HeatSeal® H535 Turbo Laminator |
HeatSeal® H535 Turbo Laminator |
|
|
H535 Turbo
Instruction Manual
Manuel d’instructions
Manual de instrucciones
To Register this product go to www.gbc.com
Pour enregistrer ce produit allez sur www.gbc.com
Para registrar este producto, entrar a www.gbc.com
X X
1 |
2 |
|
Pouch 0OUCH
Pochette
Bolsillo
4 |
5 |
|
Pouch |
3 |
0OUCH |
Pochette |
|
|
Bolsillo |
H535 Turbo Package Contents
North American Models:
Cord sets – Qty 1
IEC cord designed and rated for 120VAC/60Hz/10 A/1200W
Cooling Tray – Qty 1
A large 10” x 12.75” cooling tray that snaps on to the back of the machine has been provided with your laminating machine to help receive the laminated document and minimize any waves to assure a flat laminated document during the cooling process.
Cleaning Card - Qty. 1
The cleaning card is intended to be used after each session of laminating and will help keep residue and adhesive from getting the rollers and transferring to your laminated documents. Simply run the cleaning card through the machine on the hot setting in order to clean any adhesive that may have exited the pouch and onto the laminating machine rollers during the lamination process. By doing this you will help maintain excellent results over the life of the machine.
Tip Sheet – Qty. 1
A Tip Sheet was provided for use as a trouble shooting guide should you not get the results intened or just have general questions about laminating.
Contenu de la boîte H535 Turbo
Modèles pour l’Amérique du Nord :
Cordon amovible – Quantité 1
120VCA/60Hz/10A/1200W
Plateau de refroidissement - Quantité 1
Un grand plateau de refroidissement de 25,4 x 33,4 cm (10 x 12,75 pouces) qui se fixe au dos de l’appareil est fourni avec l’appareil de plastification pour aider à récupérer le document plastifié et pour maximiser les ondes afin de s’assurer d’avoir un document laminé plat pendant le processus de refroidissement.
Carte de nettoyage - Quantité 1
La carte de nettoyage est conçue pour être utilisée après chaque session de plastification et empêchera les résidus et la colle de se déposer sur les rouleaux et d’être transférés sur les documents plastifiés. Faites passer la carte de nettoyage dans l’appareil réglé au paramètre chaud afin de nettoyer toute colle qui aurait pu s’échapper de la pochette et se déposer sur les rouleaux de l’appareil pendant le processus de plastification. Cette pratique vous permettra d’avoir d’excellents résultats toute au long de la durée de vie de l’appareil.
Fiche « Conseils » - Quantité 1
Une fiche « conseils » est incluse et qui tient lieu de guide de dépannage au cas où vous n’obtenez pas les résultats escomptés ou en cas de questions générales sur la plastification.
Contenido del paquete H535 Turbo
Modelos norteamericanos:
Juegos de cable – Cant. 1
Cable IEC diseñado y clasificado para 120 V CA/60 Hz/10 A/1200 W
Bandeja de enfriamiento – Cant. 1
Con su máquina de laminar se proporciona una bandeja de enfriamiento grande de 10 x 12,75 pulg. (25,4 x 32,4 cm) que se adjunta a la parte trasera de la máquina para ayudar en la recepción del documento laminado y minimizar cualquier onda para asegurar un documento laminado plano durante el proceso de enfriamiento.
Tarjeta de limpieza – Cant. 1
La tarjeta de limpieza está diseñada para usarse después de cada sesión de laminación y lo ayudará a evitar que el residuo y el adhesivo queden en los rodillos y se transfieran a sus documentos laminados. Simplemente pase la tarjeta de limpieza a través de la máquina en el nivel de temperatura caliente para limpiar cualquier adhesivo que pueda haberse salido de la bolsa y haya quedado sobre los rodillos de la máquina laminadora durante el proceso de laminación. Al hacer esto ayudará a mantener excelentes resultados durante la vida de la máquina.
Hoja de consejos – Cant. 1
Se proporciona una hoja de consejos para usarla como guía para solucionar problemas si no llegara a obtener los resultados esperados o simplemente para responder preguntas generales sobre la laminación.
HeatSeal® H535 Turbo Laminator
Safety instructions |
m |
YOUR SAFETY AS WELL AS THE SAFETY OF OTHERS IS IMPORTANT TO GBC. IN THIS INSTRUCTION MANUAL AND ON THE PRODUCT ARE IMPORTANT SAFETY MESSAGES. READ THESE MESSAGES CAREFULLY.
mTHE SAFETY ALERT SYMBOL PRECEDES EACH SAFETY MESSAGE IN THIS INSTRUCTION MANUAL. THIS SYMBOL INDICATES A POTENTIAL PERSONAL SAFETY HAZARD THAT COULD HURT YOU OR OTHERS, AS WELL AS CAUSE PRODUCT DAMAGE OR PROPERTY DAMAGE.
THE FOLLOWING WARNING IS FOUND ON THE PRODUCT IN SEVERAL LANGUAGES.
ElectricalWARNINGshock hazard. Do not open. No user
servicable parts inside. Refer servicing to qualified
service personnel.
This safety message means that you could be seriously hurt or killed if you open the product and expose yourself to hazardous voltage.
The following ISO and IEC symbols appear on this product, and their meaning is as follows:
Important Safeguards |
m |
mWARNING: FOR YOUR PROTECTION DO NOT CONNECT THE POUCH LAMINATOR TO ELECTRICAL POWER UNTIL YOU READ THESE INSTRUCTIONS COMPLETELY. KEEP THESE INSTRUCTIONS IN A CONVENIENT LOCATION FOR FUTURE REFERENCE. TO GUARD AGAINST INJURY, THE FOLLOWING BASIC SAFETY PRECAUTIONS MUST BE OBSERVED IN THE SET-UP AND USE OF THIS PRODUCT.
General safeguards
•Use the unit only for its intended purposes of laminating documents.
•Do not place anything in the pouch entrance of the laminator other than documents in pouches.
•Place unit on a secure, stable work area to prevent the unit from falling and possibly causing personal injury and damage to the unit.
•Follow all warnings and instructions marked on the unit.
•The socket outlet shall be installed near the equipment and shall be easily accessible.
•Do not block the vent slots, this will cause the laminator to overheat.
•Do not block the vent slots; this will cause the laminator to overheat.
•Never insert the loose end of the pouch first into the machine. This could cause the machine to jam.
•Never attempt to do single sided lamination. This will cause the machine to jam.
•After laminating run a clean card through the machine to clean glue residue off of the rollers. This will extend the life of the roller
/N /FF #OLD
2ELEASE (OT
Special notice
Thank you for your recent purchase of a GBC Pouch Laminator. Your new laminator may emit a slight odor during the initial stage of operation. It is normal and will diminish after several hours of operation.
Cleaning
mCaution: Unplug this product before cleaning.
•Wipe exterior only with a damp cloth. Do not use detergents or solvents.
•Do not use aerosol dusters or cleaners
•Do not spray anything into the product, foreign substances can be explosive.
Important S
Electrical safeguards
•The unit must be connected to a supply voltage corresponding to the electrical rating shown on the unit.
•Unplug the unit before moving it, or when it is not in use for an extended period of time.
•Do not operate with a damaged supply cord or plug. Do not alter the attachment plug. The plug is configured for the appropriate electrical supply.
•Do not overload electrical outlets beyond their capacity; fire or electrical shock could result.
•The unit is intended for indoor use only.
•Never push objects through the cabinet slots. Do not spill liquid of any kind on this product.
•Close supervision is required when this product is used near children
Service
Do not attempt to service or repair the pouch laminator yourself. Unplug the unit and contact an authorized GBC service representative for any required repairs.
Specifications
|
GBC HeatSeal H535 Turbo |
GBC HeatSeal H535 Turbo |
|
Electrical |
120V/60Hz/ 10A / 1200W |
230V/50Hz / 5A/1140W |
|
|
|
|
|
Machine Dimensions |
20.48” X 10.64” X 5.92” |
620 x 200 x 126 MM |
|
|
|
|
|
Machine Weight |
21.27 LBS. |
9.67 KG |
|
|
|
|
|
Maximum Pouch Thickness |
1.5 - 10 MIL |
38 - 250 MIC |
|
|
|
|
|
Maximum Pouch and Board |
.100” |
2.54 MM |
|
Thru Put Thickness |
|||
|
|
||
Maximum Pouch Width |
12.5” |
317.5 MM |
|
|
|
|
|
Speed |
Up to 40”/min. |
Up to 1000mm/minute |
|
Warm Up Time |
4 – 5 Minutes |
4 – 5 Minutes |
|
|
|
|
Loading...
