3COM WL-305 User Manual

11 Mbps Wireless LAN

PC Card User Guide

Full featured wireless local area networking made simple.

Version 2.0

http://www.3com.com/

http://support.3com.com/warrantyregistration/register.pl

Published March 2001

Version 2.0.1

3Com Corporation ■ 5400		Copyright © 2001, 3Com Corporation. All rights reserved. No part of this documentation may be
Bayfront Plaza ■	Santa	reproduced in any form or by any means or used to make any derivative work (such as translation,
Clara, California	■	transformation, or adaptation) without written permission from 3Com Corporation.

95052-8145

3Com Corporation reserves the right to revise this documentation and to make changes in content from time to time without obligation on the part of 3Com Corporation to provide notification of such revision or change.

3Com Corporation provides this documentation without warranty, term, or condition of any kind, either implied or expressed, including, but not limited to, the implied warranties, terms or conditions of merchantability, satisfactory quality, and fitness for a particular purpose. 3Com may make improvements or changes in the product(s) and/or the program(s) described in this documentation at any time.

If there is any software on removable media described in this documentation, it is furnished under a license agreement included with the product as a separate document, in the hard copy documentation, or on the removable media in a directory file named LICENSE.TXT or !LICENSE.TXT. If you are unable to locate a copy, please contact 3Com and a copy will be provided to you.

UNITED STATES GOVERNMENT LEGEND

If you are a United States government agency, then this documentation and the software described herein are provided to you subject to the following:

All technical data and computer software are commercial in nature and developed solely at private expense. Software is delivered as “Commercial Computer Software” as defined in DFARS 252.227-7014 (June 1995) or as a “commercial item” as defined in FAR 2.101(a) and as such is provided with only such rights as are provided in 3Com’s standard commercial license for the Software. Technical data is provided with limited rights only as provided in DFAR 252.227-7015 (Nov 1995) or FAR 52.227-14 (June 1987), whichever is applicable. You agree not to remove or deface any portion of any legend provided on any licensed program or documentation contained in, or delivered to you in conjunction with, this User Guide.

Unless otherwise indicated, 3Com registered trademarks are registered in the United States and may or may not be registered in other countries.

3Com, AirConnect, and XJACK are registered trademarks and the 3Com logo is a trademark of 3Com Corporation.

Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation. Wi-Fi is a trademark of the Wireless Ethernet Compatibility Alliance.

All other company and product names may be trademarks of the respective companies with which they are associated.

EXPORT RESTRICTIONS: This product or software contains encryption code which may not be exported or transferred from the US or Canada without an approved US Department of Commerce export license.

CONTENTS

1 INTRODUCTION

	How Does a Wireless LAN Work?					5
	Network Association			5
	Roaming	5
	Security	5
	Ad Hoc Networks			5
	Setting Up a 3Com Wireless LAN					6
	All Wireless Networks 6
	Wired/Wireless Networks				6
	Product Registration and Support					7
2 INSTALLING THE WIRELESS CLIENT
	Requirements	9
	Disk Factory	9
	Inserting the PC Card			10
	Installing the Software			11
	Windows Wizard Installation				11
	Install Files	11
	Set Up the PC Card			12
	Install Utilities		12
	Windows NT Installation with Networking Installed							12
	Install Files	13
	Install CardWizard			13
	Set Up the PC Card			14
	Install Utilities		14
	Confirming the Installation				15
	Using the XJACK Antenna				15
	Custom Installation Options				16
	WLAN Service Area			16
	Security Settings		16
	40-bit Shared Key (Wi-Fi) Encryption						16
	128-bit Dynamic Security Link Authentication							17
	Installing the Documentation				17
3 USING THE WIRELESS LAN
	About the 3Com Icon			20
	Interpreting Status Icons			20
	Using the 3Com WLAN Configuration Utility						21

4 SETTING THE WIRELESS CLIENT CONFIGURATION

	Changing Network and Security Settings					23
	Network Settings	23
	Security Settings	24
	40-bit Shared Key (Wi-Fi) Encryption Settings 24
	128-bit Dynamic Security Link Settings						25
	Setting up Auto Network Connect				25
	Setting up an Ad Hoc Network			26
	Starting an Ad Hoc Network Session					26
	Joining an Ad Hoc Network Session					27
	Ending an Ad Hoc Network Session					27
	Changing Power, Traffic, and Address Settings						27
	Changing Your Password		28
	Running Diagnostics	29
	Viewing Configuration Information				29
5 TROUBLESHOOTING
	Diagnosing Problems	31
	Using the Tools Window		32
	Uninstalling the Card	33
	Uninstalling Software Utilities			34
	Upgrading PC Card Firmware			34

A WINDOWS NT INSTALLATION WITHOUT NETWORKING INSTALLED

	Install Files and Networking		35
	Install CardWizard	36
	Set Up the PC Card	37
	Install Utilities 37
B TECHNICAL SUPPORT
	Online Technical Services		39
	World Wide Web Site		39
	3Com Knowledgebase Web Services			39
	3Com FTP Site	39
	Support from Your Network Supplier			40
	Support from 3Com	40
	Returning Products for Repair 42

REGULATORY COMPLIANCE INFORMATION

3COM END USER SOFTWARE LICENSE AGREEMENT

INTRODUCTION

1

3Com wireless technology brings the benefits of a local area network (LAN) to your office without the restraints and expense of network wiring. If your office already has an Ethernet LAN, the 3Com 11 Mbps Wireless LAN can extend the network without adding more wires.

How Does a Wireless In a traditional LAN, computers communicate through wires. Instead of wires, a LAN Work? wireless LAN uses radio signals to communicate.

Network Association Computers that are equipped for wireless LAN communication are called wireless LAN clients. The wireless communication is called network association. Clients associate through one or more access points, which are wireless base stations that act as wireless hubs.

An access point can be connected to a wired network device such as an Ethernet hub, switch, or router to give clients access to the wired network where they can share files and printers and gain access to the Internet.

Roaming If the office space is large, you can set up multiple access points on the same network to increase coverage. When a wireless client begins to lose the signal as it moves away from an access point, it can reassociate seamlessly with another access point. This is called roaming.

Security You can set up security to encrypt your wireless transmissions so that your data cannot be deciphered if it is intercepted, and to prevent access to the network by unauthorized clients.

Ad Hoc Networks Wireless clients can associate among themselves at close range without an access point by using ad hoc (temporary) networks. You may wish to set up an ad hoc network, for example, if a group is working away from the office, or if a group in the office needs to share files apart from the LAN.

6 CHAPTER 1: INTRODUCTION

Setting Up a 3Com The type of network you decide to set up depends on the size of your office and Wireless LAN whether or not you require connection to a wired LAN. You can also set up

security for each of the different types of networks. Your set up will probably resemble one or more of the following examples.

All Wireless Networks The simplest 3Com wireless LAN consists of several clients associating in an ad hoc network without an access point.

A simple configuration consists of one access point and several clients. The clients can associate with the wireless network anywhere within the coverage area of the access point. The access point is not connected to any other network segments.

For more complex requirements, you can configure several access points as separate networks at the same site. The access points use different network identifiers called wireless LAN service areas (WLAN service areas, also called

Extended Service Set Identities or ESSID). Clients can roam within the coverage areas of access points that have the same WLAN service areas. They cannot roam to the coverage areas of access points that are configured with different WLAN service areas.

Wired/Wireless An access point can be connected to a wired LAN with an Ethernet cable to create Networks a mixed wired/wireless network. In this configuration, the access point provides

the link between the wired network and wireless clients. Clients can move freely throughout the service area of the access point and remain associated with the larger network for services such as printing and Internet access.

Multiple access points can be connected to an existing LAN to provide complete wireless network coverage. Wireless clients can roam seamlessly between different access points with the same WLAN service areas and remain associated with the larger network.

Product Registration and Support

7

Product Registration To register your product with 3Com, go to the following Web page: and Support

http://support.3com.com/warrantyregistration/frontpg.pl

For support information, see “Technical Support” on page 39 and go to the following Web page:

http://support.3com.com

INSTALLING THE WIRELESS CLIENT

2

Installing a wireless client consists of inserting the 3Com Wireless LAN PC Card with XJACK® Antenna in your computer and installing the software driver and utilities. If you have 3Com Administrator Utilities installed on a wireless client, you can manage access points or run a site survey.

Requirements	Before you start the installation, make sure that you have the following items:
	Operating System	One of the following:
		■	Windows 95
			The 3Com wireless LAN PC Card runs under Windows 95 version B
			or higher. If you do not know which version of Windows 95 is
			installed on your computer, you can display it as follows:
			In the Control Panel, double-click System to display the System
			Properties dialog box. Click the General Tab to display the
			Windows 95 version information. Version B (also known as OSR 2)
			is identified as 4.00.950b.
		■	Windows 98
		■ Windows Millennium Edition (Windows Me)
		■ Windows NT with Service Pack 4 or above
		■	Windows 2000
	Web Browser	Internet Explorer version 4 required.
		Internet Explorer version 5.5 recommended.
		You can download Internet Explorer from www.microsoft.com
	PC Card	3Com 11 Mbps Wireless LAN PC Card with XJACK Antenna
	Installation Media	One of the following 3Com CDs:
		■ 3Com End User Utilities CD, which comes with the PC Card and
			contains utilities for users.
		■ 3Com Administrator Utilities CD, which comes with the 3Com
			11 Mbps Wireless LAN Access Point and contains utilities for users
			and tools for administrators.
	Other	■ The installation program may ask for the operating system
	Requirements		installation media (usually a CD supplied with your computer) or for
			a path to the operating system files. If you have other networking
			software installed on your computer, the installation program may
			ask for its installation media.
		■ If you need to install from diskettes, see “Disk Factory”.
Disk Factory	If you are installing the software on a computer that does not have a CD-ROM
	drive, or if you choose to install the drivers manually, you will have to make
	diskettes from the 3Com CD. The setup application includes Disk Factory, a utility
	for creating disks from CD. To use disk factory, you need access to a computer

10 CHAPTER 2: INSTALLING THE WIRELESS CLIENT

with a CD-ROM drive and a floppy drive and eight or more diskettes. Make sure you have enough diskettes on hand.

1For the driver software, prepare a diskette labeled Drivers.

For the rest of the software, label diskettes numerically (Disk 1, Disk 2, Disk 3...).

2Put the 3Com CD in the CD-ROM drive. The setup program should start automatically. If it does not start, you can run it manually by selecting Run from the Start menu and specifying the srsetup.exe program (for example, d:\srsetup.exe).

3In the 3Com 11 Mbps Wireless LAN menu, click Tools and Utilities.

4In the Tools and Utilities menu, click Create Installation Diskettes.

5In the Disk Factory window, click Next.

6Select the software you want to transfer to diskette. The Disk Factory displays the number of diskettes that will be required. Make sure you have that number of diskettes.

7Select the action (for example, Create and Verify Disks), specify the destination location, and click Next.

Follow the prompts on the screen.

If you are installing the drivers manually, use the Drivers diskette when the setup wizard for your operating system prompts for drivers supplied by the manufacturer.

When you are ready to install the application software from diskette, put

3Com 11 Mbps Wireless LAN Application Disk 1 in the floppy drive and run the setup.exe program.

Inserting the PC Card

1Turn on the computer.

2Insert the 3Com PC Card into the PC Card slot until it seats snugly.

Arrows on the front of the card indicate the insertion point to the slot. Align the card properly before inserting it in the slot.

CAUTION: Forcing the card into the slot can damage the computer or the card.

		Installing the Software 11
Installing the	Depending on how your computer is set up, the installation program may ask for
Software	the operating system installation media (usually a CD supplied with your
	computer) or for a path to the operating system files. If you have other
	networking software installed on your computer, the installation program may ask
	for the networking software installation media. Make sure that you have the
	appropriate installation CDs or that you know the appropriate paths before you
	begin installing the software.
	If you need help during the installation, see “Troubleshooting” on page 31.
	Follow the instructions for your operating system:
	For this Windows version: See this procedure:
	Windows 2000, Windows	“Windows Wizard Installation” on page 11
	Millennium Edition
	(Windows Me),
	Windows 98, Windows 95
	Windows NT	“Windows NT Installation with Networking Installed” on
		page 12 or “Windows NT Installation Without Networking
		Installed” on page 35.
Windows Wizard	Make sure that the computer is running and the PC Card is inserted. The driver
Installation	installation process starts automatically when the PC Card is inserted.

Install Files

1Put the 3Com CD in the CD-ROM drive.

If you are installing from diskettes, insert the Drivers diskette.

2In the Add New Hardware Wizard window, click Next.

3Respond to the instructions in the next windows:

a When the driver location is confirmed, click Next.

bVerify the driver name (3Com 3CRWE62092A Wireless LAN PC Card) and click Next.

The installation program copies files from the 3Com CD and Windows operating system.

This copying process may take a few moments, and the progress bar may seem to update slowly.

The installation may prompt for your operating system installation CD, for a path to the operating system, or for the installation CD of other installed networking software. If it does, remove the 3Com CD and insert the appropriate CD.

cWhen you are notified that the installation is complete, remove the CD and click Finish.

4 At the prompt to restart the computer, click Yes.

12 CHAPTER 2: INSTALLING THE WIRELESS CLIENT

Set Up the PC Card After the computer restarts, the 3Com 11 Mbps Wireless LAN Client Setup window opens, in which you specify the PC Card configuration.

1In the 3Com 11 Mbps Wireless LAN Client Setup window, select Typical and click Next.

Typical configures the PC Card with the following default values:

WLAN Service Area—Attach to any WLAN Service Area automatically

Security Setting—No security (Open system)

If you want to customize the PC Card configuration, for example, to add security, select Custom. See “Custom Installation Options” on page 16 for details on custom settings. For the fastest installation, it is recommended that you use the typical settings. You can customize the configuration later as described in “Setting the Wireless Client Configuration” on page 23.

2In the Summary window, review the PC Card setup. To install the software utilities, make sure that the Start client software installation when finished box is checked.

If you are reinstalling the PC Card and already have the software utilities installed, this box is unchecked.

3Click Finish to complete the PC Card setup and start the software utilities installation.

The 3Com 11 Mbps Wireless LAN Setup program starts.

If you are installing from diskettes, insert Disk 1 and run the setup.exe program to start the software utilities installation.

Install Utilities

1Read the Welcome page and click Next.

2Read the Software License Agreement and click Yes. (If you click No, the installation stops.)

3Select a destination folder for the software files and click Next.

4In the Setup Type window, select the type of installation for the software:

Typical—Installs the software and documentation.

Compact—Installs the software, but not documentation.

Custom—Allows you to choose the components to install.

5Follow the directions in the Select Program Folder window and click Next.

6In the Desktop Icon Option window, click Yes.

7In the Setup Complete window, click Finish.

8If you are prompted to restart your computer, do so.

This completes the basic installation. To confirm the installation, see “Confirming the Installation” on page 15.

Windows NT	The following procedure is for installing the card software when networking is
Installation with	already installed on your computer. If networking is not already installed, see
Networking Installed	“Windows NT Installation Without Networking Installed” on page 35.

Windows NT Installation with Networking Installed 13

The CardWizard utility, which helps Windows NT to load and manage software, must be installed. If the installation program does not detect the CardWizard utility on your computer, it will ask whether you want to install it. If you already have a similar utility installed, you must first uninstall that utility to prevent conflicts with CardWizard.

Internet Explorer version 4 is required to view help files. It is recommended that you install Internet Explorer version 5 or later.

Install Files

1Make sure that the computer is running and the PC Card is inserted.

2Put the 3Com CD in the CD-ROM drive.

If the 3Com 11 Mbps WLAN Menu appears, click Exit.

3From the Windows Start menu, select Settings/Control Panel.

4In the Control Panel, double-click Network.

5Click the Adapters tab.

6In the Adapters tab, click Add.

7In the Select Network Adapter window, click Have Disk.

8In the Insert Disk window, make sure that the correct path to your CD-ROM drive appears in the entry box (for example, d:) and click OK.

If you are installing from diskettes, enter the path to the diskette drive.

9In the Select OEM Option window, select 3Com 3CRWE62092A Wireless LAN PC Card and click OK.

10In the PC Card Setup window, accept the default settings and click OK.

The default settings work in most cases. However, you may need to specify values for your installation.

Wait while the files are copied.

11In the Adapters tab, click Close.

12If the Microsoft TCP/IP Properties screen appears, enter the requested information for your network environment.

Refer to the Windows NT documentation for assistance. If you choose the DHCP server option, click Yes to the DHCP prompt. When you are finished entering the appropriate TCP/IP information, click OK.

13When prompted to restart the computer, click Yes.

Install CardWizard

If CardWizard was already installed before you began installing the PC Card, this portion is skipped and the installation proceeds directly to “Set Up the PC Card”.

1At the prompt to install CardWizard, click Yes.

If you click No and you do not have CardWizard installed, the installation stops.

2In the CardWizard window, click Next.

3In the CardWizard welcome page, click Next.

14 CHAPTER 2: INSTALLING THE WIRELESS CLIENT

4Read the CardWizard Software License Agreement and click Yes.

5When prompted to remove the PC Card, eject the card and click Yes.

6In the Select Type of Platform window, select your computer type and click Next. If your computer type is not listed, select Other Notebook and click Next.

7Respond to the prompts to install CardWizard.

8When the CardWizard installation finishes, click the radio button to restart the computer and click Finish.

9Insert the PC Card.

Set Up the PC Card After the computer restarts, the 3Com 11 Mbps Wireless LAN Client Setup window opens, in which you specify the PC Card configuration.

1In the 3Com 11 Mbps Wireless LAN Client Setup window, select Typical and click Next.

Typical configures the PC Card with the following default values:

WLAN Service Area—Attach to any WLAN Service Area automatically

Security Setting—No security (Open system)

If you want to customize the PC Card configuration, for example, to add security, select Custom. See “Custom Installation Options” on page 16 for details on custom settings. For the fastest installation, it is recommended that you use the typical settings. You can customize the configuration later as described in “Setting the Wireless Client Configuration” on page 23.

2In the Summary window, review the PC Card setup and click Finish.

3When prompted to run the Setup program, click OK.

4Run the Setup program:

a From the Windows Start menu, select Run.

bIn the Run dialog box, enter a path to the Setup program on the 3Com CD. For example, d:\srsetup.exe.

The 3Com 11 Mbps Wireless LAN Setup program starts.

Install Utilities

1Read the Welcome page and click Next.

2Read the Software License Agreement and click Yes. (If you click No, the installation stops.)

3Select a destination folder for the software files and click Next.

4In the Setup Type window, select the type of installation for the software:

Typical—Installs the software and documentation.

Compact—Installs the software but not documentation.

Custom—Allows you to choose the components to install.

5Follow the directions in the Select Program Folder window and click Next.

6In the Desktop Icon Option window, click Yes.

Confirming the Installation

15

7 In the next window, if the option to restart the computer appears, select it and

	click Finish.
	If you had a service pack installed before setting up the PC Card, reinstall it and
	restart the computer.
	This completes the basic installation. To confirm the installation, see “Confirming
	the Installation”.
Confirming the	When the PC Card and software are installed correctly, you will see the following
Installation	items after you restart the computer:
	■ PC Card LED is blinking.
	■ 3Com WLAN Launcher is running. This utility shows the status of your network
	association.
	■ 3Com icon is in the Windows system tray.
	■ Shortcut icon to the 3Com WLAN Launcher is on your desktop (unless you
	specified no icon during the installation).
	If you do not see the 3Com WLAN Launcher window, click the 3Com icon in the
	Windows system tray to display it.
	If the 3Com WLAN Launcher is not already running, you can start it by double
	clicking the shortcut on your desktop, or, from the Windows Start menu, select
	Start/Programs/3Com 11 Mbps Wireless LAN/3Com WLAN Launcher.
	For more information, see “Using the Wireless LAN” on page 19.
Using the	The XJACK antenna, which is attached to the end of the PC Card, has two
XJACK Antenna	positions: extended and retracted. To extend or retract the antenna, gently but
	firmly press and release it. The antenna must be extended to make a network
	association. To prevent it from damage, the antenna should be retracted when not
	in use, when you are inserting the card in your computer, or when you are
	transporting the computer.
	CAUTION: Do not pull on the antenna to remove the card.
	The figures below show the antenna extended and retracted.
