Safety warnings for electrician
4
Electrical connections
It must be ensured that the voltage and current indicated on the rating plate agree with the voltage of the user to electricity supply.
If the appliance has been equipped with a mains lead with a moulded-on type plug, the following regulations must be comply with:
The plug moulded on to the lead incorporates a fuse. For replacement, use a 5 amp BS1362 fuse. Only ASTA approved or certified fuses should be used. If the fuse cover/carrier is lost, a replacement cover/carrie must be obtained from an electrical goods retailer. If the socket outlets are not suitable for the plug fitted to the appliance, then the plug must be cut off and destroyed for safety reasons, and an appropriate plug be fitted.
When wiring the plug ensure that all strands of wire are securely retained in each terminal. Do not forget to tighten the mains lead clamp on the plug.
Electrical connections
230 V - using fixed power supply line with plug.
240 V - using fixed power supply line (Great Britain).
Fuse rating 13 amps
(The unit should only be connected up by an authorized electrician).
See rating plate for further information.
It is recommended that the socket for the plug is sited above the cooker hood or above the overhead cabinet.
This has 2 advantages:
1)The socket is not visible.
2)The appliance can easily be unplugged when necessary.
If a fixed connection is required the cooker hood should be connected by an electrical installer registered with a competent electricity company. An isolating device is to be provided on the fixed wiring side. Switches with a contact opening of more than 3mm apply as isolating devices.
These include-automatic cut-out switches, fuses and contactors (VDE 0730, s. 7, Part1).
Electrical connection for the UK
The appliance must be connected to fixed wiring with a double pole switched fused spur outlet with or without pilot lamp.
We strongly recommend the appliance to be connected only by a qualified electrician who is a member of the NICEIC who will comply with the IEE and any local regulations.
NOTE:
The terminology “DOUBLE POLE” means that both the live and the neutral supplies are switched and disconnected at the same time.
The terminations labelled SUPPLY are for the connection for the internal house wiring and the terminations labelled LOAD are for the appliance.
IMPORTANT
The wires of the mains lead supplied with this appliance are coloured in accordance with the following code:
Blue-Neutral
Brown-Live
As the colours of the flexible cord of this appliance may not correspond with the coloured markings identifying the terminals in the plug, proceed as follows: The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red.
The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black.
|
BLUE |
BROWN |
|
(NEUTRAL) |
(LIVE) |
|
|
L |
|
|
LOAD |
|
N |
L |
|
SUPPLY |
|
|
LOAD |
|
FUSE |
ON |
DP 13A, 250V |
|
|
|
|
N SUPPLY |
|
Appliances with 2 wires
5
Safety warnings |
|
When the unit is used in its extractor version, a sufficiently large |
for kitchen unit |
|
ventilation hole must be provided, with dimensions that are |
installer |
|
approximately the same as the outlet hole. |
|
|
The air outlet must not be connected to chimney flues or combus- |
|
|
tion gas ducts. The air outlet must under no circumstances be |
|
|
connected to ventilation ducts for rooms in which fuel-burning |
|
|
appliances are installed. |
|
|
It is advisable to apply for authorization from the relevant control- |
|
|
ling authority when connecting the outlet to an unused chimney |
|
|
flue or combustion gas duct. |
|
|
The air outlet installation must comply with the regulations laid |
|
|
down by the relevant authorities. |
|
|
National and regional building regulations impose a number of |
|
|
restrictions on using hoods and fuel-burning appliances con- |
|
|
nected to a chimney, such as coal or oil room-heaters and gas |
|
|
fires, in the same room. |
|
|
The local decree on fuel-burning systems specifies a maximum |
|
|
depression of 0.04 mbar in such rooms. |
|
|
Hoods can only be used safely with appliances connected to a |
|
|
chimney if the room and/or flat (air/environment combination) is |
|
|
ventilated from outside using a suitable ventilation hole approxi- |
|
|
mately 500-600 cm2 large to avoid the possibility of negative |
|
|
pressure being created during operation of the hood. |
|
|
If you have any doubts, contact the relevant controlling authority |
|
|
or building inspector’s office. |
|
|
Since the rule for rooms with out fuel burning appliances is “air |
|
|
inlet should be same size as extractor outlet hole”, an aperture of |
|
|
500-600 cm2, which is to say a larger hole, could reduce the |
|
|
performance of the extractor hood. |
|
|
If the hood is used in its filtering version (carbon filter), it will |
|
|
operate simply and safely in the above conditions without the |
|
|
need for any of the aforementioned measures. |
|
|
When the hood is used in its extractor function, the following rules |
|
|
must be followed to obtain optimal operation: |
|
|
— short and straight outlet hose |
|
|
— minimum number of bends in the outlet hose |
|
|
— Install hoses with an acute angle, always following a gentle |
|
|
curve only |
|
|
— hose as large as possible (100 mm Ø). |
|
|
Failure to observe these basic rules will drastically reduce the |
6 |
|
performance and increase the noise levels of the extractor hood. |
|
