ELECTRONIC DRYER
Use & Care Guide
For questions about features, operation/performance, parts, accessories, or service, call: 1-800-688-9900
or visit our website at...
www.maytag.com
In Canada, call: 1-800-807-6777
or visit our website at...
SÉCHEUSE ÉLECTRONIQUE
Guide d’utilisation et d’entretien
Pour assistance, installation, ou service, composez le :
1-800-807-6777
ou visitez notre site internet à..
www.maytag.ca
www.maytag.ca |
|
|
|
|
Guide de démarrage rapide/ |
Quick Start Guide/Dryer Use............ |
pg. 4 |
Utilisation de la sécheuse....p. 15 |
Para una versión en español, visite: www.maytag.com Número de pieza W10267628A
TABLE OF CONTENTS |
|
|
Page |
DRYER SAFETY .............................................................................................. |
2 |
QUICK START GUIDE/DRYER USE .............................................................. |
4 |
Drying and Cycle Tips ............................................................................... |
6 |
Cycles ........................................................................................................ |
6 |
Additional Features .................................................................................... |
7 |
Status Lights ............................................................................................... |
7 |
Controls Locked......................................................................................... |
7 |
Changing Cycles, Options, and Modifiers.................................................. |
8 |
Drying Rack Option................................................................................... |
8 |
DRYER CARE ................................................................................................. |
9 |
Cleaning the Dryer Location ...................................................................... |
9 |
Cleaning the Lint Screen ............................................................................ |
9 |
Cleaning the Dryer Interior ........................................................................ |
9 |
Removing Accumulated Lint...................................................................... |
9 |
Vacation and Moving Care ........................................................................ |
9 |
TROUBLESHOOTING................................................................................. |
10 |
WARRANTY................................................................................................. |
12 |
ASSISTANCE OR SERVICE......................................................... |
BACK COVER |
TABLE DES MATIÈRES |
|
|
|
|
Page |
SÉCURITÉ DE LA SÉCHEUSE....................................................................... |
|
13 |
GUIDE DE DÉMARRAGE RAPIDE/ |
|
|
UTILISATION DE LA SÉCHEUSE................................................................. |
|
15 |
Conseils pour le séchage et les programmes............................................ |
|
17 |
Programmes............................................................................................. |
|
17 |
Caractéristiques supplémentaires............................................................. |
|
18 |
Témoins lumineux ................................................................................... |
|
18 |
Controls Locked (commandes verrouillées) ............................................. |
|
18 |
Changement des programmes, options et modificateurs.......................... |
19 |
|
Option de grille de séchage..................................................................... |
|
19 |
ENTRETIEN DE LA SÉCHEUSE .................................................................... |
|
20 |
Nettoyage de l'emplacement de la sécheuse ........................................... |
|
20 |
Nettoyage du filtre à charpie.................................................................... |
|
20 |
Nettoyage de l’intérieur de la sécheuse ................................................... |
|
20 |
Retrait de la charpie accumulée .............................................................. |
|
20 |
Précautions à prendre pour les vacances et avant un déménagement ..... |
20 |
|
DÉPANNAGE .............................................................................................. |
|
21 |
GARANTIE................................................................................................... |
|
23 |
ASSISTANCE OU SERVICE ....................................... |
COUVERTURE ARRIÈRE |
|
W10260034A W10267628A - SP
DRYER SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.” These words mean:
DANGER
WARNING
You can be killed or seriously injured if you don't immediately follow instructions.
You can be killed or seriously injured if you don't follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can happen if the instructions are not followed.
2
IMPORTANT: The gas installation must conform with local codes, or in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54.
The dryer must be electrically grounded in accordance with local codes, or in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70.
WARNING: For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, or to prevent property damage, personal injury, or death.
–Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
–WHAT TO DO IF YOU SMELL GAS:
•Do not try to light any appliance.
•Do not touch any electrical switch; do not use any phone in your building.
•Clear the room, building, or area of all occupants.
•Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
•If you cannot reach your gas supplier, call the fire department.
–Installation and service must be performed by a qualified installer, service agency, or the gas supplier.
WARNING: Gas leaks cannot always be detected by smell.
Gas suppliers recommend that you use a gas detector approved by UL or CSA.
For more information, contact your gas supplier.
If a gas leak is detected, follow the “What to do if you smell gas” instructions.
3
QUICK START GUIDE/DRYER USE
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as gasoline, away from dryer.
Do not dry anything that has ever had anything flammable on it (even after washing).
Failure to follow these instructions can result in death, explosion, or fire.
WARNING
Fire Hazard
No washer can completely remove oil.
Do not dry anything that has ever had any type of oil on it (including cooking oils).
Items containing foam, rubber, or plastic must be dried on a clothesline or by using an Air Cycle.
Failure to follow these instructions can result in death or fire.
For a summary of how to use your dryer following installation, see the QUICK START GUIDE on the next page.
4
QUICK START GUIDE
NOTE: This Use and Care Guide covers several different models. Your dryer may not have all of the cycles and features described.
WARNING: To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY INSTRUCTIONS before operating this appliance. The following is a guide to using your dryer.
Please refer to specific sections of this manual for more detailed information.
START
1. Clean lint screen before each load.
2. Place laundry in dryer and shut door.
3. Press POWER.
4.Select SENSOR DRY or TIMED DRY Cycle.
5.Select WRINKLE PREVENT, if desired. See “Additional Features.”
6.Select CYCLE SIGNAL to turn off, if desired. See “Additional Features.”
7.Press and Hold START to start.
SENSOR DRY CYCLES
Sensor Dry Cycles automatically match the cycle setting to the type of load, and adjust drying time for optimal performance. See the “Cycles Sensor Dry Preset Settings Chart.”
To make changes during a Sensor Dry Cycle:
1.Press PAUSE/CANCEL once.
2.Select DRYNESS LEVEL and/or OPTION.
NOTE: Dryness Level selections can be made only while using Sensor Dry Cycles. Selecting More, Normal, or Less automatically adjusts the sensed time needed.
3. Press and Hold START.
TIMED DRY CYCLES
Use a Timed Dry cycle to set a drying time and temperature.
1.Press POWER.
2.Rotate the dial to select a Timed Dry Cycle.
3. Press the TIME ADJUST up or down until the desired drying time is displayed.
4.Press TEMPERATURE until the desired temperature illuminates.
5.Press and Hold START.
To make changes during a Timed Dry Cycle:
1.Press PAUSE/CANCEL once.
2.Adjust the Time and/or Options.
3. Press and Hold START.
TIMED DRY - Use this cycle if items are still damp after a Sensor Dry cycle.
RAPID DRY - Use for items requiring a short drying time.
FRESHEN UP - Use this cycle to help smooth out wrinkles from clean, dry clothes.
STOPPING OR RESTARTING
To pause/stop the dryer at any time - Open the door or press
PAUSE/CANCEL once.
To restart the dryer - Close the door. Press and Hold START button until dryer starts.
To end/cancel the dryer at anytime - Press PAUSE/CANCEL twice or open the door.
5
Drying and Cycle Tips
Select the correct cycle and dryness level or temperature for your load. If a Sensor Dry Cycle is running, the display shows the estimated cycle time when your dryer is automatically sensing the dryness level of your load. If a Timed Cycle is running, the display shows the exact number of minutes remaining in the cycle.
Cool Down tumbles the load without heat during the last few minutes of all cycles. Cool Down makes the loads easier to handle and reduces wrinkling. The length of the Cool Down depends on the load size and dryness level.
Drying tips
■Follow care label directions when they are available.
■If desired, add a fabric softener sheet. Follow package instructions.
■Remove the load from the dryer as soon as tumbling stops to reduce wrinkling. This is especially important for permanent press, knits, and synthetic fabrics.
■Avoid drying heavy work clothes with lighter fabrics. This could cause overdrying of lighter fabrics, leading to increased shrinking or wrinkling.
Cycle tips
■Dry most loads using the preset cycle settings.
■Refer to the Sensor Dry or Timed Dry Cycles Preset Settings chart (in the “Cycles” section) for a guide to drying various loads.
■Drying temperature and Dryness Level are preset when you choose an Sensor Dry Cycle. You can select a different dryness level, depending on your load, by pressing Dryness Level and choosing More or Less.
NOTE: You cannot use the Timed Dry Cycle Adjust Up or Down arrow buttons and you cannot modify temperature with the Sensor Dry cycles.
■If you wish to adjust the cycle length of a Timed Dry Cycle, press the Timed Dry Cycle Adjust up or down arrow buttons. Adjust the temperature of a Timed Dry Cycle by pressing TEMPERATURE until the desired temperature is selected.
NOTE: The Dryness Level option is not available with Timed Dry Cycles.
Cycles
Select the drying cycle that matches the type of load you are drying. See the Sensor Dry Cycles Preset Settings or the Timed Dry Cycle Preset Settings chart.
Cycle Control knob
Sensor Dry Cycles
Sensor Dry Cycles allow you to match the cycle to the load you are drying. See the following Sensor Dry Cycles Preset Settings chart. Each cycle dries certain fabrics at the recommended temperature. A sensor detects the moisture in the load and automatically adjusts the drying time for optimal drying.
Sensor Dry Cycles Preset Settings
Sensor Dry Cycles |
Temperature |
Time* |
Load Type |
|
(Minutes) |
|
|
|
COTTON/TOWELS or |
High |
45 |
HEAVY DUTY |
|
|
Heavy fabrics, cotton towels, |
|
|
bedspreads |
|
|
|
|
|
JEANS |
Regular |
55 |
Denim |
|
|
|
|
|
NORMAL |
Medium |
40 |
Sturdy fabrics, work clothes, |
|
|
sheets |
|
|
|
|
|
WRINKLE CONTROL |
Low |
35 |
No-iron fabrics, sport shirts, |
|
|
casual business clothes, |
|
|
permanent press blends |
|
|
|
|
|
DELICATE |
Extra Low |
30 |
Synthetic fabrics, washable knit |
|
|
fabrics, no-iron finishes |
|
|
*Estimated Time with dryness level (Normal) setting. Time will vary depending on load type and load size.
Timed Dry Cycles
Use Timed Dry Cycles to select a specific amount of drying time and temperature. When a Timed Dry Cycle is selected, the Estimated Time Remaining display shows the actual time remaining in your cycle. You can change the actual time in the cycle by pressing the Timed Dry Cycle Adjust Up or Down arrow buttons. See “Changing Cycles, Options, and Modifiers.”
Timed Dry Cycles Preset Settings
Timed Dry Cycles Load |
Temperature |
Default Time |
Type |
|
(Minutes) |
|
|
|
TIMED DRY |
High |
40 |
Heavyweight, bulky items, |
|
|
bedspreads, work clothes |
|
|
|
|
|
RAPID DRY |
High |
23 |
Small loads, sturdy fabric |
|
|
|
|
|
FRESHEN UP |
Regular |
20 |
Helps to smooth out |
|
|
wrinkles |
|
|
|
|
|
6
Additional Features
You may follow the progress of your dryer with the drying Status indicator lights.
Temperature
Temperature settings are used with the Timed Dry Cycles. Press TEMPERATURE until the desired temperature setting illuminates. Temperature settings cannot be used with the Sensor Dry Cycles.
Air Fluff
Use the Air Fluff temperature setting for items that require drying without heat such as rubber, plastic and heat-sensitive fabrics. This chart shows examples of items that can be dried using Air Fluff.
Type of Load |
Time* |
|
(Minutes) |
|
|
Foam rubber - pillows, padded bras, stuffed toys |
20 - 30 |
|
|
Plastic - Shower curtains, tablecloths |
20 - 30 |
|
|
Rubber-backed rugs |
40 - 50 |
|
|
Olefin, polypropylene, sheer nylon |
10 - 20 |
|
|
*Reset time to complete drying, if needed.
When using Air Fluff
■Check that coverings are securely stitched.
■Shake and fluff pillows by hand periodically during the cycle.
■Dry item completely. Foam rubber pillows are slow to dry.
NOTE: Air Fluff is not available with Sensor Dry cycles.
WRINKLE PREVENT Feature
WRINKLE PREVENT helps smooth out wrinkles that form when you cannot unload the dryer promptly at the end of a cycle. During this option, the dryer periodically starts and stops, tumbling the load for 90 minutes.
■Press the WRINKLE PREVENT feature to get up to 90 minutes of heat-free, periodic tumbling at the end of a cycle. Stop at any time by pressing the WRINKLE PREVENT feature or opening the dryer door.
■WRINKLE PREVENT is preset to OFF. The sensor Dry cycles will retain the WRINKLE PREVENT setting. For example, if you select the WRINKLE PREVENT feature in the Normal cycle, the WRINKLE PREVENT feature will be on the next time you select the Normal cycle.)
NOTE: If you do not select the WRINKLE PREVENT feature, the dryer stops after the cool down period.
Cycle Signal
When on, this feature produces an audible sound when the drying cycle is finished. Promptly removing clothes at the end of the cycle reduces wrinkling.
Press SIGNAL ON/OFF. The light on the control will glow yellow when the Cycle Signal is on.
NOTE: When the WRINKLE PREVENT feature is selected and the Cycle Signal is on, an audible sound will be emit every 5 minutes until the clothes are removed, or the WRINKLE PREVENT feature ends.
Status Lights
Follow the progress of your dryer with the drying Status indicator lights.
Wet
The Wet light illuminates at the beginning of a Sensor Dry Cycle if a wet item is detected.
■In a Sensor Dry Cycle, if a wet item is not detected after approximately 5 minutes, the dryer goes directly into Cool Down and the Cool Down and WRINKLE PREVENT indicators illuminate, if selected.
■In a Timed Dry Cycle, wet items are not detected. The dryer will continue to run for the length of time selected, and the Wet light will illuminate. The damp light will not illuminate.
Damp
The Damp light illuminates in a Sensor Dry Cycle when the laundry is approximately 80% dry.
Cool Down
The Cool Down light illuminates during the cool down part of the cycle. Laundry cools for ease in handling.
Dry
The Dry light illuminates when the drying cycle is finished. This indicator stays on during WRINKLE PREVENT.
WRINKLE PREVENT
The WRINKLE PREVENT light illuminates when this option is selected. This indicator stays on with Dry.
Clean Lint Screen
The Clean Lint Screen light is a reminder to check to see whether the lint screen needs to be cleaned. The Clean Lint Screen light will come on when the machine is turned on. The light will flash until the cycle is started or the door is opened, and then the light will turn off.
Controls Locked
This feature allows you to lock your settings to avoid unintended use of the dryer. You can also use the control lock feature to avoid unintended cycle or option changes during dryer operation.
To enable the control lock feature:
Press and hold CYCLE SIGNAL button for 3 seconds. The CONTROLS LOCKED icon lights up, and a single beep tone is heard. To unlock, press and hold CYCLE SIGNAL button for
3 seconds. The indicator light turns off.
7
Changing Cycles, Options, and Modifiers
You can change Sensor Dry Cycles, Timed Dry Cycles, Options, and Modifiers, anytime before pressing START.
NOTE: Three short tones sound if an unavailable combination is selected. The last selection will not be accepted.
Changing Cycles after pressing START
1.Press PAUSE/CANCEL twice. This ends the current cycle.
2.Select the desired cycle and options.
3.Press and hold START. The dryer starts at the beginning of the new cycle.
NOTE: If you do not press START within 5 minutes of selecting the cycle, the dryer automatically shuts off.
Changing Options and Modifiers after pressing Start
You can change an Option or Modifier anytime before the selected feature begins.
1.Press PAUSE/CANCEL once.
2.Select the new feature.
3.Press and hold START to continue the cycle.
NOTE: If you happen to press PAUSE/CANCEL twice, the program clears and your dryer shuts down. Restart the selection process.
Drying Rack Option
Use the drying rack to dry items such as sweaters and pillows without tumbling. The drum turns, but the rack does not move.
If your model does not have a drying rack, you may be able to purchase one for your model. To find out whether your model allows drying rack usage and for information on ordering, please refer to the front page of the manual or contact the dealer from whom you purchased your dryer.
NOTE: The drying rack must be removed for normal tumbling. Do not use Sensor Dry cycles with the drying rack.
To use the drying rack
Do not remove the lint screen. 1. Open dryer door.
A
A.Front edge
2.Place drying rack inside dryer drum, positioning the back wire on the ledge of the inner dryer back panel. Push down on front edge of drying rack to secure over the lint screen.
B
A
A.Drying rack front edge
B.Dryer back panel
3.Put the wet items on top of the drying rack. Leave space between the items so air can reach all the surfaces.
NOTE: Do not allow items to hang over the edge of the drying rack.
4.Close the door.
5.Press the POWER button.
6.Select a Timed Dry Cycle and temperature (see following chart). Items containing foam, rubber, or plastic must be dried on a clothesline or by using the Air Fluff temperature setting.
7.You may change the cycle time by pressing Timed Dry Cycle Adjust Up or Down arrow buttons. Reset time as needed to complete drying. Refer to the following table.
8.Press and hold START button (about 3 seconds).
NOTE: Check the lint screen and remove any lint accumulated from items dried on the drying rack.
This chart shows examples of items that can be rack dried and the suggested cycle, temperature setting and drying time. Actual drying time will depend on the amount of moisture items hold.
Rack Dry |
Setting |
Temp. |
Time* |
|
|
|
(Minutes) |
|
|
|
|
Wool Sweaters |
Timed |
Low |
60 |
Block to shape and lay flat |
Dry Cycle |
|
|
on the drying rack. |
|
|
|
|
|
|
|
Stuffed toys or pillows |
Timed |
Low |
60 |
Cotton or polyester fiber |
Dry Cycle |
|
|
filled |
|
|
|
|
|
|
|
Stuffed toys or pillows |
Timed |
Air Fluff |
90 |
Foam rubber filled |
Dry Cycle |
(no heat) |
|
|
|
|
|
|
|
|
|
Sneakers or canvas shoes |
Timed |
Air Fluff |
90 |
|
Dry Cycle |
(no heat) |
|
*Reset time to complete drying, if needed.
NOTE: You must remove drying rack for normal tumbling. Do not use Sensor cycles with the drying rack.
8
Loading...
