L 98685 FL

EN WASHING MACHINE

USER MANUAL

L 96485 FL





2

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

ACCESSORIES AND CONSUMABLES

In the AEG webshop, you’ll find everything you need to keep all your AEG appliances looking spotless and working perfectly. Along with a wide range of accessories designed and built to the high quality standards you would expect, from specialist cookware to cutlery baskets, from bottle holders to delicate laundry bags…

Visit the webshop at:

www.aeg-electrolux.com/shop

Contents 3

CONTENTS

4 Safety information

6 Environment concerns

7 Product description

8 Accessories

8 Control panel

13 Washing programmes

16 BEFORE FIRST USE

17 Using the appliance

18 Activating the appliance and setting a programme

18 Loading the laundry

19 Using the detergent and additives

21 Starting a programme

22 At the end of programme

22 Helpful hints and tips

24 Care and cleaning

29 Trouble shooter and service

32 Technical data

32 Installation

The following symbols are used in this user manual:

Important information concerning your personal safety and information on how to avoid damaging the appliance.

General information and tips

Environmental information

Subject to change without notice

4 Safety information

SAFETY INFORMATION

Before the installation and use, read this manual carefully:

For your safety and the safety of your property

To help the environment

For the correct operation of the appliance.

Always keep these instructions with the appliance also if you move or give it to a different person.

The manufacturer is not responsible if an incorrect installation and use causes damage.

Children and vulnerable person safety

Do not let persons, children included, with reduced physical sensory, reduced mental functions or lack of experience and knowledge use the appliance. They must have supervision or instruction for the operation of the appliance by a person who is responsible for their safety.

Keep all packaging away from children. There is the risk of suffocation or injury.

Keep all detergents away from children.

Keep children and pets away from the appliance when the door is open.

Before you close the appliance door, make sure that children and pets are not into the drum.

If the appliance has a child safety device, we recommend to activate it.

Child safety device

When you activate this device, you cannot close the door. This prevents children or pets to be closed in the drum. To activate the device, turn it clockwise, until the groove is horizontal. To deactivate the device, turn it counterclockwise, until the groove is vertical.

General safety

Do not use the appliance for professional use. The appliance is only for domestic use.

Do not change the specifications of this appliance. There is the risk of injury and damage to the appliance.

Do not put flammable products or items that are wet with flammable products in, near or on the appliance. Risk of explosion or fire.

Obey the safety instructions on the detergent packaging to prevent burns to eyes, mouth and throat.

Make sure that you remove all metal objects from the laundry. Hard and sharp material can cause damage to the appliance.

Safety information



5





Do not touch the glass of the door while a programme operates. The glass can be hot (only for front-loading appliances).

Care and cleaning

Deactivate the appliance and disconnect the mains plug from the mains socket.

Do not use the appliance without the filters. Make sure that the installation of the filters is correct. An incorrect installation causes water leakages.

Internal lamp

This appliance has an internal lamp that comes on when you open the door and goes off when the door is closed.

WARNING!

Do not look directly into the beam of the lamp.

To replace the internal lamp, contact the service centre.

Disconnect the mains plug from the mains socket before the replacement of the internal lamp.

Installation

The appliance is heavy, be careful when you move it.

Do not transport your appliance without the transit bolts, you can damage internal components and cause leakages or malfunctions.

Do not install and connect a damaged appliance.

Make sure to remove all packaging and transport bolts.

Make sure that the mains plug is disconnected from the mains socket during installation.

Only a qualified person must do the electrical installation, the plumbing and the installation of the appliance. This to prevent the risks of structural damage or injury.

Do not install or use the appliance where the temperature is less than 0 °C.

When you install the appliance on a carpet floor, make sure that there is air circulation between the appliance and the carpet. Adjust the feet to have the necessary space between the appliance and the carpet.

Water connection

Do not connect the appliance with old hoses already used. Only use new hoses.

Make sure not to cause damage to the water hoses.

Do not connect the appliance to new pipes or pipes not used for a long time. Let the water flow for some minutes, then connect the inlet hose.

The first time you use the appliance, make sure that the water hoses and the couplings do not have leakages.

Electrical connection

Make sure that the appliance is earthed.

Make sure that the electrical information on the rating plate agrees with the power supply.

Always use a correctly installed shockproof socket.

6Environment concerns

Do not use multiple plugs and extension cables. There is a risk of fire.

Do not replace or change the mains cable. Contact the service centre.

Make sure not to cause damage to the mains plug and cable.

Connect the mains plug to the mains socket only at the end of the installation. Make sure that there is access to the mains plug after the installation.

Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.

Discard the appliance

1.Disconnect the mains plug from the mains socket.

2.Cut off the mains cable and discard it.

3.Discard the door catch. This prevents children or pets to be closed in the appliance. There is a risk of suffocation (only for front-loading appliances).

ENVIRONMENT CONCERNS

The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local council, your household waste disposal service or the shop where you purchased the product.

Packaging materials

Recycle the materials with the symbol .

Put the packaging in applicable containers to recycle it.

Ecological hints

To help the environment, use less water and energy, obey these instructions:

Set a programme without the prewash phase to wash laundry with normal soil.

Always start a washing programme with the maximum load of laundry.

If necessary, use a stain remover when you set a programme with a low temperature.

To use the correct quantity of the detergent, check the water hardness of your domestic system

Product description



7





PRODUCT DESCRIPTION

1



2



3



9



10

11

4

5

6

12

7

8

13

1Worktop

2Detergent dispenser

3Control panel

4Door handle

5Internal lamp

6Rating plate

7Drain pump

8Feet for the appliance level

9Water drain hose

10Water inlet hose

11Mains cable

12Transit bolts

13Feet for the appliance level

8 Accessories

ACCESSORIES

1

2

1

Spanner







To remove the transit bolts.





2

Plastic caps







To close the holes on the rear side of







the cabinet after the removal of the







transit bolts.





3

Anti-flood inlet hose

4

3



To prevent possible leakage





4

Plastic hose guide

To connect the drain hose on the edge of a sink.

CONTROL PANEL

1







2













3





































































































Glätten

















Koch/Bunt

Gewichtssensor











































Auffrischen

















Extra Leise





























Dampf



























































































































































Energiesparen

















Pflegeleicht













































































































Super Eco

















Leichtbügeln



























Memory 1









20Min. - 3kg

















Feinwäsche



























Memory 2



































































Jeans

















Wolle/Seide















































Spülen

















Daunen

Temp.

U/Min.

Flecken/





Extra



Zeit



Zeit-





















































Start/Pause









































Schleudern/







































Pumpen







Auto Off



Anti-Allergie





Vorw.



Spülen



Sparen



vorwahl

































































































































4

5

12

11

10

9

8

7

6

1Auto Off button

2Programme knob

3Display

4Dampf touch button

5Memory touch buttons

6Start/Pause touch button

7Zeitvorwahl touch button

8Zeit Sparen touch button

9Extra Spülen touch button

10Flecken/Vorwäsche/Einweichen touch button

11Spin reduction touch button (U./Min.))

12Temperature touch button (Temp.)

AEG L 96485 FL User Manual

9

TOUCH SCREEN

Do not wear gloves when you touch the buttons.

Make sure the touch screen and buttons are always clean and dry.

AUTO OFF button 1

Press this button to activate or deactivate the appliance. A tune sounds when the appliance is activated.

The AUTO OFF function automatically deactivates the appliance to decrease energy consumption when:

• Before press button 6 , you do not use the appliance for five minutes. Press button 1 to activate the appliance again.

After 5 minutes from the end of the washing programme. Refer to 'At the end of programme'.

Programme knob 2

Turn this knob to set a programme. The related programme indicator comes on.

Display 3

A B C D

J I H G F E

The text bar:

A• Guides you in the use of the appliance.

Shows the programme status and phase.

Shows alarm messages. Refer to 'Trouble shooter and service' .

The symbols appear on the display when the related phase or function is set.

B



Child lock













Door locked



You cannot open the door when the symbol is on.

C

You can open the door only when the symbol goes off.

If the symbol stays on but the programme is completed:



There is water in the drum.

The ' Rinse Hold ' function is on.

10

The time of the day

When you activate the appliance the display shows the time of the day for some seconds. To adjust the clock, refer to "Clock setting".

The programme duration

When the washing programme starts, the programme time decreases every minute.

Programme duration symbol

The symbol comes on when the digits shows the programme duration.

D • The end time of the washing programme .

Programme end symbol

The symbol comes on when the digits shows the programme end time.

The time of delay

When you set the delayed start the time of the programme end increases by steps of 30 minutes till 10 hours and by steps of one hour till 20 hours.

The end of the programme The display shows a zero.

This part comes on only if the door is open - Refer to 'Loading the laundry'.

The programme maximum load

E The weight of the laundry

The indicator bar fills accordingly to the laundry weight.

The indicator fully fills when you put the maximum load.

If you need to set a function

An empty indicator bar comes on when the related function is available with the set programme. If an indicator bar does not come on, it means that it is not available.

The function symbol comes on when the function is set.

The indicator bar fills accordingly to the set function.

If you make an incorrect selection the text bar on the display tells that the selection is not possible.

Time save

The symbol comes on when you set the following functions:

F Shortened duration

Extra quick

Extra rinsing

G

The indicator bar fills accordingly the numbers of rinses.

11

Stains

Prewash

H

Soak

The indicator bar fills accordingly to the set functions.



The default spin speed of the programme.

I

_ _ _

No spin 1)

Rinse hold

1) Only available for Spin/Drain programme.



The default temperature of the programme.

J

Cold wash



DAMPF BUTTON 4

Touch button 4 to set the steam level. This is possible only with programmes where the steam function is available. The duration of the steam phase changes accordingly to your selection.

MEMORY BUTTONS 5

Touch one of the buttons 5 to memorise a programme or to set a memorised programme. Memorise a programme

1.Press button 1 to activate the appliance.

2.Turn the programme knob ( 2 ) to your favourite programme.

3.If it is necessary, set one or more functions.

4.Touch and hold one of the buttons 5 for some seconds. The buzzer sounds and the display shows that the programme is saved. .

Set a memorised programme

1.Touch the button where you memorised the programme you want to set.

2.The programme indicator comes on and the display shows all the information.

To cancel a memorised programme you can only memorise a new programme.

START/PAUSE BUTTON 6

Touch button 6 to start or interrupt a programme.

ZEITVORWAHL BUTTON 7

Touch button 7 to delay the start of a programme from 30 minutes to 20 hours.

ZEITSPAREN BUTTON 8

Touch button 8 to decrease the programme time.

12

You can select:

SHORTENED DURATION

To wash items with daily soil.

EXTRA QUICK

To wash quickly items with almost no soil.

Some programmes accept only one of these functions.

EXTRA SPÜLEN BUTTON 9

Touch button 9 to add rinsing phases to a programme.

Use this function for persons allergic to detergents and in areas where the water is soft.

FLECKEN, VORWÄSCHE UND EINWEICHEN BUTTON 10

Touch button 10 to set one of the these functions:

FLECKEN

Use this function for laundry with hard stains to remove.

When you set this function, put the stain remover into compartment .

The programme duration increases.

This function is not available with a temperature lower than 40° C.

VORWÄSCHE

Use this function for heavy soil.

The appliance adds a prewash phase to the main wash. The programme duration increases.

EINWEICHEN

Use this function for heavy soil.

The appliance soaks the laundry at 30°C for about half an hour before to wash.

SPIN BUTTON 11

Touch button 11 to:

• Decrease the maximum speed of the spin phase of the programme. The display shows only the spin speeds available with the set programme.

Deactivate the spin phase (' No Spin ' function).

Activate the ' Rinse Hold ' function.

Set this function to prevent fabric creases. The appliance does not drain the water when the programme is completed.

TEMPERATURE BUTTON 12

Touch button 12 to change the default temperature.

Symbols - - - and = cold water

Acoustic signals function

You can hear the acoustic signals when:

You activate the appliance.

You deactivate the appliance.

Loading...
+ 28 hidden pages
