Trane TAM7A0C36H31SB, TAM7A0B30H21SB, TAM7A0C42H31SB, TAM7A0C60H51SB, TAM7B0C60H51SA User Manual

...
4.8 (6)

Variable Speed Modular

Multi-position

Air Handlers

2-5 Tons

TAM7A0A24H21SB TAM7A0C48H41SB TAM7A0B30H21SB TAM7A0C60H51SB TAM7A0C36H31SB TAM7B0C60H51SA TAM7A0C42H31SB

PUB. NO. 22-1847-03

Features

and Benefits

Unique cabinet design

2% or less air leakage

Precision applied - durable door seals

Specially designed air seal around refrigerant, condensate and conduit connections

Double wall foamed cabinet system

R-4.2 Insulating Value (Avg Insulating Value R-8.2)

No loose fiber design

Smooth cleanable interior design

Sweat eliminating design

Composite foamed cabinet doors

Water proof cabinet design

Integrated horizontal drain pans

Modular cabinet

Multi-position up/down flow horizontal left/right

Side return option (sold as accessory)

Control board protection pocket built into cabinet wall

Premarked Conduit Connection Locations

Alert port to view control board codes without door removal

Alert code notification

Low voltage terminal connection point

Phillips head door fasteners

Vortica® blower with polarized plug

connections and integrated slide deck for easy removal

Aluminum coil with integrated slide deck for easy removal and polarized plug connections on coil EEV

Patented enhanced coil fin

Electronic Expansion Valve (EEV) with low ambient and low superheat compressor protection

Dual refrigerant compatible as shipped

Slide in electric heaters with polarized plug connections (sold as accessory)

Slide in hot water coils with polarized plug connections (sold as accessory)

UVC light kit with safety switch and polarized plug connections (sold as accessory)

Labeled panels and connections

Molded in 1" standard filter rail

Variable speed ECM motor

Soft start fan motor operation

Comfort RTM mode

Built in fan delay modes

Maximum width of 23.5"

Compact 20.8" depth with doors removed

Fused 24v power

Safety door switch

5 year warranty

10-year warranty registered

Optional extended warranty available

© 2012 Trane

2

Pub. No. 22-1847-03

Contents

Features and Benefits

2

Optional Equipment



4

Unique Cabinet Design Features and Benefits

5

General Data



6

TAM7A0A24H21SB



6

TAM7A0B30H21SB



6

TAM7A0C36H31SB



6

TAM7A0C42H31SB



6

TAM7A0C48H41SB



6

TAM7A0C60H51SB



6

TAM7B0C60H51SA



6

Performance Data



7

Electrical Data



13

Field Wiring



20

Convertibility



24

Dimensions



25

Pub. No. 22-1847-03

3

Optional Equipment

OPTIONAL EQUIPMENT FOR AIR HANDLERS

Accessory Number

Description

Fits Cabinet Size

BAYEVAC05BK1AA

Electric Heater, 5kW, Breaker, RS-485 Control, 1 Ph

A to C

BAYEVAC05LG1AA

Electric Heater, 5kW, Lugs, RS-485 Control, 1 Ph

A to C

BAYEVAC08BK1AA

Electric Heater, 8kW, Breaker, RS-485 Control, 1 Ph

A to C

BAYEVAC08LG1AA

Electric Heater, 8kW, Lugs, RS-485 Control, 1 Ph

A to C

BAYEVAC10BK1AA

Electric Heater, 10kW, Breaker, RS-485 Control, 1 Ph

A to C

BAYEVAC10LG1AA

Electric Heater, 10kW, Lugs, RS-485 Control, 1 Ph

A to C

BAYEVBC15BK1AA

Electric Heater, 15kW, Breaker, RS-485 Control, 1 Ph

B to C

BAYEVBC20BK1AA

Electric Heater, 20kW, Breaker, RS-485 Control, 1 Ph

C

BAYEVCC25BK1AA

Electric Heater, 25kW, Breaker, RS-485 Control, 1 Ph

C

BAYEVAC10LG3AA

Electric Heater, 10kW, Lugs, RS-485 Control, 3 Ph

A to C

BAYEVBC15LG3AA

Electric Heater, 15kW, Lugs, RS-485 Control, 3 Ph

B to C

BAYSUPFLGAA

Supply Duct Flange A

A

BAYSUPFLGBA

Supply Duct Flange B

B

BAYSUPFLGCA

Supply Duct Flange C

C

BAYRETFLGAA

Return Duct Flange A

A

BAYRETFLGB

Return Duct Flange B

B

BAYRETFLGCA

Return Duct Flange C

C

BAYSRKIT100A

Side Return Kit

A to C

TASB175SB

Plenum Stand with integrated sound baffle A

A

TASB215SB

Plenum Stand with integrated sound baffle B

B

TASB235SB

Plenum Stand with integrated sound baffle C

C

MITISRKIT01A

Side Return Kit with filter

A to C

BAYICSKIT01A

Internal Condensate Switch Kit

A to C

BAYHHKIT001A

Horizontal Hanger Kit

A to C

BAYUVCLK001A

UVC Lights

A to C

BAYLVKIT100A

Low Voltage Conduit Entry Kit

A to C

BAYSPEKT200A

Single Power Entry Kit

A to C

BAYWVAA05SC1AA

Hydronic Coil - 50,000 BTUH - Slide-in with control

A to A

BAYWVBB07SC1AA

Hydronic Coil - 70,000 BTUH - Slide-in with control

B to B

BAYWVCC08SC1AA

Hydronic Coil - 80,000 BTUH - Slide-in with control

C to C

BAYWACC11SC1AA

Hydronic Coil - 100,000 BTUH - Add-on

C to C

BAYWVBRD485A

RS-485 Control for BAYWACC11SC1AA

C to C

4

Pub. No. 22-1847-03

Unique Cabinet Design

Features and Benefits

5 Conduit

Connections

Locations

R Integrated Horizontal

Drain Pans

7 Alert Code Viewport

6 Tool-less Door

Fasteners

ECompact 20.8” Depth with Doors Removed

1 Unique Cabinet Design

-Double wall foamed cabinet system

-Waterproof Cabinet Design

-R-4.2 Insulating Value (Avg Insulating Value R-8.2)

-Composite Foamed Cabinet Doors

-Sweat Eliminating Cabinet Design

-Loose Fiber Eliminating Design

-Smooth Cleanable Cabinet Design

2 Precision Durable Door Seals

3 Refrigeration Connections

4 Condensate Connections

5Conduit Connection Locations - Dimples or target to mark Conduit Connection locations on Left, Right, and Top

6 Tool-less Door Fasteners

7 Alert Code Viewport

-Alert Codes can be Viewed Without Door Removal

-Control Protection Pocket

1 Unique Cabinet Design

2 Precision Durable

Door Seals

Q Electronic Expansion

Valve (EEV)

3 Refrigeration

Connections

9 All Aluminum Coil

4 Condensate

Connections

T Safety Door Switch

8VorticaTM Blower and Deck

0 Labeled Panels and Connections

W Maximum width is 23.5”

8VorticaTM Blower and Deck - Polarized Plug on Blower

9All Aluminum Coil

-Integrated Slide Deck for Easy Removal

-Polarized Plug connections on Coil EEV

-Patented Enhanced Coil Fin

0 Labeled Panels and Connections

Q Electronic Expansion Valve (EEV)

-Low Ambient and Low Superheat Protection

-Dual Refrigerant Compatible as Shipped

W Maximum width is 23.5”

E Compact 20.8” Depth with Doors Removed R Integrated Horizontal Drain Pans

T Safety Door Switch - Fused 24V Power

Y Modular Cabinet

Pub. No. 22-1847-03

5

General

Data





PRODUCT SPECIFICATIONS





MODEL

TAM7A0A24H21SB

TAM7A0B30H21SB

TAM7A0C36H31SB

RATED VOLTS/PH/HZ.

200-230/1/60

200-230/1/60

200-230/1/60

RATINGS 1

See O.D. Specifications

See O.D. Specifications

See O.D. Specifications

INDOOR COIL — Type

Plate Fin

Plate Fin

Plate Fin

Rows — F.P.I.

3 - 14

3 - 14

3 - 14

Face Area (sq. ft.)

3.67

5.04

5.50

Tube Size (in.)

3/8

3/8

3/8

Refrigerant Control

EEV

EEV

EEV

Drain Conn. Size (in.) 2

3/4 NPT

3/4 NPT

3/4 NPT

DUCT CONNECTIONS

See Outline Drawing

See Outline Drawing

See Outline Drawing

INDOOR FAN — Type

Centrifugal

Centrifugal

Centrifugal

Diameter-Width (In.)

11 X 8

11 X 10

11 X 10

No. Used

1

1

1

Drive - No. Speeds

Direct - Variable

Direct - Variable

Direct - Variable

CFM vs. in. w.g.

See Fan Performance Table

See Fan Performance Table

See Fan Performance Table

No. Motors — H.P.

1 - 1/2

1 - 1/2

1 - 1/2

Motor Speed R.P.M.

Variable ECM

Variable ECM

Variable ECM

Volts/Ph/Hz

208-230/1/60

208-230/1/60

208-230/1/60

F.L. Amps

3.0

3.0

3.0

FILTER







Filter Furnished?

No

No

No

Type Recommended

Throwaway

Throwaway

Throwaway

No.-Size-Thickness

1 - 16 X 20 - 1 in.

1 - 20 X 20 - 1 in.

1 - 22 X 20 - 1 in.

REFRIGERANT

R-410A

R-410A

R-410A

Ref. Line Connections

Brazed

Brazed

Brazed

Coupling or Conn. Size — in. Gas

3/4

3/4

7/8

Coupling or Conn. Size — in. Liq.

3/8

3/8

3/8

DIMENSIONS

H x W x D

H x W x D

H x W x D

Crated (In.)

51-1/2 x 19 x 23-1/2

56-1/2 x 23 x 23-1/2

57-1/4 x 25-1/4 x 23-1/2

Uncrated

49-7/8 x 17-1/2 x 21-3/4

55-11/16 x 21-5/16 x 21-3/4

56-15/16 x 23-1/2 x 21-3/4

WEIGHT







Shipping (Lbs.) / Net (Lbs.)

127/116

150/138

157/146





PRODUCT SPECIFICATIONS





MODEL

TAM7A0C42H31SB

TAM7A0C48H41SB

TAM7A0C60H51SB,TAM7B0C60H51SA



RATED VOLTS/PH/HZ.

200-230/1/60

200-230/1/60

200-230/1/60



RATINGS 1

See O.D. Specifications

See O.D. Specifications

See O.D. Specifications



INDOOR COIL — Type

Plate Fin

Plate Fin

Plate Fin



Rows — F.P.I.

4 - 14

4 - 14

4 - 14



Face Area (sq. ft.)

5.04

5.96

5.96



Tube (in.)

3/8

3/8

3/8



Refrigerant Control

EEV

EEV

EEV



Drain Conn. Size (in.) 2

3/4 NPT

3/4 NPT

3/4 NPT



DUCT CONNECTIONS

See Outline Drawing

See Outline Drawing

See Outline Drawing



INDOOR FAN — Type

Centrifugal

Centrifugal

Centrifugal



Diameter-Width (In.)

11 X 10

11 X 10

11 X 10



No. Used

1

1

1



Drive - No. Speeds

Direct - Variable

Direct - Variable

Direct - Variable



CFM vs. in. w.g.

See Fan Performance Table

See Fan Performance Table

See Fan Performance Table



No. Motors — H.P.

1 - 1/2

1 - 3/4

1 - 1



Motor Speed R.P.M.

Variable ECM

Variable ECM

Variable ECM



Volts/Ph/Hz

208-230/1/60

208-230/1/60

208-230/1/60



F.L. Amps

3.0

4.2

5.5



FILTER









Filter Furnished?

No

No

No



Type Recommended

Throwaway

Throwaway

Throwaway



No.-Size-Thickness

1 - 22 X 20 - 1 in.

1 - 22 X 20 - 1 in.

1 - 22 X 20 - 1 in.



REFRIGERANT

R-410A

R-410A

R-410A



Ref. Line Connections

Brazed

Brazed

Brazed



Coupling or Conn. Size — in. Gas

7/8

7/8

7/8



Coupling or Conn. Size — in. Liq.

3/8

3/8

3/8



DIMENSIONS

H x W x D

H x W x D

H x W x D



Crated (In.)

57-1/4 x 25-1/4 x 23-1/2

62-3/4 x 25-1/4 x 23-1/2

62-3/4 x 25-1/4 x 23-1/2



Uncrated

56-15/16 x 23-1/2 x 21-3/4

61-3/4 x 23-1/2 x 21-3/4

61-11/16 x 23-1/2 x 21-3/4



WEIGHT









Shipping (Lbs.) / Net (Lbs.)

162/151

175/163

175/163

1 These Air Handlers are AHRI. certified with various Split System Air Conditioners and Heat Pumps (AHRI STANDARD 210/240). Refer to the Split System Outdoor Unit Product Data Guides for performance data.

2 3/4" Male Plastic Pipe (Ref.: ASTM 1785-76)

6

Pub. No. 22-1847-03

03-1847-22 .No .Pub

7

TAM7A0A24 AIRFLOW PERFORMANCE

CONSTANT CFM MODE / CONSTANT TORQUE MODE

OUTDOOR

COOLING

Airflow





EXTERNAL STATIC PRESSURE





HEATING

Airflow



EXTERNAL STATIC PRESSURE



MULTIPLIER

AIRFLOW









AIRFLOW



































(TONS)

SETTING

Power

0.1

0.3

0.5

0.7

0.9

SETTING

Power

0.1

0.3

0.5

0.7

0.9







































360

CFM

542

/ 652

547

/ 559

548

/ 407

547 / NA

541 / NA

390

CFM

586

599

600

599

595



CFM/ton

Watts

38

/ 59

67

/ 71

101 / 78

137 / NA

175 / NA

CFM/ton

Watts

46

80

115

153

192









































380

CFM

574

/ 679

583

/ 593

587

/ 464

588

/ 167

581 / NA

410

CFM

618

633

636

637

629

1.5 tons

CFM/ton

Watts

43

/ 65

75

/ 78

110 / 87

148 / 94

185 / NA

CFM/ton

Watts

53

88

124

163

202







































400

CFM

605

/ 705

618

/ 626

624

/ 513

625

/ 325

618 / NA

430

CFM

650

665

669

672

660





CFM/ton

Watts

49

/ 71

82

/ 85

119 / 96

158

/ 101

196 / NA

CFM/ton

Watts

59

96

134

174

212









































420

CFM

636

/ 731

651

/ 658

659

/ 556

660

/ 406

653 / NA

450

CFM

681

696

703

704

696



CFM/ton

Watts

55

/ 78

90

/ 93

128

/ 105

168

/ 112

207 / NA

CFM/ton

Watts

66

104

144

185

225











































360

CFM

723

/ 809

743

/ 746

754

/ 666

756

/ 563

748

/ 428

390

CFM

780

800

809

811

802



CFM/ton

Watts

75 / 101

115

/ 118

158

/ 133

201

/ 144

242

/ 153

CFM/ton

Watts

94

137

182

227

268











































380

CFM

761

/ 843

782

/ 784

793

/ 710

796

/ 617

788

/ 500

410

CFM

818

838

848

851

842

2 tons †

CFM/ton

Watts

86 / 113

128

/ 131

172

/ 146

216

/ 159

259

/ 168

CFM/ton

Watts

106

151

198

244

287







































400 †

CFM

799

/ 877

820

/ 821

832

/ 751

835

/ 666

827

/ 561

430

CFM

856

876

887

889

881





CFM/ton

Watts

97 / 125

141

/ 144

187

/ 161

233

/ 174

276

/ 183

CFM/ton

Watts

119

167

215

262

307









































420

CFM

836

/ 911

858

/ 858

870

/ 792

873 /712

866

/ 615

450

CFM

894

913

925

927

920



CFM/ton

Watts

109

/ 139

155

/ 158

203

/ 175

250

/ 189

294

/ 199

CFM/ton

Watts

134

183

233

282

327











































360

CFM

892

/ 979

914

/ 930

927

/ 869

930

/ 796

923

/ 709

390

CFM

964

986

997

1000

992



CFM/ton

Watts

130

/ 168

179

/ 189

229

/ 207

278

/ 222

324

/ 232

CFM/ton

Watts

164

218

271

322

370









































380

CFM

939 / 1024

962

/ 976

974

/ 918

978

/ 849

971

/ 766

410

CFM

1013

1034

1045

1049

1040

2.5 tons

CFM/ton

Watts

149

/ 190

201

/ 211

253

/ 230

304

/ 244

351

/ 255

CFM/ton

Watts

188

244

299

353

400







































400

CFM

986 / 1070

1009

/ 1023

1022 / 967

1026 / 901

1019 / 821

430

CFM

1063

1083

1095

1097

1089





CFM/ton

Watts

170

/ 215

225

/ 236

279

/ 255

332

/ 270

380

/ 280

CFM/ton

Watts

214

273

331

385

434







































420

CFM

1035

/ 1118

1058

/ 1072

1071

/ 1018

1074 / 953

1066 / 877

450

CFM

1114

1135

1145

1145

1135



CFM/ton

Watts

194

/ 242

251

/ 264

308

/ 282

362

/ 297

411

/ 307

CFM/ton

Watts

243

305

365

420

469







































360

CFM

1065

/ 1148

1088

/ 1102

1101

/ 1048

1103 / 985

1095 / 910

390

CFM

1160

1181

1190

1189

1157



CFM/ton

Watts

209

/ 261

269

/ 282

327

/ 301

382

/ 315

431

/ 325

CFM/ton

Watts

272

337

397

453

486









































380

CFM

1126

/ 1209

1149

/ 1164

1160

/ 1111

1161

/ 1050

1151 / 978

410

CFM

1225

1244

1249

1230

1146

3 tons

CFM/ton

Watts

244

/ 301

307

/ 322

367

/ 341

423

/ 355

472

/ 364

CFM/ton

Watts

317

384

444

486

477







































400

CFM

1190

/ 1271

1211

/ 1227

1220

/ 1175

1218

/ 1115

1164

/ 1046

430

CFM

1291

1305

1298

1217

1135





CFM/ton

Watts

285

/ 347

350

/ 368

412

/ 386

467

/ 399

483

/ 408

CFM/ton

Watts

368

434

486

476

468











































420

CFM

1255

/ 1334

1273

/ 1289

1278

/ 1239

1237

/ 1180

1151

/ 1113

450

CFM

1355

1361

1285

1206

1124



CFM/ton

Watts

331

/ 397

397

/ 418

459

/ 435

483

/ 448

475

/ 455

CFM/ton

Watts

422

485

475

467

460









































NOTES:

























3. Torque mode will reduce airflow when static is above approximately 0.3"

























water column.











1. † Factory Setting























































4. All heating modes default to Constant CFM





2. Status LED will blink once per 100 CFM requested. In torque mode, actual airflow may be lower.









5. Cooling airflow values are with wet coil, no filter











































































Minimum Heating Airflow Settings



BAYEVAC05BK1AA



MINIMUM HEATER AIRFLOW CFM - HEATER MATRIX









BAYEVAC08BK1AA



BAYEVAC10BK1AA











MODEL NO.

BAYEVAC05LG1AA

BAYEVAC08LG1AA



BAYEVAC10LG1AA

BAYEVAC10LG3AA



BAYEVCB15LG3AA

BAYEVBC15BK1AA

BAYEVBC20BK1AA

TAM7A0A24H21SB

638/713

638/900



675 1 /900

600/713



--

--

--





















WITHOUT HEAT PUMP / WITH HP

SEE AIR HANDLER NAMEPLATE FOR APPROVED COMBINATIONS

1 Heater not qualified for 208V when installed in horizontal left position without Heat Pump

NOTE: Minimum auxiliary heating airflow is automatically configured by the air handler model and the auxiliary heater model number. This is not field adjustable.

Trane TAM7A0C36H31SB, TAM7A0B30H21SB, TAM7A0C42H31SB, TAM7A0C60H51SB, TAM7B0C60H51SA User Manual

8

03-1847-22 .No .Pub

TAM7A0B30 AIRFLOW PERFORMANCE

CONSTANT CFM MODE / CONSTANT TORQUE MODE

OUTDOOR

COOLING

Airflow





EXTERNAL STATIC PRESSURE



HEATING

Airflow



EXTERNAL STATIC PRESSURE



MULTIPLIER

AIRFLOW







AIRFLOW

































(TONS)

SETTING

Power

0.1

0.3

0.5

0.7

0.9

SETTING

Power

0.1

0.3

0.5

0.7

0.9







































360

CFM

591

/ 685

560

/ 538

533

/ 299

509 / NA

482 / NA

390

CFM

630

609

588

566

540



CFM/ton

Watts

30

/ 41

58

/ 56

87

/ 63

118 / NA

150 / NA

CFM/ton

Watts

35

65

96

128

161







































380

CFM

618

/ 711

593

/ 572

569

/ 359

547 / NA

524 / NA

410

CFM

657

639

621

601

578

1.5 tons

CFM/ton

Watts

33

/ 45

62

/ 60

93

/ 68

125 / NA

158 / NA

CFM/ton

Watts

38

70

102

136

169





































400

CFM

645

/ 738

624

/ 605

604

/ 410

584 / NA

562 / NA

430

CFM

683

669

653

636

614





CFM/ton

Watts

37

/ 49

67

/ 65

99

/ 73

132 / NA

166 / NA

CFM/ton

Watts

42

75

109

143

177







































420

CFM

659

/ 751

639

/ 621

620

/ 434

602 / NA

581 / NA

450

CFM

709

698

685

669

649



CFM/ton

Watts

38

/ 50

69

/ 67

102 / 76

136 / NA

170 / NA

CFM/ton

Watts

45

80

115

151

186









































360

CFM

750

/ 840

741

/ 726

731

/ 575

719

/ 344

704 / NA

390

CFM

800

797

791

781

766



CFM/ton

Watts

51

/ 66

87

/ 85

125 / 96

163 / 99

200 / NA

CFM/ton

Watts

60

99

139

180

219









































380

CFM

784

/ 874

779

/ 764

771

/ 622

762

/ 419

748 / NA

410

CFM

834

834

830

822

810

2 tons †

CFM/ton

Watts

57

/ 72

95

/ 92

134

/ 104

174

/ 107

213 / NA

CFM/ton

Watts

66

107

150

192

233





































400 †

CFM

818

/ 908

816

/ 802

811

/ 667

803

/ 484

792 / NA

430

CFM

868

871

869

864

853





CFM/ton

Watts

62

/ 79

103

/ 100

144

/ 113

186

/ 117

227 / NA

CFM/ton

Watts

73

116

161

205

248









































420

CFM

835

/ 924

834

/ 820

831

/ 689

824

/ 513

813 / 180

450

CFM

902

908

908

905

895



CFM/ton

Watts

66

/ 83

107

/ 104

150

/ 118

192

/ 122

234 / 132

CFM/ton

Watts

80

126

172

219

263







































360

CFM

904 / 1017

908

/ 921

909

/ 804

907

/ 658

898 / 454

390

CFM

967

977

982

982

974



CFM/ton

Watts

80 / 105

125

/ 129

172

/ 144

219

/ 150

264 / 148

CFM/ton

Watts

95

145

196

247

295







































380

CFM

947 / 1061

955

/ 968

959

/ 856

958

/ 718

951 / 538

410

CFM

1012

1025

1033

1034

1027

2.5 tons

CFM/ton

Watts

89 / 117

138

/ 142

188

/ 158

237

/ 165

285 / 163

CFM/ton

Watts

106

160

214

268

318





































400

CFM

991 / 1106

1002

/ 1016

1009 / 908

1010 / 779

1003 / 614

430

CFM

1057

1074

1084

1087

1078





CFM/ton

Watts

100

/ 131

152

/ 156

205

/ 174

257

/ 182

307 / 180

CFM/ton

Watts

119

176

234

290

342





































420

CFM

1013

/ 1129

1026

/ 1040

1034 / 934

1036 / 808

1029 / 650

450

CFM

1104

1124

1136

1139

1128



CFM/ton

Watts

106

/ 138

159

/ 164

214

/ 182

268

/ 190

318 / 189

CFM/ton

Watts

133

194

255

314

366





































360

CFM

1063

/ 1182

1080

/ 1095

1091 / 993

1094 / 873

1085 / 727

390

CFM

1147

1170

1184

1185

1170



CFM/ton

Watts

120

/ 156

177

/ 182

236

/ 201

292

/ 211

344 / 210

CFM/ton

Watts

147

211

276

336

389







































380

CFM

1120

/ 1241

1140

/ 1157

1153

/ 1059

1156 / 945

1444 / 809

410

CFM

1208

1233

1247

1245

1223

3 tons

CFM/ton

Watts

137

/ 178

199

/ 205

262

/ 225

321

/ 235

374 / 236

CFM/ton

Watts

168

238

306

367

418





































400

CFM

1179

/ 1304

1202

/ 1221

1216

/ 1127

1216

/ 1018

1198 / 890

430

CFM

1271

1298

1309

1300

1271





CFM/ton

Watts

157

/ 203

224

/ 231

290

/ 252

351

/ 263

403 / 265

CFM/ton

Watts

193

267

337

398

446









































420

CFM

1210

/ 1337

1233

/ 1255

1247

/ 1162

1245

/ 1055

1224 / 931

450

CFM

1338

1363

1368

1350

1314



CFM/ton

Watts

168

/ 217

237

/ 246

305

/ 267

306

/ 279

417 / 281

CFM/ton

Watts

221

299

369

427

472







































NOTES:























3. Torque mode will reduce airflow when static is above approximately























0.35" water column.









1. † Factory Setting

















































4. All heating modes default to Constant CFM





2. Status LED will blink once per 100 CFM requested. In torque mode, actual airflow may be lower.





5. Cooling airflow values are with wet coil, no filter







































































Minimum Heating Airflow Settings







MINIMUM HEATER AIRFLOW CFM - HEATER MATRIX









BAYEVAC05BK1AA

BAYEVAC08BK1AA

BAYEVAC10BK1AA









MODEL NO.

BAYEVAC05LG1AA

BAYEVAC08LG1AA

BAYEVAC10LG1AA

BAYEVAC10LG3AA

BAYEVCB15LG3AA

BAYEVBC15BK1AA

BAYEVBC20BK1AA

TAM7A0B30H21SB

723/808

723/1020

765/1020

680/808

765/1063

850/1105

--

WITHOUT HEAT PUMP / WITH HP

SEE AIR HANDLER NAMEPLATE FOR APPROVED COMBINATIONS

NOTE: Minimum auxiliary heating airflow is automatically configured by the air handler model and the auxiliary heater model number. This is not field adjustable.

03-1847-22 .No .Pub

9

TAM7A0C36 AIRFLOW PERFORMANCE

CONSTANT CFM MODE / CONSTANT TORQUE MODE

OUTDOOR

COOLING

Airflow





EXTERNAL STATIC PRESSURE





HEATING

Airflow



EXTERNAL STATIC PRESSURE



MULTIPLIER

AIRFLOW









AIRFLOW



































(TONS)

SETTING

Power

0.1

0.3

0.5

0.7

0.9

SETTING

Power

0.1

0.3

0.5

0.7

0.9









































350

CFM

724

/ 858

704

/ 706

694

/ 530

695

/ 297

698 / 19

400

CFM

813

797

794

799

806



CFM/ton

Watts

44

/ 63

77

/ 77

111 / 85

148 / 90

185

/ 163

CFM/ton

Watts

57

94

133

174

215









































370

CFM

759

/ 892

744

/ 747

738

/ 585

740

/ 387

742 / 84

420

CFM

849

837

835

841

849

2 tons

CFM/ton

Watts

49

/ 69

84

/ 84

120 / 93

158 / 98

197

/ 135

CFM/ton

Watts

63

102

142

185

228







































390

CFM

795

/ 924

784

/ 787

780

/ 635

783

/ 460

786

/ 213

440

CFM

884

876

876

883

891





CFM/ton

Watts

54

/ 75

91

/ 91

129

/ 102

169

/ 107

209

/ 120

CFM/ton

Watts

69

110

153

197

242











































410

CFM

830

/ 957

823

/ 826

822

/ 683

824

/ 524

827

/ 329

450

CFM

902

895

897

902

912



CFM/ton

Watts

60

/ 82

99

/ 99

139

/ 111

180

/ 117

222

/ 123

CFM/ton

Watts

72

114

158

203

249









































350

CFM

879 / 1026

876

/ 905

877

/ 776

881

/ 639

884

/ 488

400

CFM

992

991

998

1005

1014



CFM/ton

Watts

68

/ 97

110

/ 116

153

/ 130

197

/ 138

240

/ 143

CFM/ton

Watts

91

138

188

237

287









































370

CFM

923 / 1067

924

/ 952

927

/ 830

932

/ 702

936

/ 565

420

CFM

1036

1040

1048

1057

1064

2.5 tons

CFM/ton

Watts

77 / 107

121

/ 127

167

/ 142

213

/ 151

258

/ 157

CFM/ton

Watts

101

152

204

256

307







































390

CFM

968 / 1110

971

/ 999

977

/ 883

983

/ 762

987

/ 634

440

CFM

1081

1089

1099

1110

1116





CFM/ton

Watts

86 / 118

133

/ 139

181

/ 155

230

/ 166

277

/ 172

CFM/ton

Watts

113

167

221

277

330





































410

CFM

1012

/ 1153

1020

/ 1047

1028 / 935

1034 / 820

1039 / 700

450

CFM

1105

1113

1125

1136

1141



CFM/ton

Watts

96 / 130

146

/ 153

197

/ 170

248

/ 181

298

/ 187

CFM/ton

Watts

119

174

231

287

341





































350

CFM

1036

/ 1175

1044

/ 1070

1053 / 961

1060 / 848

1064 / 731

400

CFM

1175

1189

1203

1214

1215



CFM/ton

Watts

102

/ 137

153

/ 160

206

/ 177

257

/ 189

308

/ 196

CFM/ton

Watts

140

200

261

321

377







































370 †

CFM

1090

/ 1229

1102

/ 1129

1114

/ 1024

1122 / 916

1123 / 805

420

CFM

1234

1251

1267

1275

1272

3 tons †

CFM/ton

Watts

116

/ 154

171

/ 178

227

/ 196

282

/ 209

334

/ 217

CFM/ton

Watts

159

223

288

351

406







































390

CFM

1145

/ 1285

1161

/ 1188

1176

/ 1087

1184 / 984

1184 / 877

440

CFM

1295

1315

1331

1335

1325





CFM/ton

Watts

132

/ 173

191

/ 198

251

/ 218

309

/ 231

363

/ 240

CFM/ton

Watts

180

250

318

381

435









































410

CFM

1204

/ 1343

1223

/ 1249

1238

/ 1152

1246

/ 1051

1242 / 948

450

CFM

1327

1348

1362

1364

1350



CFM/ton

Watts

150

/ 195

213

/ 221

277

/ 241

337

/ 256

391

/ 264

CFM/ton

Watts

192

264

264

396

449









































350

CFM

1199

/ 1338

1218

/ 1244

1233

/ 1146

1241

/ 1046

1237 / 942

400

CFM

1380

1403

1414

1409

1389



CFM/ton

Watts

149

/ 193

211

/ 219

274

/ 239

335

/ 254

389

/ 262

CFM/ton

Watts

214

289

360

422

472











































370

CFM

1269

/ 1408

1291

/ 1317

1307

/ 1223

1311

/ 1126

1300

/ 1025

420

CFM

1459

1478

1481

1467

1395

3.5 tons

CFM/ton

Watts

172

/ 222

240

/ 249

307

/ 270

370

/ 285

423

/ 294

CFM/ton

Watts

248

327

397

456

476







































390

CFM

1342

/ 1481

1367

/ 1393

1380

/ 1301

1378

/ 1206

1358

/ 1108

440

CFM

1538

1550

1542

1504

1388





CFM/ton

Watts

200

/ 255

273

/ 282

343

/ 304

405

/ 320

456

/ 329

CFM/ton

Watts

287

366

433

478

472











































410

CFM

1419

/ 1555

1442

/ 1468

1449

/ 1379

1438

/ 1286

1394

/ 1189

450

CFM

1575

1583

1570

1501

1385



CFM/ton

Watts

232

/ 291

309

/ 319

380

/ 341

440

/ 357

478

/ 367

CFM/ton

Watts

307

385

450

477

470









































NOTES:

























3. Torque mode will reduce airflow when static is above approximately

























0.35" water column.









1. † Factory Setting





















































4. All heating modes default to Constant CFM





2. Status LED will blink once per 100 CFM requested. In torque mode, actual airflow may be lower.









5. Cooling airflow values are with wet coil, no filter











































































Minimum Heating Airflow Settings



BAYEVAC05BK1AA





MINIMUM HEATER AIRFLOW CFM - HEATER MATRIX











BAYEVAC08BK1AA



BAYEVAC10BK1AA



























MODEL NO.

BAYEVAC05LG1AA



BAYEVAC08LG1AA



BAYEVAC10LG1AA

BAYEVAC10LG3AA



BAYEVCB15LG3AA

BAYEVBC15BK1AA

BAYEVBC20BK1AA

TAM7A0C36H31SB

876/979



876/1236



927/1236

824/979



927/1288

1030/1339

1236/1442











WITHOUT HEAT

PUMP / WITH HP















SEE AIR HANDLER NAMEPLATE FOR APPROVED COMBINATIONS





NOTE: Minimum auxiliary heating airflow is automatically configured by the air handler model and the auxiliary heater model number. This is not field adjustable.

Loading...
+ 19 hidden pages
