Operating and Installation
Instructions
Ceramic combiset with Induction CS 1212
CS 1221
To prevent accidents and machine damage,
read the Operating Manual before
en - CA
installation or use. |
M.-Nr. 07 353 950 |
Contents
IMPORTANT SAFETY INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Description of the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 CS 1212 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 CS 1221 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Burner data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Before using for the first time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Induction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 How it works. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Noises . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Cookware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Turning the combiset On/Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Residual heat indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Auto-heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Booster function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Keep warm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Safety features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Child Safety Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Safety cut-out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Overheating protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Frequently asked questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Technical Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2
Contents
SAFETY INSTRUCTIONS FOR INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . 30
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Installation dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 CS 1212 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 CS 1221 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 Cut out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Installation of multiple appliances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 Attach the spring clips and support bars . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 Installing the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 Sealing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 Tiled surfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Electrical connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Help protect our environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
3
IMPORTANT SAFETY INSTRUCTIONS
WARNINGWhen using your appliance follow basic precautions, including the following:
Read all instructions before installation or use to prevent injury and appliance damage.
This appliance conforms to all uniform safety codes and regulations. The manufacturer cannot be held responsible for damage or injury caused by improper use of this appliance.
Keep these operating instructions in a safe place and pass them on to any future user.
SAVE THESE INSTRUCTIONS
Children
~Activate the Child Safety Lock so that the combiset cannot be turned on inadvertently.
~Children should not be left unattended in an area where the appliance is in use. Never allow children to sit or stand on any part of the appliance.
Caution: Do not store items of interest to children in cabinets above the appliance. Children climbing on the appliance to reach these items could be injured.
~The appliance is hot during use and remains so for some time after being switched off. Keep children away from the appliance.
~Ensure that any packing material, is disposed of safely and kept out of the reach of children. Danger of suffocation!
Correct usage
~Only use the combiset for residential cooking, and for the purposes described in this manual.
Other uses are not permitted and can be dangerous. The manufacturer will not be held liable for damage caused by unauthorized use or improper operation of any kind.
~Persons who lack physical, sensory or mental abilities, or experience with the appliance should not use it without supervision or instruction by a responsible person.
~ Keep all pots and pans out of the reach of children. Danger of burning or scalding.
4
IMPORTANT SAFETY INSTRUCTIONS
Technical Safety
~Installation, repair and maintenance work should be performed by a Miele authorized service technician. Work by unqualified persons could be dangerous and may void the warranty.
~Before installing the combiset, check for externally visible damage. Do not operate a damaged appliance.
~To guarantee the electrical safety of this appliance, continuity must exist between the appliance and an effective grounding system. It is imperative that this basic safety requirement be met. If there is any doubt, have the electrical system of the house checked by a qualified electrician. The manufacturer will not be held responsible for damages caused by the lack, or inadequacy, of an effective grounding system.
~Before installation, make sure that the voltage and frequency listed on the data plate correspond with the household electrical supply. This data must correspond to prevent injury and appliance damage. Consult a qualified electrician if in doubt.
~Do not use an extension cord to connect this appliance to electricity. Extension cords do not guarantee the required safety of the appliance.
~Do not use the appliance until it has been properly installed in the countertop.
~Install the appliance so that the power cord does not come into contact with any portion of the cooktop which may become hot during use.
~Before servicing, disconnect the appliance from the main power supply.
~Do not operate any appliance with a damaged cord or plug, or if the appliance has been damaged in any manner. Contact Miele’s Technical Service Department.
~Under no circumstances open the outer casing of the appliance.
~The combiset must not be installed outdoors.
~While the appliance is under warranty repairs should only be performed by an authorized service technician. Otherwise the warranty is void.
~In the event of any damage to the appliance, it must be turned off immediately and disconnected from the main power supply. Contact Miele’s Technical Service Department.
Do not use the appliance until it has been repaired. Ensure power is not supplied to the appliance until repair work is completed.
~Defective components should be replaced by Miele original spare parts only. Only with these parts can the manufacturer guarantee the safety of the appliance.
5
IMPORTANT SAFETY INSTRUCTIONS
~ Do not cook on a broken combiset. Any breakages or cracks in the ceramic surface of the appliance are defects and must be treated as such. If the combiset should break, cleaning solutions and spills may penetrate the broken combiset and create a risk of electric shock. Do not use the appliance until it has been repaired.
Safety
~Individuals with a pacemaker or similar medical device:
Please note that an electromagnetic field develops when the combiset is turned on. It is not likely that this will affect the pacemaker or similar device. If in doubt contact the manufacturer of the device or your doctor.
~Keep magnetized items, e.g. credit cards, disks, etc. away from the combiset while in operation. Damage may result.
~Do not touch the combiset or the surrounding areas during or immediately after use. The combiset may be hot even though it is dark in color. Wait until the residual heat indicators go out.
~Protect your hands with oven mitts or potholders when using the appliance. Use only dry, heat resistant potholders. Moist or damp potholders used on hot surfaces can result in steam burns. Do not let the potholder touch the hot heating elements. Do not use towels or other bulky items near the appliance.
~Do not heat unopened containers. Built-up pressure may cause the container to burst and result in injury.
~Do not flambé under an exhaust hood. Flames could be drawn up into the hood by the suction and the grease filters may ignite.
6
IMPORTANT SAFETY INSTRUCTIONS
~Do not store items on the appliance when not in use. Items could melt or catch fire from residual heat or if the appliance is turned on inadvertently. Always switch the cooking zone(s) off after use.
~Flammable materials should not be stored on or near the appliance.
~The combiset is fitted with a cooling fan. Drawers under the combiset are not recommended. If a drawer is fitted directly underneath the combiset, ensure that there is sufficient space between the drawer, its contents and the underside of the appliance in order to ensure sufficient ventilation for the combiset. Do not store small items or paper in the drawer. They could get sucked into the housing by the fan and cause damage or impair cooling. Ensure that no aerosols, combustible liquids or other flammable materials are kept in this drawer. If cutlery inserts are to be placed in the drawer they must be made of heat-resistant material.
~Metallic items kept in a drawer under the combiset can become hot when the appliance is used for a longer period of time. Use caution.
~If the combiset is installed above a pyrolytic oven it should not be used during the pyrolytic process. The overheating protection feature of the combiset might be activated.
~Never cover the appliance with a cloth. A fire may result.
~Be aware of loose fitting or hanging garments when operating the appliance, they may present a fire hazard.
~Never leave a combiset unattended at high settings or when cooking with oil or fat. Overheated oil could ignite. Always heat oil slowly, monitoring it as it heats.
~Never heat an empty pan unless the pan manufacturer states that you can do so.
~Do not use water on grease fires. Smother or use a dry chemical or foam-type extinguisher on any fire or flame.
~Make certain that the power cords of small appliances do not come in contact with the appliance. The insulation of the cable could become damaged. Danger of electric shock!
~Be careful not to drop anything on the ceramic surface of the combiset. Even lightweight objects may cause damage.
~Use the proper pan size. Select cookware with flat bottoms large enough to cover the heating element. Using undersized cookware will expose a portion of the heating element and may result in ignition of clothing or handles becoming hot. The proper size pot or pan will also improve efficiency.
7
IMPORTANT SAFETY INSTRUCTIONS
~Pot and pan handles should be turned inward and not extend over the countertop to reduce the risk of burns, ignition of flammable materials, and spills.
~Do not use pots or pans with pronounced edges or ridges on the ceramic combiset. These could scratch the combiset permanently. See "Cookware" for more information. Grains of salt and sand can cause scratches. Make sure that the bases of any pots and pans are clean, free of any fat or oils, and are dry.
~ Any spills should be removed as quickly as possible to prevent them from burning on and becoming difficult to remove.
The manufacturer cannot be held liable for damage caused by non-compliance with these Important Safety instructions.
SAVE THESE INSTRUCTIONS AND REVIEW THEM PERIODICALLY
~To prevent burns and breathing difficulty, allow the combiset to cool before cleaning. Some cleaners may produce toxic fumes if applied to a hot surface.
~Keep the combiset clean. Salt, sugar, and grit can cause scratches.
~When wiping spills on a hot combiset with a wet sponge or cloth, be careful to avoid steam burns.
~Do not let flammable materials,
i.e. cooking grease, accumulate on the appliance.
~Do not use a steam cleaner to clean this appliance. Steam could penetrate electrical components and cause a short circuit.
~Do not allow solid or liquid sugar, pieces of plastic or foil to fall on the burner when hot. If these residues are allowed to cool on the ceramic surface pitting or even cracking may occur.
8
Description of the unit
CS 1212
a Burner with double booster (BI/II)
b Burner with single booster (BI)
cDisplay
dCooking zone indicators
eIndicators
Control knobs for the burners:
frear
gfront
Indicators
l On/Off indicator
m Booster indicator
n "Residual Heat" indicator
9
Description of the unit
CS 1221
a Burner with double booster |
Indicators |
||||||
b Display |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
c Indicators |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
d Control knob |
l On/Off indicator |
||||||
|
m Booster indicator |
||||||
|
n "Residual Heat" indicator |
||||||
10
Description of the unit
Display
ß= No pan on burner or pan is unsuitable
A = Auto-heat
F = Fault (see "Frequently asked questions")
C / 0 = Safety cut-out feature (see "Safety features")
I = Booster I activated
II = Booster II activated
H = Overheating protection (see "Safety features")
L = Child safety lock (see "Safety features")
Burner data
Burner |
|
CS 1212 |
|
|
|
|
|
|
|
|
Minimum to maximum |
Rating in watts 240 V** |
|
|
|
diameter in cm* |
|
|
|
|
|
|
|
|
Front |
|
normal: |
|
1400 |
(10 cm - 16 cm) |
with Booster: |
|
1800 |
|
|
|
|||
|
|
|
|
|
|
|
normal: |
|
2300 |
Rear |
(16 cm - 23 cm) |
with Booster I: |
|
3000 |
|
|
with Booster II: |
|
3700 |
|
|
|
|
|
|
|
|
|
|
|
|
Total: |
|
3700 |
|
|
|
|
|
CS 1221
Minimum to maximum |
Rating in watts 240 V** |
|
|
diameter* |
|
|
|
|
|
|
|
7" - 11 3/4" |
normal: |
|
2400 |
(18 cm - 30 cm) |
with Booster I: |
|
3000 |
|
with Booster II: |
|
3700 |
|
|
|
|
*Pots with a bottom diameter in the stated range may be used.
**The stated power may vary depending on the size and material of the cookware.
11
Before using for the first time
Clean the combiset
^Before using for the first time, clean the appliance with a damp cloth and dry with a soft cloth.
Do not use liquid dish soap to clean the combiset, this may cause permanent blue discolorations.
Heat the appliance
When the combiset is first connected to the power supply and after a power failure, all indicators in the display will light up for approx. 1 second. The combiset can be used as normal once the indicators go out.
Metal components of the appliance have a protective coating which may give off a slight odor the first time the appliance is heated.
The smell will dissipate after a short time and does not indicate a faulty connection or appliance defect.
12
Induction
How it works
An induction coil is located under the burner. When the burner is switched on, this coil creates a magnetic field which impacts directly on the base of the pan and heats it up. The burner itself is heated indirectly by the heat given off by the pan.
Induction burners only work when a magnetic based pan is placed on it (see "Cookware").
Induction automatically recognizes the size of the pan, i.e. heat is only generated in the area covered by the base of the pan.
The burner will not work:
–if it is switched on without a pan in place, or if the pan is unsuitable (non-magnetic base).
–if the diameter of the pan is too small.
–if the pan is taken off the burner when it is turned on.
If this happens, ß will flash in the display.
If a suitable pan is placed on the burner within 3 minutes, ß will go out and you can continue cooking as normal.
If no pan or an unsuitable pan is placed on the burner, the burner and the combiset will switch off automatically after 3 minutes. 0 will flash alternately with C in the display.
To use the burner again as normal, first turn the control knob to "0".
Be careful not to place cutlery or other metal objects on the combiset. When the appliance is switched on, or when there is residual heat present, there is the risk of metal objects heating up quickly.
Beware of burns.
Depending on the material, other objects left on the combiset could also melt or catch fire.
Turn off the burner after use.
13
Induction
Noises
When using an induction burner, the following noises can occur in the pan, depending on what it is made of and how it is constructed.
–Higher power settings may cause a buzz. This will decrease or cease altogether when the power setting is reduced.
–If the pan base is made of layers of different materials (e.g. a sandwiched base), a cracking sound may be heard.
–You may hear a clicking sound from the electronic switches, especially on lower settings.
The appliance has a cooling fan to help extend the life of the electronics. When the combiset is being used at high levels for a long period of time, this will come on and you will hear a whirring sound. The fan may continue to run after the appliance has been switched off.
14
Induction
Cookware
Suitable pans include:
–stainless steel pans with a magnetic base
–enameled steel pans
–cast iron pans
Unsuitable pans:
–stainless steel pans without a magnetic base
–aluminum and copper pans
–glass, ceramic or earthenware pots and pans
To test whether a pot or pan is suitable for use on an induction combiset, hold a magnet to the base of the pan. If the magnet sticks, the pan is suitable.
Unless the pan manufacturer states that you can do so, do not use pans with very thin bases on this combiset, and never heat empty pans. This could damage the appliance and cookware, and effect the uniformity of the cooking.
Pan size
To make optimum use of the burner, choose cookware that fits between the inner and outer marking of the burner. If the base diameter of the pan is smaller than the inner marking, the induction heating will not work. The burner will behave as if it has no pan on it.
15
