SOPM-HM65
2nd/3rd Gen Intel® Core™ Open Pluggable Specification
(OPS) Digital Signage Player with Intel® HM65 Chipset
Quick Reference Guide
1st Ed – 20 October 2014
Copyright Notice
Copyright 2014 Avalue Technology Inc., ALL RIGHTS RESERVED.
Part No. E2017SP65A0R
SOPM-HM65
FCC Statement
A Message to the Customer
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/
2 SOPM-HM65 Quick Reference Guide
Quick Reference Guide
3
Content
1. Getting Started ............................................................................................................ 4
1.1 Safety Precautions ................................................................................................ 4
1.2 Packing List ........................................................................................................... 4
1.3 System Specifications ........................................................................................... 5
1.4 System Overview ................................................................................................... 6
1.4.1 Front View .................................................................................................................................... 6
1.5 System Dimensions ............................................................................................... 7
1.5.1 Front & Top view .......................................................................................................................... 7
2. Hardware Configuration ............................................................................................. 8
2.1 Installing Memory & Half size Mini PCI-e device ................................................... 9
2.2 Installing Hard Disk Drive & CPU ........................................................................ 11
SOPM-HM65 Quick Reference Guide
SOPM-HM65
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
1 x SOPM-HM65
1 x DVD-ROM
4 SOPM-HM65 Quick Reference Guide
5
1.3 System Specifications
Component
Mother Board
EPIC board with Intel® HM65 Express Chipset
CPU
Intel® rPGA988 Socket(Socket G2) 2nd/3rd Generation Core™ i7/i5/i3, Pentium®
and Celeron® Processors (Max TDP 35W)
CPU Cooler (Type)
CPU Fan
Memory
One 204-pin DDR3 1333/ 1066 Non-ECC SODIMM, Up to 8GB
Power Supply
The 80-pin right angle blind mate plug connector
(p/n: TX25-80P-LT-H1E)
Adapter
Power: DC IN +12V ~ +19V (from monitor)
Audio
1 x Mic-In, 1 x Line-Out
Wireless LAN
Optional Wireless 802.11 b/g/n (via mini PCI-e or USB)
Expansion Card
1 x Half size Mini PCI-e socket
Storage
Device bay
Support 1 x 2.5” SATA HDD /SSD (7mm)
External I/O
USB Port
2 x USB 2.0 type A
Audio Port
Line-out, Mic-In
LAN Port
1 x Realtek RTL8111E PCI-Express Gigabit Ethernet
SAM connector
2 x SMA connector
Audio code
Realtek ALC661 Audio Codec
Mechanical
Power Type
Single power ATX Support S0, S1, S3, S4, S5
Dimension
200 x 119 x 30mm
Weight
1.9bls (0.86Kgs)
Color
Black
Reliability
EMI Test
CE/FCC Class A
Operating
Temperature
0 ~ 40°C (32 ~ 140°F) (w/HDD), Ambient w/Air Flow
Operating Humidity
-20 ~ 75°C (-4 ~ 167°F)
Storage Temperature
0 ~ 90% Relative Humidity, Non-condensing
Quick Reference Guide
Note: Specifications are subject to change without notice.
SOPM-HM65 Quick Reference Guide
SOPM-HM65
Connectors
Label
Function
Note
MIC IN
Microphone-in audio jack
LINE OUT
Line-out jack
LAN
RJ-45 Ethernet connector
USB
2 X USB 2.0 Type A connectors
1.4 System Overview
1.4.1 Front View
6 SOPM-HM65 Quick Reference Guide
7
(Unit: mm)
1.5 System Dimensions
1.5.1 Front & Top view
Quick Reference Guide
SOPM-HM65 Quick Reference Guide
SOPM-HM65
2. Hardware
Configuration
Note: If you need more information, please visit our website:
http://www.avalue.com.tw
8 SOPM-HM65 Quick Reference Guide
9
2.1 Installing Memory & Half size Mini PCI-e device
Quick Reference Guide
Step1. Remove 8 screws from the bottom of your system.
SOPM-HM65 Quick Reference Guide
SOPM-HM65
Memory
Half size Mini PCI-e card
Step2. Remove the chassis.
Step3.1 Properly install the Memory & Half size Mini PCI-e device and press until properly
seated.
Step3.2 Re-assemble your system back through previous steps to complete the
installation.
10 SOPM-HM65 Quick Reference Guide
11
2.2 Installing Hard Disk Drive & CPU
Quick Reference Guide
Step1. Remove the screws from the top of your system.
Step2. Remove the screws from Hard Disk Drive.
SOPM-HM65 Quick Reference Guide
SOPM-HM65
Step3. Remove the chassis.
Step4. Remove the cooler in order to install CPU.
Step5. Properly install the CPU and press until properly seated.
12 SOPM-HM65 Quick Reference Guide
