Sylvania SRTD413 User Manual

OWNER’S

MANUAL

COLOR TV/DVD

SRTD413 (13 inch)

INSTRUCCIONES

EN ESPAÑOL INCLUIDAS.

As an ENERGY STAR®

Partner, our company has determined that this product meets the ENERGY STAR® guidelines for energy efficiency. ENERGY STAR® is a U.S. registered mark.

If you need additional operating assistance after reading this owner’s manual, please call

TOLL FREE : 1-800-968-3429.

Please read before using this equipment

AVERTISSEMENT POUR UNE TABLE ROULANTE PORTATIVE

S3126A

PORTABLE CART WARNING

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE

TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The caution marking is located on the rear of the cabinet.

THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE APPLIANCE.

IMPORTANT SAFEGUARDS

1.Read instructions-All the safety and operating instructions should be read before the appliance is operated.

2.Retain Instructions-The safety and operating instructions should be retained for future reference.

3.Heed Warnings-All warnings on the appliance and in the operating instructions should be adhered to.

4.Follow Instructions-All operating and use instructions should be followed.

5.Cleaning-Unplug TV/DVD from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

EXCEPTION: A product that is meant for uninterrupted service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to unplugging the appliance in the cleaning description otherwise required in item 5.

6.Attachments-Do not use attachments not recommended by the TV/DVD manufacturer as they may cause hazards.

7.Water and Moisture-Do not use this TV/DVD near waterfor example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

8.Accessories-Do not place this TV/DVD on an unstable cart, stand, tripod, bracket, or table. The TV/DVD may fall, causing serious injury to someone, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the TV/DVD. Any mounting of the

appliance should follow the manufacturer’s instructions and should use a mounting accessory recommended by the manufacturer. An appliance

and cart combination should be moved with care.

Quick stops, excessive force, and

uneven surfaces may cause the appliance and cart combination to over-

turn.

Accessoires- Ne placez pas cette TV/DVD sur une table roulante, un support, un trépied, une console ou une table instable. Cette TV/DVD risquerait de tomber, pouvant gravement blesser quelqu'un et l'appareil même pourrait être sérieusement endommagé. N'utilisez qu'une table roulante, un support, un trépied, une console ou une table recommandé par le fabriquant, ou vendu avec la TV/DVD. Pour n'importe quelle installation de l'appareil, on devra suivre les instructions du fabriquant et l'on devra utiliser les accessoires d'installation recommandés par le fabriquant. L'ensemble combiné de l'appareil avec une table roulante devra être déplacé avec précaution. Des arrêts brusques, une force excessive et des surfaces inégales peuvent provoquer le renversement de l'ensemble combiné de l'appareil/table roulante.

9.Ventilation-Slots and openings in the cabinet and the back or bottom are provided for ventilation and to ensure reliable operation of the TV/DVD and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the TV/DVD on a bed, sofa, rug, or other similar surface. This TV/DVD should never be placed near or over a radiator or heat register. This TV/DVD should not be placed in a builtin installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

10.Power Sources-This TV/DVD should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For TV/DVDs intended to operate from battery power, or other sources, refer to the operating instructions.

11.Grounding or Polarization-This TV/DVD is equipped with a polarized alternating-current line plug(a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

– 2 –

EN

0C28

FIGURE A

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONAL ELECT RICAL CODE

						ANTENNA
						L EAD I N
						W I R E
	GROUND
	C L A M P
						ANTENNA
						DI SCHARG E UN I T
						(NEC SECTION 8 10 -2 0)
EL ECTRI C
SE RV I CE
EQ U I PMEN T
						G RO UNDI NG CO NDUCTORS
						(NEC SECTION 8 10 -2 1)
					G RO UND CL AMPS
NEC - NATI O NAL EL ECTRI CAL CO DE			POWER SERVI C E G RO UNDI NG
			EL EC TR O DE SYSTEM
S2 8 9 8 A			(NEC ART 2 50 , PART H)

12.Power-Cord Protection-Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

13.Outdoor Antenna grounding-If an outside antenna or cable system is connected to the TV/DVD, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. (Fig. A)

14.Lightning-For added protection for this TV/DVD receiver during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the TV/DVD due to lightning and power-line surges.

15.Power Lines-An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

16.Overloading-Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.

17.Object and Liquid Entry-Never push objects of any kind into this TV/DVD through openings as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the TV/DVD.

18.Servicing-Do not attempt to service this TV/DVD yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

19.Damage Requiring Service-Unplug this TV/DVD from the wall outlet and refer servicing to qualified service personnel under the following conditions:

a.When the power-supply cord or plug is damaged or frayed.

b.If liquid has been spilled, or objects have fallen into the TV/DVD.

c.If the TV/DVD has been exposed to rain or water.

d.If the TV/DVD does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions, as improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the TV/DVD to its normal operation.

e.If the TV/DVD has been dropped or damaged in any way.

f.When the TV/DVD exhibits a distinct change in perfor- mance-this indicates a need for service.

20.Replacement Parts-When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, injury to persons or other hazards.

21.Safety Check-Upon completion of any service or repairs to this TV/DVD, ask the service technician to perform routine safety checks to determine that the TV/DVD is in proper operating condition.

22.Heat-This TV/DVD product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

– 3 –

EN

0C28

PRECAUTIONS

IMPORTANT COPYRIGHT INFORMATION

Unauthorized copying, broadcasting, public performance and lending of discs are prohibited.

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

FCC WARNINGThis equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.

RADIO-TV INTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1)Reorient or relocate the receiving antenna.

2)Increase the separation between the equipment and receiver.

3)Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4)Consult the dealer or an experienced radio/TV technician for help.

LASER SAFETY

This unit employs a laser. Only a qualified service person should remove the cover or attempt to service this device, due to possible eye injury.

CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO NOT STARE INTO BEAM.

LOCATION: INSIDE, NEAR THE DECK MECHANISM.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

The serial number of this product may be found on the back of the unit. No other TV/DVD has the same serial number as yours. You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.

Date of Purchase

Dealer Purchase from

Dealer Address

Dealer Phone No.

Model No.

Serial No.

– 4 –

EN

0C28

LOCATION

SYMBOLS USED IN THIS MANUAL

For safe operation and satisfactory performance of your TV/DVD, keep the following in mind when selecting a place for its installation:

•Shield it from direct sunlight and keep it away from sources of intense heat.

•Avoid dusty or humid places.

•Avoid places with insufficient ventilation for proper heat dissipation. Do not block the ventilation holes at the top or bottom of the unit. Do not place the unit on a carpet because this will block the ventilation holes.

•Install unit in a horizontal position.

•Avoid locations subject to strong vibration.

•Do not place the TV/DVD near strong magnetic fields.

•Avoid moving TV/DVD to locations where temperature differences are extreme.

AVOID THE HAZARDS OF ELECTRICAL SHOCK AND FIRE

•Do not handle the power cord with wet hands.

•Do not pull on the power cord when disconnecting it from an AC wall outlet. Grasp it by the plug.

•If by accident, water is spilled on your unit, unplug the power cord immediately and take the unit to an Authorized Service Center for servicing.

•Do not put your fingers or objects into the TV/DVD disc loading tray.

•Do not place anything directly on top of the unit.

The following symbols below appear in some headings and notes in this manual, with the following meanings

TV

:Description refers to TV operation (in the TV mode).

DVD-V

:Description refers to playback of DVD video discs (in the DVD mode).

CD

:Description refers to playback of audio CDs (in the DVD mode).

MP3

:Description refers to playback of MP3 discs (in the DVD mode).

QUICK

:Description refers to the items to be set by the QUICK mode (in the DVD mode).

WARNING

Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place or after heating a cold room or under conditions of high humidity. If a DVD is played in a TV/DVD which has moisture, it may damage the DVD and TV/DVD. Therefore when the condensation occurs inside the unit, turn POWER on and allow at least 2 hours for the unit to dry out.

SUPPLIED ACCESSORIES

Remote Control Unit	Batteries	Owner’s Manual
		Owner's Manual

NE226UD

2 AA Batteries

1EMN20123

•If you need to replace these accessories, please refer to the PART NO. under the illustrations and call 1-800- 488-1222.

•Depending on your antenna system, you may need different types of Combiners (Mixer) or Separators (Splitter). Contact your local electronics store for these items.

•We do not recommend the use of universal remote controls. Not all of the functions may be controlled with a universal remote control. If you decide to use a universal remote control with this unit, please be aware that the code number given may not operate this unit. In this case, please call the manufacturer of the universal remote control.

– 5 –

EN

0C28

TABLE OF CONTENTS

C IMPORTANT SAFEGUARDS . . . . . . . . . . . . .2

C PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . .4

LOCATION . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

AVOID THE HAZARDS OF ELECTRICAL SHOCK AND FIRE . . . . . . . . . . . . . . . . . . . . . .5

SYMBOLS USED IN THIS MANUAL . . . . . . .5 WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

C SUPPLIED ACCESSORIES . . . . . . . . . . . . . . .5

C TABLE OF CONTENTS . . . . . . . . . . . . . . . . . .6

C FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

C OPERATING CONTROLS AND FUNCTIONS . . .8

INSTALLING THE BATTERIES . . . . . . . . . . .9

C PREPARATION FOR USE . . . . . . . . . . . . . . .10

ANTENNA/CABLE CONNECTIONS . . . . . . .10 CONNECTING TO FRONT A/V INPUT JACKS .11

CONNECTING TO AN AMPLIFIER/RECEIVER EQUIPPED WITH DIGITAL INPUT JACK (DVD, CD, MP3 sound only) . . . . . . . . . . . . . .11

CONNECTING TO AN AMPLIFIER/RECEIVER WITH A DOLBY DIGITAL DECODER

(for DVD) . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

TV SECTION
C SET UP FOR USE . . . . . . . . . . . . . . . . . . . . .	13

SELECTING THE LANGUAGE . . . . . . . . . . .13 CHANNEL SET UP . . . . . . . . . . . . . . . . . . . . .13 DELETING (OR ADDING) CHANNEL(S) . . .14

C TV OPERATION . . . . . . . . . . . . . . . . . . . . . . .15

WATCHING A TV PROGRAM . . . . . . . . . . . .15 DEGAUSSING . . . . . . . . . . . . . . . . . . . . . . . .15 PICTURE CONTROL . . . . . . . . . . . . . . . . . . .15 SLEEP TIMER . . . . . . . . . . . . . . . . . . . . . . . . .16 CLOSED CAPTION SYSTEM . . . . . . . . . . . .16 V-CHIP SET UP . . . . . . . . . . . . . . . . . . . . . . . .17

DVD SECTION

C ABOUT THE DISCS . . . . . . . . . . . . . . . . . . . .19

PLAYABLE DISCS . . . . . . . . . . . . . . . . . . . . .19 DISC TYPES . . . . . . . . . . . . . . . . . . . . . . . . . .19

C PLAYING A DISC . . . . . . . . . . . . . . . . . . . . . .20

BASIC PLAYBACK . . . . . . . . . . . . . . . . . . . .20 GENERAL FEATURES . . . . . . . . . . . . . . . . . .20 DISC MENU . . . . . . . . . . . . . . . . . . . . . . . . . .20 TITLE MENU . . . . . . . . . . . . . . . . . . . . . . . . .20 RESUME . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 PAUSE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 STEP BY STEP PLAYBACK . . . . . . . . . . . . .21 FAST FORWARD/REVERSE SEARCH . . . . .21 SLOW FORWARD / SLOW REVERSE . . . . .21

C SEARCH FUNCTION . . . . . . . . . . . . . . . . . .22

TRACK SEARCH . . . . . . . . . . . . . . . . . . . . . .22 TITLE / CHAPTER SEARCH . . . . . . . . . . . . .22 TIME SEARCH . . . . . . . . . . . . . . . . . . . . . . . .22 MARKER SETUP SCREEN . . . . . . . . . . . . . .22

C SPECIAL PLAYBACK FUNCTION . . . . . . . .23

REPEAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 PROGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . .23 RANDOM PLAYBACK . . . . . . . . . . . . . . . . .23

C PLAYING A MP3 DISC . . . . . . . . . . . . . . . . . .24

MP3 PLAYBACK . . . . . . . . . . . . . . . . . . . . . .24 REPEAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 PROGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . .24 RANDOM PLAYBACK . . . . . . . . . . . . . . . . .24

C CHANGING THE SETTINGS . . . . . . . . . . . .25

SUBTITLE LANGUAGE . . . . . . . . . . . . . . . .25 AUDIO LANGUAGE . . . . . . . . . . . . . . . . . . .25 STEREO SOUND MODE . . . . . . . . . . . . . . . .25 CAMERA ANGLE . . . . . . . . . . . . . . . . . . . . . .25 BLACK LEVEL SETTING . . . . . . . . . . . . . . .25 VIRTUAL SURROUND . . . . . . . . . . . . . . . . .25

C THE ON-SCREEN INFORMATION . . . . . . .26

C CHANGING THE DVD SETUP ITEMS . . . .27

LANGUAGE SETTING . . . . . . . . . . . . . . . . .27 DISPLAY SETTING . . . . . . . . . . . . . . . . . . . .28 AUDIO SETTINGS . . . . . . . . . . . . . . . . . . . . .28 PARENTAL CONTROL . . . . . . . . . . . . . . . . .29 INITIALIZE . . . . . . . . . . . . . . . . . . . . . . . . . . .29

C TROUBLESHOOTING GUIDE . . . . . . . . . . .30

C MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . .32

DISC HANDLING . . . . . . . . . . . . . . . . . . . . . .32

C SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . .33

C ESPAÑOL . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

C WARRANTY . . . . . . . . . . . . . . . . . . .Back Cover

– 6 –

EN

0C28

FEATURES

TV Mode

•181 channel capability PLL frequency synthesizer tuner

(A converter may be necessary to view scrambled cable channels.)

•Infrared remote control

•Trilingual on screen menu display selectable in English, Spanish or French

¡Sleep Timer

The Sleep Timer function enables the unit to turn off without pressing POWER after a preselected time period.

¡Closed Caption Decoder

You may view specially labeled (cc) TV programs, movies, news, etc. with either a dialogue caption or text display added to the program.

¡Auto Shut Off Function

If there is no air signal input from the antenna terminal and no operation for 15 minutes, the TV/DVD will turn itself off automatically.

¡V-CHIP

Enables parents to prevent their children from watching inappropriate material on TV.

DVD Mode

¡Dolby Digital sound

This TV/DVD can output a Dolby Digital audio signal from the digital audio output jack.

¡Still/fast/slow/step playback

Various playback modes are available including still pictures, fast forward/reverse, slow motion and frame by frame.

¡Random playback for audio CD and MP3

This TV/DVD can shuffle the order of tracks to play them in random order.

¡Program playback for audio CD and MP3

You can program the order of tracks to play in any desired order.

¡DVD menus in a desired language

You can display DVD menus in a desired language, if available on a DVD disc.

¡Screen saver/Auto power-off functions

The screen saver program starts when there is no input from the TV/DVD for 5 minutes in the stop mode. When the screen saver program has been in opperation for 15 minutes, the power will automatically turn off.

¡Subtitles in a desired language

You can select a desired language for the display subtitles, if that language is available on a DVD disc.

¡Selecting a camera angle

You can select the desired camera angle, if a DVD disc contains sequences recorded from different angles.

¡Choices for audio language and sound mode

You can select the desired audio language and sound mode, if different languages and modes are available on a DVD disc.

¡Parental lock

You can set the control level to limit playback of DVD discs which may not be suitable for children.

¡Automatic detection of discs

This TV/DVD automatically detects if the loaded disc is DVD, audio CD or MP3.

¡On-screen display

Information about the current operation can be displayed on a TV screen, allowing you to confirm the currently active functions (such as program playback).

¡Search

Chapter search / Title search / Track search / Time search

¡Repeat

Chapter / Title / Track / Group / All / A-B

¡Marker

The location on a specific DVD disc designated by the user can be accessed later.

¡Resume Play

User can resume to playback from the location at which

play was stopped.

¡Virtual Surround

¡Bit rate indication

¡DRC (Dynamic range control)

You can control the range of the difference between the loudest and softest sounds.

– 7 –

EN

0C28

OPERATING CONTROLS AND FUNCTIONS

TV/DVD FRONT PANEL [Fig. 1]

VIDEO	L AUDIO R	POWER	VOLUME	CHANNEL	STOP	SKIP	PLAY SKIP	PAUSE OPEN/CLOSE HEADPHONE
							SEARCH

	1	2	3	4	5	6	7	8	9	10 11 12 13	14
REMOTE CONTROL				[Fig. 2]			7. Remote Sensor Window
							8. STOP Button [page 20]
								Stops operation of the disc.
							9. SKIP H Button [page 22]
								Begins playback from beginning of current chap-
	POWER PICTURE		SELECT	CLOSE				ter or track.
				OPEN/
4					13			SEARCH (REV) E Button (Front Panel)
36	1	2	3		34			[page 21]
								During playback or in the pause mode, press and
				CH.	6
16	4	5	6					hold button down for a few seconds to change

reverse playback speed.

		7	8	9		5	10. PLAY Button [page 20]
		SLEEP		+100	VOL.
	17							Begins playback of disc.
			0	+10
	9	SKIP		V.SURR	MUTE	35		Press to change to DVD mode when in TV mode.
							11. SKIP G Button [page 22]
	11					19
								Begins playback from beginning of next chapter.
	10		PLAY			18
		REV		FWD				SEARCH (FWD) D Button (Front Panel)
			STOP			8		[page 21]
					DISC
	12	PAUSE	SLOW		MENU	33		During playback or in the pause mode, press and
		DISPLAY						hold button down for a few seconds to change for-
	23					32		ward playback speed.
				ENTER
	20	SETUP	TITLE		RETURN	31	12. PAUSE Button [page 21]
						30		Pauses the current disc movement.
	21	CLEAR	SEARCH MODE REPEAT		A-B
						29	13. OPEN/CLOSE Button [page 20]
	22
			AUDIO	SUBTITLE	ANGLE			Press to open disc tray to insert a disc or to open to
		MODE
	15					28		remove a disc.
	24					27	14. HEADPHONE Jack
								To connect headphone (not supplied) for personal
	25					26
								listening.
	1. Disc loading tray						15. MODE Button [pages 23-25]
								Activates program playback or random playback
	2. VIDEO input Jack [page 11]							mode when playing CDs or MP3.
	Connect to the video output jack of a video						16. Number Buttons
	camera or VCR, Video game system.							TV Mode: [page 15]
	3. AUDIO L/R input Jacks [page 11]
								Press two digits to directly access the desired channel.
	Connect to the audio output jacks of a video							Remember to press 0 before a single digit channel.
	camera or VCR, Video game system.							+100 Button
	4. POWER Button [page 13]							Press to select cable channels which are higher than 99.
	Press to turn the power on and off.							DVD Mode: [page 22]
	5. VOLUME K/L (VOL. m/n) Buttons							Press to enter the desired number.
	Press to control the volume level.							+10 Button
	6. CHANNEL K/L (CH. K/L) Buttons [page 14]							Press to enter the desired numbers which are greater
	Press to select memorized channel.							than 9.
	Press to change to TV mode when in DVD mode.
							– 8 –	EN

0C28

TV/DVD REAR VIEW

[Fig. 3]

ANT.

COAXIAL

37

38

39

17.SLEEP Button [page 16]

Press SLEEP to display the sleep timer and begin operation. The shut off time can be determined by the number of times you press this button. (0, 30, 60, 90 or 120 minutes)

18.REV h Button [page 21]

Press to view the DVD picture in fast reverse motion. Press PAUSE, then press this button to begin slow motion playback. Press this button repeatedly to change the reverse speed of slow motion.

FWD g Button [page 21]

Press to fast forward the Disc. Press PAUSE, then press this button to begin slow motion playback. Press this button repeatedly to change the forward speed of slow motion.

19.V.SURR (VIRTUAL SURROUND) Button

[page 25]

Press to set virtual surround on/off.

20.SETUP Button [pages 13,27-29]

Press to enter or exit the TV menu or DVD setup mode.

21.TITLE Button [page 20]

Displays the title menu on DVD disc.

22.CLEAR Button [pages 22-24]

Resets a setting.

23.DISPLAY Button TV Mode:

Press to display the channel number on the screen. If you press it a second time, the channel number will disappear.

DVD Mode: [page 26]

Displays the current DVD status on the TV screen.

24.SEARCH MODE Button [page 22]

Press to locate a desired point.

25.AUDIO Button [page 25]

Press to select a desired audio language or sound mode available on a DVD disc.

26.SUBTITLE Button [page 25]

Press to select a desired subtitle language.

27.REPEAT Button [page 23]

Repeats playback of the current disc, title, chapter, group or track.

32.Arrow Buttons

TV Mode: [page 13]

Press to select a setting mode from the menu on the TV screen.

Press to select or adjust from a particular menu.

DVD Mode: [page 20]

Use when making settings while watching the display on a TV screen.

33.DISC MENU Button [page 20]

Displays the menus available on a DVD disc.

34.SELECT Button [page 20]

Press to change to TV mode, front A/V input mode or DVD mode .

NOTE: When you select the DVD mode by this button, press PLAY or OPEN/CLOSE first. Otherwise, the DVD features do not function.

35.MUTE Button

Press MUTE to turn off the sound portion of the TV program. (Volume level display turns LIGHT RED from LIGHT BLUE.) Press MUTE again or press VOL. m or nto restore sound.

36.PICTURE Button [page 15]

Press to enter picture adjustment mode.

37.Power cord

Connect to a standard AC outlet (120V/60Hz). NOTE: Remove the power cord from the hook on

the back of the TV to avoid breaking a wire before you connect to a standard AC outlet.

38.COAXIAL digital audio out Jack (DVD Audio Only) [pages 11, 12]

Connect to the digital input of an external amplifier or receiver.

39.ANT. in Jack

Connect to an antenna, cable system or satellite system.

INSTALLING THE BATTERIES

28.	ANGLE Button [page 25]	1)Open the battery compartment cover by pressing the
	Press to change the camera angle to see the sequence	cover on the remote unit in the direction of the arrow.
	being played back from a different angle available on	2)Insert 2 “AA” penlight batteries into the battery
	a DVD disc.
		compartment in the direction indicated by the
29.	REPEAT A-B Button [page 23]
		polarity (+/-) markings.
	Repeats playback of a selected section.
		3)Replace the cover.
30.	RETURN Button [page 25]
	Returns to the previous operation in the DVD setup
	mode.	NOTES
31.	ENTER Button [pages 13, 20]
		¡Do not mix alkaline and manganese batteries.
	Press to accept a setting.
		¡Do not mix old and new batteries.
	– 9 –				EN

0C28

PREPARATION FOR USE

ANTENNA/CABLE CONNECTIONS

Satellite Box or Cable Box (Not supplied)

From

Cable System

OUT

From Cable System or

Satellite Dish

Rod Antenna

(Not supplied) VHF/UHF Antenna (Not supplied)

IN

		VHF Antenna
		(Not supplied)
		UHF Antenna
	or	(Not supplied)
COAXIAL ANT.	VHF/UHF
	or Combiner
	(Not supplied)

ANT.

75-ohm Coaxial	or
Cable (Not supplied)

or	Flat twin-lead cable	[Fig. 4]

Note to CATV system installer:

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical.

NOTE:

Before plugging the antenna into the ANT. IN jack of the TV/DVD, check that the pin is not bent. If it is bent, straighten the pin as illustrated, then plug the pin into the ANT. IN jack of the TV/DVD.

Bent pin

Cable Plug

(Needs to be straightened)(Straight pin)

VHF/UHF COMBINED ANTENNA

The VHF/UHF Rod Antenna (not supplied) is detachable. Insert the stem of the antenna into the hole on the upper-back portion of the TV/DVD. Connect the VHF/UHF Rod Antenna or VHF/UHF Combination Antenna to the ANT. terminal of the TV/DVD as shown in the diagram above. For the best reception, fully extend the VHF/UHF Rod Antenna and make the necessary adjustments. (Avoid touching the top section when adjusting.)

VHF/UHF SEPARATE ANTENNAS

In some areas it will be necessary to use an outdoor antenna.

CABLE WITHOUT CONVERTER/ DESCRAMBLER BOX

Use this connection if your cable system connects directly to your TV/DVD without a converter box. Use the TV/ DVD Remote Control to select channels.

CABLE WITH CONVERTER/DESCRAMBLER BOX OR SATELLITE BOX

If your cable service supplies you with a converter box or if you use a satellite system, you can use the basic connection shown here.

Channel selection must be made with the converter box or satellite box. This means that channels cannot be changed using the TV/ DVD Remote Control.

TO VIEW A SCRAMBLED/UNSCRAMBLED CHANNEL

1.Set the TV/DVD channel selector to the output channel of the Cable Converter Box or Satellite Box. (Ex. CH3)

2.Select the channel to view on your Cable Converter Box or Satellite Box.

– 10 –

EN

0C28

CONNECTING TO FRONT A/V INPUT JACKS

When you watch a program recorded on another source (VCR video camera Video game system), use the audio/video input jacks on the front of the TV/DVD.

Connect the audio/video output	AUX
jacks of the source to the AUDIO
L/R and VIDEO jacks of this
TV/DVD. Then press SELECT until
"AUX" appears on the screen.

NOTE:

•When you connect a monaural VCR (another source) to this TV/DVD, connect the Audio output jack of the monaural VCR (another source) to the AUDIO L jack of this TV/DVD. The audio will distributed in both L and R channel equally.

	[Front of the TV/DVD]
[Another source]	To the
	audio out-
	put jacks
	Audio/Video
	cables	VIDEO	L–AUDIO–R
	(not supplied)
etc.

To the video
output jack	[Fig. 5]

CONNECTING TO AN AMPLIFIER/RECEIVER EQUIPPED WITH DIGITAL INPUT JACK (DVD, CD, MP3 sound only)

Use an audio coaxial digital cable available at retail stores for the audio connections.

Amplifier/receiver equipped with digital input jacks

ANT.

COAXIAL

To coaxial digital audio input jack

To COAXIAL digital audio out jack [Fig. 6] (only DVD audio out)

NOTES:

•The audio source on a disc in a 5.1 channel Dolby Digital surround format cannot be recorded as digital sound by an MD or DAT deck.

•Be sure to turn off the power to all components in the system before making connections.

•Refer to the Owner's Manuals for the components to be connected to the TV/DVD.

•Set DOLBY DIGITAL to OFF for audio output in the setup mode. Playing a TV/DVD using incorrect settings may generate noise distortion and may also damage the speakers. (See page 28 to set DOLBY DIGITAL to OFF.)

•This will only allow 2-channel DVD sound to be listened to on the amplifier.

– 11 –

EN

0C28

CONNECTING TO AN AMPLIFIER/RECEIVER WITH A

DOLBY DIGITAL DECODER (for DVD)

To use this TV/DVD to play a DVD disc in a 5.1 channel Dolby Digital surround format, the TV/DVD can outputs a DOLBY DIGITAL Data stream from its COAXIAL digital audio out jack. By hooking the TV/DVD up to a receiver with Dolby Digital decoder, you can enjoy high-quality surround sound as enjoyed in movie theaters.

Use audio coaxial digital cables available at retail stores for the audio connections.

	Center
	speaker	ANT.
Front speaker		COAXIAL
		Front speaker
(left)		(right)

Amplifier/receiver with			To COAXIAL digital
Dolby Digital decoder	To coaxial ditigal		audio out jack
	audio input jack		(only DVD audio out)
Surround	Surround	Subwoofer
speaker	speaker
(left)	(right)

[Fig. 7]

NOTES:

•Be sure to turn off the power to all components in the system before connecting another component.

•Refer to the Owner's Manuals for the components to be connected to the TV/DVD.

•If connected to a receiver with Dolby Digital decoder, set DOLBY DIGITAL to ON for audio output in the setup mode. (See page 28 to set DOLBY DIGITAL to ON.)

•Unless connected to a receiver with Dolby Digital decoder, set DOLBY DIGITAL to OFF for audio output in the setup mode. Playing a TV/DVD using incorrect settings may generate noise distortion and may also damage the speakers.

•Only DVD audio is available using the digital audio out jack.

Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

– 12 –

EN

0C28
