SOFTWARE VERSION RELEASE 1.0
KD165
OWNER’S GUIDE
WELCOME
Congratulations on choosing the Kohler KD165 digital Piano with the AUTO PLAY player piano function. The KD165 was designed to turn a your digital piano into a state-of-the-art player piano.
OVERVIEW
The moment you insert a special CD into the almost invisible controller, or select a song from a floppy disk or the onboard hard drive, your KD165 becomes a player piano. Enjoying piano music at its best is as close as the touch of a button. The easy-to-use remote control gives you the convenience you are accustomed to with your audio devices. Familiar controls like Play, Stop, Preset Volume and Track Select make this sophisticated system as easy to operate as your CD player.
The Kohler KD165 captures all the musical expressions of the original performing artist. Then the KD165 goes further, providing dazzling accompaniments by orchestras and bands. Many of the CDs have vocal tracks recorded by noted artists. The expansive CD library from two major player piano company’s library will satisfy your every musical wish.
You can also play Standard MIDI files from the floppy drive or the hard drive. The KD165 will “find” the piano part (if any recorded) in the MIDI file and direct it to the Grand Piano sound as well as to the player mechanism to move the keys.
The KD165 will read and play the QRS and Piano Disc CD library and any standard MIDI file.
3
GETTING STARTED
Controls and Indicators
Table 1. Remote control Identification
Treble Control |
|
|
Random Play |
|
|
Repeat |
CD Player Power ON/OFF |
|
Bass Control |
|
|
Accompaniment Balance |
|
|
|
Playback Expression Curve Select |
|
Preset Volume LOW |
External Source Select |
|
|
||
Play |
Preset Volume MEDIUM and CONCERT |
|
Next Track |
||
|
||
Previous Track |
Global Volume Up |
|
Pause |
|
|
Stop |
Global Volume Down |
|
|
KOHLERCD
The Kohler KD CD remote controller is an IR (infra red) device. The remote control operates best when you point it directly at the front of the KOHLER CD control unit, or at the external IR sensor. Battery: The remote controller’s battery compartment contains 2 AAA type batteries.
5
Table 2. Stationary Controller
1 |
2 |
3 |
4 |
5 |
6 |
7 |
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
AUX |
|
IR SENSOR |
AMI OUT |
RIGHT OUT LEFT |
RIGHT OUT LEFT |
POWER RAIL |
POWER
KOHLER
8 9 10 11 12
1 |
IR SENSOR |
8 |
ON/OFF BUTTON |
|
External IR sensor connector. |
|
Used to turn on and o the unit. |
2 |
ANALOG MIDI OUT |
9 |
LED DISPLAY |
|
Used to send special analog MIDI |
|
Displays CD track numbers and |
|
signal to external device. |
|
control functions. |
|
Note: Function is not available in |
|
|
|
firmware MIDI processor V59 |
10 |
IR SENSOR |
|
and under. |
|
Remote controller sensor. |
3 & 4 |
LINE OUTPUT RIGHT AND LEFT |
11 |
DISC TRAY OPEN BUTTON |
|
Used to connect external amplifier |
|
Used to open the CD Tray. |
|
and/or powered speakers to the |
|
|
|
KOHLERCD. |
12 |
DISC TRAY |
5 & 6 |
LINE INPUT LEFT AND RIGHT |
|
Used to hold CD to be played. |
|
|
||
|
Used to connect an external audio |
|
|
|
source to the KOHLERCD. |
|
|
7POWER RAIL CONNECTOR
Used to connect the solenoid engine to the KOHLERCD.
6
