DECLARATION OF CONFORMITY

Manufacturer’s Name:

DigiTech

Manufacturer’s Address:

8760 S. Sandy Parkway



Sandy, Utah 84070, USA

declares that the product:



Product name:

Hyper Phase

Product option:

all (requires Class II power



adapter that conforms to the



requirements of EN60065,



EN60742, or equivalent.)

conforms to the following Product Specifications:

Safety:

IEC 60065 (1998)

EMC:

EN 55013 (1990)



EN 55020 (1991)

Supplementary Information:

The product herewith complies with the requirements of the Low Voltage Directive 72/23/EEC and the EMC Directive 89/336/EEC as amended by Directive 93/68/EEC.

Vice-Presidentof Engineering

8760 S. Sandy Parkway

Sandy, Utah 84070, USA

Date: May 30, 2002

European Contact:

Your local DigiTech Sales and



Service Office or



Harman Music Group



8760 South Sandy Parkway



Sandy, Utah



84070 USA



Ph: (801) 566-8800



Fax: (801) 568-7583

Warning

For your protection, please read the following:

Important Safety Instructions

1.Read these instructions.

2.Keep these instructions.

3.Heed all warnings.

4.Do not use this apparatus near water.

5.Clean only with dry cloth.

6.Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

7.Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

8.Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

9.Unplug this apparatus during lightning storms or when unused for long periods of time.

10.No user serviceable parts inside. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supplycord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

11.WARNING:To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.

12.Refer to labels on the unit, including bottom cover, or other markings and pertinent information.

WARRANTY: We atDigiTech are proud of our products andback-upeach one with the following warranty:

1.The warranty registration card must be mailed within ten days after purchase date to validate this warranty.

2.DigiTech warrants this product, when used solely within the U.S., to be free from defects in materials and workmanship under normal use and service.

3.DigiTech liability under this warranty is limited to repairing or replacing defective materials that show evidence of defect, provided the product is returned to DigiTech WITH RETURN AUTHORIZATION, where all parts and labor will be covered up to a period of one year (this warranty is extended to a period ofsix years when the product has been properly registered by mail or through our website). A Return Authorization number may be obtained from DigiTech by telephone.The company shall not be liable for any consequential damage as a result of the product's use in any circuit or assembly.

4.Proof-of-purchaseis considered to be the burden of the consumer.

5.DigiTech reserves the right to make changes in design, or make additions to, or improvements upon this product without incurring any obligation to install the same on products previously manufactured.

6.The consumer forfeits the benefits of this warranty if the product's main assembly is opened and tampered with by anyone other than a certified DigiTech technician or, if the product is used with AC voltages outside of the range suggested by the manufacturer.

7.The foregoing is in lieu of all other warranties, expressed or implied, and DigiTech neither assumes nor authorizes any person to assume any obligation or liability in connection with the sale of this product. In no event shall DigiTech or its dealers be liable for special or consequential damages or from any delay in the performance of this warranty due to causes beyond their control.

NOTE:The information contained in this manual is subject to change at any time without notification. Some information contained in this manual may also be inaccurate due to undocumented changes in the product or operating system since this version of the manual was completed.The information contained in this version of the owner's manual supersedes all previous versions.

The Hyper Phase is a multi-functionphaser pedal that offers seven different types of phasing effects and CIT™ cabinet modeling. The following sections outline how the knobs and pedal functions work.

1. Speed Knob

Controls the speed of the phase shift sweep. Turn this knob clockwise to increase the speed, and counter-clockwiseto decrease the speed.

2. Depth Knob

Controls the depth of the phase shift effect. Turn this knob clockwise to increase the depth, and counter-clockwiseto decrease the depth.

3.AC Adapter Jack

Connect a DigiTech PS200R (9VDC output) power supply to this jack. Use the proper supply for your area’s Mains line voltage.

4. Regen Knob

Controls the amount of regeneration (feedback) in the phaser effect. Turn this knob clockwise to increase the regeneration, and counterclockwise to decrease the regeneration. When 4-RISE/FALL is selected, this knob creates a rising sweep when set between the minimum and 12 o’clock positions, and a falling sweep when set between the 12 o’clock and maximum positions.

1 2 3 4



5

11



10

6

9

7



8

5.Type Knob

Selects 1 of the 7 different phaser effect types. 1-STAGE A - A 4 stage phase shifter.2-STAGE B - An 8 stage phase shifter.3-STAGE C - A 12 stage phase shifter.

4-RISE / FALL - Creates a constant rising phaser sound when theREGEN knob is set between the minimum and 12 o’clock positions, or a constant falling phaser sound when theREGEN knob is set between the 12 o’clock and maximum positions.

5-TRIG UP* - The phaser effect starts at the bottom of its sweep when the trigger threshold is reached. Use theREGEN knob to adjust the trigger threshold sensitivity andSPEED knob to adjust sweep rate. Regeneration is fixed when Triggered Up is selected.

6-TRIG DOWN* - The phaser effect starts at the top of its sweep when the trigger threshold is reached. Use theREGEN knob to adjust the trigger threshold sensitivity andSPEED knob to adjust sweep rate. Regeneration is fixed when Triggered Down is selected.

7-STEP - Creates a random square wave phase effect similar to a sample and hold filter on a synthesizer.

*Using a distortion pedal before the Hyper Phase may cause inconsistent triggering due to the non-dynamicnature of distorted signals.

6. Input Jack

Connect your instrument to this jack. Connecting a guitar cable to this jack supplies battery power even though the Indicator LED may not be lit. To prolong battery life, disconnect all cables from the pedal when not in use.

7. Pedal Release Pins

These two pins are spring-loadedhinges that hold the pedal in place. Push these pins in to release the pedal from the pedal chassis exposing the battery compartment. (See battery replacement diagram).

8. Pedal

Press the pedal to turn the effect on and off.

9. Out 1(Mono) Jack

Connect this output to a single guitar amplifier or mixer channel when only one amp or mixer channel is being used.

10. Indicator LED

This LED indicates when the effect is turned on. If the LED becomes dim or does not light when the cables are connected, the battery needs to be replaced.

11. Out 2 Jack

Connect this output to a second amplifier or mixer channel for stereo phasing. Stereo is the best way to get the most effective stereo phaser experience from the Hyper Phase pedal.

Connections

The Hyper Phase has a single input and a pair of outputs. Out 1 is used if the Hyper Phase is being connected to only one amplifier or mixer channel panned center.Out 2 is used for stereo operation. ConnectOut 1 to the first amplifier or mixer channel panned left andOut 2 to the second amplifier or mixer channel panned right.

The Hyper Phase also has built-inCIT™ cabinet modeling that can be enabled. This is a useful tool when running a distortion pedal into the Hyper Phase and then running direct into a mixer or recorder. CIT creates aguitar-through-an-amplifiersound without having to use a guitar amp.

To Enable CIT™ Cabinet Modeling:

Press the pedal down and apply power (connect a guitar cable to the Hyper Phase input or connect the PS200R power supply to the AC adapter jack). CIT™ cabinet modeling has to be turned on each time you apply power to the Hyper Phase.

Battery Replacement

1.Using the tip of a 1/4” guitar cable, push one of the release pins in on either side of the pedal, and remove the pedal from the pedal chassis.

2.Remove the battery from the battery compartment and disconnect the battery cable.

3.Connect a new battery to the battery cable and put it back in the battery compartment. Make sure the battery cable does not interfere with the spring or pedal switch arm.

4.Place one hole of the pedal over its corresponding pin.

5.Push the opposite pin in and lower the other side of the pedal into place over the depressed pin. Release the pin. When the pedal is properly fastened, both release pins are flush with the outer side of the pedal.

Pedal

Pedal Switch

Arm

Pedal Release

Pin

Battery

Compartment

Spring

9V DC Battery

Pedal Release

Pin

Pedal Chassis

SPECIFICATIONS:

Controls - Speed, Depth, Regen,Type, On/Off Pedal

Jacks - Input, Out 1 (Mono), Out 2

Input Impedance - 1 MOhms

Output Impedance - 100 Ohms

Power Supply - 9V Alkaline Dry Battery

Power Consumption - 4.8Watts (w/optional PS200R power supply)

Battery Life - Approximately 4 hours (with continuous usage)

Dimensions - 4 15/16”(L) x 3 1/8”(W)

x2 1/8”(H)

Weight - 1.38 lbs.

Optional Power Supply

PS200R - 100 (100V ~ 50/60Hz)

PS200R - 120 (120V ~ 60Hz)

PS200R - 230 (230V ~ 50Hz)

PS200R - 240 (240V ~ 50Hz)

DigiTech

8760 South Sandy Parkway

Sandy, Utah 84070

PH (801) 566-8800

FAX (801) 566-7005

DigiTech and X-Seriesare trademarks of the Harman Music Group Inc.

Copyright - Harman Music Group

Hyper Phase Stereo Phaser

Owners Manual 18-1806V-A

Please visit DigiTech on the World Wide Web at:

www.digitech.com

Printed in China
