Ultra Bar 9 Introduction
Ultra Bar 9 Features
Unpacking: Thank you for purchasing the Ultra Bar 9 by ADJ Products, LLC. Every Ultra Bar 9 has been thoroughly tested and has been
shipped in perfect operating condition. Carefully check the shipping
carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your xture for any
damage and be sure all accessories necessary to operate the unit has
arrived intact. In the case damage has been found or parts are missing, please contact our toll free customer support number for further
instructions. Do not return this unit to your dealer without rst contacting customer support.
Introduction: The ADJ Ultra Bar 9 is a DMX intelligent, LED bar fix-
ture. This xture can be used in a stand alone mode or connected
in a Master/Slave conguration. This wash has five operating modes:
Sound Active mode, Auto mode, RGB mode, Built-In Program mode,
and DMX control mode.
Customer Support: ADJ Products, LLC provides a customer support
line, to provide set up help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.adj.com for any comments or suggestions. Service Hours are Monday through Friday 8:00 a.m. to 4:30 p.m.
Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@adj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
• Multi-Colors
• Six Operating Modes
• Electronic Dimming 0-100%
• Built in Microphone
• DMX-512 protocol
• 3-Pin DMX Connection
• Seven DMX Modes: 3 Channel Mode, 5 Channel Mode, 6 Channel
Mode, 7 Channel Mode, 8 Channel Mode, 9 Channel Mode, and 11
Channel Mode
• Kling-Net Ready (EZ Kling Box Required) (9 Channel Mode only)
• Magnetic Quick Align
• ADJ RFC compatiable (Not Included)
• Power Cord Daisy Chain (See page 22)
Ultra Bar 9 Warranty Registration
The Ultra Bar 9 carries a 2 year limited warranty. Please fill out the
enclosed warranty card to validate your purchase. All returned service
items whether under warranty or not, must be freight pre-paid and
accompany a return authorization (R.A.) number. The R.A. number
must be clearly written on the outside of the return package. A brief
description of the problem as well as the R.A. number must also be
written down on a piece of paper included in the shipping carton. If
the unit is under warranty, you must provide a copy of your proof of
purchase invoice. You may obtain a R.A. number by contacting our
customer support team on our customer support number. All packages returned to the service department not displaying a R.A. number
on the outside of the package will be returned to the shipper.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures warranty. In the unlikely event your unit may require service please contact
ADJ Products, LLC.
PLEASE recycle the shipping carton when ever possible.
Ultra Bar 9 Installation
The unit should be mounted using a mounting clamp (not provided),
axing it to the mounting bracket that is provided with the unit.
Always ensure that the unit is rmly xed to avoid vibration and slipping while operating. Always ensure that the structure to which you
are attaching the unit is secure and is able to support a weight of 10
times the unit’s weight. Also, always use a safety cable that can hold
12 times the weight of the unit when installing the xture.
The equipment must be installed by a professional, and it must be
installed in a place where it is out of the reach of people’s grasp.
ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 3ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 2
Page 3
Ultra Bar 9 Safety Precautions
Ultra Bar 9 Set Up
• To reduce the risk of electrical shock or re, do not expose this unit
rain or moisture
• Do not spill water or other liquids into or on to your unit.
• Do not attempt to operate this unit if the power cord has been
frayed or broken. Do not attempt to remove or break o the ground
prong from the electrical cord. This prong is used to reduce the risk
of electrical shock and re in case of an internal short.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user
serviceable parts inside.
• Never operate this unit when it’s cover is removed.
• Never plug this unit in to a dimmer pack
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit, if it becomes damaged.
• This unit is intended for indoor use only, use of this product out`
doors voids all warranties.
• During long periods of non-use, disconnect the unit’s main power.
• Always mount this unit in safe and stable matter.
• Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them,
paying particular attention to the point they exit from the unit.
• Cleaning -The fixture should be cleaned only as recommended by
t he manufacturer. See page 23 for cleaning details.
• Heat -The appliance should be situated away from heat sources
such as radiators, heat registers, stoves, or other appliances (inclu d ing amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain or water.
D. The appliance does not appear to operate normally or exhibits a
marked change in performance.
Power Supply: The ADJ Ultra Bar 9 contains a automatic voltage
switch, which will auto sense the voltage when it is plugged into the
power source. With this switch there is no need to worry about the correct power voltage, this unit can be plugged in anywhere.
DMX-512: DMX is short for Digital Multiplex. This is a universal pro-
tocol used as a form of communication between intelligent fixtures
and controllers. A DMX controller sends DMX data instructions from
the controller to the fixture. DMX data is sent as serial data that travels from fixture to fixture via the DATA “IN” and DATA “OUT” XLR terminals located on all DMX fixtures (most controllers only have a DATA
“OUT” terminal).
DMX Linking: DMX is a language allowing all makes and models of
dierent manufactures to be linked together and operate from a single
controller, as long as all xtures and the controller are DMX compliant. To ensure proper DMX data transmission, when using several
DMX fixtures try to use the shortest cable path possible. The order
in which fixtures are connected in a DMX line does not influence the
DMX addressing. For example; a fixture assigned a DMX address of 1
may be placed anywhere in a DMX line, at the beginning, at the end,
or anywhere in the middle. When a fixture is assigned a DMX address
of 1, the DMX controller knows to send DATA assigned to address 1
to that unit, no matter where it is located in the DMX chain.
Data Cable (DMX Cable) Requirements (For DMX Operation):
The Ultra Bar 9 can be controlled via DMX-512 protocol. The Ultra Bar
9 has 7 DMX channel modes, please see pages 9-10 for the dierent
modes. The DMX address is set on the back panel of the Ultra Bar 9.
Your unit and your DMX controller require a standard 3-pin XLR connector for data input and data
output (Figure 1). We recommend Accu-Cable DMX
cables. If you are making your own cables, be sure
to use standard 110-120 Ohm shielded cable (This
cable may be purchased at almost all pro lighting stores). Your cables should be made with a
male and female XLR connector on either end of
the cable. Also remember that DMX cable must be daisy chained and
cannot be split.
Figure 1
ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 4 ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 5
Page 4
Ultra Bar 9 Set Up
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
DMX512
DMX+,DMX-,COMMON
1
2
3
Termination reduces signal errors and
avoids signal transmission problems
and interference. It is always advisable
to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)
and PIN 3 (DMX +) of the last fixture.
POWER
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
and PIN 3 (DMX +) of the last fixture.
Ultra Bar 9 Operating Instructions
Notice: Be sure to follow gures two and three when making your own
cables. Do not use the ground lug on the XLR connector. Do not connect the cable’s shield conductor to the ground lug or allow the shield
conductor to come in contact with the XLR’s outer casing. Grounding
the shield could cause a short circuit and erratic behavior.
COMMON
1
DMX512 IN
3
3-PIN XLR
2
Figure 2
XLR Pin Conguration
1 Ground
3 Hot
Pin 1 = Ground
Pin 2 = Data Compliment (negative)
Pin 3 = Data True (positive)
When longer runs of cable are
Figure 4
Pin 1
Pin 2
Pin 3
Do Not Use
Do Not Use
XLR Male Socket
1 Ground
DMX512 OUT
3-PIN XLR
2 Cold
3 Hot
1
3
2
DMX +
DMX -
XLR Female Socket
2 Cold
Figure 3
Special Note: Line Termination.
used, you may need to use a terminator on the last unit to avoid erratic
behavior. A terminator is a 110-120 ohm 1/4 watt resistor which is connected between pins 2 and 3 of a male XLR connector (DATA + and
DATA -). This unit is inserted in the female XLR connector of the last
unit in your daisy chain to terminate the line. Using a cable terminator
(ADJ part number Z-DMX/T) will decrease the possibilities of erratic
behavior.
5-Pin XLR DMX Connectors.
512 data cables for DATA transmission in place of 3-pin. 5-pin DMX
xtures may be implemented in a 3-pin DMX line. When inserting standard 5-pin data cables in to a 3-pin line a cable adaptor must be used,
these adaptors are readily available at most electric stores. The chart
below details a proper cable conversion.
Conductor 5-Pin XLR Male (In)3-Pin XLR Female (Out)
Ground/Shield
Data Compliment (- signal)
Data True (+ signal)
Not Used
Not Used
ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 6
Termination reduces signal errors and
1
avoids signal transmission problems
3
and interference. It is always advisable
2
to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)
Some manufactures use 5-pin DMX-
3-Pin XLR to 5-Pin XLR Conversion
Pin 1
Pin 2
Pin 3
LED Display On/Off:
To set the LED display to turn off after 20 seconds, press the MODE
and DOWN buttons at the same time. Now the display will disappear
after 20s. Press any button to turn the display on again. To allow the
display to stay On at all times, press the MODE and UP buttons at
the same time.
Operating Modes:
The Ultra Bar 9 has six operating modes:
• Sound-Active mode - The unit will react to sound, chasing through
the built in programs.
• Built-In Program - There are 22 built-in programs to choose from.
• Static Color Mode - There are 35 colors to choose from.
• Auto Mode - A auto program will run with adjustable fade speed.
• RGB Mode - Choose one of the four colors to remain static or
adjust the intensity of each color to make your desired color.
• DMX control mode - This function will allow you to control each
individual fixtures traits with a standard DMX 512 controller.
Static Color Mode:
1. Plug the fixture in and press the MODE button until “C0.XX” is
displayed.
2. There are 35 colors to choose from. Select your desired color by
pressing the UP and DOWN buttons. After you have selected
your desired color you can activate strobing by pressing the SET
UP button to enter the Flash (strobe) mode.
3. “FS.XX” will now be displayed, this is Flash mode. The Flash can
be adjusted between “FS.00” (flash off) to “FS.15” (fastest flash).
RGB Dimmer Mode:
1. Plug the fixture in and press the MODE button until “r.XXX” is dis played. Then press the SET UP button to scroll through RGB col-
ors.
2. When “r.XXX” is displayed you are in Red dimming mode. Press
the UP and DOWN buttons to adjust intensity.
3. When “G.XXX” is displayed you are in Green dimming mode.
Press the UP and DOWN buttons to adjust intensity.
4. When “b.XXX” is displayed you are in Blue dimming mode. Press
the UP and DOWN buttons to adjust intensity.
ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 7
Page 5
Ultra Bar 9 Operating Instructions
Ultra Bar 9 Operating Instructions
5. After you have adjusted the RGB colors to make your desired
color you can then activate strobing by pressing the SET UP but ton to enter the Flash (strobe) mode.
6. “FS.XX” will be displayed, this is Flash mode. The Flash can be
adjusted between “FS.00” (flash off) to “FS.15” (fastest flash).
Built-In Program Mode:
1. Plug the fixture in and press the MODE button until “Pr.XX” is dis played. “XX” represents a number from 1-22. Use the UP or DOWN
buttons to scroll through the 22 programs. Programs 21 and 22
have adjustable colors. Once you have found your desired program
press the SET UP button.
2. Pressing the SET UP button will display “SP.XX”. When this is dis played you can adjust the running speed of your desired program.
Use the UP or DOWN button to adjust the speed between “SP.01”
(slowest) and “SP.99” (fastest). Once you have set your desired run ning speed, you can press the SET UP button to to enter the Fade
adjustment mode.
3. Pressing the SET UP button will display “Fd.XX”. When this is dis played you can adjust the fade speed of your desired program.
Use the UP or DOWN button to adjust the speed between “Fd.01”
(fastest) and “Fd.99” (slowest) or “Fd.00” (Off). Once you have set
your desired fade speed, you can press the SET UP button to to
enter the Flash (Strobe) mode.
4. After pressing SET UP, “FS.XX” will be displayed, this is Flash mode.
The Flash can be adjusted between “FS.00” (flash off) to “FS.15”
(fastest flash).
• PROGRAMS 21 & 22 - If you have chosen programs 21 or 22, after
the Flash mode, press the SET UP button. “C1.XX” will be displayed.
This is the base color, use the UP and DOWN buttons to scroll
through the 7 colors. Once you have chosen your base color, press
the SET UP button again so that “C2.XX” is displayed. This is the
moving color, use the UP and DOWN buttons to scroll through the 7
colors.
Sound Active Mode:
In this mode the Ultra Bar 9 will react to sound, and chase through
the different colors.
1. Plug the fixture in and press the MODE button until “SU.XX” is
displayed. “XX” represents the sound sensitivity level.
2. Use the UP or DOWN buttons to adjust the sound sensitivity.
“SU.00” is off, “SU.01 is the lowest sensitivity, and “SU.31” is the
highest. After adjusting the sound sensitivity, press SET UP if you
wish to activate the Flash mode.
3. “FS.XX” will now be displayed, this is Flash mode. The Flash can
be adjusted between “FS.00” (flash off) to “FS.15” (fastest flash).
Auto Run Mode:
In this mode the Ultra Bar 9 will run a auto program.
1. Plug the fixture in and press the MODE button until “AUTO” is dis-
played.
2. After you have activated Auto Run mode, press the SET UP but ton to adjust the fade time.
3. Once you press SET UP “Fd.XX” should be displayed. Use the UP
or DOWN buttons to set the fade speed to either “Fd.00” (fade
off) or between “Fd.01” (fastest speed) and “Fd.99” (slowest
speed). After adjusting the fade speed, press SET UP if you
wish to activate the Flash mode.
4. “FS.XX” will now be displayed, this is Flash mode. The Flash can
be adjusted between “FS.00” (flash off) to “FS.15” (fastest flash).
DMX Mode:
Operating through a DMX controller gives the user the freedom to
create their own programs tailored to their own individual needs.
This function also allows you to use your fixtures as spot lights. The
Ultra Bar 9 has 7 DMX modes: 3 Channel mode, 5 Channel mode, 6
Channel mode, 7 Channel mode, 8 Channel mode, 9 Channel mode,
& 11 Channel mode. See pages 13-20 for each modes’ DMX traits.
1. This function will allow you to control each individual fixture’s
traits with a standard DMX 512 controller.
2. To run your fixture in DMX mode press the MODE button until
“d.XXX” is displayed. “XXX” represents the current displayed ad dress. Use the UP or DOWN buttons to select your desired DMX
address, then press the SETUP button so that “Ch.XX” is displayed.
3. Use the UP or DOWN buttons to scroll through the DMX Channel
modes. The Channel modes are listed below:
• To run the 3 Channel Mode, press the MODE button until “Ch.03”
is displayed. This is the 3 Channel DMX Mode.
• To run the 5 Channel Mode, press the MODE button until “Ch.05”
ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 9ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 8
Page 6
Ultra Bar 9 Operating Instructions
Ultra Bar 9 Operating Instructions
is displayed. This is the 5 Channel DMX Mode.
• To run the 6 Channel Mode, press the MODE button until “Ch.06”
is displayed. This is the 6 Channel DMX Mode.
• To run the 7 Channel Mode, press the MODE button until “Ch.07”
is displayed. This is the 7 Channel DMX Mode.
• To run the 8 Channel Mode, press the MODE button until “Ch.08”
is displayed. This is the 8 Channel DMX Mode.
• To run the 9 Channel Mode, press the MODE button until “Ch.09”
is displayed. This is the 9 Channel DMX Mode.
9 Channel Mode will work with Kling-Net.
• To run the 11 Channel Mode, press the MODE button until
“Ch.11” is displayed. This is the 11 Channel DMX Mode.
4. Please see pages 13-20 for DMX values and traits.
5. After you have chosen your desired DMX Channel mode plug in
the fixture via the XLR connections to any standard DMX control-
ler.
Default Running Mode:
This is a default running mode. When this mode is activated all modes
will return to their default settings and a Auto program will run.
1. Plug the fixture in and press the MODE and SET UP buttons at the
same time.
ADJ RFC:
This function is used to activate and deactivate the ADJ RFC (Remote
Control). When this function is activated you can control the fixture
using the ADJ RFC. Please see page 12 for ADJ RFC controls and
functions.
1. Plug the fixture in and press the MODE button until “Auto” is dis-
played.
2. Press the SET UP button until “rF.XX” is displayed. “XX” repre sents either “on” or “oF”.
3. Press the UP or DOWN buttons to either activate the remote func tion (On) or deactivate it (Off).
1. Plug the fixture in and press the MODE button until the DMX
address is displayed.
2. Press the SET UP button until “dr-X” is displayed. This is the dim mer setting. “X” represents the dimming mode.
3. Use the UP and DOWN buttons to find your desired dimming
curve. Press SET UP when you are finished.
Ultra Bar 9 Master-Slave Configuration
Master-Slave Configuration:
This function will allows you to link units together to run in a Master-Slave
mode. In Master-Slave operation one unit will act as the controlling unit
and the others will react to the controlling units built-in programs. Any
unit can act as a Master or as a Slave however, only one unit can be programmed to act as the “Master.”
Master-Slave Connections and Settings:
1. Daisy chain your units via the XLR connector on the rear of the unit.
Use standard XLR data cables to link your units together. Remember
that the Male XLR connector is the input and the Female XLR con-
nector is the ouput. The first unit in the chain (master) will use the
female XLR connector only. The last unit in the chain will use the
male XLR connector only.
2. Set the “Master” unit to your desired operating mode and then
connect the “Slave” unit or units.
3. For the “Slave” unit(s) press the MODE button until “SLAu” is dis played. The “Slave” unit(s) will now follow the “Master” unit.
Dimming Curve:
This is used to set the dimming curve used with DMX mode. See
page 22 for the different dimming curves. The dimming curves are in
the order they appear in the unit.
ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 10
ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 11
Page 7
Ultra Bar 9 ADJ RFC Operation
The ADJ RFC remote (sold seperately) has many different functions and allows you to control your Ultra Bar 9 from long distance. The ADJ RFC remote
can control your system up to 150 ft. To use the RFC you must first activate
the fixtures receiver, to activate the receiver please see the instructions on
page 10.
BLACKOUT - Pressing this button will blackout the fixture. Press this button
for more then 3 seconds to activate default running mode. All modes will return to their default settings.
AUTO RUN - This button will run an automatic program. You can control the
fade speed of the Auto Run by pressing the Flash button twice and then adjust the speed using the “+” and “-” buttons. Press the Flash button once to
enter Flash mode and use the “+” and “-” buttons to adjust the Flash speed.
PROGRAM SELECTION - This button will activate 1 of 2 modes; Color Select
mode or Built-In Programs.
1. Press this button to activate Color Static mode. Use the “+” or “-” to scroll
through the 35 colors. Once you have found your color, you can press the
Flash Button to activate strobing and use the “+” or “-” to adjust the Flash
rate.
2. Press this button to enter Built-In Program mode. Use the “+” or “-” to scroll
through the 22 built-in programs. Once you have found your desired program
and you can press the SPEED button and then use the “+” and “-” buttons to
adjust the program speed. You can press the Flash Button to activate strobing and use the “+” or “-” to adjust the Flash rate. Press the Flash button twice
to enter the Fade speed adjustment and use the “+” and “-” buttons to adjust
the Fade speed.
FLASH - This button will activate the flash (strobe) effect. You can control the
flash speed by pressing the “+” and “-” buttons. Pressing this button again
will activate fade mode (if available). You can adjust the fade speed by pressing the “+” and “-” buttons.
Ultra Bar 9 3 Channel Mode
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
Ultra Bar 9 5 Channel Mode
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 STROBING
0 - 15 NOTHING
16 - 255 STROBING SLOW - FAST
5 MASTER DIMMER
0 - 255 0% - 100%
SPEED - Press this button and use the “+” & “-” buttons to adjust the speed
of the Built-In Programs.
SOUND ACTIVE - This button activates sound active mode. Use the “+” & “-”
buttons to adjust the sound sensitivity level.
R G B - Press either one of these buttons and the press the “+” or “-” to adjust the brightness.
“+” and “-” - Use these buttons to adjust the flash rate, speed of the Auto
Run and built in programs, fade speed, sound sensitivity, and output intensity.
Use these buttons to scroll through the static colors and built-In programs.
ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 12 ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 13
Page 8
Ultra Bar 9 6 Channel Mode Ultra Bar 9 7 Channel Mode
Channel Value Function
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 COLOR MACROS
0 - 255 (Please see the color macro chart page 21)
5 STROBING
0 - 15 NOTHING
16 - 255 STROBING SLOW - FAST
6 MASTER DIMMER
0 - 255 0% - 100%
Channels 1, 2, & 3 will not work, when Channel 4 is being used.
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 MASTER DIMMER
0 - 255 0% - 100%
5 STROBING/PROGRAM SPEED/SOUND
SENSITIVITY ADJUSTMENTS
0 - 15 NOTHING
16 - 255 STROBING SLOW - FAST
0 - 255 PROGRAM SPEED SLOW - FAST
0 - 255 SOUND SENSITIVITY LEAST - MOST
6 DIMMING/COLOR MACRO/
PROGRAM MODE/SOUND ACTIVE
0 - 51 DIMMER MODE
52 - 102 COLOR MACRO MODE
103 - 204 PROGRAM MODE
205 - 255 SOUND ACTIVE MODE
7 COLOR MACROS & PROGRAMS
0 - 255 COLOR MACROS
(See the Color Macro Chart on page 21)
0 - 24 PROGRAM 1
25 - 35 PROGRAM 2
36 - 46 PROGRAM 3
47 - 57 PROGRAM 4
58 - 68 PROGRAM 5
69 - 79 PROGRAM 6
80 - 90 PROGRAM 7
91 - 101 PROGRAM 8
102 - 112 PROGRAM 9
113 - 123 PROGRAM 10
ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 14 ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 15
Page 9
Ultra Bar 9 7 Channel Mode
Channel Value Function
Ultra Bar 9 8 Channel Mode
Channel Value Function
7 PROGRAMS CONT.
124 - 134 PROGRAM 11
135 - 145 PROGRAM 12
146 - 156 PROGRAM 13
157 - 167 PROGRAM 14
168 - 178 PROGRAM 15
179 - 189 PROGRAM 16
190 - 200 PROGRAM 17
201 - 211 PROGRAM 18
212 - 222 PROGRAM 19
223 - 233 PROGRAM 20
234 - 244 PROGRAM 21
245 - 255 PROGRAM 22
When Channel 7 is between the values of 234 - 255 (Programs 21
& 22), Channel 3 will let you select a ow color, and Channel 4 will
let you select a base color. Channel 5 will control the speed of the
ow color. See the Color Macro Chart on page 26 to select your
ow color and base color.
When Channel 6 is between the values of 0-51, Channels 1-3 are
used, and Channel 5 will control strobing.
When Channel 6 is between the values of 52-102, Channel 7 is in
Color Macros Mode, and Channel 5 will control strobing.
When Channel 6 is between the values of 103-204, Channel 7 is in
Program Mode, and Channel 5 will control the program speed.
When Channel 6 is between the values of 205-255, Channel 7 is in
Sound Active Mode, and Channel 5 will control the sound sensi-
tivity.
ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 16 ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 17
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 0 - 255 COLOR MACROS
(See the Color Macro Chart on page 21)
5 PROGRAMS
0 - 15 NO FUNCTION
16 - 25 PROGRAM 1
26 - 35 PROGRAM 2
36 - 45 PROGRAM 3
46 - 55 PROGRAM 4
56 - 65 PROGRAM 5
66 - 75 PROGRAM 6
76 - 85 PROGRAM 7
86 - 95 PROGRAM 8
96 - 105 PROGRAM 9
106 - 115 PROGRAM 10
116 - 125 PROGRAM 11
126 - 135 PROGRAM 12
136 - 145 PROGRAM 13
146 - 155 PROGRAM 14
156 - 165 PROGRAM 15
166 - 175 PROGRAM 16
176 - 185 PROGRAM 17
186 - 195 PROGRAM 18
196 - 205 PROGRAM 19
206 - 215 PROGRAM 20
216 - 225 PROGRAM 21
226 - 235 PROGRAM 22
236 - 245 AUTO RUN
246 - 255 SOUND ACTIVE
Page 10
Ultra Bar 9 8 Channel Mode
Channel Value Function
Ultra Bar 9 9 Channel Mode
Channel Value Function
6 PROGRAM SPEED/SOUND SENSITIVE
0 - 255 PROGRAM SPEED SLOW - FAST
0 - 255 SOUND SENSITIVITY
LEAST SENSITIVE - MOST SENSITIVE
7 STROBING
0 - 15 NOTHING
16 - 255 STROBING SLOW - FAST
8 MASTER DIMMER
0 - 255 0% - 100%
When Channel 5 is between the values of 216 - 235 (Programs 21
& 22), Channel 3 will let you select a ow color, and Channel 4 will
let you select a base color. Channel 6 will control the speed of the
ow color. See the Color Macro Chart on page 26 to select your
ow color and base color.
When Channel 4 is being used, Channels 1-3 will not function.
When Channel 5 is between the values of 16-245, Channel 6 will
control the program speed.
When Channel 6 is between the values of 246-255, Channel 6 will
control the sound sensitivity.
1 RED 1-3
0 - 255 0% - 100%
2 GREEN 1-3
0 - 255 0% - 100%
3 BLUE 1-3
0 - 255 0% - 100%
4 RED 4-6
0 - 255 0% - 100%
5 GREEN 4-6
0 - 255 0% - 100%
6 BLUE 4-6
0 - 255 0% - 100%
7 RED 7-9
0 - 255 0% - 100%
8 GREEN 7-9
0 - 255 0% - 100%
9 BLUE 7-9
0 - 255 0% - 100%
ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 18 ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 19
Page 11
Ultra Bar 9 11 Channel Mode Ultra Bar 9 Color Macro Chart
Channel Value Function
1 RED 1-3
0 - 255 0% - 100%
2 GREEN 1-3
0 - 255 0% - 100%
3 BLUE 1-3
0 - 255 0% - 100%
4 RED 4-6
0 - 255 0% - 100%
5 GREEN 4-6
0 - 255 0% - 100%
6 BLUE 4-6
0 - 255 0% - 100%
7 RED 7-9
0 - 255 0% - 100%
8 GREEN 7-9
0 - 255 0% - 100%
9 BLUE 7-9
0 - 255 0% - 100%
10 STROBING
0 - 15 NOTHING
16 - 255 STROBING SLOW - FAST
11 MASTER DIMMER
0 - 255 0% - 100%
COLOR
BASTARD AMBER
MEDIUM AMBER
PALE AMBER GOLD
GALLO GOLD
GOLDEN AMBER
LIGHT RED
MEDIUM RED
MEDIUM PINK
BROADWAY PINK
FOLLIES PINK
LIGHT LAVENDER
SPECIAL LAVENDER
LAVENDER
INDIGO
HEMSLEY BLUE
TIPTON BLUE
LIGHT STEEL BLUE
LIGHT SKY BLUE
SKY BLUE
BRILLIANT BLUE
LIGHT GREEN BLUE
BRIGHT BLUE
PRIMARY BLUE
CONGO BLUE
PALE YELLOW GREEN
MOSS GREEN
PRIMARY GREEN
DOUBLE CTB
FULL CTB
HALF CTB
DARK BLUE
WHITE
FULL RED
FULL GREEN
RED
255 206 143
254 177 153
254 192 138
254 165 98
254 121 0
176 17 0
96 0 11
234 139 171
224 5 97
175 77 173
119 130 199
147 164 212
88 2 163
0 38 86
0 142 208
52 148 209
1 134 201
0 145 212
0 121 192
0 129 184
0 83 115
0 97 166
1 100 167
0 40 86
209 219 182
42 165 85
0 46 35
8 107 222
107 156 231
165 198 247
0 0 189
255
255 0 0
0 0255
0 0 255FULL BLUE
GREEN
255 255
BLUE
ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 20 ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 21
Page 12
Ultra Bar 9 Photo Metric Chart
Ultra Bar 9 Dimming Curves
Ultra Bar 9 Fuse Replacement
Disconnect the unit from its power source. Remove the power cord
from the unit. Once the cord has been removed, you will find that the
fuse holder is located inside the power socket. Insert a flat-head screw
driver into the power socket and gently pry out the fuse holder. Remove
the bad fuse and replace with a new one. The fuse holder also has a
holder for a spare fuse.
Ultra Bar 9 Trouble Shooting
Listed below are a few common problems the user may encounter,
with solutions.
Unit not responding to DMX:
1. Check that the DMX cables are connected properly and are
wired correctly (pin 3 is “hot”; on some other DMX devices
pin 2 may be ‘hot’). Also, check that all cables are connected
to the right connectors; it does matter which way the inputs
and outputs are connected.
Unit does not respond to sound:
1. Quiet or high pitched sounds will not activate the unit.
2. Make sure that Sound Active mode is activated.
Ramp Effect
Standard
Stage
TV
Architectural
Theatre
(Fade Time) (Fade Time)
Ultra Bar 9 Power Cord Daisy Chain
With this feature you can connect the xtures to one another
using the IEC input and output sockets. The quantity that can be
connected is 15 xtures maximum. After 15 xtures you will need
to use a new power outlet. They must be the same xtures. DO
NOT mix xtures.
ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 22
Ultra Bar 9 Cleaning
Due to fog residue, smoke, and dust cleaning the internal and external optical lenses must be carried out periodically to optimize light
output.
1. Use normal glass cleaner and a soft cloth to wipe down the
outside casing.
2. Clean the external optics with glass cleaner and a soft cloth
every 20 days.
3. Always be sure to dry all parts completely before plugging
the unit back in.
Cleaning frequency depends on the environment in which the fixture
operates (i.e. smoke, fog residue, dust, dew).
ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 23
Page 13
Ultra Bar 9 Warranty
MANUFACTURER’S LIMITED WARRANTY
A. ADJ Products, LLC hereby warrants, to the original purchaser, ADJ Products, LLC products
to be free of manufacturing defects in material and workmanship for a prescribed period from
the date of purchase (see specific warranty period on reverse). This warranty shall be valid only if the
product is purchased within the United States of America, including possessions and
territories. It is the owner’s responsibility to establish the date and place of purchase by acceptable
evidence, at the time service is sought.
B. For warranty service you must obtain a Return Authorization number (RA#) before sending back the
product–please contact ADJ Products, LLC Service Department at 800-322-6337. Send the product
only to the ADJ Products, LLC factory. All shipping charges must be pre-paid. If the requested repairs or
service (including parts replacement) are within the terms of this warranty, ADJ Products, LLC will pay
return shipping charges only to a designated point within the United States. If the entire instrument is
sent, it must be shipped in it’s original package. No accessories should be shipped with the product. If
any accessories are shipped with the product, ADJ Products, LLC shall have no liability whatsoever for
loss of or damage to any such accessories, nor for the safe return thereof.
C. This warranty is void if the serial number has been altered or removed; if the product is modified in any
manner which ADJ Products, LLC concludes, after inspection, affects the reliability of the product; if the
product has been repaired or serviced by anyone other than the ADJ Products, LLC factory unless prior
written authorization was issued to purchaser by ADJ Products, LLC; if the product is damaged because
not properly maintained as set forth in the instruction manual.
D. This is not a service contract, and this warranty does not include maintnance, cleaning or periodic check
up. During the period specified above, ADJ Products, LLC will replace defective parts at its expense
with new or refurbished parts, and will absorb all expenses for warranty service and repair labor by
reason of defects in material or workmanship. The sole responsibility of ADJ Products, LLC under this
warranty shall be limited to the repair of the product, or replacement thereof, including parts, at the sole
discretion of ADJ Products, LLC. All products covered by this warranty were manufactured after August
15, 2012, and bear indentifying marks to that effect.
Ultra Bar 9 Notes
E. ADJ Products, LLC reserves the right to make changes in design and/or improvements upon its products
without any obligation to include these changes in any products theretofore manufactured.
No warranty, whether expressed or implied, is given or made with respect to any accessory supplied with
products described above. Except to the extent prohibited by applicable law, all implied warranties made
by ADJ Products, LLC in connection with this product, including warranties of merchantability or fitness,
are limited in duration to the warranty period set forth above. And no warranties, whether expressed or
implied, including warranties of merchantability or fitness, shall apply to this product after said period
has expired. The consumer’s and/or Dealer’s sole remedy shall be such repair or replacement as is
expressly provided above; and under no circumstances shall ADJ Products, LLC be liable for any loss or
damage, direct or consequential, arising out of the use of, or inability to use, this product.
This warranty is the only written warranty applicable to ADJ Products, LLC Products and
supersedes all prior warranties and written descriptions of warranty terms and conditions heretofore
published.
MANUFACTURER’S LIMITED WARRANTY PERIODS:
•LightingProducts=1-year(365days)LimitedWarranty(Such as: Special Effect Lighting, Intelligent
Lighting, UV lighting, Strobes, Fog Machines, Bubble Machines, Mirror Balls, Par Cans, Trussing,
Lighting Stands etc. excluding LED and lamps)
•LaserProducts=90-DayLimitedWarranty
•L.E.D.Products=2-year(730days)LimitedWarranty(excluding motors, PCB boards, and power
supplies, which have a 1-year (365 day Limited Warranty) and batteries which have a 180 day
limited warranty).
ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 25ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 24
Page 14
Ultra Bar 9 Specifications
Model:
Voltage: 100V ~ 240V/50~60Hz
LEDs: 9 x 3W TRI LED’s
Beam Angle: 40 Degrees
Working Position: Any safe working position
Power Draw: 35W
Power Cord Daisy Chain: 15 Fixtures Max.
Fuse: 2 Amp
Weight: 6lbs./ 2.6Kgs.
Dimensions: 41.75” (L) x 2.5” (W) x 3.5” (H)
1060 x 63 x 90mm
Colors: RGB Color Mixing
DMX Channels: 7 DMX Modes: 3 Channel Mode,
5 Channel Mode, 6 Channel Mode,
7 Channel Mode, 8 Channel Mode,
9 Channel Mode, & 11 Channel
Mode
Warranty: 2 Year (730 days) Limited Warranty
Ultra Bar 9
Auto Sensing Voltage: This xture contains a automatic volt-
age switch, which will auto sense the voltage when it is plugged
into the power source.
Please Note: Specications and improvements in the design of
this unit and this manual are subject to change without any prior
written notice.
ADJ Products, LLC
6122 S. Eastern Ave. Los Angeles, CA 90040 USA
Tel: 323-582-2650 / Fax: 323-725-6100
Web: www.adj.com / E-mail: info@americandj.com
ADJ Products, LLC - www.adj.com - Ultra Bar 9 User Manual Page 26
A.D.J. Supply Europe B.V.
Junostraat 2
6468 EW Kerkrade
Netherlands
service@adjgroup.eu / www.adj.com
Tel: +31 45 546 85 00 / Fax: +31 45 546 85 99
Loading...
