HAOF1620
Oscillating
Table Fan
HAOF720/HAOF920
HAOF1220/HAOF1620
Owner ’s Guide
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
PLEASE READ AND SAVE
THESE IMPORTANT
SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should
always be followed to reduce the risk of fire, electric shock, and injury
to persons, including the following:
1) Read all instructions before using the appliance.
2) To avoid fire or shock hazard, plug the appliance directly into a
120 V AC electrical outlet.
3) Keep the cord out of heavy traffic areas. DO NOT let the cord
hang over the edge of a table or counter. To avoid fire hazard,
NEVER put the cord under rugs, near heat registers, radiator,
stoves, or heaters.
4) To protect against electrical hazards, DO NOT immerse in water or
other liquids. Do not use near water.
5) Close supervision is necessary when any appliance is used by or
near children, or by disabled people.
6) Always unplug the fan before moving it, putting on or taking off
parts, cleaning, or whenever the fan is not in use. Be sure to pull
by the plug and not the cord.
7) Avoid contact with moving parts. DO NOT operate without fan
grills properly in place.
8) DO NOT operate any appliance with a damaged cord or plug, if
motor fan fails to rotate, after the appliance malfunctions, or if it
has been dropped or damaged in any manner. Return appliance
to manufacturer for examination, electrical or mechanical
adjustment, or repair.
9) DO NOT operate in the presence of explosive and/or flammable
fumes.
10) Use appliance only for intended household use as described in this
manual. Any other use not recommended by the manufacturer
may cause fire, electric shock, or injury to persons. The use of
attachments not recommended or sold by The Holmes Group may
cause hazards.
11) DO NOT use outdoors.
12) Always use on a dry, level surface.
13) Keep unit away from heated surfaces and open flames.
14) WARNING:To reduce the risk of fire or electric shock, DO NOT
use this fan with any solid-state speed control device.
15) DO NOT attempt to repair or adjust any electrical or mechanical
functions on this unit. Doing so will void your warranty. The
inside of the unit contains no user serviceable parts. All servicing
should be performed by qualified personnel only.
PLEASE READ AND SAVE
THESE IMPORTANT
SAFETY INSTRUCTIONS
A
G
B
C
D
E
M
For the HAOF720, your product comes fully assembled.
Please skip to the Operating Instructions.
For all other fans, please continue below with the
Pre-Assembly Instructions.
Pre-Assembly
Step 1: Remove your fan from inside the box, being careful not to
Base Assembly
Step 1: Insert the body into the base.
Step 2: Tighten the base nut onto the bottom of the body.
Fan Head Assembly
Step 1: Remove protective plastic sleeve from the motor shaft.
Step 2: Position the rear grill over the motor shaft, making sure the
Step 3: Secure the rear grill in its place using the rear grill-mounting
Step 4: FOR HAOF920
Step 5: Center the front grill by aligning the Holmes logo on the grill
ILLUSTRATION
A. Grill Hub
B. Front Grill
C. Blade Nut
D. Blade
E. Rear Grill Mounting-Nut
F. Rear Grill
G. Motor Shaft
H. Motor Housing Prong
I. Oscillation Knob
J. Motor Housing
K. Body
L. Speed Control Knob
M. Base
N. Base Nut
F
H
I
J
K
L
N
THIS PRODUCT IS EQUIPPED WITH A POLARIZED AC
(Alternating Current)PLUG (a plug having one blade wider
than the other). This plug will fit into the power outlet
only one way. If the plug does not fit fully into the outlet,
reverse the plug. If it still does not fit, contact qualified
personnel to install the proper outlet.
DO NOT DEFEAT THE SAFETY PURPOSE OF THIS
POLARIZED PLUG IN ANY WAY.
ASSEMBLY INSTRUCTIONS
