Avaya 4620SW, 4621SW, 4620 User Manual

0 (0)

4620/4620SW/4621SW IP Telephone

User Guide

555-233-781

Issue 3

April 2006

© 2006 Avaya Inc.

All Rights Reserved.

Notice

While reasonable efforts were made to ensure that the information in this document was complete and accurate at the time of printing, Avaya Inc. can assume no liability for any errors. Changes and corrections to the information in this document may be incorporated in future releases.

For full legal page information, please see the complete document, Avaya Legal Page for Hardware Documentation, Document number 03-600759.

To locate this document on our Web site, simply go to http://www.avaya.com/support and search for the document number in the search box.

Documentation disclaimer

Avaya Inc. is not responsible for any modifications, additions, or deletions to the original published version of this documentation unless such modifications, additions, or deletions were performed by Avaya. Customer and/or End User agree to indemnify and hold harmless Avaya, Avaya's agents, servants and employees against all claims, lawsuits, demands and judgments arising out of, or in connection with, subsequent modifications, additions or deletions to this documentation to the extent made by the Customer or End User.

Link disclaimer

Avaya Inc. is not responsible for the contents or reliability of any linked Web sites referenced elsewhere within this documentation, and Avaya does not necessarily endorse the products, services, or information described or offered within them. We cannot guarantee that these links will work all of the time and we have no control over the availability of the linked pages.

Warranty

Avaya Inc. provides a limited warranty on this product. Refer to your sales agreement to establish the terms of the limited warranty. In addition, Avaya’s standard warranty language, as well as information regarding support for this product, while under warranty, is available through the following Web site:

http://www.avaya.com/support

Copyright

Except where expressly stated otherwise, the Product is protected by copyright and other laws respecting proprietary rights. Unauthorized reproduction, transfer, and or use can be a criminal, as well as a civil, offense under the applicable law.

Avaya support

Avaya provides a telephone number for you to use to report problems or to ask questions about your product. The support telephone number

is 1-800-242-2121 in the United States. For additional support telephone numbers, see the Avaya Web site:

http://www.avaya.com/support

Software License

USE OR INSTALLATION OF THE PRODUCT INDICATES THE END USER’S ACCEPTANCE OF THE TERMS SET FORTH HEREIN AND THE GENERAL LICENSE TERMS AVAILABLE ON THE AVAYA WEBSITE AT http://support.avaya.com/LicenseInfo/ (“GENERAL LICENSE TERMS”). IF YOU DO NOT WISH TO BE BOUND BY THESE TERMS, YOU MUST RETURN THE PRODUCT(S) TO THE POINT OF PURCHASE WITHIN TEN (10) DAYS OF DELIVERY FOR A REFUND OR CREDIT.

Avaya grants End User a license within the scope of the license types described below. The applicable number of licenses and units of capacity for which the license is granted will be one (1), unless a different number of licenses or units of capacity is specified in the Documentation or other materials available to End User. “Designated Processor” means a single stand-alone computing device. “Server” means a Designated Processor that hosts a software application to be accessed by multiple users. “Software” means the computer programs in object code, originally licensed by Avaya and ultimately utilized by End User, whether as stand-alone Products or pre-installed on Hardware. “Hardware” means the standard hardware Products, originally sold by Avaya and ultimately utilized by End User.

License Type(s):

Designated System(s) License (DS). End User may install and use each copy of the Software on only one Designated Processor, unless a different number of Designated Processors is indicated in the Documentation or other materials available to End User. Avaya may require the Designated Processor(s) to be identified by type, serial number, feature key, location or other specific designation, or to be provided by End User to Avaya through electronic means established by Avaya specifically for this purpose.

Third-party Components

Certain software programs or portions thereof included in the Product may contain software distributed under third party agreements (“Third Party Components”), which may contain terms that expand or limit rights to use certain portions of the Product (“Third Party Terms”). Information identifying Third Party Components and the Third Party Terms that apply to them is available on Avaya’s web site at:

http://support.avaya.com/ThirdPartyLicense/

Interference

Using a cell, mobile, or GSM telephone, or a two-way radio in close proximity to an Avaya IP Telephone might cause interference.

Contents

About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7

Intended Audience. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7

Issue Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7

What’s New in This Document . . . . . . . . . . . . . . . . . . . . . . . . . . . .

8

How to Use This Document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

8

Document Organization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9

Conventions Used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9

Symbolic Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

10

Typographic Conventions. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

10

Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

10

Chapter 1: Introducing Your 4620/4620SW/4621SW IP Telephone . . . .

11

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

11

The 4620/4620SW/4621SW IP Telephone. . . . . . . . . . . . . . . . . . . . . . .

12

About the Feature Key Expansion Unit (EU24/EU24BL) . . . . . . . . . . . . . .

16

Navigating Application Screens . . . . . . . . . . . . . . . . . . . . . . . . . . .

16

4620/4620SW/4621SW IP Telephone Applications. . . . . . . . . . . . . . . . . .

18

Phone Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

18

Speed Dial Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

18

Call Log Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

19

Web Access Application (Optional) . . . . . . . . . . . . . . . . . . . . . . .

19

4620/4620SW/4621SW Telephone Options. . . . . . . . . . . . . . . . . . . .

19

Additional 4620/4620SW/4621SW Functionality . . . . . . . . . . . . . . . . . . .

20

Push Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

20

Automatic Backup/Retrieval Feature . . . . . . . . . . . . . . . . . . . . . . .

20

Chapter 2: Using Your 4620/4620SW/4621SW IP Telephone . . . . . . .

21

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

21

Call Appearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

21

Making Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

21

Manual Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

22

Automatic Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

22

Redialing a party . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

23

Dialing a party using a Speed Dial button . . . . . . . . . . . . . . . . . .

24

Automatically dialing a party using an administered Line/Feature button

24

Calling a party from the Call Log . . . . . . . . . . . . . . . . . . . . . . .

25

Calling a party from the Web Access application . . . . . . . . . . . . . .

26

Issue 3 April 2006 3

Contents



Receiving Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

26

Call Handling Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

26

Conference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

27

Hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

27

Mute. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

28

Speaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

28

Changing from the Speaker to the handset or headset . . . . . . . . . . .

29

Changing from the handset or headset to the Speaker . . . . . . . . . . .

29

Turning the Speaker on during a call. . . . . . . . . . . . . . . . . . . . .

29

Turning the Speaker off during a call. . . . . . . . . . . . . . . . . . . . .

29

Ending a call while the Speaker is active . . . . . . . . . . . . . . . . . .

29

Transfer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

29

Retrieving a Voice Mail Message . . . . . . . . . . . . . . . . . . . . . . . . . . .

30

Logging Off the Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

30

Reinstating the Phone After a Logoff . . . . . . . . . . . . . . . . . . . . . .

31

Forcing a Login to the Phone . . . . . . . . . . . . . . . . . . . . . . . . . . .

31

Chapter 3: Using the Speed Dial Application . . . . . . . . . . . . . . .

33

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

33

Entering Data on Speed Dial Screens . . . . . . . . . . . . . . . . . . . . . . . .

33

Entering Characters Using the Dialpad . . . . . . . . . . . . . . . . . . . . .

33

Editing During or After Entry . . . . . . . . . . . . . . . . . . . . . . . . . . .

34

Name Entry Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

35

Adding a Speed Dial Button. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

36

Updating Speed Dial Button Label Information . . . . . . . . . . . . . . . . . . .

37

Deleting a Speed Dial Button Label . . . . . . . . . . . . . . . . . . . . . . . . .

38

Chapter 4: Using the Call Log Application. . . . . . . . . . . . . . . . .

41

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

41

About the Call Log. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

41

Viewing a Call Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

42

Adding a Call Log Entry to a Speed Dial Button. . . . . . . . . . . . . . . . . . .

43

Deleting Call Log Entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

44

Deleting a Single Call Log Entry . . . . . . . . . . . . . . . . . . . . . . . . .

44

Deleting All Entries from a Call Log . . . . . . . . . . . . . . . . . . . . . . .

45

Disabling the Call Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

45

4 4620/4620SW/4621SW IP Telephone User Guide



Contents

Chapter 5: Using the Web Access Application . . . . . . . . . . . . . .

47

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

47

Web Access Authentication. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

48

Navigating Web Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

48

Navigating the Home Page and Other

49

Standard-Size Web Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Entering Text on Web Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

50

Entering Characters Using the Dialpad . . . . . . . . . . . . . . . . . . . . .

51

Adding a Speed Dial Button for a Web Site Telephone Number . . . . . . . . . .

52

Chapter 6: 4620/4620SW/4621SW IP Telephone Options . . . . . . . . .

53

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

53

Accessing the Options Main Menus . . . . . . . . . . . . . . . . . . . . . . . . .

54

Application Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

55

Setting the Redial Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

55

Setting the Phone Screen on Answer? Option . . . . . . . . . . . . . . . . .

56

Setting the Phone Screen on Calling? Option . . . . . . . . . . . . . . . . . .

56

Setting the Display Call Timers? Option . . . . . . . . . . . . . . . . . . . . .

57

Setting the Message Display Rate . . . . . . . . . . . . . . . . . . . . . . . .

57

Setting the Call Appearance Width . . . . . . . . . . . . . . . . . . . . . . . .

58

Setting Visual Alerting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

58

Enabling/Disabling the Call Log . . . . . . . . . . . . . . . . . . . . . . . . .

58

Personal Ringing Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

59

Status Screen Viewing Options . . . . . . . . . . . . . . . . . . . . . . . . . . . .

60

Viewing IP Address Status . . . . . . . . . . . . . . . . . . . . . . . . . . . .

60

Viewing Quality of Service (QoS) Status . . . . . . . . . . . . . . . . . . . . .

60

Viewing Interface Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

61

Viewing Miscellaneous Status . . . . . . . . . . . . . . . . . . . . . . . . . .

61

Changing the Display Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . .

61

Viewing the Network Audio Quality . . . . . . . . . . . . . . . . . . . . . . . . .

62

Logging Off the 4620/4620SW/4621SW IP Telephone . . . . . . . . . . . . . . . .

62

Reinstating the Phone After a Log Off . . . . . . . . . . . . . . . . . . . . . .

63

Backup/Restore Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

63

Settings Saved During a Backup . . . . . . . . . . . . . . . . . . . . . . . . .

64

Setting the Automatic Backup Option . . . . . . . . . . . . . . . . . . . . . .

65

Verifying Backup/Retrieval Status . . . . . . . . . . . . . . . . . . . . . . . .

66

Retrieving and Restoring Data from a Backup File . . . . . . . . . . . . . . .

67

Setting a User ID, Password, and other FTP

68

(File Transfer Protocol) Options. . . . . . . . . . . . . . . . . . . . . . . . .

Issue 3 April 2006 5

Contents



Feature Button Labeling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

70

Changing a Phone/PC Ethernet Interface . . . . . . . . . . . . . . . . . . . . . .

72

Selecting an Alternate Language . . . . . . . . . . . . . . . . . . . . . . . . . . .

73

Chapter 7: Headsets and Handsets . . . . . . . . . . . . . . . . . . . .

75

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

75

Headsets for 4600 Series IP Telephones . . . . . . . . . . . . . . . . . . . . . . .

75

Handsets for 4600 Series IP Telephones . . . . . . . . . . . . . . . . . . . . . . .

76

Chapter 8: Telephone Management and Troubleshooting . . . . . . . .

77

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

77

Interpreting Ringer Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

77

Interpreting Display Icons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

79

Testing Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

80



Testing the Telephone's Lights and Display . . . . . . . . . . . . . . . . . . .

80

Basic Troubleshooting Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

80

Troubleshooting 4620/4620SW/4621SW Applications. . . . . . . . . . . . . . . .

83

Resetting and Power Cycling the IP Telephone . . . . . . . . . . . . . . . . . . .

85



Resetting Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

85



Power Cycling the Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

86

Index

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

87

6 4620/4620SW/4621SW IP Telephone User Guide

About This Guide

Overview

This guide covers how to use your new 4620/4620SW/4621SW IP Telephone. The 4620/ 4620SW/4621SW is simple to use while offering the latest advances in telephony systems. IP (Internet Protocol) telephones obtain their operational characteristics from your central telephone server rather than residing in the phone unit itself. Updates and new features are downloaded to your phone without intervention or the need for phone replacement.

This guide contains eight chapters, geared to how you actually use the phone, each of which is described in the section titled Document Organization.

Intended Audience

This document is intended for IP telephone users who have a 4620/4620SW/4621SW IP Telephone. It is not intended to be a technical reference guide for System Administrators or phone technicians.

Issue Date

This document was issued for the first time in July, 2002. It has been revised as follows:

for Release 1.8 in June, 2003,

for Release 2.0 in December, 2003,

for Release 2.1 in July, 2004,

for Release 2.2 in April, 2005, and

for Issue 3 (Release 2.4) in April, 2006

The April 2006 version of this guide supersedes all previous versions.

Issue 3 April 2006 7

About This Guide

What’s New in This Document

Issue 3 reflects changes to the document title and legal pages only. There are no significant changes in telephone operation for Software Release 2.4

How to Use This Document

This guide is organized to help you find topics in a logical manner. Read it from start to finish to get a thorough understanding of how to use your 4620/4620SW/4621SW IP Telephone. Or, use the Table of Contents or Index to locate information specific to a task or function you want to perform.

8 4620/4620SW/4621SW IP Telephone User Guide

Document Organization

Document Organization

This guide contains the following chapters:

Chapter 1: Introducing Your

Describes each element on the face of the telephone.

4620/4620SW/4621SW IP

Also covers telephone navigation, applications and

Telephone

features.

Chapter 2: Using Your 4620/

Covers all call-related information, such as initiating

4620SW/4621SW IP

calls, receiving calls, speed dialing, calling a party on the

Telephone

call log, conferencing and transferring calls, accessing



and retrieving voice mail messages, logging off the



phone for security purposes and logging back on to the



phone.





Chapter 3: Using the Speed

Describes how to add, update, and remove Speed Dial

Dial Application

buttons, to facilitate quick dialing of frequently called



numbers.

Chapter 4: Using the Call Log

Describes how to view entries on each of the three types

Application

of call logs, add a log entry to a Speed Dial button, and



delete one or more call log entries.





Chapter 5: Using the Web

Explains how to use the 4620/4620SW/4621SW’s Web

Access Application

access functions.

Chapter 6: 4620/4620SW/

Provides first-time use setup and ongoing maintenance

4621SW IP Telephone Options

procedures for 4620/4620SW/4621SW Telephone



options. Also covers troubleshooting certain phone



functions.





Chapter 7: Headsets and

Provides a list of headsets and handsets compatible with

Handsets

4600 Series IP Telephones, and ordering information.

Chapter 8: Telephone

Covers testing your phone’s operation and provides

Management and

basic troubleshooting actions, if you encounter errors or

Troubleshooting

experience problems.





Conventions Used

This guide uses the following textual, symbolic, and typographic conventions to help you interpret information.

Issue 3 April 2006 9

About This Guide

Symbolic Conventions

Note:

This symbol precedes additional information about a topic.

Typographic Conventions

This guide uses the following typographic conventions:

Document

Underlined type indicates a section or sub-section in this



document containing additional information about a topic.





“Document”

Italic type enclosed in quotes indicates a reference to an external



document or a specific chapter/section of an external document.





Italics

Italic type indicates the result of an action you take or a system



response in step by step procedures.

Conference

In step by step procedures, words shown in bold represent a



single telephone button that should be pressed/selected.





Related Documentation

This guide and other related documentation is available online at the following URL: http://www.avaya.com/support.

For a Quick Reference to 4620/4620SW/4621SW features and applications, see the

4620/4620SW/4621SW IP Telephone Quick Reference (Document Number 16-300003).

For information related to installing an IP telephone, see the 4600 Series IP Telephone Installation Guide (Document Number 555-233-128).

For information related to using the telephone stand or wall-mounting a 4620/4620SW/4621SW IP Telephone, see the 4620/4620SW/4621SW/4622SW/4625SW IP Telephone Stand Instructions (Document Number 16-300299).

For information about using an EU24/EU24BL Expansion Module with any of the telephones described in this guide, see the EU24/EU24BL Expansion Module User Guide (Document Number 555-250-702).

For information related to maintaining an IP Telephone System on a Local Area Network, see the 4600 Series IP Telephone LAN Administrator Guide (Document Number 555-233-507).

Standard telephone features are described in the Overview for Avaya Communication Manager (Document Number 03-300468).

10 4620/4620SW/4621SW IP Telephone User Guide

Chapter 1: Introducing Your 4620/4620SW/4621SW IP Telephone

Introduction

This chapter introduces you to the layout of the 4620/4620SW/4621SW IP Telephone. It provides a description for each functional button and other phone characteristics, briefly describes each 4620/4620SW/4621SW application, and provides basic instructions for navigating display screens.

Note:

The 4620 and 4620SW SW IP Telephones have the exact same appearance, user interface, and functionality. The phones do have somewhat different internal circuitry, and, unlike the 4620, the 4620SW supports Russian and multi-byte characters (Chinese, Japanese, and Hebrew), as covered in Selecting an Alternate Language in Chapter 6: 4620/4620SW/4621SW IP Telephone Options. When the term “4620” is used anywhere in this document, the information also applies to the 4620SW, unless otherwise noted.

Note:

The 4620SW and the 4621SW are almost exactly the same telephone. Both telephones have the same appearance, user interface, and functionality. The phones do have somewhat different internal circuitry, and the 4621SW has a special backlighted display. Like the 4620SW, the 4621SW supports Russian and multi-byte characters (Chinese, Japanese, and Hebrew), as covered in Selecting an Alternate Language in Chapter 6: 4620/4620SW/4621SW IP Telephone Options. When this document uses the terms “4620” and 4620SW,” the information also applies to the 4621SW, unless otherwise noted.

Issue 3 April 2006 11

Introducing Your 4620/4620SW/4621SW IP Telephone

The 4620/4620SW/4621SW IP Telephone

The 4620/4620SW/4621SW IP Telephone is an innovative telephone that gives you access to the World Wide Web while offering the latest features and applications. The large display area allows up to 12 application-specific buttons to be presented and labeled at one time.

Additionally, 12 Line/Feature buttons, 4 softkeys, and other fixed buttons provide access to powerful capabilities such as:

call server-based features,

speed dialing,

a Call Log, and

a WML (Wireless Markup Language, a Web development protocol) browser.

This last feature is covered in detail in Chapter 5: Using the Web Access Application. The WML browser provides access to Web sites tailored specifically for devices with smaller display screens like cell phones and Personal Data Assistants.

In addition to these features and applications, the 4620/4620SW/4621SW provides a robust menu of options to customize your phone preferences.

Your telephone’s display area coincides with how your System Administrator sets up the Line/ Feature buttons. The 4 softkeys assist you in using 4620/4620SW/4621SW applications and features. The 14 standard (labeled) buttons assist in telephone operation and call handling. A built-in, two-way Speaker, and an infrared interface (not applicable on the 4621SW) combine to provide ease of use and flexibility. The telephone has an adjustable stand that moves to optimize your viewing position via the button on the back.

Figure 1 shows the face of the 4620/4620SW/4621SW IP Telephone. This diagram contains numbered “callouts” identifying the phone’s primary features and buttons. If you are viewing this guide online, you can click the callout to jump to the corresponding feature or button description. Otherwise, each callout is described in detail in Table 1 following the diagram.

12 4620/4620SW/4621SW IP Telephone User Guide

Avaya 4620SW, 4621SW, 4620 User Manual

The 4620/4620SW/4621SW IP Telephone

Figure 1: 4620/4620SW/4621SW IP Telephone

1

2

3







3





4

4

5

6

7

16

8



9

17

10

18

11

19

12



13

20

14

21

15

22

Issue 3 April 2006 13

Introducing Your 4620/4620SW/4621SW IP Telephone

Table 1: 4620/4620SW/4621SW IP Telephone Button/Feature Descriptions

Callout

Button/Feature

Button/Feature



Number

Name

Description









1

Message Waiting

When lit, indicates you have a message waiting on your voice



Lamp

messaging system. This indicator can also be optioned to





flash for incoming calls.



2

Display

The display screen is 4 inches by 2.9 inches. Information





displayed varies according to the application/function





currently active. When the phone is idle, the top area displays





the current date and time. When someone is calling you, the





name/phone number of that person displays in the top area.





The display has eight lines. Six display lines are devoted to





the current application. One line shows softkey labels for the





current application and one line shows Help and other





procedural messages. Four grayscale colors are used to





indicate activity.



3

Line/Feature

Twelve Line/Feature buttons provide both call appearances



buttons

(lines for incoming and outgoing calls) and application-specific





functionality.



4

Softkeys

Used to navigate to, or start application-specific actions, such





as Call a number, Cancel the current activity, Save entered





data such as a Speed Dial label.



5

Phone/Exit

Displays the Phone application main screen or, if applicable,





exits the current call server-based feature and normalizes the





display.



6

Options

Displays the Options main screen, from which display and





application settings can be updated.



7

Page Left/Right

Shifts from one page to another in the same application, when





the display presents the “paging indicator” (

). These





buttons have no effect when the Paging Indicator is not





displayed.



8Speaker LED Lights steadily when the Speaker is active.

Indicator

9

Speaker

Accesses the Speaker feature.

10Headset LED Lights steadily when the headset is active.

Indicator

1 of 2

14 4620/4620SW/4621SW IP Telephone User Guide





The 4620/4620SW/4621SW IP Telephone

Table 1: 4620/4620SW/4621SW IP Telephone Button/Feature Descriptions (continued)

Callout

Button/Feature

Button/Feature

Number

Name

Description







11

Headset

With a headset connected, changes audio control from the





handset or Speaker to the headset.

12

Mute LED

Lights steadily when the handset, headset or Speaker is



Indicator

muted.

13

Mute

Turns off the active Speaker, handset, or headset





microphone, to prevent the other person from hearing you.

14

Volume Control

Adjusts the handset, Speaker, headset, or ringer volume,





depending on which item is in use. When you increase or





decrease the volume, the top display area shows an icon to





indicate the item for which you are adjusting the volume. A





visual “volume meter” that shows the volume level follows the





icon. This button also controls the volume of the key click





sounds. Key clicks sound when you press fixed buttons on the





phone such as the dialpad or softkeys.

15

Headset Jack

Provides a port for connecting a headset on the underside of





the phone.

16

Hold

Red button used to place a call on hold.

17

Transfer

Transfers a call to another phone.

18

Conference

Sets up conference calls with more than one other person.

19

Drop

Drops the last person added to a Conference call or ends the





current call, if you are not on a Conference call.

20

Redial

Redials the last number dialed from the phone or displays a





list of the last six numbers dialed for selection. Set using the





Options button described in Chapter 6: 4620/4620SW/





4621SW IP Telephone Options.

21Numeric (Dialing) Standard 12 button pad for dialing phone numbers.

Pad

22

Feature Key

Provides a port (on the underside of the phone) for connecting



Expansion Unit

the optional EU24/EU24BL (Feature Key Expansion Unit),



Connection Jack

which provides additional telephone Feature buttons.





2 of 2







Issue 3 April 2006 15

Introducing Your 4620/4620SW/4621SW IP Telephone

About the Feature Key Expansion Unit (EU24/EU24BL)

The Feature Key Expansion Unit is an optional device that can be connected to your 4620 IP Telephone. The EU24 and EU24BL contain 24 buttons onto which your System Administrator sets up additional IP telephone features and/or call appearances (incoming and outgoing lines).

The EU24BL is essentially the same as an EU24, except with a backlit display. When we use the term “EU24” anywhere in this guide, the information also applies to the EU24BL, unless otherwise noted.

The EU24 is recommended for use with the 4620 and 4620SW IP Telephones. The EU24BL is recommended for use with the 4621SW IP Telephone.

For usage instructions, see the EU24/EU24BL Expansion Module User Guide (Document Number 555-250-702, available at http://www.avaya.com/support).

Navigating Application Screens

Your 4620 IP Telephone uses Phone Feature buttons, Line/Feature buttons, and Softkeys to allow you maximum flexibility in phone operation and application usage. While reviewing this section, it can help to refer to Figure 1: 4620/4620SW/4621SW IP Telephone on page 13.

Phone Feature buttons are used in the Phone application and appear on the face of the telephone around the dialpad. Phone buttons have an icon on the top of the button, to indicate the button’s function. These buttons provide mostly call-handling features like Transfer, Conference, Hold, or Redial. Two new phone feature buttons are:

Phone/Exit (

) - used to exit call server-based features and restore the Phone screen

to the display, and



Options () - used to access the Options function to set certain phone parameters and view phone/server/connection status and other information for troubleshooting.

The Page Left and Page Right buttons ( ) (between the Phone/Exit and Options buttons) are also considered phone buttons. Use them to move forward (Right Arrow) or backward (Left Arrow) from one display screen to another. These paging buttons work in conjunction with the paging indicators ( ) you may see on an application screen. Paging indicators show that a screen has more than one page, and allow you to navigate forward and back through those additional pages. To activate the function or feature represented by a phone button, just press the appropriate button.

Line/Feature buttons ( ) appear on both sides of the display area. These buttons provide call appearances (Lines) and other call-related features (as administered by your System Administrator) in the Phone application. They also serve as application-specific buttons in the Call Log or other applications. For example, pressing a Line/Feature button in the Call Log application selects the corresponding entry, allowing you to take further action with your

16 4620/4620SW/4621SW IP Telephone User Guide

Navigating Application Screens

selection. When you enter text on a screen (for example, a Speed Dial button label), several Line/Feature buttons provide editing features like backspacing or hyphenation.

Here is an example of the difference between a Line/Feature button’s functionality in the Phone application versus other applications. To call someone from the Phone application (the default display screen) you press the first Line/Feature (call appearance) button and dial your party. But in the Call Log application, pressing the first Line/Feature button displays detailed information about the first call log entry.

In addition to the call-related icons and features explained in Table 1, the icons and background display colors in Table 2 are associated with certain administrable features on the call server, and might appear on the display. Several features, such as flash, wink, and flutter, are associated with Call Center operations, and might not apply to many 4620 users.

Table 2: Icons/Background Colors for Features on the 4620/4620SW/4621SW



Description/

Feature Button Display

Icon

Condition

Background Color







None

Feature is on/active.

White

None

Feature is off/inactive.

Light Gray

None

Feature denied (Broken Flutter). This is a temporary condition,

Light Gray



accompanied by an “error beep” on the first occurrence. This





condition then changes to the off/inactive state.



None

Idle. Indicates a (call appearance) line is available.

White



Ringing. Indicates an incoming call is arriving on this line.

White



Active. Indicates the line is in use.

Light Gray



On Hold. Indicates a call is on hold on this line.

Dark Gray



(Soft) Hold. Indicates this line's call was put on hold pending a

Dark Gray



conference or a transfer.





Flash. Used for Call Center operations.

Light Gray



Flutter. Used for Call Center operations.

Light Gray



Wink. Used for Call Center operations.

Light Gray

Issue 3 April 2006 17

Introducing Your 4620/4620SW/4621SW IP Telephone

Four softkeys ( ) appear directly below the display area. They allow you to access the other 4620 applications. In an application, they allow you to perform application-specific functions, like add, save, edit, delete, or cancel. The labels above the softkeys reflect their function relative only to that specific screen.

4620/4620SW/4621SW IP Telephone Applications

Your 4620 IP Telephone provides four applications (Phone, Speed Dial, Call Log, and Web). Additionally, use the Options function to define settings, personalize your phone, and troubleshoot certain functions. All applications appear in the display area, accessed by the softkeys appearing below the display.

A brief description of each application follows.

Phone Application

The Phone application is the primary application. Use this application to make and receive calls, and perform call-handling operations like conference calling or transferring calls to another phone.

Chapter 2: Using Your 4620/4620SW/4621SW IP Telephone provides information on using the Phone application.

Speed Dial Application

The Speed Dial application provides access to the Speed Dial buttons that facilitate automatic dialing. Use this application to:

set up buttons for speed dialing,

update Speed Dial button labels, or

remove the label from a Speed Dial button.

Chapter 3: Using the Speed Dial Application describes how to set up, update and remove labels from Speed Dial buttons. Calling using a Speed Dial button is covered in Chapter 2: Using Your 4620/4620SW/4621SW IP Telephone.

18 4620/4620SW/4621SW IP Telephone User Guide

4620/4620SW/4621SW IP Telephone Applications

Call Log Application

The Call Log application provides three lists, each showing up to 30 outgoing, incoming answered or missed calls. Use this application to call a person directly from the Call Log or to add a log entry’s name and phone number to a Speed Dial button. In addition, you can disable the Call Log for privacy purposes by setting the Call Log Disable option, as described in Chapter 6: 4620/4620SW/4621SW IP Telephone Options.

Chapter 4: Using the Call Log Application covers viewing, deleting log entries, and adding a Call Log entry to a Speed Dial button. Making a call from the Call Log is covered in Chapter 2: Using Your 4620/4620SW/4621SW IP Telephone.

Web Access Application (Optional)

The Web Access application allows you to access Web pages reachable through links from a Home page (and connected pages). This application is optional and is specifically administered by your System Administrator. Depending on the Home page links available, you can browse Corporate intranet sites or browse the World Wide Web.

Chapter 5: Using the Web Access Application covers navigating Web access screens and pages, and provides information about entering text on Web pages. Making a call from the Web Access application is covered in Chapter 2: Using Your 4620/4620SW/4621SW IP Telephone.

4620/4620SW/4621SW Telephone Options

Access the Options function using the Options () button below and to the right of the display area. Using Options menus, you set certain phone parameters, such as display area contrast, how you want the Redial button to work, the language in which information displays, when you want your saved information backed up or restored, or how you want your Feature buttons labeled. You can also view telephone status screens for troubleshooting or information purposes. Chapter 6: 4620/4620SW/4621SW IP Telephone Options covers all options.

Issue 3 April 2006 19

Introducing Your 4620/4620SW/4621SW IP Telephone

Additional 4620/4620SW/4621SW Functionality

Push Feature

Your System Administrator can “push” a Web page, a text message, an audio message, or any combination of those items to your 4620/4620SW/4621SW IP Telephone. Depending on how the pushed material is administered, it may override what is otherwise presented by the telephone. In general, the pushed content is also accompanied by one or more notification tones. Specifically, your System Administrator can:

Use the telephone’s browser to display a specific Web page instead of displaying whatever you were viewing. Alternatively, the System Administrator can have a Web page available in the background, for you to view when you use the Web application. Typically, in this second case, you would generally get a message on the display’s top line alerting you to the waiting Web page.

Present a text message on the top display line. This message may temporarily overwrite whatever is otherwise displayed on the top line.

Present an audio message, even if you are on a call. If you are not on a call, the telephone usually goes off-hook automatically on the Speaker. If you are on a call, the party with whom you are speaking is automatically put on Hold and cannot hear the pushed message. Once you start hearing the pushed message, you can stop listening by selecting a Call Appearance Line (for example, the line you were on when the pushed message came in), going back on-hook, etc. Typically though, pushed audio messages involve emergencies or other important information, and should be listened to. Once a message completes, you can return to your existing call.

Automatic Backup/Retrieval Feature

If your telephone is appropriately administered, (see Backup/Restore Options), you can store your Speed Dial button data, options settings and other personal settings on an FTP (File Transfer Protocol) server in your network. When you log in to any 4620/4620SW/4621SW IP Telephone supporting Release 2.1 or later software, that telephone attempts to retrieve your data from that server. Assuming both the original phone and the second phone are properly administered, this second telephone displays your data and settings, even if you have never used that particular phone before. Your System Administrator has more information about how this feature operates.

If the telephone supports the automatic retrieval procedure described in the previous paragraph, your phone also automatically stores changes you make to associated button data, settings, etc.

20 4620/4620SW/4621SW IP Telephone User Guide

Chapter 2: Using Your 4620/4620SW/4621SW IP Telephone

Introduction

This chapter describes how to make calls, receive calls, retrieve voice mail messages, and log off your 4620/4620SW/4621SW IP Telephone. The telephone Line/Feature buttons that assist in call handling are also covered in this chapter.

Call Appearances

In the Phone application, a call appearance, by default, takes up the entire display width, while administered Feature buttons take up half the display width. When a call appearance is full-width, use the Line/Feature buttons on either side of that row to select that call appearance, and usually, all associated messages. When a call appearance is half-width, for example, the full width default has been changed, use only the Line/Feature buttons on the appropriate side of that row to select that call appearance. In the case of half-width call appearances, call-associated messages show on the top display line instead of on that row. See

Chapter 6: 4620/4620SW/4621SW IP Telephone Options for information about setting the call appearance width.

Depending on how your phone is administered, you might have some blank Line/Feature button labels. Pressing a Line/Feature button associated with a blank label has no effect.

Making Calls

You have several ways of making calls. You can:

lift the handset,

activate a headset if one is connected to your phone,

use the Speaker, or

use an automatic dial feature like speed dial, redial, or abbreviated dialing. This section describes all of these calling methods.

Issue 3 April 2006 21

Using Your 4620/4620SW/4621SW IP Telephone

Note:

You can set an option for whether the Phone screen displays when you make an outgoing call, or whether the current screen remains displayed. See Application Options in Chapter 6: 4620/4620SW/4621SW IP Telephone Options for details.

Manual Dialing

Dial a call manually by picking up the handset, activating your headset, or pressing the Speaker button.

1.Pick up the handset, activate your headset, or press the Speaker button and dial.

If the Phone screen is active, the first available call appearance line displays the off-hook

( ) icon and the background appears shaded.

If the Phone screen is not active, the top display line provides call-related messages. If applicable, the Call Timer displays at the top of the display area.

Note:

Displaying the Call Timer is optional and is set by means of the Options button. See Chapter 6: 4620/4620SW/4621SW IP Telephone Options for information.

2.Use the dialpad to enter the number you want to call.

The number entered displays on the active call appearance line and the 4620 IP Telephone initiates the call.

3.Hang up the handset, deactivate the headset, or press the Speaker button to end the call.

Automatic Dialing

Automatic dialing includes:

redialing a previously called number,

speed dialing a number programmed on a Speed Dial button,

using an administered Abbreviated Dialing Feature button to initiate a call,

dialing a party listed on your Call Log, or

dialing a party from a Web page displayed through the Web Access application.

Note:

The 4620 IP Telephone often receives telephone numbers through the Call Log or Web Access application that are not immediately “dialable.” For example, the Call Log might contain an incoming call from the following U.S. phone number: 732-555-1234. In general, if you try to dial that number as is, the call cannot go

22 4620/4620SW/4621SW IP Telephone User Guide

Making Calls

through - first you have to dial one or more digits to obtain an outside line, access your corporate telephone network, or add some other code before you can return the call. As of Release 1.8, the 4620 IP Telephone can, if appropriately administered, automatically dial those “extra” digits for you. So with one touch, the telephone automatically dials 91-732-555-1234. Your telephone administrator has information on setting up this Enhanced Dialing capability.

If all lines are in use, automatic dialing will not work.

Redialing a party

Depending on how you have set up your Redial option, selecting Redial automatically dials the most recent number dialed, or displays a list of the last six outgoing calls for selection of the number to be dialed. Chapter 6: 4620/4620SW/4621SW IP Telephone Options, covers setting the Redial feature. Both procedures follow.

Note:

Your Telephone Administrator can turn off the Redial feature, or can restrict your phone to dialing only the last number dialed. If the Redial feature is turned off, pressing the Redial button generates an error tone. If the Redial feature is restricted to only the last number dialed, follow the instructions below for redialing the last number called.

Redialing the last number called:

Press the Redial () Feature button.

The last number dialed is automatically redialed.

Redialing using a list of the last six numbers called:

1.Press the Redial () Feature button.

The Redial screen displays the last six unique numbers dialed and the prompt “Select number to dial.” appears at the top of the display.

2.Press the Line/Feature button associated with the number you want to redial.

If the call can be dialed, the Phone application screen displays and the selected number dials automatically.

If the selected number cannot be dialed (for example, if all call appearance lines are currently on Hold), all Redial entries are disabled. If you press a number for redialing while in this state, an error beep tone sounds and no further action occurs.

3.Proceed with the call.

A Call Log entry is created for this call.

Issue 3 April 2006 23

Using Your 4620/4620SW/4621SW IP Telephone

Dialing a party using a Speed Dial button

Automatic dialing of pre-stored numbers is the most common method of automatic dialing. You can set up Speed Dial buttons and select the party you want to call by pressing that button. For information on setting up Speed Dial buttons, see Chapter 3: Using the Speed Dial Application. Because the 4620 IP Telephone’s advanced capabilities allow up to 108 speed dial entries, speed dialing as described here is convenient and efficient.

1.Press the SpDial softkey at the bottom of the display screen.

The first twelve Speed Dial buttons display, one name/number per button, and the prompt “Select entry to dial” appears at the top of the display area.

2.If the party you want to call appears on the display, proceed to Step 3. If the party you want

to call is not shown, press the Page Right ( ) button to display the next page of entries,

Continue until the number/party you want displays. You can also press the Page Left (

)

button to display the preceding page of entries.



3.Press the Line/Feature button associated with the name/number of the person you want to call.

The number of the selected person dials automatically.

4.Pick up the handset, activate the headset, or use the Speaker to proceed with the call.

5. Hang up the handset, deactivate the headset, or press the Speaker (

) button to end

the call.



Automatically dialing a party using an administered Line/Feature button

Your System Administrator can program individual numbers on Line/Feature buttons (this is called Abbreviated Dialing). If so, such numbers display on the Phone application screen (or the Feature Key Expansion Unit, if this optional device is attached to your phone) with labels assigned by the System Administrator.

If the label for the number you want to call appears in the display area, press the appropriate button,

or



Press the Page Right ( ) or Page Left (

) button(s) below the display area until the

label of the party you want to call displays. Then press that button.

The number dials automatically and the screen displays the appropriate call appearance line as active.

Note:

Usually, you can re-label administered Feature buttons as you see fit, as described in Feature Button Labeling on page 70.

24 4620/4620SW/4621SW IP Telephone User Guide

Making Calls

Calling a party from the Call Log

Your 4620 IP Telephone maintains a log of up to 90 outgoing, incoming answered, and incoming unanswered calls to/from your phone. Each log can have up to 30 calls.

1.To call a party listed in the Call Log, press the Log softkey at the bottom of the display area.

The first six missed calls display, one name/number per button, and the prompt “Select entry for details” appears at the top of the display area.

2.If the party you want to call is in a different Call Log, press the softkey that represents the Call Log where that entry appears (either Outgo or InAns).

The selected Call Log displays.

3.If the party you want to call appears, proceed to Step 4. If the party you want to call is not

displayed, press the Page Right (

) button to display the next page of entries. Continue

until the number/party you want displays. You can also press the Page Left (

) button to

display the preceding page of entries.





4.Press the Line/Feature button associated with the name/number of the person you want to call.

The associated Call Detail screen displays.

5.Select Call.

The phone goes off-hook and the selected party’s number is dialed. If the “Phone Screen on Calling” option is set to “Yes” (as described in Chapter 6: 4620/4620SW/4621SW IP Telephone Options) the Phone application screen displays. A Call Log entry is created for this call.

Note:

If your administrator has set up the Enhanced Dialing feature, selecting Call causes the 4620 to automatically add any appropriate digits (such as those required to get an outside line) to phone numbers in the Missed and InAns Call Logs. If you press Call, but the call does not go through, check with your Telephone Administrator to ensure that the Enhanced Dialing feature is set up properly for your environment.

6. Proceed with the call as usual.

See Chapter 4: Using the Call Log Application for more information about the Call Log.

Issue 3 April 2006 25

Using Your 4620/4620SW/4621SW IP Telephone

Calling a party from the Web Access application

Your 4620’s optional Web Access application can automatically dial Web links designated by the Web page author as phone numbers. To call a party using a Web link, just select that link.

Note:

If your administrator has set up the Enhanced Dialing feature, selecting a link to call a party causes the 4620 to automatically add any appropriate digits (such as those required to get an outside line) to phone numbers. If you select a call link, but the call does not go through, check with your Telephone Administrator to ensure that the Enhanced Dialing feature is set up properly for your environment.

Receiving Calls

When someone calls you and the Phone screen is active, the Bell ( ) icon appears as the phone rings and (if so administered) the Voice Message light flashes. When the Phone screen is active, call information displays on the incoming call appearance line. If the Phone screen is not active, call information appears on the top display line.

To receive the call, pick up the handset, activate the headset, or press the Speaker button and talk.

Note:

You can set an option for whether the Phone screen displays when you receive an incoming call, or whether the current screen remains displayed. You can also set an option to flash the Message Waiting Lamp when the phone rings. See Application Options in Chapter 6: 4620/4620SW/4621SW IP Telephone Options for details.

Call Handling Features

The features described in this section are available while calls are in progress. Use the dedicated Feature buttons on the telephone itself, or administered Feature buttons available using the 4620’s softkeys, as applicable.

Note:

Features can also be accessed through an optional Feature Key Expansion Unit, described in Chapter 1: Introducing Your 4620/4620SW/4621SW IP Telephone.

26 4620/4620SW/4621SW IP Telephone User Guide

Call Handling Features

Conference

The Conference feature allows you to conference up to the maximum number of parties set by your System Administrator.

Adding another party to a call

1.Dial the first party, then press the Conference () button.

The line’s display area changes to white text with a dark gray background. The current call is placed on hold, the Soft Hold () icon displays, and you hear a dial tone.

2.Dial the number of the next party and wait for an answer.

3.Press the Conference () button again to add the new party to the call.

4.Repeat Steps 1- 3 for each party you want to conference in to the call.

Adding a held call to the current call

1.Press the Conference () button.

The icon on the current line changes to the Soft Hold () icon.

2.Press the Line/Feature button of the held call.

3.Press the Conference () button again.

All parties are now connected.

Dropping the last person added to the call

Press the Drop ( ) button.

The last party connected to the conference call is dropped from the call.

Hold

The Hold feature puts a call on hold until you retrieve it.

Placing a call on hold

Press the Hold ( ) button.

The line’s display area changes to white text with a dark gray background, and the Hold ( ) icon displays.

Issue 3 April 2006 27
