RENLIG GB
DW60
ENGLISH |
4 |
ENGLISH |
4 |
Contents
Safety information |
4 |
Setting and starting a washing programme |
15 |
Product description |
6 |
Care and cleaning |
|
Control panel |
7 |
16 |
|
Washing programmes |
9 |
What to do if… |
17 |
Use of the appliance |
10 |
Technical data |
19 |
Setting the water softener |
10 |
Installation |
19 |
Use of dishwasher salt |
11 |
Water connection |
20 |
Use of rinse aid |
12 |
Electrical connection |
21 |
Loading cutlery and dishes |
12 |
Environment concerns |
21 |
Use of detergent |
14 |
IKEA GUARANTEE |
21 |
Subject to change without notice
Safety information
For your safety and correct operation of the appliance, read this manual carefully before installation and use. Always keep these instructions with the appliance even if you move or sell it. Users must fully know the oper-
ation and safety features of the appliance.
Correct use
•The appliance is designed exclusively for domestic use.
•Only use the appliance to clean household utensils that are applicable for dishwashers.
•Do not put solvents in the appliance. Risk of explosion.
•Put the knives and all items with sharp points in the cutlery basket with their points down. If not, put in a horizontal position in the upper basket.
•Use only branded products for dishwashers (detergent, salt, rinse aid).
•If you open the door while the appliance is in operation, hot steam can escape. Risk of skin burns.
•Do not remove dishes from the dishwasher before the end of the washing programme.
•When the washing programme is completed, disconnect the mains plug from the mains socket and close the water tap.
•Only an authorised service engineer can repair this appliance. Use only original spare parts.
•Do not do repairs yourself to prevent injury and damage to the appliance. Always contact your local After Sales Service.
General safety
•Persons (including children) with reduced physical sensory, mental capabilities or lack of experience and knowledge must not use the appliance. They must have supervision or instruction for the operation of the appliance by a person responsible for their safety.
•Obey the safety instructions from the manufacturer of the dishwasher detergent to prevent burns to eyes, mouth and throat.
•Do not drink the water from the dishwasher. Detergent residues can stay in your appliance.
•Always close the door when you do not use the appliance to prevent injury and not to stumble over the open door.
•Do not sit or stand on the open door.
Child safety
•Only adults can use this appliance. Children must get supervision to make sure that they do not play with the appliance.
•Keep all the packaging away from children. There is a risk of suffocation.
•Keep all detergents in a safe area. Do not let children touch the detergents.
•Keep children away from the appliance when the door is open.
ENGLISH |
5 |
Installation
•Make sure that the appliance is not damaged because of transport. Do not connect a damaged appliance. If necessary, contact the supplier.
•Remove all packaging before first use.
•A qualified and competent person must do the electrical installation.
•A qualified and competent person must do the plumbing installation.
•Do not change the specifications or modify this product. Risk of injury and damage to the appliance.
•Do not use the appliance:
–if the mains cable or water hoses are damaged,
–if the control panel, worktop or plinth area are damaged, that you can get access to the inner side of the appliance.
If you have any doubts, please contact your After Sales Service. Refer to the list of the After Sales Services at the end of user manual.
•Do not drill into the sides of the appliance to prevent damage to hydraulic and electrical components.
Warning! Carefully obey the instructions for electrical and water connections.
ENGLISH
Product description
1
2
3
4
5
1Upper basket
2Water hardness dial
3Salt container
4Detergent dispenser
5Rinse aid dispenser
6
9
7
6
6Rating plate
7Filters
8Lower spray arm
9Upper spray arm
ENGLISH |
7 |
Control panel
|
5 |
|
|
|
4 |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1 2 3
A B
1On/off button
2Half-load button
3Programme selection/cancel button (SELECT/CANCEL)
4Indicator lights
5Programme indicator lights
Indicator lights
The indicator light comes on when the washing programme is completed. Auxiliary functions:
• Level of the water softener.
• Activation/deactivation the audible signals.
• An alarm if the appliance has a malfunction.
|
The indicator light comes on when it is neces- |
|
sary to fill the rinse aid. Refer to the chapter |
1) |
'Use of rinse aid'. |
The indicator light comes on when it is necessary to fill the salt container. Refer to the chap-
1) ter 'Use of dishwasher salt'.
The salt indicator light can stay on for some hours, but it does not have an unwanted effect on the operation of the appliance.
1) The indicator light is off while a washing programme operates.
ENGLISH |
8 |
Programme selection/cancel button
Use the programme selection/cancel button for these operations:
•To set the washing programme. Refer to the chapter 'Setting and starting a washing programme'.
•To set the water softener. Refer to the chapter 'Setting the water softener'.
•To deactivate/activate the audible signals. Refer to the section 'Audible signals'.
•To cancel a washing programme in progress. Refer to the chapter 'Setting and starting a washing programme'.
Half-load button
The half-load option is not available for all washing programmes. Refer to the chapter 'Washing programmes'.
•Load dishes in the upper and lower basket.
•Decrease the detergent dosage when you use the half-load option.
•Press the half-load button to set the option.
–The half-load indicator light comes on, when the half-load option is selectable.
With the half-load button pressed the time duration and the consumption of wa-
ter and energy are reduced.
Setting mode
The appliance is in setting mode when all the programme indicator lights are off and the end indicator light flashes.
The appliance must be in setting mode for these operations:
–To set a washing programme.
–To set the water softener level.
–To deactivate/activate the audible signals. If a programme indicator light is on, cancel the programme to go back to the setting mode. Refer to the chapter "Setting and starting a washing programme".
Programme indicator lights A and B
Apart the selection of the corresponding washing programme, these lights have an auxiliary functions:
•The adjustment of the water softener level.
•Deactivation/activation of the audible signals.
Audible signals
You can hear an audible signal:
•At the end of the washing programme.
•When the appliance has a malfunction. The activation of the audible signals is set at the factory.
Do these steps to deactivate the audible signals:
1. Switch on the appliance.
2. Make sure that the appliance is in setting mode.
3. Press and hold the programme selection/ cancel button until programme indicator light A flashes and programme indicator light B comes on.
4. Press the programme selection/cancel button again.
–Programme indicator light A comes on.
–Programme indicator light B starts to flash.
5.Wait until programme indicator light A goes off.
–Programme indicator light B continues to flash.
–The end indicator light comes on.
The audible signals are activated.
6.Press the programme selection/cancel button again.
– The end indicator light goes off.
The audible signals are deactivated.
7.Switch off the appliance to save the operation.
Do these steps to activate the audible signals:
1.Do the above procedure until the end indicator light comes on.
ENGLISH |
9 |
Washing programmes
Washing programmes
Programme |
Degree of |
Type of load |
Programme description |
Half-load op- |
|
|
soil |
|
|
tion |
|
|
|
Crockery, |
Prewash |
yes |
|
|
|
Main wash up to 70°C |
|
||
Intensive |
Heavy soil |
cutlery, pots |
2 intermediate rinses |
|
|
|
|
and pans |
Final rinse |
|
|
|
|
|
Drying |
|
|
|
|
Crockery, |
Prewash |
yes |
|
|
Normal soil |
Main wash up to 65°C |
|
||
Normal |
cutlery, pots |
2 intermediate rinses |
|
||
|
and pans |
Final rinse |
|
||
|
|
|
|||
|
|
|
Drying |
|
|
|
Normal or |
Crockery |
Main wash up to 60°C |
no |
|
Quick |
Final rinse |
|
|||
light soil |
and cutlery |
|
|||
1) |
|
|
|||
|
|
|
|
||
|
|
|
|
|
|
|
|
|
Prewash |
yes |
|
|
|
Crockery |
Main wash up to 50°C |
|
|
Eco 2) |
Normal soil |
1 intermediate rinse |
|
||
and cutlery |
|
||||
|
Final rinse |
|
|||
|
|
|
Drying |
|
|
|
|
Partial load |
1 cold rinse (to prevent food |
|
|
Rinse & |
Any |
(to be com- |
scraps to bond). |
no |
|
pleted later |
Detergent is not necessary |
||||
Hold |
|
|
|||
|
in the day) |
with this programme. |
|
||
|
|
|
1)This is the perfect daily programme to clean a not fully load. Ideal for a family of 4 persons who only want to load breakfast and dinner crockery and cutlery.
2)Test programme for test institutes. This is the economy washing programme. Please refer to separate leaflet supplied, for test data. Available only in 3 languages (English, French, German) just for test institutes purpose.
Consumption values (for full washing cycle)
Programme |
Programme duration |
Energy consumption |
Water consumption |
|
(minutes) |
(kWh) |
(litres) |
|
120-130 |
1,8-2,0 |
22-24 |
|
|
|
|
|
105-115 |
1,5-1,7 |
23-25 |
|
|
|
|
|
30 |
0,9 |
9 |
|
|
|
|
1) |
130-140 |
1,0-1,2 |
14-16 |
|
|
|
|
|
|
|
|
