSTALLATION: There shall be a space not less than 1 inch from the top of your refrigerator, not less than 1/4 inch from both sides and 1 inch or more from the back of the refrigerartor to the adjacent walls respectively. This requirements is good for open and close of the door and also for heat emission.

DIMENSIONS



Refrigerator handles are provided separately with dedicated commercial code and packaging.











Depth without handles and without wooden cabinet panel

24''

Disclaimer: while every effort has been made to insure the accuracy of the information contained in





Depth corpus

22''

this brochure, Fratelli Bertazzoni reserves the right to change any part of the information at any time





without notice.

Height

83 1/2''







Fratelli Bertazzoni, Bertazzoni and the winged wheel brand icon are registered trademarks of

Width

35 3/8''

Bertazzoni Spa.





WWW.BERTAZZONI.COM
