710 D/760 D
Einbau-Flachschirm-Dunstabzugshauben
Build-In Flat-Screen Fume Extractor Hood
Montageund Gebrauchsanweisung Installation and Operating Instructions
Dimensions: |
|
|
|
Height |
Width |
Depth |
(in mm) |
387 |
599 |
275 |
(without screen) |
|
|
|
(20 mm screen) |
Weight: |
|
|
|
Net: 13 kg |
|
|
|
Connection value: |
710D/760D |
|
|
Total connected load: |
190/260W |
|
|
Fan motor: |
|
110/2 x 110 W |
|
Lighting: |
|
1 x 14 W |
|
|
|
(fluoroscent lamp 760D) |
|
|
|
2 X 40 W (sockets for E 14 |
|
|
|
candle bulbs 710 D) |
|
Fan outputs (settings) to DIN 44 971 |
|
||
Lengt of the cable: |
120 cm |
|
|
760 D |
Continuosly |
Intensive |
|
|
variable |
|
|
Exhaust air: |
214 m3/h-358 m3/h |
500 m3/h |
|
Return air: |
125 m3/h-226 m3/h |
268 m3/h |
|
710 D |
Setting 1 |
Setting 2 |
Setting 3 Setting 4 |
Exhaust air: |
151 m3/h |
230 m3/h |
280 m3/h 355 m3/h |
Return air: |
102 m3/h |
166 m3/h |
187 m3/h 216 m3/h |
Exhaust air system 120 mm dia.
The MKZ wallbox and all associated parts are not available in the UK.
Technical data
37
