Intel® Desktop Board DG35EC

Product Guide

Order Number: E30452-001

Revision History

Revision

Revision History

Date

-001

First release of the Intel® Desktop Board DG35EC Product Guide

February 2008

If an FCC declaration of conformity marking is present on the board, the following statement applies:

FCC Declaration of Conformity

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

For questions related to the EMC performance of this product, contact:

Intel Corporation, 5200 N.E. Elam Young Parkway, Hillsboro, OR 97124 1-800-628-8686

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and the receiver.

Connect the equipment to an outlet on a circuit other than the one to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications to the equipment not expressly approved by Intel Corporation could void the user’s authority to operate the equipment.

Tested to comply with FCC standards for home or office use.

Canadian Department of Communications Compliance Statement

This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

Le présent appareil numerique német pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la classe B prescrites dans le Réglement sur le broullage radioélectrique édicté par le ministére des Communications du Canada.

Disclaimer

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. Intel products are not intended for use in medical, life saving, or life sustaining applications. Intel may make changes to specifications and product descriptions at any time, without notice.

Desktop Board DG35EC may contain design defects or errors known as errata which may cause the product to deviate from published specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.

Copies of documents which have an ordering number and are referenced in this document, or other Intel literature, may be obtained from Intel Corporation by going to the World Wide Web site at: http://www.intel.com/ or by calling 1-800-548-4725.

Intel and the Intel logo are trademarks of Intel Corporation in the U.S. and other countries. * Other names and brands may be claimed as the property of others.

Copyright © 2008, Intel Corporation. All rights reserved.

Preface

This Product Guide gives information about board layout, component installation, BIOS update, and regulatory requirements for Intel® Desktop Board DG35EC.

Intended Audience

The Product Guide is intended for technically qualified personnel. It is not intended for general audiences.

Use Only for Intended Applications

All Intel Desktop Boards are evaluated as Information Technology Equipment (I.T.E.) for use in personal computers (PC) for installation in homes, offices, schools, computer rooms, and similar locations. The suitability of this product for other PC or embedded non-PC applications or other environments, such as medical, industrial, alarm systems, test equipment, etc. may not be supported without further evaluation by Intel.

Document Organization

The chapters in this Product Guide are arranged as follows:

1Desktop Board Features: a summary of product features

2Installing and Replacing Desktop Board Components: instructions on how to install the Desktop Board and other hardware components

3Updating the BIOS: instructions on how to update the BIOS

AError Messages and Indicators: information about BIOS error messages and beep codes

BRegulatory Compliance: safety standards, regulations, and product certifications

Conventions

The following conventions are used in this manual:

CAUTION

Cautions warn the user about how to prevent damage to hardware or loss of data.

NOTE

Notes call attention to important information.

iii

Intel Desktop Board DG35EC Product Guide

Terminology

The table below gives descriptions of some common terms used in the product guide.

Term

Description





GB

Gigabyte (1,073,741,824 bytes)





GHz

Gigahertz (one billion hertz)





KB

Kilobyte (1024 bytes)





MB

Megabyte (1,048,576 bytes)





Mbit

Megabit (1,048,576 bits)





MHz

Megahertz (one million hertz)





iv

Contents

1

Desktop Board Features





Desktop Board Components.................................................................................

11



Processor..........................................................................................................

13



Main Memory.....................................................................................................

13



Intel® G35 Express Chipset .................................................................................

14



Intel G35 Graphics Subsystem......................................................................

14



Audio Subsystem ...............................................................................................

15



Legacy Input/Output (I/O) Controller ....................................................................

16



LAN Subsystem .................................................................................................

16



LAN Status Indicators..................................................................................

16



Hi-Speed USB 2.0 Support ..................................................................................

17



Enhanced IDE Interface ......................................................................................

17



Serial ATA.........................................................................................................

17



Expandability.....................................................................................................

18



BIOS................................................................................................................

18



Serial ATA and IDE Auto Configuration...........................................................

18



PCI and PCI Express* Auto Configuration .......................................................

18



Security Passwords.....................................................................................

18



Hardware Management Features ..........................................................................

19



Hardware Monitoring and Fan Speed Control ..................................................

19



Chassis Intrusion........................................................................................

19



Power Management Features ...............................................................................

20



ACPI.........................................................................................................

20



Hardware Support ......................................................................................

20



Power Connectors ...............................................................................

20



Fan Headers .......................................................................................

21



LAN Wake Capabilities.................................................................................

21



Instantly Available PC Technology..........................................................

21



+5 V Standby Power Indicator...............................................................

22



Wake from USB ..................................................................................

23



Wake from PS/2 Keyboard/Mouse..........................................................

23



PME# Signal Wake-up Support..............................................................

23



WAKE# Signal Wake-up Support ...........................................................

23



ENERGY STAR* Qualified .............................................................................

23



Speaker............................................................................................................

23



Battery.............................................................................................................

23



Real-Time Clock.................................................................................................

23

2

Installing and Replacing Desktop Board Components





Before You Begin ...............................................................................................

25



Installation Precautions.......................................................................................

26



Prevent Power Supply Overload ....................................................................

26



Observe Safety and Regulatory Requirements.................................................

26



Installing the I/O Shield ......................................................................................

27



Installing and Removing the Desktop Board ...........................................................

28



Installing and Removing a Processor.....................................................................

29



Installing a Processor ..................................................................................

29

v

Intel Desktop Board DG35EC Product Guide





Installing a Processor Fan Heat Sink..............................................................

32



Connecting the Processor Fan Heat Sink Cable................................................

33



Removing the Processor ..............................................................................

33



Installing and Removing Memory..........................................................................

34



Guidelines for Dual Channel Memory Configuration..........................................

34



Two or Four DIMMs .............................................................................

34



Three DIMMs ......................................................................................

35



Installing DIMMs ........................................................................................

36



Removing DIMMs........................................................................................

38



Installing and Removing a PCI Express x16 Card ....................................................

39



Installing a PCI Express x16 Card .................................................................

39



Removing the PCI Express x16 Card..............................................................

40



Connecting the Diskette Drive Cable .....................................................................

41



Connecting the IDE Cable....................................................................................

42



Connecting Serial ATA (SATA) Cables....................................................................

43



Connecting to the Internal Headers and Connectors ................................................

44



S/PDIF Connector .......................................................................................

45



Front Panel Audio Header ............................................................................

45



IEEE 1394a Header.....................................................................................

46



Serial Port Header ......................................................................................

46



Front Panel Header .....................................................................................

46



Alternate Front Panel Power LED Header ........................................................

47



USB 2.0 Headers ........................................................................................

47



Chassis Intrusion Header .............................................................................

48



Connecting to the Onboard Audio System..............................................................

48



Connecting Chassis Fan and Power Supply Cables...................................................

49



Chassis Fan Cables .....................................................................................

49



Power Supply Cables...................................................................................

50



Setting the BIOS Configuration Jumper .................................................................

51



Clearing Passwords ............................................................................................

52

3

Updating the BIOS





Updating the BIOS with the Intel® Express BIOS Update Utility.................................

59



Updating the BIOS with the ISO Image BIOS Update File or the Iflash Memory





Update Utility...............................................................................................

60



Obtaining the BIOS Update File ....................................................................

60



Updating the BIOS with the ISO Image BIOS Update File .................................

60



Updating the BIOS with the Iflash Memory Update Utility .................................

61



Recovering the BIOS...................................................................................

62

A

Error Messages and Indicators





BIOS Beep Codes...............................................................................................

63



BIOS Error Messages ..........................................................................................

63

B

Regulatory Compliance





Safety Standards ...............................................................................................

65



Place Battery Marking .................................................................................

65



European Union Declaration of Conformity Statement..............................................

66



Product Ecology Statements ................................................................................

67



Recycling Considerations .............................................................................

67



Lead-free 2LI/Pb-free 2LI Board ...................................................................

70



Restriction of Hazardous Substances (RoHS) ..................................................

71

vi





Contents



EU RoHS ............................................................................................

71



China RoHS ........................................................................................

72

EMC Regulations ................................................................................................

74



Ensure Electromagnetic Compatibility (EMC) Compliance..................................

75

Product Certifications..........................................................................................

76



Board-Level Certification Markings ................................................................

76



Chassis and Component Certifications............................................................

77

Figures



1.

Desktop Board DG35EC Components...............................................................

11

2.

LAN Connector LEDs .....................................................................................

16

3.

Location of the +5 V Standby Power Indicator ..................................................

22

4.

Installing the I/O Shield ................................................................................

27

5.

Desktop Board DG35EC Mounting Screw Hole Locations .....................................

28

6.

Lift the Socket Lever .....................................................................................

29

7.

Lift the Load Plate.........................................................................................

30

8.

Remove the Protective Socket Cover ...............................................................

30

9.

Remove the Processor from the Protective Processor Cover ................................

31

10.

Install the Processor .....................................................................................

31

11.

Close the Load Plate .....................................................................................

32

12.

Connecting the Processor Fan Heat Sink Cable to the Processor Fan Header..........

33

13.

Dual Channel Memory Configuration with Two DIMMs ........................................

34

14.

Dual Channel Memory Configuration with Four DIMMs........................................

35

15.

Dual Channel Memory Configuration with Three DIMMs ......................................

35

16.

Use DDR2 DIMMs .........................................................................................

36

17.

Installing a DIMM .........................................................................................

37

18.

Installing a PCI Express x16 Card ...................................................................

39

19.

Removing a PCI Express x16 Card ..................................................................

40

20.

Connecting the Diskette Drive Cable................................................................

41

21.

Connecting the IDE Cable ..............................................................................

42

22.

Connecting a Serial ATA Cable........................................................................

43

23.

Internal Headers ..........................................................................................

44

24.

Back Panel Audio Connectors .........................................................................

48

25.

Location of the Chassis Fan Headers................................................................

49

26.

Connecting Power Supply Cables ....................................................................

50

27.

Location of the BIOS Configuration Jumper Block ..............................................

51

28.

Removing the Battery ...................................................................................

57

29.

Desktop Board DG35EC China RoHS Material Self Declaration Table.....................

73

vii

Intel Desktop Board DG35EC Product Guide



Tables



1.

Feature Summary..........................................................................................

9

2.

Desktop Board DG35EC Components...............................................................

12

3.

LAN Connector LEDs .....................................................................................

17

4.

S/PDIF Connector Signal Names .....................................................................

45

5.

Front Panel Audio Header Signal Names for Intel High Definition Audio.................

45

6.

IEEE 1394a Signal Header Names ...................................................................

46

7.

Serial Port Header Signal Names.....................................................................

46

8.

Front Panel Header .......................................................................................

46

9.

Alternate Front Panel Power LED Header ..........................................................

47

10.

USB 2.0 Header Signal Names........................................................................

47

11.

Chassis Intrusion Header ...............................................................................

48

12.

Back Panel Audio Connector Definition.............................................................

48

13.

Jumper Settings for the BIOS Setup Program Modes..........................................

52

14.

Beep Codes .................................................................................................

63

15.

BIOS Error Messages ....................................................................................

63

16.

Safety Standards..........................................................................................

65

17.

Lead-Free Second Level Interconnect Marks .....................................................

71

18.

China RoHS Environmentally Friendly Use Period Mark .......................................

72

19.

EMC Regulations...........................................................................................

74

20.

Product Certification Markings ........................................................................

76

viii

1 Desktop Board Features

This chapter briefly describes the features of Intel® Desktop Board DG35EC. Table 1 summarizes the major features of the Desktop Board.

Table 1. Feature Summary

Form Factor

microATX (243.84 millimeters [9.60 inches] x 243.84 millimeters



[9.60 inches])







Processor

Support for an Intel® processor in the LGA775 package

Main Memory

Four 240-pin, DDR2 1.8 V SDRAM Dual Inline Memory Module





(DIMM) sockets



800/667 MHz single or dual channel DDR2 SDRAM interface



Support for up to 8 GB of system memory







Chipset

Intel® G35 Express Chipset consisting of:



Intel G35 Express Chipset Graphics and Memory Controller Hub





(GMCH)



Intel® 82801HB I/O Controller Hub (ICH8)

Graphics

Intel G35 Express Chipset with Intel® Graphics Media Accelerator





X3500 (Intel® GMA X3500)



Support for dual independent displays via VGA/DVI-D



One PCI Express* x16 connector supporting PCI Express graphics





add-in cards









Audio

Onboard subsystem, featuring:





― Independent multi-streaming 6-channel (5.1) and 2-channel





stereo





― Intel® High Definition Audio interface





― RealTek* ALC888S audio codec





― S/PDIF connector









Expansion

One PCI Express x16 connector

Capabilities

Two PCI Express x1 connectors





One PCI* connector







Legacy I/O Support

Legacy I/O Controller that provides:





― One diskette drive interface





― One serial port header





― PS/2* keyboard and mouse ports









Peripheral

Up to 10 USB 2.0 ports

Interfaces



― Six ports routed to the back panel









― Four ports routed to two USB headers



Up to two IEEE 1394a ports





― One port routed to the back panel





― One port routed to an IEEE 1394a header



Four Serial ATA (SATA) channels (3.0 Gb/s) via ICH8



One IDE interface with ATA-66/100 support (two devices)









continued

9

Intel Desktop Board DG35EC Product Guide

Table 1. Feature Summary (continued)

BIOS

Intel® Platform Innovation Framework for extensible firmware





interface



8 Mbit symmetrical flash memory device



Support for SMBIOS



Intel® Rapid BIOS Boot



Intel® Express BIOS Update

Power Management

Support for Advanced Configuration and Power Interface (ACPI)



Suspend to RAM (STR)



Wake on USB, PCI Express, PS/2, LAN, and front panel



ENERGY STAR* capable







Hardware

Voltage sense to detect out of range power supply voltages

Management

Thermal sense to detect out of range temperatures





Three fan headers



Three fan sense inputs to monitor fan speed





LAN Support

Intel® 82566DC Gigabit (10/100/1000 Mb/s) Ethernet LAN controller

Operating System

Microsoft Windows Vista* Ultimate

Support

Microsoft Windows Vista Enterprise





Microsoft Windows Vista Business



Microsoft Windows Vista Home Premium



Microsoft Windows Vista Home Basic



Microsoft Windows Vista Ultimate 64-bit edition



Microsoft Windows Vista Enterprise 64-bit edition



Microsoft Windows Vista Business 64-bit edition



Microsoft Windows Vista Home Premium 64-bit edition



Microsoft Windows Vista Home Basic 64-bit edition



Microsoft Windows* XP Media Center Edition 2005



Microsoft Windows XP Professional



Microsoft Windows XP Professional x64 Edition



Microsoft Windows XP Home







For more information about Desktop Board DG35EC, including the Technical Product Specification (TPS), BIOS updates, and device drivers, go to http://support.intel.com/support/motherboards/desktop/.

10

Intel DG35EC User Manual

Desktop Board Features

Desktop Board Components

Figure 1 shows the approximate location of the major components on Desktop Board DG35EC.

Figure 1. Desktop Board DG35EC Components

11

Intel Desktop Board DG35EC Product Guide

Table 2. Desktop Board DG35EC Components

Label

Description





A

PCI bus connector





B

IEEE 1394a header





C

PCI Express x1 connector 2





D

Speaker





E

PCI Express x1 connector 1





F

PCI Express x16 connector





G

Rear chassis fan header (3-pin)





H

Back panel connectors





I

12 V processor core voltage connector (2 x 2 pin)





J

Processor socket





K

Processor fan header (4-pin)





L

DDR2 DIMM 0 sockets





M

DDR2 DIMM 1 sockets





N

Front chassis fan header (3-pin)





O

Serial header





P

Diskette drive connector





Q

Main power connector (2 x 12 pin)





R

IDE connector





S

Chassis intrusion header





T

Serial ATA connectors (4)





U

Front panel header





V

Alternate front panel power LED header





W

High-speed USB 2.0 headers (2)





X

BIOS configuration jumper block





Y

Battery





Z

S/PDIF connector





AA

Front panel audio header





Go to the following locations for more information about:

Desktop Board DG35EC

http://www.intel.com/design/motherbd

Supported processors

http://www.intel.com/go/findCPU

12

Desktop Board Features

Processor

CAUTION

Failure to use an appropriate power supply and/or not connecting the 12 V (2 x 2 pin) power connector to the Desktop Board may result in damage to the board, or the system may not function properly.

Desktop Board DG35EC supports an Intel processor in the LGA775 package. Processors are not included with the Desktop Board and must be purchased separately. The processor connects to the Desktop Board through the LGA775 socket.

Go to the following locations for more information about:

Instructions on installing or upgrading the processor, page 29 in Chapter 2

Supported processors for Desktop Board DG35EC, http://www.intel.com/go/findCPU

Main Memory

NOTE

To be fully compliant with all applicable Intel® SDRAM memory specifications, the board should be populated with DIMMs that support the Serial Presence Detect (SPD) data structure. If your memory modules do not support SPD, you will see a notification to this effect on the screen at power up. The BIOS will attempt to configure the memory controller for normal operation.

The Desktop Board supports the dual or single channel memory configurations defined below.

Four 240-pin Double Data Rate 2 (DDR2) SDRAM Dual Inline Memory Module (DIMM) connectors with gold-plated contacts

Support for:

Non-ECC DDR2 800/667 1.8 V

Serial Presence Detect (SPD) memory only

Unbuffered, non-registered single or double-sided DIMMs

Memory configurations listed below:

Up to 2.0 GB utilizing 256 Mb technology

Up to 4.0 GB utilizing 512 Mb or 1 Gb technology

Up to 8.0 GB utilizing 1 Gb technology

13

Intel Desktop Board DG35EC Product Guide

Go to the following locations for more information about:

SDRAM specifications, http://www.intel.com/technology/memory/

Installing memory, page 34 in Chapter 2

Tested memory, http://www.cmtlabs.com/mbsearch.asp or http://www.intel.com/products/motherboard/index.htm?iid=HMPAGE+Header_2_P roduct_MB

Intel® G35 Express Chipset

The Intel G35 Express Chipset consists of the following devices:

Intel G35 Express Chipset Graphics and Memory Controller Hub (GMCH) with Direct Media Interface (DMI)

Intel 82801HB I/O Controller Hub (ICH8) with DMI

The GMCH component provides interfaces to the processor, memory, PCI Express, and the DMI interconnect. The component also provides integrated graphics capabilities supporting 3D, 2D, and display capabilities. The ICH8 is a centralized controller for the board’s I/O paths.

For more information on the Intel G35 Express Chipset go to http://developer.intel.com/products/chipsets/G35/index.htm.

Intel G35 Graphics Subsystem

The Intel G35 Express Chipset contains two separate, mutually exclusive graphics options. Either the integrated Intel Graphics Media Accelerator X3500 (GMA X3500) graphics controller is used or a PCI Express x16 add-in card can be used.

The GMA X3500 graphics controller supports dual independent displays via the VGA and DVI-D connectors on the Desktop Board back panel. When a PCI Express x16 add-in card is installed on the Desktop Board, the Intel GMA X3500 graphics controller is disabled.

14

Desktop Board Features

The Intel GMA X3500 graphics controller has the following features:

667 MHz core frequency

Advanced graphics performance, including:

DX10.0* and OpenGL* 1.5 support

Shader Model 4.0 support

Enhanced video playback support, including:

Intel® Clear Video Technology (for more information go to http://www.intel.com/products/chipsets/clear_video/)

Support for playback of HD-DVD and Blu-ray Disc* technology DVDs

Software DVD at 30 fps full screen

Dynamic Video Memory Technology (DVMT) support up to 256 MB

Advanced display support, including:

DVI specification 1.0 compliant

Dual independent display support (VGA/DVI-D)

High Definition Content Protection (HDCP) version 1.1 support

DDC2B compliant interface with Advanced Digital Display 2 card or Media Expansion Card (ADD2/MEC), support for TV-out/TV-in and DVI digital display connections

Support all HD formats including 720p, 1080i, and 1080p

Support for flat panels up to 2048 x 1536 at 75 Hz (when in dual-channel mode) or digital CRT/HDTV at 1920 x 1080 at 60 Hz (with ADD2/MEC)

Audio Subsystem

The onboard audio subsystem consists of the following:

Intel ICH8 I/O controller hub

RealTek ALC888S audio codec

Back panel audio connectors

Intel High Definition audio front panel audio header

3-pin S/PDIF connector

The audio subsystem supports the following features:

A signal-to-noise (S/N) ratio of 95 dB

Independent multi-streaming 5.1 audio (using the back panel audio connectors) and stereo (using the Intel High Definition front panel audio header)

All back panel audio connectors support automatic re-tasking

Go to the following locations for more information about:

Audio drivers and utilities http://support.intel.com/support/motherboards/desktop/

The front panel audio solution, page 45

The location and description the of back panel audio connectors, Figure 24 on page 48

15

Intel Desktop Board DG35EC Product Guide

Legacy Input/Output (I/O) Controller

The I/O controller features the following:

Low pin count (LPC) interface

One serial port interface via an onboard header

One diskette drive interface

Serial IRQ interface compatible with serialized IRQ support for PCI systems

PS/2-style mouse and keyboard interfaces

Intelligent power management, including a programmable wake up event interface

PCI power management support

LAN Subsystem

The LAN subsystem includes:

Intel® ICH8

Intel 82566DC Gigabit (10/100/1000 Mb/s) Ethernet LAN controller

RJ-45 LAN connector with integrated status LEDs

The subsystem features:

CSMA/CD protocol engine

LAN connect interface between ICH9DH and the LAN controller

PCI bus power management

For information about LAN software and drivers go to

http://support.intel.com/support/motherboards/desktop

LAN Status Indicators

Two LEDs are built into the RJ-45 LAN connector located on the back panel (see Figure 2). These LEDs indicate the status of the LAN.

Figure 2. LAN Connector LEDs

16

Desktop Board Features

Table 3 describes the LED states when the board is powered up and the LAN subsystem is operating.

Table 3. LAN Connector LEDs

LED

LED Color

LED State

Indicates









A (Link)

Green

Off

LAN link is not established













On

LAN link is established













Blinking

LAN activity is occurring









B (Speed)

N/A

Off

10 Mb/s data rate











Green

On

100 Mb/s data rate











Yellow

On

1000 Mb/s data rate









Hi-Speed USB 2.0 Support

The Desktop Board supports up to 10 USB 2.0 ports (six ports routed to the back panel and four ports routed to two internal headers) via ICH8. USB 2.0 ports are backward compatible with USB 1.1 devices. USB 1.1 devices will function normally at USB 1.1 speeds.

USB 2.0 support requires both an operating system and drivers that fully support USB 2.0 transfer rates. Disabling Hi-Speed USB in the BIOS reverts all USB 2.0 ports to USB 1.1 operation. This may be required to accommodate operating systems that do not support USB 2.0.

Enhanced IDE Interface

The board’s IDE interface handles the exchange of information between the processor and peripheral devices such as hard disk drives and CD-ROM drives. The interface supports:

Up to two IDE devices (such as hard drives)

ATAPI-style devices (such as CD-ROM drives)

Older PIO Mode devices

Ultra DMA-33 and ATA-66/100 protocols

Serial ATA

The Desktop Board supports four Serial ATA channels (3.0 Gb/s) via ICH8, connecting one device per channel.

17

Intel Desktop Board DG35EC Product Guide

Expandability

For system expansion, the Desktop Board provides the following expansion slots:

One PCI Express x16 connector

Two PCI Express x1 connectors

One PCI bus connector

BIOS

The BIOS provides the Power-On Self-Test (POST), the BIOS Setup program, the PCI/PCI Express and IDE auto-configuration utilities, and the video BIOS. The BIOS is stored in the Serial Peripheral Interface (SPI) Flash device.

The BIOS can be updated by following the instructions on page 59 in Chapter 3.

Serial ATA and IDE Auto Configuration

If you install a Serial ATA or IDE device (such as a hard drive) in your computer, the auto-configuration utility in the BIOS automatically detects and configures the device for your computer. You do not need to run the BIOS Setup program after installing a Serial ATA or IDE device. You can override the auto-configuration options by specifying manual configuration in the BIOS Setup program.

PCI and PCI Express* Auto Configuration

If you install a PCI/PCI Express add-in card in your computer, the PCI/PCI Express auto-configuration utility in the BIOS automatically detects and configures the resources (IRQs, DMA channels, and I/O space) for that add-in card. You do not need to run the BIOS Setup program after you install a PCI/PCI Express add-in card.

Security Passwords

The BIOS includes security features that restrict whether the BIOS Setup program can be accessed and who can boot the computer. A supervisor password and a user password can be set for the BIOS Setup and for booting the computer, with the following restrictions:

The supervisor password gives unrestricted access to view and change all Setup options. If only the supervisor password is set, pressing <Enter> at the password prompt of Setup gives the user restricted access to Setup.

If both the supervisor and user passwords are set, you must enter either the supervisor password or the user password to access Setup. Setup options are then available for viewing and changing depending on whether the supervisor or user password was entered.

18

Desktop Board Features

Setting a user password restricts who can boot the computer. The password prompt is displayed before the computer is booted. If only the supervisor password is set, the computer boots without asking for a password. If both passwords are set, you can enter either password to boot the computer.

For instructions on resetting the password, see Clearing Passwords on page 52.

Hardware Management Features

The hardware management features of Desktop Board DG35EC enable the board to be compatible with the Wired for Management (WfM) specification. The board has several hardware management features including the following:

Fan speed monitoring and control

Thermal and voltage monitoring

Chassis intrusion detection

Hardware Monitoring and Fan Speed Control

The features of the hardware monitoring and fan speed control include:

Monitoring of power supply voltages to detect levels above and below acceptable values

Fan speed controllers and sensors integrated into the legacy I/O controller

Thermal sensors in the processor, GMCH, and ICH8, plus an onboard remote sensor

Thermally monitored closed-loop fan control, for all onboard fans, that can adjust fan speed or switch the fans off as needed

Chassis Intrusion

The board supports a chassis security feature that detects if the chassis cover has been removed. The security feature uses a mechanical switch on the chassis that can be connected to the chassis intrusion header on the Desktop Board. See Figure 23 for the location of the chassis intrusion header.

19

Intel Desktop Board DG35EC Product Guide

Power Management Features

Power management is implemented at several levels, including:

Software support through the Advanced Configuration and Power Interface (ACPI)

Hardware support:

Power connectors

Fan headers

LAN wake capabilities

Instantly Available PC technology (Suspend to RAM)

+5 V standby power indicator LED

Wake from USB

Wake from PS/2 keyboard/mouse

Power Management Event signal (PME#) wakeup support

WAKE# signal wake-up support

ENERGY STAR qualified

ACPI

ACPI gives the operating system direct control over the power management and Plug and Play functions of a computer. The use of ACPI with the Desktop Board requires an operating system that provides full ACPI support.

Hardware Support

Power Connectors

ATX12V-compliant power supplies can turn off the computer power through system control. When an ACPI-enabled computer receives the correct command, the power supply removes all non-standby voltages.

When resuming from an AC power failure, the computer returns to the power state it was in before power was interrupted (either on or off). The computer’s response can be set by using the Last Power State feature in the BIOS Setup program’s Boot menu.

The Desktop Board has two power connectors. See Figure 26 on page 50 for the location of the power connectors.

20

Desktop Board Features

Fan Headers

The function/operation of the fans is as follows:

The fans are on when the computer is in the ACPI S0 state.

The fans are off when the computer is in the ACPI S3, S4, or S5 state.

All fan headers support closed-loop fan control that can adjust the fan speed or switch the fan on or off as needed.

All fan headers have a +12 V DC connection.

The Desktop Board has a 4-pin processor fan header and two 3-pin chassis fan headers.

LAN Wake Capabilities

CAUTION

For LAN wake capabilities, the 5 V standby line for the power supply must be capable of delivering adequate +5 V standby current. Failure to provide adequate standby current when using this feature can damage the power supply.

LAN wakeup capabilities enable remote wake-up of the computer through a network. The LAN subsystem monitors network traffic and upon detecting a Magic Packet* frame, it asserts a wake-up signal that powers up the computer.

Instantly Available PC Technology

CAUTIONS

For Instantly Available PC technology, the 5 V standby line for the power supply must be capable of delivering adequate +5 V standby current. Failure to provide adequate standby current when using this feature can damage the power supply and/or effect ACPI S3 sleep state functionality.

Power supplies used with this Desktop Board must be able to provide enough standby current to support the standard Instantly Available (ACPI S3 sleep state) configuration. If the standby current necessary to support multiple wake events from the PCI and/or USB buses exceeds power supply capacity, the Desktop Board may lose register settings stored in memory.

Instantly Available PC technology enables the board to enter the ACPI S3 (Suspend-to- RAM) sleep state. While in the S3 sleep state, the computer will appear to be off. If the computer has a dual-colored power LED on the front panel, the sleep state is indicated by the LED turning amber. When signaled by a wake-up device or event, the computer quickly returns to its last known awake state.

The Desktop Board supports the PCI Bus Power Management Interface Specification. Add-in cards that support this specification can participate in power management and can be used to wake the computer.

21

Intel Desktop Board DG35EC Product Guide

+5 V Standby Power Indicator

CAUTION

If the AC power has been switched off and the standby power indicator is still lit, disconnect the power cord before installing or removing any devices connected to the board. Failure to do so could damage the board and any attached devices.

The Desktop Board’s standby power indicator, shown in Figure 3, is lit when there is standby power still present on the board even when the computer appears to be off. For example, when this green LED is lit, standby power is still present at the memory module sockets and the PCI bus connectors.

Figure 3. Location of the +5 V Standby Power Indicator

For more information on standby current requirements for the Desktop Board, refer to the Technical Product Specification by going to http://support.intel.com/support/motherboards/desktop/, finding the product, and clicking on the Technical Documents tab.

22

Desktop Board Features

Wake from USB

NOTE

Wake from USB requires the use of a USB peripheral that supports Wake from USB.

USB bus activity wakes the computer from an ACPI S3 state.

Wake from PS/2 Keyboard/Mouse

PS/2 keyboard/mouse activity wakes the computer from an ACPI S3 state.

PME# Signal Wake-up Support

When the PME# signal on the PCI bus is asserted, the computer wakes from an ACPI S3, S4, or S5 state.

WAKE# Signal Wake-up Support

When the WAKE# signal on the PCI Express bus is asserted, the computer wakes from an ACPI S2, S3, S4, or S5 state.

ENERGY STAR* Qualified

In 2007, the US Department of Energy and the US Environmental Protection Agency revised the ENERGY STAR requirements. Intel worked directly with these two governmental agencies to define the new requirements. Currently Intel Desktop Boards meet the new ENERGY STAR requirements.

For information about the ENERGY STAR specifications, see: http://www3.intel.com/cd/channel/reseller/asmo-na/eng/337748.htm.

Speaker

A speaker is mounted on the Desktop Board. The speaker provides audible error code (beep code) information during the Power-On Self-Test (POST).

Battery

A battery on the Desktop Board keeps the values in CMOS RAM and the clock current when the computer is turned off. Go to page 53 for instructions on how to replace the battery.

Real-Time Clock

The Desktop Board has a time-of-day clock and 100-year calendar. The battery on the Desktop Board keeps the clock current when the computer is turned off.

23
