Operating Instructions
DCD-PRO210
Professional Dual CD Player
FLIPFLOP
4295 Charter Street
Los Angeles Ca. 90058
www.americandj.com
12/03
CONTENTS |
|
CAUTIONS REGARDING HANDLING................................................................................................. |
3 |
PRODUCT INFORMATION...................................................................................................................... |
5 |
CUSTOMER SUPPORT ......................................................................................................................... |
6 |
SET-UP................................................................................................................................................ |
6 |
FEATURES............................................................................................................................................ |
7 |
FUNCTIONS AND CONTROLS |
|
REMOTE UNIT............................................................................................................................. |
8 |
PLAYER UNIT............................................................................................................................. |
12 |
LIQUID CRYSTAL DISPLAY.................................................................................................................. |
13 |
BASIC OPERATION |
|
LOADING/EJECTING DISC....................................................................................................... |
14 |
SELECTING TRACKS................................................................................................................ |
14 |
STARTING/STOPPING PLAYBACK........................................................................................... |
14 |
ADJUSTING TIME DISPLAY...................................................................................................... |
15 |
PITCH ADJUSTMENTS............................................................................................................. |
15 |
PITCH BENDING....................................................................................................................... |
16 |
PROGRAMMING AND PROGRAM PLAY................................................................................. |
17 |
RELAY (FLIP-FLOP)................................................................................................................... |
18 |
LOOPING.................................................................................................................................. |
18 |
SHUT DOWN PROCEDURES.............................................................................................................. |
19 |
HANDLING COMPACT DISC............................................................................................................... |
19 |
WARRANTY....................................................................................................................................... |
20 |
SPECIFICATIONS............................................................................................................................. |
21 |
Please Note: All specifications and improvements to and in the design of this unit and this manuals are subject to change at any time without any prior written or published noticed.
For service parts visit http://parts.americandj.com
©American Audio® - www.AmericanAudio.us - DCD-PRO210™ Instruction Manual Page 2
ELECTRICAL SAFETY PRECAUTIONS
NOTE: This CD player uses a semiconductor laser. It is recommended for use in a room at the following temperature: 41˚F - 95˚F / 5˚C - 35˚C
CAUTION:
1.Handle the power supply cord carefully. Do not damage or deform; it may cause electric shock or malfunction when used. Hold plug attachment when removing from wall outlet. Do not pull on the cord.
2.To avoid electric shock, do not open the top cover when the unit is plugged in. If problems occur with the unit, call your local American Audio® dealer.
3.Do not place metal objects or spill liquid inside the CD player. Electric shock or malfunction may occur.
The serial and model number for this unit is located on the rear panel. Please write down the numbers here and retain for future reference.
Model No._____________________________
Serial No._____________________________
NOTE: This product satisfies FCC regulations when shielded cables and connectors are used to connect the unit to other equipment. To prevent electromagnetic interference with electrical appliances such as radios and televisions, use shielded cables and connectors for connections.
CAUTION:
USE OF CONTROLS OR ADJUSTMENTS OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE
THE COMPACT DISC PLAYER SHOULD NOT BE ADJUSTED OR REPAIRED BY ANYONE EXCEPT PROPERLY QUALIFIED SERVICE PERSONNEL.
CAUTION: TO PREVENT ELECTRIC SHOCK DO NOT USE THIS (POLARIZED) PLUG WITH AN EXTENSION CORD, RECEPTACLE, OR OTHER OUTLET UNLESS THE BLADES CAN BE CAREFULLY INSERTED TO PREVENT BLADE EXPOSURE
ATTENTION: POUR PREVENIR LES CHOCS ELECTRIQUES NE PAS UTILISER CETTE FICHE POLARISEE AVEC UN PROLONGATEUR, UNE PRISE DE COURANT OU UNE AUTRE SORTIE DE COURANT, SAUF SI LES LAMES PEUVENT ETRE INSEREES A FOND SANS EN LAISSER AUCUNE PARTIE A DECOUVERT.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO WATER OR MOISTURE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
–Reorient or relocate the receiving antenna.
–Increase the separation between the equipment and receiver.
–Connect the unit into an electrical outlet on a circuit different from that to which the receiver is connected.
–Consult the dealer or an experienced radio/ TV technician for help.
©American Audio® - www.AmericanAudio.us - DCD-PRO210™ Instruction Manual Page 3
ELECTRICAL SAFETY PRECAUTIONS
ELECTRICAL PRECAUTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product'senclosurethatmaybeofsufficientmagnitude to constitute a risk of electric shock to persons.
CAUTION: TO REDUCE THE RISK OF ELECTRIC |
The exclamation point within an equilateral triangle is |
SHOCK, DO NOT REMOVE THE COVER (OR BACK). |
intended to alert the user to the presence of important |
THERE ARE NO USER SERVICEABLE PARTS |
operating and maintenance (servicing) instructions in |
INSIDE REFER SERVICE TO YOUR AUTHORIZED |
the literature accompanying the appliance. |
AMERICAN AUDIO® SERVICE TECHNICIAN. |
|
IMPORTANT SAFETY INSTRUCTIONS
READ INSTRUCTIONS —All the safety and operating instructions should be read before the product is operated.
RETAIN INSTRUCTIONS — The safety and operating instructionsshouldberetainedforfuturereference.
HEED WARNINGS — All warnings on the product and in the operating instructions should be adhered to.
FOLLOW INSTRUCTIONS — All operating and use instructions should be followed.
CLEANING— The product should be cleaned only with apolishingclothorasoftdrycloth.Nevercleanwith furniturewax,benzine,insecticidesorothervolatile liquids since they may corrode the cabinet.
ATTACHMENTS — Do not use attachments not recommendedbytheproductmanufacturerasthey may cause hazards.
WATER AND MOISTURE — Do not use this product near water — for example, near a bathtub, wash bowl,kitchensink,orlaundrytub;inawetbasement; or near a swimming pool; and the like.
ACCESSORIES —Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the product. Any mounting of the product should follow the manufacturerʼs instructions, and should use a mounting accessory recommended by the manufacturer.
CART — A product and cart combination should be movedwithcare.Quickstops,excessiveforce,and uneven surfaces may cause the product and cart combination to overturn.
VENTILATION— Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should not be placedin a built-in installationsuch as a bookcaseor rack unless proper ventilation is provided or the manufacturerʼs instructions have been adhered to.
POWERSOURCES—This product should be operated onlyfromthetypeofpowersourceindicatedonthe marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company.
LOCATION – The appliance should be installed in a stable location.
NONUSE PERIODS– The power cord of the appliance should be unplugged from the outlet when left unused for a long period of time.
GROUNDING OR POLARIZATION |
OBJECTANDLIQUIDENTRY- Never push objects of |
• Ifthisproductisequippedwithapolarizedalternating |
any kind into this product through openings as they |
currentlineplug(aplughavingonebladewiderthan |
may touch dangerous voltage points or short-out |
theother),itwillfitintotheoutletonlyoneway.This |
parts that could result in a fire or electric shock. |
isasafetyfeature.Ifyouareunabletoinserttheplug |
Never spill liquid of any kind on the product. |
fullyintotheoutlet,tryreversingtheplug.Iftheplug |
SERVICING — Do not attempt to service this product |
should still fail to fit, contact your electrician to |
yourselfasopeningorremovingcoversmayexpose |
replace your obsolete outlet. Do not defeat the |
you to dangerous voltage or other hazards. Refer all |
safety purpose of the polarized plug. |
servicing to qualified service personnel. |
• If this product is equipped with a three-wire |
DAMAGEREQUIRINGSERVICE - Unplugthisproduct |
groundingtypeplug,aplughavingathird(grounding) |
from the wall outlet and refer servicing to qualified |
pin,itwillonlyfitintoagroundingtypepoweroutlet. |
service personnel under the following conditions: |
Thisisasafetyfeature.Ifyouareunabletoinsertthe |
• When the power-supply cord or plug is damaged. |
plug into the outlet, contact your electrician to |
• If liquid has been spilled, or objects have fallen into |
replace your obsolete outlet. Do not defeat the |
the product. |
safety purpose of the grounding type plug. |
• If the product has been exposed to rain or water. |
POWER-CORD PROTECTION - Power-supply cords |
• Iftheproductdoesnotoperatenormallybyfollowing |
should be routed so that they are not likely to be |
theoperatinginstructions.Adjustonlythosecontrols |
walked on or pinched by items placed upon or |
that are covered by the operating instructions as an |
against them, paying particular attention to cords at |
improper adjustment of other controls may result in |
plugs,conveniencereceptacles,andthepointwhere |
damage and will often require extensive work by a |
they exit from the product. |
qualified technician to restore the product to its |
OUTDOOR ANTENNA GROUNDING — If an outside |
normal operation. |
antennaorcablesystemisconnectedtotheproduct, |
• If the product has been dropped or damaged in any |
be sure the antennaor cablesystem is groundedso |
way. |
astoprovidesomeprotectionagainstvoltagesurges |
• When the product exhibits a distinct change in |
andbuilt-upstaticcharges.Article810oftheNational |
performance — this indicates a need for service. |
ElectricalCode,ANSI/NFPA70,providesinformation |
REPLACEMENT PARTS -- When replacement parts |
with regard to proper grounding of the mast and |
arerequired,besuretheservicetechnicianhasused |
supporting structure, grounding of the lead-in wire |
replacement parts specified by the manufacturer or |
to an antenna discharge unit, size of grounding |
have the same characteristics as the original part. |
conductors, location of antenna-discharge unit, |
Unauthorizedsubstitutionsmayresultinfire,electric |
connection to grounding electrodes, and |
shock, or other hazards. |
requirementsforthegroundingelectrode.SeeFigure |
SAFETY CHECK - Upon completion of any service or |
A. |
repairs to this product, ask the service technician to |
LIGHTNING — For added protection for this product |
performsafetycheckstodeterminethattheproduct |
duringalightningstorm,orwhenitisleftunattended |
is in proper operating condition. |
and unused for long periods of time, unplug it from |
WALLORCEILINGMOUNTING— The product should |
the wall outlet and disconnect the antenna or cable |
not be mounted to a wall or ceiling. |
system. This will prevent damage to the product |
HEAT—Theproductshouldbesituatedawayfromheat |
due to lightning and power-line surges. |
sources such as radiators, heat registers, stoves, or |
POWER LINES —An outside antenna system should |
other products (including amplifiers) that produce |
notbelocatedinthevicinityofoverheadpowerlines |
heat. |
or other electric light or power circuits, or where it |
|
can fall into such power lines or circuits. When |
|
installing an outside antenna system, extreme care |
|
should be taken to keep from touching such power |
|
lines or circuits as contact with them might be fatal. |
|
OVERLOADING — Do not overload wall outlets, |
|
extensioncords,orintegralconveniencereceptacles |
|
as this can result in a risk of fire or electric shock. |
ANTENNA |
|
|
|
LEAD IN |
|
WIRE |
|
GROUND |
|
CLAMP |
|
ANTENNA |
|
DISCHARGE UNIT |
|
(NEC SECTION 810-20) |
ELECTRIC |
GROUNDING CONDUCTORS |
SERVICE |
(NEC SECTION 810-21) |
EQUIPMENT |
GROUND CLAMPS |
|
|
|
POWER SERVICE GROUNDING |
Fig. A |
ELECTRODE SYSTEM |
|
(NEC ART 250, PART H) |
NEC — NATIONAL ELECTRICAL CODE
©American Audio® - www.AmericanAudio.us - DCD-PRO210™ Instruction Manual Page 4
PRODUCT INFORMATION
I. Heat - The CD player should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances (including amplifiers) that produce heat.
2.Do not let insecticides, benzene, or thinner come in contact with the surface of the unit.
3.Never disassemble or modify your unit in any way, doing so will void your manufactures warranty.
4.Never plug this unit in to a dimmer pack
5.Do not attempt to operate this unit if it becomes damaged in any way.
6.This unit is intended for indoor use only, use of this product outdoors voids all warranties.
7.Always mount this unit in safe and stable matter.
8.Disconnect from main power before making any type of connection.
9.Cleaning -
•The CD Player should be cleaned only as recommended by the manufacturer. Use a soft cloth to wipe down the outside of the unit. For stubborn stains moisten a soft cloth with class cleaner or other mild detergent to wipe away any stains. Use a soft cloth to wipe any residual cleaner. Never use volatile cleaners such as benzene, solvent, or thinner to clean your unit, these cleaners will damage the units surface.
•Cleaning the pick-up lens - The pick-up lens should not become dirty under normal usage. If the lens does become dirty, contact American Audio Technical Support for further instructions. Third party lens cleaners available but not highly recommended. Use of some of these cleaner may damage the pickup lens, be sure to follow extreme caution when using these types of cleaners.
This unit has been thoroughly tested and has been shipped in perfect operating condition. Carefully check the shipping carton for damage that may have occurred during shipping. If the carton appears to be damaged, carefully inspect your unit for any damage. Be sure all accessories needed to operate the unit has arrived intact. In the event damage has been found or parts are missing, please contact our toll free customer support number for further instructions. Please do not return the unit to your dealer without first contacting customer support.
LINE VOLTAGE SELECTION
•The desired voltage may be set with the VOLTAGE SELECTOR switch on the rear panel (using a flat head screw driver).
•Do not force the VOLTAGE SELECTOR switch as this may cause damage
•If the VOLTAGE SELECTOR switch does not move smoothly, please contact a qualified service technician.
|
DIGITAL OUT |
|
DIGITAL OUT |
CONNECT TO |
AUDIO OUT |
CONNECT TO |
AUDIO OUT |
REMOTE CONTROL |
|
REMOTE CONTROL |
|
|
2 |
|
1 |
Voltage Line Selector Switch
WARRANTY INFORMATION
The DCD-PRO210™ carries a TWO year (730 days) limited warranty. This warranty covers parts and labor. Please fill out the enclosed warranty card to validate your purchase and warranty. All returned service items whether under warranty or not, must be freight prepaid and accompany a return authorization (R.A.) number. If the unit is under warranty, you must provide a copy of your proof of purchase invoice. Please contact American Audio® customer support at (800) 322-6337 for a R.A. number.
©American Audio® - www.AmericanAudio.us - DCD-PRO210™ Instruction Manual Page 5
CUSTOMER SUPPORT
Customer Support: American Audio® provides a toll free customer support line, to provide set up help and to answer any question should you encounter problems during your set up or initial operation. You may also visit us on the web at www.AmericanAudio.us for any comments or suggestions. For service related issue please contact American Audio®. Service Hours are Monday through Friday 9:00 a.m. to 5:00 p.m. Pacific Standard Time.
Voice: |
(800) 322-6337 |
Fax: |
(323) 582-2941 |
E-mail: |
support@AmericanAudio.us |
Warning! To prevent or reduce the risk of electrical shock or fire, do not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not attempt any repairs yourself, doing so will void your manufactures warranty. In the unlikely event your unit may require service please contact customer support. Please do not return to your dealer without first contacting customer support.
SET-UP
1.Checking the Contents:
Be sure your DCD-PRO210™ was shipped with the following:
1) |
DCD-PRO210™ Dual CD player unit. |
1) DCD-PRO210™ Controller Head Unit |
2) |
Dual Male to Male RCA cable. |
1)Warranty card. |
1)Operating instructions (this booklet).
2.Installing the Units
1)Place your unit on a flat surface or mount it in a secure rack mount case.
2)Be sure the player is mounted in a well ventilated area where it will not be exposed to direct sunlight, high temperatures, or high humidity.
3)Try to place the unit as far as possible from TVs and tuners, as the unit may cause undesirable interference.
3.Connections
1)Be sure main power is connected last to prevent any electrical damage.
2)AUDIO CONNECTIONS: Use the included RCA cable to connect the DCD-PRO210™ outputs to the line inputs of a mixer. Never connect a CD player's output to a mixers "phono" inputs.
CAUTION: Be sure to use the supplied control cables. Using a different type of cable may result in unit damage. To avoid server unit damage, be sure main power is off when connecting the control cables.
CAUTION:
•The player will work normally when the main unit is mounted with the front panel within 15 degrees of the vertical plane. If the unit is tilted excessively, discs may not be loaded or unloaded properly. (Figure 1)
CAUTION:
•The LCD is designed to be clearly visible within the angles shown in Figure 2. Mount the control unit so that the visual angle is within this range.
Figure 1 |
Figure 2 |
©American Audio® - www.AmericanAudio.us - DCD-PRO210™ Instruction Manual Page 6
MAIN FEATURES
• |
Jog Wheel Pitch Bend (b) |
• 8 Times Over Sampling 1 Bit D/A Converter |
• |
Single or Continuous Play |
• 60 Second Transport Protection (a) |
• |
Selectable Time Display |
• Easy Track Programming |
• |
Auto Cue |
• 10+ Track Skipping |
• |
Flip Flop™ (Relay Playback) (d) |
• Fader "Q" Start Control (c) |
• |
4 Different Speed Scans |
• 20 Programmable Tracks |
|
|
• Pitch Display |
(a)60 SECOND TRANSPORT PROTECTION: The CD transport tray will automatically close if left open for more than 60 seconds. If a CD is left in the tray it will immediately cue.
(b)JOG WHEEL PITCH BEND: During normal playback, the inner jog wheel acts as a momentary pitch bend. Turing the wheel in a clockwise direction will increase the speed and turning the wheel in a counter-clockwise direction will decrease the speed.
(c)FADER “Q” START CONTROL: This feature is used in conjunction with American Audio® mixers that also feature “Fader Q Start” control. Connect your DCD-PRO210 as described in the set-up section of this manual. After set-up is completed, insert CD's in to both drives. By moving the mixer’s crossfader from left to right you can start and pause your DCD-PRO210 playback functions. For Example, if your mixer’s crossfader is all the way to the left player one is playing, player two is in cue or pause mode. If slice the fader at least 20% to the right, player one will continue to play and player two will begin to play, mixing both sides together. When the crossfader is slid all the way to the right, player two will is playing, and player one will go into cue or pause mode. You can create great effects similar to scratching with this feature. “Q” Start control is easy to use and mastering this feature will help you create amazing effects with your music.
(d)FLIP-FLOP™: For FLIP-FLOP™ results you must use both disc drives. Connect your DCD-PRO210 as described in the setup section of this manual. This feature will start the next player side once one player side has ended. For example, if disc drive one is playing a disc and it ends, disc drive two will instantly begin to play. You may set FLIP-FLOP™ to play track to track or disc to disc. For more information on this feature, see FLIP-FLOP™ on page 18.
©American Audio® - www.AmericanAudio.us - DCD-PRO210™ Instruction Manual Page 7
