Quick Start Guide
This product meets applicable national SAR limits of 2.0 W/kg. The specific maximum SAR values can be found on page 19 of this user guide.
When carrying the product or using it while worn on your body, either
www.sar-tick.com
use an approved accessory such as a holster or otherwise maintain a distance of 10 mm from the body to ensure compliance with RF exposure requirements. Note that the product may be transmitting even if you are not making a phone call.
The mobile phone is in compliance with the requirement of EN 60950-1: 2006 amendment A12: 2011. There will appear a warning box when the volume level is over 6. If the user selects left soft key in the warning box, the volume can be increased and the phone will repeat the acknowledgement more than once every 20h of cumulative listening time.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use.
1 |
1.1 |
Keys |
Your mobile................... |
Navigation key |
|
|
Confirm an option (press the middle of the key) |
Send call
Access to call log (idle screen)
Power on/off the handset (long press)
End call
Return to idle
Left soft key
Right soft key
Dial the voicemail number (long press)
1 |
8 |
5 |
|
|
2 |
6 |
3
4 |
7 |
1 |
Left soft key |
7 |
Vibration alert |
2 |
Call log (idle screen) |
8 |
Navigation key : |
|
Send call |
|
Menu/Confirm an option |
3 |
Voicemail (long key-press) |
|
Increase volume |
4 |
Lock Key (long press |
|
Reduce volume |
|
key) |
|
New SMS |
5 |
Right soft key |
|
Alarm |
6 |
Power on/Power off |
|
|
|
End call |
|
|
From Idle screen
-Short key-press: enter zero
-Long key-press: input+/p/w, “+” are used for dialing
an international call, “P” and “W” are used for calling the extension.
In Edit mode:
- Short key-press: Input symbol (text edit mode) 0 (add numbers)
From Idle screen
-Short key-press: input *
-Long press: lock keypad In Edit mode:
-Short key-press: change input methods
-Long press *: select writing language
From Idle screen
-Short key-press: input #
-Long key-press: activate/deactivate the vibrator In Edit mode:
-Short key-press: input “
” (space)
1.2Idle screen icons
Battery charge level.
Meeting mode: your phone vibrates, but neither rings nor beeps.
Silence mode: your phone neither rings, beeps nor vibrates.
Flight mode.
Headset connected.
Alarm clock programmed.
Missed calls.
Roaming.
Level of network reception.
Unread SMS.
Unread MMS.
Message full.
Call divert.
2 Getting started ............
2.1Set-up
Removing and installing the back cover
Removing and installing the battery
Inserting and removing TF card
Inserting and removing SIM
Charging the battery
Connect the battery charger to your phone and mains socket respectively.
•The charging may take about 20 minutes to start if the battery is flat.
•Be careful not to force the plug into the socket.
•Make sure the battery is correctly inserted before connecting the charger.
•The mains socket must be near to the phone and easily accessible (avoid electric extension cables).
•When using your telephone for the first time, charge the battery fully (approximately 3 hours). You are advised to fully charge the battery (
).
•To reduce power consumption and energy waste, when battery is fully charged, disconnect your charger from the plug; reduce the backlight time, etc.
The charge is complete when the animation stops.
2.2Power on your phone
Hold down the
key until the phone powers on.
2.3Power off your phone
Hold down the
key from the idle screen.
3 Calls...............................
3.1Making a call
Dial the desired number, press the
key to place the call. If you make a mistake, you can delete the incorrect digits by pressing the
key.To hang up the call, press the
key.
Making an emergency call
If your phone is covered by the network, dial emergency number and press the
key to make an emergency call. This works even without a SIM card and without typing the PIN code or unlocking the keypad.
3.2Calling your voicemail (1)
You can see SIM voice mail in this menu.
3.3Receiving a call
When you receive an incoming call, press the
key to talk and then hang up using the
key.
3.4Available functions during the call
During a call, you can use your directory, short messages, etc. without losing your correspondent.
English - CJB19X0ALAAA
1
4 Camera ...................
This function enables you to take pictures. Press to take the picture.
5 Call log ....................
You can access your call memory by pressing
from the idle screen, or press the
key and select the
icon from the menu.
In this menu, you will see all call history.
6 Games .....................
Two games named Snake and Sokoban were embedded in the phone, for more information please refers to “help” in the game.
7 Tools ........................
7.1Alarm
Your mobile phone has a built-in alarm clock with snooze feature.
7.2Calculator
Press the up, down, left, right and OK key to select +, - ×, ÷ and = respectively.
Press
to delete the figure.
7.3Calendar
Once you enter this menu, there is a monthly-view calendar for you to view the date; you can go to any day you want.
8
IP5000_ALCATEL 2052X_QG_Eng_GB_CE_13_140801.indd 1
2
7.4Bluetooth
You can transfer data, such as music to other device using Bluetooth. Search the device and accept/transfer data. The received data is automatically stored in the directory.
7.5Unit conversion
Unit conversion support weight conversion and length conversion.
7.6Fake call
You can create fake call through this function.
7.7Call filter
Management and preview the whitelist and blacklist, and can enable blacklist, enable whitelist, also can turn off this feature.
7.8Browser
This function enables you to surf the Internet using the mobile phone.
Note: Consulting the local network operator for related fee and specific setup.
7.9Services
STK service is the tool kit of SIM card.This phone supports the service functionThe specific items depend on SIM card and network. Service menu will be automatically added to the phone menu when supported by network and SIM card.
9
(1) Contact your network operator to check service availability.
3 |
4 |
5 |
6 |
7 |
8 Messages .................
8.1Create SMS
From the main menu select “Messages” to create text message. You can type a message send it to a recipient in the SIM card directory. You can type a message, and you're also able to insert a pre-defined message from “Templates”.While writing a message, select “Options” to access all the messaging options.
Specific letters (accent) will increase the size of the SMS, this may cause multiple SMS to be sent to your recipient.
8.2Create MMS
Select Options-Add subject, it will switch to MMS interface automatically.
9 Media ........................ |
|
10 My files.................. |
12 Settings................. |
|
||
9.1 |
Music |
|
The phone provides a certain space for users to manage files and |
From the main menu, select the menu |
and select the function |
|
|
support the memory card. The capacity of the memory card is |
of your choice in order to customize your telephone: Profiles, |
||||
|
|
|
|
|||
Use this function to play audio files. Press |
to play/pause the audio |
selectable.You can use the file manager to conveniently manage various |
Phone settings, Call settings, Network selection, Connectivity, |
|||
player, short press or to last or next audio, in audio player interface, |
directories and files on the phone and the memory card. |
Security and Restore factory setting. |
|
|||
press |
and |
to tune volume. |
|
|
|
|
9.2Videos
Use this funtion to play video files. Press
to play/pause the video player, short press
and
to tune volume; press
or
to last or next video.
9.3FM radio
Your phone is equipped with a radio. You can use the application as a traditional radio with saved channels. In FM radio interface, press
to play/pause the playing process of the current channel, press
and
to tune volume.
9.4Images
You can view images through this funciton.
9.5Recorder
Use this function to record audio files. The phone support WAV, AMR or MP3. The recording file you stopped will be stored in my music list automatically.
11 Contacts ............... |
13 Input mode |
|||
11.1 |
Consulting your contacts |
This mode allows you to type a text by choosing a letter or a sequence |
||
of characters associated with a key. Press the key several times until |
||||
You can access your call memory by pressing from the idle screen, |
the desired letter is highlighted.When you release the key the highlight |
|||
character is inserted into the text. |
||||
or press the |
key and select the icon from the menu. In this |
|||
|
||||
menu, you will see all call history. |
|
|||
11.2 |
Adding a contact |
|
||
Select the menu “Add contacts” then save it to “Phone”, “SIM” as |
|
|||
you like. |
|
|
|
|
ALCATEL is a trademark of Alcatel-Lucent and is used under license by
TCT Mobile Limited.
© Copyright 2014 TCT Mobile Limited
All rights reserved
TCT Mobile Limited reserves the right to alter material or technical specification without prior notice.
