R7 English

Table of Contents

Before measuring your Blood Pressure	3
Notes on safety	4
Names and functions of the parts	5
How to insert the batteries	6
How to set the Date and Time	7
How to measure Blood Pressure correctly	7
How to obtain a correct posture	9
How to measure Blood Pressure	10
How to use the Memory function	11
How to use the Graph function	12
How to change the settings	13
Auto memory	14
Position sensor	15
Left or right wrist measurement	15
Alarm	15
Time	16
Delete data	16
Reset settings	16
What is Blood Pressure?	17
Blood pressure at the upper arm and wrist	18
Maintenance and storage	19
Error indication	20
Troubleshooting	21
Spare parts and accessories	22
Specifications	22

Dear Customer,

Thank you for purchasing this OMRON product. OMRON products are known for their reliability and advanced technology. By buying this OMRON R7 wrist blood pressure monitor with position sensor you have chosen for a high quality and innovative instrument. We hope that you will be fully satisfied with your new blood pressure monitor. Please take your time to read this instruction manual carefully before using it for the first time. If you still have questions please contact your OMRON dealer or the distributor as mentioned on the packaging. They will be pleased to help you.

We wish you a healthy future!

2

R7 English

Before measuring your Blood Pressure

Notes on Safety Please read thoroughly before using this monitor.

•The warning signs and the sample icons shown here are listed for you to use the product safely and correctly as well as to prevent the risk of damage to you and others.

•The icons and meanings are shown as follows.

Warning sign	Contents
Caution	Indicates matters in which bodily harm or material damage* may
	arise as a result of incorrect handling.

*Material damage refers to a wide range of damage involving your house, household goods, domestic animals, and pets.

Examples of signs

The icon indicates prohibitions (what you cannot do). Matters involving actual prohibitions are indicated by text or pictures in or near .

The left icon refers to "prohibition to disassemble".

The icon indicates something compulsory (always follow). Matters involving actual compulsory actions are indicated by text or pictures in or near .

The left icon refers to "general compulsion".

Caution

Self-diagnosis of measured results and treatment are dangerous. Please follow the instructions of your doctor.

•Self-diagnosis may worsen the disease.

•When the arterial sclerosis proceeds due to diabetics, hyperlipemia, or hypertension, it may cause peripheral circulatory disturbance. For these cases, blood pressure may differ greatly between measurement at the wrist and the brachial.

Do not use this monitor for the infant or the person who cannot express one's intention.

•They may suffer accident or trouble.

Do not use this monitor for purposes other than measuring blood pressure.

•You may suffer accident or trouble.

Do not use portable phones near this monitor.

•The monitor may operate erroneously.

Do not disassemble or modify the main unit or the wrist cuff of the blood pressure monitor.

• Correct measurement will be impossible.

3

R7 English

Notes on safety

Important instructions for obtaining meaningful readings

•Avoid eating and drinking (alcohol), smoking, sport and taking medicines before measuring your blood pressure as this could affect your blood pressure level.

•Before you start sit comfortably on a chair and relax. It is recommended to check your blood pressure at least twice a day, in the morning after getting up and in the evening after work, or as advised by your doctor.

•Do not move and do not speak while the measurement is being taken. Avoid measuring your blood pressure while you are in a moving vehicle.

•Allow an interval of at least three minutes between readings. Otherwise congestion of blood might occur and distort the readings. Always remove the cuff between readings.

•Bare your wrist and take of your watch and jewellery before applying the cuff. Do not constrict the flow of your blood if you push up your sleeve.

Cautions

Blood pressure measurement is not suitable in case of serious arteriosclerosis (hardening of the arteries).

•The pulse rate indicator is not suitable for monitoring the frequency of cardiac pacemakers.

•If you suffer from disorders of heart rhythm, known as arrythmia, you should only use this blood pressure monitor in consultation with your doctor. In certain cases oscillometric measurement methods can produce incorrect readings.

•Pregnant women should only measure their own blood pressure in consultation with their doctor since the readings may be changed by the pregnancy.

Please remember: Self-measurement is not the same as medical treatment! You should never change the dose of medicines as prescribed by your doctor!

Before using your OMRON R7 for the first time

Your blood pressure monitor: the benefits

The OMRON R7 is a compact fully automatic wrist blood pressure monitor. Operating on the oscillometric principle it measures your blood pressure and pulse rate comfortable and quickly from the wrist. It contains an intelligent system for “fuzzy” controlled inflation, known as “Intellisense”. This is an advanced method of oscillometric measurement. No pre-setting of reinflation is necessary.

The OMRON R7 has a Position Sensor. The Position Sensor is able to determine the optimal height of your wrist (heart level) for the blood pressure measurement. Measuring at the heart level is extremely important since measuring at a higher or lower position will give wrong results.

The OMRON R7 has a large DOT matrix display enabling you to enlarge the digits and showing you graphs. Together with the built in alarm function for same time measurements or pill intake your OMRON R7 is the optimal device to manage your blood pressure.

4

		R7 English
Main unit	Batteries for monitoring	Storage case
	(Two LR03 alkaline batteries)

Instruction Manual		Blood pressure pass		Guarantee card

Names and functions of the parts

Main unit

Wrist Cuff

Battery Cover

5

R7 English

Systolic Blood

Pressure Display

Diastolic Blood

Pressure Display

Date/Time Display

Mark

Displayed when a stored measurement is shown.

Pulse Display

MEMORY RECALL button

Push this button to see the measured values stored in the monitor.

GRAPH CALL button

Push this button to see the graph.

ON/OFF button

Button	SETTING button
Push to move the displayed item	Push this button to set
forward. Push to move the	various items on the monitor
displayed item backward.	such as time and date.

Push this button to measure your blood pressure or to switch the monitor off.

How to insert the batteries

Use this monitor after inserting batteries in the main unit.

1.Open the battery compartment.

2.Insert the batteries (Type LR03 / AAA) as shown in the figure. Ensure the polarity (+/-) of the batteries is correct.

3.Close the battery cover.

6

R7 English

With new batteries (long life alkaline batteries) you are able to measure app. 300 times under normal conditions. Please switch off the monitor after using it. If you forget to switch the monitor off it will switch off itself after app. 2 minutes. Please take the batteries out of the monitor if you intend not to use the monitor for a long period (app. 2 months).

How to set the Date and Time

Before using your OMRON R7 for the first time, you have to set the date and time. After turning the monitor on by pushing the on/off button the initial screen (see picture) will be available for a few seconds. After the initial screen you will proceed automatically to the TIME SET screen. (For instruction how to set the date and time refer also to page 16 in Chapter How to change the settings.)

After reaching the time screen you will see the Gregorian calendar (year/day/month). The year will be flashing.

1.By using the ( ) buttons you can set the current year.

2.By pushing the SET button you will lock the year and proceed to the next item.

For setting the month, date and time repeat step 1 and 2. After setting the minutes you will proceed to the DELETE DATA screen. Please turn off your monitor by pushing the on/off button. Your OMRON R7 is ready for use now.

Initial Screen

Time Screen

How to measure Blood Pressure correctly

How to wrap the cuff

In order to measure your blood pressure correctly it is needed to wrap the cuff around your wrist in a correct way. If not, correct measurements are not possible. Please follow the coming instructions (left wrist):

1)Make sure that your wrist is bare and will be wrapped over your skin.

2)Make sure that you clothing is not constraining the flow of your blood.

3)Make sure that the wrist (left or right) to measure is selected from the settings menu (see also page 15). The left wrist is preset.

7
