Polar S710 User Manual

179291.S710 GBR B.fh8 8/3/01 14:36 Page 1

•OwnIndex™ to reliably predict your VO2max

•OwnCal™ the most accurate calorie

consumption calculation

• OwnCode™ locks out possible interference from other heart rate monitors

• Infra red data communication with your computer and Uplink™ feature

• Cycling features - speed, altitude and thermometre. Optional cadence and power output.

179271 GBR B

HEART RATE MONITOR

Composite

C M Y CM MY CY CMY K

GBR

S710™ USER’S MANUAL

HEART RATE MONITOR

Quick Guide

Signal/Light	Up
	•	move onward
	•	increase the
		selected value

Stop				Down
•	exit the			•	move backward
	displayed mode			•	reduce the
•	return to the				selected value
	Time of day display

OK

•start measuring the heart rate

•lock in your selection

How to start measuring your heart rate (BasicUse)

1.Place the transmitter around your chest and wet the electrodes. Place the wrist receiver on your wrist.

2.Press and hold the OK button to start the measurement. The stopwatch and the exercise recording start. Your heart rate will appear in about

15 seconds.

How to stop measuring your heart rate

1.Press the stop button. The stopwatch and other calculations stop. Heart rate measurement continues but exercise data is not recorded into a file anymore.

2.Press the stop button again. The receiver returns to the Time of day display.

The Polar S710 offers you various possibilities on customising exercise sessions to fit your personal needs.

For example, use the Interval Trainer function to guide you through a complete interval training session. Or, you can choose the functions that suit you best: e.g. timers, recovery calculation and cycling information. After training, you can review your exercise file and transfer it to your computer for analysis with Polar Precision Performance™ software. Monitor your fitness level, and any long-term changes in it, by performing the quick and easy Polar Fitness Test™.

Please read this manual carefully to familiarise yourself with the Polar S710. Here is where you can find the information you need to use and maintain your equipment. The function road map on the front cover is a quick guide to the versatile features of the Polar S710; please tear it off.

Please refer to the glossary for special terms, display symbols and text explanations. The alphabetical index will help you quickly find answers to any questions that you might encounter while using your Polar S710.

Thank you for choosing Polar!

S710 man GBR/B kopio.pm6	1	8/3/01, 14:33

CONTENTS

A. Getting going .......................	5
Heart rate monitor parts . .......................	5
Buttons and their functions ....................	6
Easy start ...................................................	8
How to prepare the wrist receiver .....	8
Installing the Polar Bike Mount .........	9
Installing the Polar Speed Sensor ......	9
How to put the transmitter on ........	11
How to start measuring
your heart rate ...................................	11
How to stop measuring
your heart rate ...................................	12
After exercising ..................................	12
Modes and their functions ....................	13
B. How to enter settings ........	18
User information settings .....................	19
Exercise settings .....................................	22
Selecting exercise type ..........................	22
Setting exercise sets ..........................	23
Setting timers ................................	25
Setting heart rate limits ...............	25
Heart rate limits on/off .................	25
Setting interval type .....................	26
Setting number of intervals .........	27
Setting recovery calculation .........	28
Naming exercise sets .........................	29

Setting recording rate ...........................	30
Turning functions on/off .......................	32
OwnCal calorie counter on/off .........	32
Fitness test on/off ..............................	32
Predicted maximum
heart rate on/off ................................	33
Altitude and thermometre on/off ...	33
Bicycle feature settings ........................	34
Wheel size ..........................................	34
Cadence on/off ..................................	36
Power on/off ......................................	37
Autostart on/off .................................	37
Naming bike 1 or 2 ............................	38
Monitor settings ....................................	39
Activity/button sound on/off ............	39
Selecting measuring units ................	39
Help on/off .........................................	40
Watch settings ........................................	41
Setting alarm .....................................	41
Setting time of day ............................	42
Setting date ........................................	42
Reminders on/off ...............................	43
Setting tips .............................................	44
Swap time 1 or time 2 .......................	44
Shortcut to watch settings ...............	44
Swap measuring units .......................	44
Swap date, user ID,
user name and logo ..........................	44

C. Exercise ................................	45
Measure mode .......................................	45
Autostart for recording
a cycling exercise.. ........................... ..48
Exercise recording mode .......................	49
Illuminating the display ....................	50
Heart rate zone alarm on/off ...........	50
Swapping the heart rate limits ........	50
Storing lap and split time .................	51
Pausing the exercise ..........................	51
Swapping the displayed
exercise information .........................	52
Resetting the stopwatch to zero .....	54
Starting an exercise set .........................	54
Exercising with Interval Training Set ...	55
Warm-up phase ..................................	56
Interval phase ....................................	56
Cool-down phase ...............................	59
Interrupting an interval
training exercise ................................	60
Exercising with BasicSet ........................	60
Starting the timers ............................	60
Starting the recovery calculation .....	61
Stopping the exercise ............................	61
Tips during exercise ...............................	61
Swapping the exercise type ..............	61
Swapping the bike setting ...............	62

Resetting the trip distance ...............	62
Returning to the manually
set altitude .........................................	62
Restarting the interval or
recovery calculation ..........................	62
Interrupting an interval or
recovery calculation ..........................	63
Interrupting a phase of an
interval training exercise ..................	63
Heart touch function .........................	63
D. How to recall
training information ..........	64
Exercise time ...........................................	66
Recovery information of BasicSet ........	66
Exercise distance ....................................	66
Speed information .................................	66
Cadence information .............................	66
Altitude ...................................................	67
Temperature ...........................................	67
Ascended metres/feet ............................	67
Power .................................................... .	67
Pedalling index .......................................	67
Left right pedalling balance .................	67
Heart rate limits .....................................	67
Exercise time within, above and below
the heart rate zones ..............................	67

S710 man GBR/B kopio.pm6	2-3	8/3/01, 14:33

Calorie expenditure ...............................	68
Cumulative calorie count ......................	68
Cumulative exercise time count ...........	68
Cumulative riding time .........................	68
Odometer ...............................................	68
Interval Training information ...............	69
Warm-up phase ..................................	69
Interval phase ....................................	70
Cool-down phase ...............................	71
Lap information .....................................	71
Recorded samples ..................................	73
Deleting a file .........................................	73
Deleting all files .....................................	74
Records file .............................................	74
Resetting cumulative
counts to zero ........................................	75
Returning to your previous
maximum value ......................................	76
E. Connection to computer ....	77
Downloading training data
to computer ............................................	77
Uploading settings from computer ......	78
F. Polar Fitness Test .................	80
OwnIndex ...............................................	80
Predicted maximum heart rate .............	82
Fitness test settings ................................	83
Carrying out the test .............................	83
Update OwnIndex and HRmax-p .............	85
Fitness classes .........................................	86

G. Care and maintenance .......	88
H. Precautions .........................	91
I. Frequently asked questions95
J. Technical Specifications .....	99
K. Limited Polar Warranty ...	102
L. Disclaimer .........................	103
M.Polar glossary ...................	104
Display symbols ....................................	105
Display texts .........................................	106
Index ......................................................	110

A. GETTING GOING

Heart rate monitor parts and their functions

The elastic strap holds the transmitter comfortably, yet firmly, in the correct position.

The Polar T61™ transmitter detects your heart rate and transmits it to the wrist receiver.

The Polar S710 wrist receiver displays your heart rate and cycling data during exercise. Enter your personal settings into the receiver and analyse the exercise files after you’re done.

A 5

S710 man GBR/B kopio.pm6	4-5	8/3/01, 14:33

Buttons and their functions

Signal/ Light Turns the beep on or off. Turns the backlight on.

Reset	Resets the heart rate monitor.
Stop	Return - Stops measuring the heart rate.
	Exits the displayed mode and returns to
	the previous mode level.
	Returns to the Time of day display
	from any mode by pressing and
	holding the stop button.
OK	Accept - Starts measuring the heart rate (start).
	Enters the displayed mode shown on
	the lower level (start). Locks in your
	selection (ok). Records lap information
	(lap). The Help text (start, ok or lap)
	that appears on the display above the
	button indicates its use.

SIGNAL/

LIGHT

RESET

STOP

OK

A 6

Up Moves to the following mode. Increases the selected value.

Down Returns to the previous mode. Decreases the selected value.

Useful tips

•Briefly pressing a button (approximately 1 second) will do different things than pressing and holding the button for a longer period of time (approximately 2 to 5 seconds). If your press the button for a longer period of time, you can use shortcuts.

•The buttons are slightly stiffer than those of an ordinary watch to prevent them from being pressed accidentally.

•You can always return to the Time of day display from the Options setting or File recalling loops by pressing and holding the stop button.

•See the glossary for display symbols and text interpretation.

A 7

S710 man GBR/B kopio.pm6	6-7	8/3/01, 14:33

Easy start

How to prepare the wrist receiver

1. Since the display is blank when the receiver leaves the factory, you have to activate the wrist receiver by pressing the OK button twice, after which the Time of day display appears. This is a one-off procedure; once you have turned on your receiver you can not turn it off anymore.

2. You may start measuring your heart rate right away using the default settings. However, the following settings are ones that it would be useful to change as soon as possible: Time of day (see section Setting the watch) and personal user settings (see section User information settings).

3.Polar S710 has various functions that you can use according to your personal training needs. For more information, see section Modes and their functions. You

can either manually enter the settings by pressing the receiver buttons or you can define your settings Polar Precision Performance software, after which the data should be transferred from your computer to the wrist receiver.

4.Wear the wrist receiver as you would wear an ordinary watch. If you go biking, we recommend attaching the wrist receiver to a Polar Bike Mount™.

A 8

A 9

-50 cm -1´8´´

Installing the Polar Bike Mount

Use cable ties to secure the bike mount snugly on the rubber pad.

Attach the receiver by securing the wrist strap.

Installing the Polar Speed Sensor™

The Polar Speed Sensor measures speed and distance when cycling.

1.Check the front side of the front fork to find a suitable place for the speed sensor. The sensor should be attached 20-50 cm/ 8"-1’8" from the mounted wrist receiver.

2.Clean and dry the area underneath the rubber pad before you attach it to the front fork.

3.Adjust the angle of the sensor at 45 - 90 degrees as shown in the illustrations.

4.Pass the cable ties through the sensor holes and loosely adjust the ties. Do not tighten fully yet.

If the cable ties are too short for your bicycle, put two of them together to make them longer.

S710 man GBR/B kopio.pm6	8-9	8/3/01, 14:33

5.There are two spoke magnet options. You only need to install one of them. One is installed by rotating it around the spoke before putting the metal cover on, another by tightening the screw. The magnet must be facing the speed sensor.

6.Fine-tune the positioning of both the magnet and the sensor so that the magnet passes the sensor closely but does not touch it. The maximum distance between the speed sensor and the spoke magnet should be 5 mm/ 0,2". Once positioned correctly, tighten the cable ties securely and cut off any excess cable tie ends.

Your safety is important to us. While riding your bike, please keep your eyes on the road to prevent possible accidents and injury. Check that you can turn the handle bar normally and cable wires for brakes or gearing do not catch on the sensor. Check also that the sensor does not disturb pedalling or the use of brakes or gearing.

A 10

How to put the transmitter on

1.Attach the transmitter to the elastic strap.

2.Adjust the strap length to fit snugly and comfortably. Secure the strap around your chest, just below the chest muscles, and buckle it.

3.Lift the transmitter off your chest and moisten the grooved electrode areas on the back.

4.Check that the wet electrode areas are firmly against your skin and the Polar logo is in a central, upright position.

How to start measuring your heart rate

1.Begin with the display that shows the time of day.

2.Keep the wrist receiver within

1 metre/ 3 feet of your transmitter.

3.Check that you are not near other people that have heart rate monitors, high voltage power lines, televisions, mobile phones or other sources of electromagnetic disturbance.

A 11

S710 man GBR/B kopio.pm6	10-11	8/3/01, 14:33

4.Press the OK button to start measuring your heart rate. A heart symbol will start flashing and your heart rate (beats per minute) will appear in a maximum of 15 seconds.

5.Press OK again. The stopwatch starts running and you can start exercising. The exercise data will only be stored in a file if you have turned the stopwatch on.

How to stop measuring your heart rate

1.Press the stop button. The stopwatch and other calculations stop.

The heart rate measuring continues, although exercise data is no longer recorded.

2.Press the stop button again. The heart rate measuring stops. The receiver shows the Time of day display again.

After exercising

1.Carefully wash the transmitter with a mild soap and water solution.

2.Rinse it with pure water.

3.Dry the transmitter carefully with a soft towel.

4.Store the transmitter in a clean and dry place. Dirt impairs the elasticity and functioning of the transmitter. Sweat and moisture can keep the electrodes wet and the transmitter activated, which shortens battery life.

A 12

Modes and their functions

Your Polar S710 has six main modes: Time of day, Exercise, File, Options, Fitness test and Connection.

1. TIME OF DAY

You can use your Polar heart rate monitor as an ordinary watch with date, weekday indicator and alarm function.

You can also change between two different countries’ time

zones. In addition, the following functions can be uploaded from a computer:

•7 reminders with alarm sounds

•your personal logo, user number or user name

2.EXERCISE

In the Exercise mode, you measure your heart rate and exercise information is recorded in the File mode. You can preset up to five exercise sets for your personal needs. When you start exercising, just select one of the saved sets. Or, you can select BasicUse (heart rate measurement without heart rate limits, timers or other exercise guiding functions).

A 13

S710 man GBR/B kopio.pm6	12-13	8/3/01, 14:33

A.During BasicUse, you can save 99 split and lap times with detailed heart rate and cycling information for each lap. You can configure the display to show information on the following:

•your current heart rate/ average heart rate/ a reading of your maximum heart rate in percentages

•the current exercise time (stopwatch)

•time of day

•current lap and split time as well as the lap number

•calorie count for your exercise session

•current, average and maximum speed

•trip distance

•altitude

•metres/ feet ascended

•temperature

•cadence*

•Power output*

•left right pedalling balance*

•pedalling index*

B.Freely programmable BasicSet will automatically guide you through your exercise session with the help of the following functions:

•three adjustable target heart rate limits

•three adjustable, alternating timers

•time-based or heart-rate-based recovery calculation

*Optional Polar Cadence Sensor or Polar Power Output Sensor required.

A 14

C. Freely programmable Interval Trainer will automatically guide you through your interval training session with the help of the following, preset exercise phases:

•warm-up with a target heart rate zone and a countdown timer

•up to 30 intervals with a target heart rate zone. After each interval you have a recovery calculation option.

•cool-down with a target zone and a countdown timer functions.

3.FILE

Your receiver stores exercise information in 99 exercise files:

•the start date and time of the exercise

•total exercise time

•the average and maximum heart rate readings for the exercise session

•the recovery value (only BasicSet)

•total distance of the exercise

•average and maximum speed

•average and maximum cadence*

•average, maximum and minimum altitude

•average, maximum and minimum temperature

•metres/ feet ascended

•output power in watts*

•pedalling index*

•left right pedalling balance*

•heart rate limits used during the exercise

A 15

S710 man GBR/B kopio.pm6	14-15	8/3/01, 14:33

•time spent in, above and below your target zones during exercise

•OwnCal calorie expenditure

•cumulative calorie expenditure

•cumulative exercise time

•cumulative riding time

•odometer

•your interval training information: warm-up, interval and cool-down phases

•your lap information: best lap time; lap and split times; current, average and maximum heart rate for each lap; cycling information at the end of the lap

•heart rate and cycling samples saved at the preset recording rate

In addition to an exercise file, your cumulative and maximum exercise values are updated in records file.

4. OPTIONS

In the Options mode, you can enter the following settings:

Exercise settings: You can select BasicUse with no settings or 5 freely programmable BasicSets or Interval Training Sets

Memory settings: Set the recording rate of your heart rate of 5 seconds, 15 seconds or 1 minute

*Optional Polar Cadence Sensor or Polar Power Output Sensor required.

A 16

Function settings: OwnCal calorie counter on/off, fitness test on/off, predicted maximum heart rate on/off, altitude on/off

Bicycle feature settings: bike 1 or 2 on/off, wheel size, cadence* on/off, output power* on/off, autostart on/off

User-specific information: weight, height, date of birth, gender, activity level, maximum heart rate and maximal oxygen uptake

Monitor settings: activity/button sound on/off, measurement units, Help on/off

Watch settings: alarm, time of day, date, reminders on/off

5. FITNESS TEST

In this mode you can:

•perform the Polar Fitness Test

•recall your latest test results; OwnIndex and HRmax-p values

•update your user information to reflect your most recent OwnIndex and HRmax-p values

6. CONNECTION

In this mode you can:

•upload your receiver settings from your computer with Polar Precision Performance version 3.0 or later

•download recorded exercise information to your computer for detailed analysis with Polar Precision Performance version 3.0 or later

A 17

S710 man GBR/B kopio.pm6	16-17	8/3/01, 14:33

B. HOW TO ENTER SETTINGS

This section describes how to manually enter settings by pressing the receiver buttons. However, Polar S710 offers you another and faster way as well: prepare your settings with Polar

Precision Performance software and upload them to your receiver from your computer. After preparing your settings you can upload options lock function. Your options can no longer be changed until you deactivate the options lock from the “user features” of your software. See the “Uploading settings

from computer” chapter.

Time Of Day File Options Fit. TestConnect

Exercise SetMemory SetFunction SetBike Set User Set Monitor Set Watch Set

B 18

User information settings

Options

User Set

Weight Height Birthday Sex Activity HRmax VO2max

In the User Set loop you can move forward only by pressing OK.

The digits run faster if you press and hold the up or down button as you adjust the value. Release the button when approaching the desired value.

Measuring units depend on your choice in Options/ Monitor Set/ Unit 1 or Unit 2.

	Units 1	Units 2
Weight	kg	lbs
Height	cm	ft/ inch
Date of birth setting order	day - month - year	month - day - year

1.In the Time of day display scroll up or down until OPTIONS is displayed.

2.Press OK to enter the Options mode. EXERCISE SET is displayed.

3.Scroll up or down until USER SET is displayed.

4.Press OK to start the user information settings.

Weight (kg or lbs)

5. Scroll up or down to adjust your weight. Press OK.

Height (cm or ft/ inch)

6. Scroll up or down to adjust your height. Press OK.

B 19

S710 man GBR/B kopio.pm6	18-19	8/3/01, 14:33

Units 2: setting order is month - day - year.

Date of birth (Birthday)

7. Scroll up or down to adjust your day of birth. Press OK.

8. Month appears. Scroll up or down to select your month of birth. Press OK.

9. Year appears. Scroll up or down to adjust the year of birth. Press OK.

Sex

10. Scroll up or down to select your gender. Press OK.

Activity level (Activity)

11.Scroll up or down to select your activity level for Polar Fitness Test. Press OK.

Assess your long-term physical activity level. Do not change your activity level description if your regular exercise habits have changed during the last six months.

Low	You do not participate regularly in programmed recreational sport
	or heavy physical activity. E.g. you walk only for pleasure or
	occasionally exercise sufficiently to cause heavy breathing or
	perspiration.
Middle	You participate regularly in recreational sports. E.g. you cycle 15-
	30 km per week or spend 1/2-2 hours per week in comparable
	physical activity or, your work requires modest physical activity.
High	You participate regularly, at least 3 times a week, in heavy physical
	exercise. E.g. you cycle 30-60 km per week or spend 2-3 hours per
	week in comparable physical activity.
	B 20

Top	You participate regularly in heavy physical exercise at least 5 times
	a week. E.g. you exercise to improve performance for competitive
	purposes.

Maximum heart rate value (HRmax)

12.Your age-predicted maximum heart rate value is displayed as a default setting when you set this value for the first time. If you know your exact clinically tested current maximum heart rate value, set the value by scrolling up or down.

13.Press OK.

If you do not know this value, update it in the Fitness Test mode after having carried out the Polar Fitness Test.

Maximal oxygen uptake value (VO2max)

14.The wrist receiver suggests value 35 for females and value 45 for males as a default setting when you set this value for the first time. If you know your exact clinically tested current maximal oxygen uptake value, set the value by scrolling up or down.

15.Press OK. User Set appears.

If you do not know this value, update it in Fitness Test mode after having carried out the Polar Fitness Test

To continue your settings, press the stop button or to return to the Time of day display, press and hold the stop button.

B 21

S710 man GBR/B kopio.pm6	20-21	8/3/01, 14:33

Exercise settings

When you start setting your exercise preferences your first choice is to select whether you want to set your personal exercise set or to exercise with BasicUse option. If you select to start setting the exercise sets, your second choice is whether you want to select BasicSet or an Interval Training Set.

Selecting exercise type

BasicUse (E0)

BasicUse is a simple mode for exercising. You do not have to do any settings before exercising with this Exercise mode. While exercising, you can see the following optional values:

•current heart rate and average heart rate of the exercise

•stopwatch

•time of day

•splitand lap times

Additionally, you can follow calories of your exercise session, percentage of your maximum heart rate and cycling infromation, if you have set all the user information and turned the functions on.

Exercise set (E1-E5)

During exercising with this mode you can see the same optional values as in the BasicUse mode. Additionally, the exercise set will guide you through your exercise according to the settings you have made. You can also name the exercise sets e.g. after an exercise type.

You can set following exercise guiding functions:

•3 heart rate limits

•3 countdown timers

•interval function

•recovery calculation

B 22

Setting exercise sets

Preset exercise sets ready for five exercise sets; when you start exercising, just select one of the sets.

Interval Training Set

If you choose interval on, you can set 3 different exercise phases for each exercise set in following order:

Warm-up phase
•	countdown timer 1	On/OFF
•	heart rate limits 1	On/OFF

Interval phase

•interval calculation type: manual, timer, heart-rate- or distancebased interval

•number of repeated interval phases

• heart rate limits 2		On/OFF
•	recovery calculation	On/OFF
Cool-down phase
•	countdown timer 3	On/OFF
• heart rate limits 3		On/OFF

If you set the countdown timers of the phase off, you have to manually stop the phase.

BasicSet

If you choose interval off, you can set the following functions to your exercise:

•	timer 1	On/OFF
•	timer 2	On/OFF
•	timer 3	On/OFF
• heart rate limits 1		On/OFF
• heart rate limits 2		On/OFF
• heart rate limits 3		On/OFF
•	recovery calculation	On/OFF

You should select the timers on sequentially. E.g. you cannot set timer 3 on if timer 1 is off.

B 23

S710 man GBR/B kopio.pm6	22-23	8/3/01, 14:33

1.

In the Time of day display

Options

scroll up or down until

OPTIONS is displayed.

Exercise Set

2.

Press OK to enter the

E0

E1

E2

E3

E4

E5

Options mode. EXERCISE

SET is displayed.

3.Press OK to start the exercise settings. BasicUse E0 or exercise set E1 - E5 is displayed.

4.Scroll up or down until the desired exercise type is displayed. Press OK.

If you chose BasicUse (E0): to return to the Time of day display, press and hold the stop button and skip the rest of the exercise settings.

If you chose exercise set (E1-E5) Interval On/OFF is displayed.

5.Scroll up or down to turn the interval function on or off. Press OK. Timer 1 is displayed.

Exercise Set 1 - 5

Interval On

Interval OFF (BasicSet)

Recovery Hr

Timer 1

Timer 2

Timer 3

Limits 1

Limits 2

Limits 3

Recovery Timer

Timer 1

Limits 1

Interval

Repeat

Limits 2

Recovery

Timer3

Limits 3

Timer

Interval

Timer

Manual Interval

Interval Hr

Interval Distance

Recovery Hr

Recovery Distance

B 24

Setting timers

If you start from the Time of day display, repeat steps 1-5.

6.Scroll up or down until desired timer is displayed. Press OK to start setting the timer.

7.Scroll up or down to turn the timer on or off. Press OK. Timer OFF: skip steps 8-9.

8.Scroll up or down to adjust minutes. Press OK.

9.Scroll up or down to adjust seconds. Press OK.

Setting heart rate limits

If you start from the Time of day display, repeat steps 1-5.

6.Scroll up or down until desired limits are displayed.

7.Press OK to start setting the limits.

8.Lim High appears. Scroll up or down to adjust your upper limit. Press OK.

9.Lim Low appears. Scroll up or down to adjust your lower limit. Press OK.

Turning heart rate limits on/off

If you start from the Time of day display, repeat steps 1-5.

6.Scroll up or down until Limits is displayed.

7.Press and hold the signal/light button to turn limits on or off. Release. You can also turn the limits off in the Lim Low loop by scrolling

the down button.

B 25

S710 man GBR/B kopio.pm6	24-25	8/3/01, 14:33

Setting interval type

You can select four optional types of intervals:

A. Time-based interval	Ends your interval when you have used
	the preset time.
B. Heart-rate-based interval	Ends your interval as you reach the
	preset heart rate. When selecting heart-
	rate-based interval, recovery calculation
	must be set on.
C. Distance-based interval	Ends your interval as you reach the
	selected distance.
D. Manual interval	End the interval training session
	by pressing OK.

If you start from the Time of day display, repeat steps 1-5.

6.Scroll up or down until Interval TIMER/ Hr/ DIST/ MANUAL is displayed. Press OK to start setting the interval type. TIMER/ Hr/ DIST/ MANUAL is flashing.

7.Scroll up or down to select the interval type that will be used to end the interval. Press OK. If you chose manual interval skip steps 8 - 9.

B 26

A. Time-based interval

8.Scroll up or down to adjust minutes. Press OK.

9.Scroll up or down to adjust seconds. Press OK. Interval TIMER appears.

Or

B. Heart-rate-based interval

8.Scroll up or down to adjust the heart rate that will end your interval. Press OK. Interval Hr appears.

Or

C. Distance-based interval

8.Scroll up or down to adjust kilometres. Press OK.

9.Scroll up or down to adjust hundreds of metres. Press OK.

Setting the number of intervals

Units 2: Adjustable units are miles and feet.

If you start from the Time of day display, repeat steps 1-5.

You can set up to 30 intervals.

6.Scroll up or down until Repeat is displayed.

7.Press OK to start setting the number of intervals.

8.Scroll up or down to adjust the number of intervals. Press OK.

Or

If you do not know in advance the precise amount of the desired intervals, select continuous interval. The intervals will succeed until you manually stop the interval phase or until 30 intervals have been made.

8.Scroll down until Cont appears. Press OK.

B 27

S710 man GBR/B kopio.pm6	26-27	8/3/01, 14:33

Setting recovery calculation

You can select 3 optional types of recoveries:

A. Recovery timer	Ends your recovery as you reach the preset time.
B. Recovery heart rate	Ends your recovery as you reach the preset
	heart rate.
C. Recovery distance	Ends your recovery as you reach the selected
	distance.

If you start from the Time of day display, repeat steps 1-5.

6.Scroll up or down until Recovery TIMER/ Hr/ DIST is displayed.

7.Press OK to start setting recovery calculation on or off. On/OFF is flashing.

8.Scroll up or down to turn the recovery calculation on or off. Press OK. OFF: skip steps 9-11.

On: TIMER/ Hr/ DIST is flashing.

9.Scroll up or down to select recovery timer, heart rate or distance. Press OK.

A. RecoTime is displayed.

10.Scroll up or down to adjust minutes. Press OK.

11.Scroll up or down to adjust seconds. Press OK. Recovery TIMER appears.

Or

B. RecoHr is displayed.

10.Scroll up or down to adjust the value. Press OK. Recovery Hr appears.

Or

B 28

C. Rec. DIST is displayed.

10.Scroll up or down to adjust kilometres. Press OK.

11.Scroll up or down to adjust hundreds

of metres. Press OK. Recovery DIST appears.

Units 2: Adjustable units are miles and feet.

To continue your settings, press the stop button or to return to the Time of day display, press and hold the stop button.

Naming exercise sets

You can name the exercises with seven letters, numbers or punctual marks. The available digits are: 0-9, space, A-Z, a-z, - % / ( ) * + : ?.

1.In the Time of day display scroll up or down until OPTIONS is displayed.

2.Press OK to enter the Options mode. EXERCISE SET is displayed.

3.Press OK. E0-E5 is displayed.

4.Scroll up or down until desired exercise set (E1 - E5) is displayed.

5.Press and hold signal/light button. Adjustable letter is flashing.

6.Scroll up or down to select the desired mark. Press OK.

7.Repeat previous step until you have chosen all 7 letters.

To continue your settings, press the stop button or to return to the Time of day display, press and hold the stop button.

B 29

S710 man GBR/B kopio.pm6	28-29	8/3/01, 14:33

Options

Memory Set

Rec.Rate 5 Sec / 15 Sec / 60 Sec

Setting recording rate

1. In the Time of day display scroll up or down until OPTIONS

is displayed.

2. Press OK to enter the Options mode. EXERCISE SET is displayed.

3.Scroll up or down until MEMORY SET is displayed.

4.Press OK to start the memory settings. Rec.Rate is displayed.

5.Scroll up or down to select the desired recording rate. As you change the recording rate you can see the memory there is left in the lower row. Press OK.

The recording time of Polar S710 depends on the selected recording rate (5 s, 15 s, or 60 s). When the memory is full, you can continue exercising but the exercise is no longer recorded.

B 30

The following table shows the maximum exercise times for each recording rate.

Altitude	Speed	Cadence	Power	Rec. Rate 5s	Rec. Rate 15s	Rec. Rate 60s
On	On	On	On	4 h 57 min	14 h 53 min	59 h 34 min
On	On	On	OFF	8 h 56 min	26 h 48 min	99 h 59 min
On	On	OFF	On	5 h 35 min	16 h 45 min	67 h 01 min
On	On	OFF	OFF	11 h 10 min	33 h 31 min	99 h 59 min
On	OFF	OFF	OFF	14 h 53 min	44 h 41 min	99 h 59 min
OFF	On	On	On	5 h 35 min	16 h 45 min	67 h 02 min
OFF	On	On	OFF	11 h 10 min	33 h 31 min	99 h 59 min
OFF	On	OFF	On	6 h 23 min	19 h 09 min	76 h 37 min
OFF	On	OFF	OFF	14 h 53 min	44 h 41 min	99 h 59 min
OFF	OFF	OFF	OFF	44 h 42 min	99 h 59 min	99 h 59 min
					in one file	in one file
					and total 130 h	and total 520 h

The use of exercise sets and lap recording reduces the maximum exercise times.

To continue your settings, press the stop button or to return to the Time of day display, press and hold the stop button.

B 31

S710 man GBR/B kopio.pm6	30-31	8/3/01, 14:33

Turning functions on/off

Options

Function Set

OwnCal On/OFFFit. Test On/OFFHRmax-p On/OFFAltitude On/OFF

1.In the Time of day display scroll up or down until OPTIONS is displayed.

2.Press OK to enter the Options mode. EXERCISE SET is displayed.

3.Scroll up or down until FUNCTION SET is displayed.

4.Press OK to start the function settings. OwnCal is displayed.

To set the following functions on you have to set your user information. If kg/lbs are displayed as you start setting the function on, the wrist receiver points out that you have not set your all user information.

OwnCal calorie counter on/off

If you start from the Time of day display, repeat steps 1-4.

5.Press OK to start setting the OwnCal function. On/OFF starts to flash.

6.Scroll up or down to set the OwnCal on or off. Press OK.

In addition to heart rate OwnCal takes into account the preset user information. Update the HRmax-p and OwnIndex values to receive current OwnCal information.

Fitness test on/off

If you start from the Time of day display, repeat steps 1-4.

5. Scroll up or down until Fit. Test is displayed.

B 32

6.Press OK to start setting the fitness test. On/OFF starts to flash.

7.Scroll up or down to set the fitness test on or off. Press OK.

Predicted maximum heart rate on/off (HRmax-p)

If you start from the Time of day display, repeat steps 1-4.

5.Scroll up or down until HRmax-p is displayed.

6.Press OK to start setting the HRmax-p. On/OFF starts to flash.

7.Scroll up or down to set the HRmax-p on or off. Press OK.

HRmax-p can be turned on only if Polar Fitness Test is on.

Altitude and thermometre on/off

If you start from the Time of day display, repeat steps 1-4

5.Scroll up or down until Altitude is displayed.

6.Press OK to start setting the altitude measurement and thermometre. On/OFF starts to flash.

7.Scroll up or down to set the altitude on or off. Press OK.

If you turned Altitude off, skip the rest of the altitude settings.

8.If you turned Altitude on, “Wait...” appears for a few seconds.

9.Altitude and a flashing number appear. Start adjusting the starting point altitude. Adjustable units of 1/ 2 can be changed by pressing and holding the signal/light button.

Scroll up or down until the desired altitude is displayed. Press OK. It is recommended that you reset the altitude whenever a reliable reference is available.

To continue setting your settings, press the stop button or to return to the Time of day display, press and hold the stop button.

B 33

S710 man GBR/B kopio.pm6	32-33	8/3/01, 14:33
