Residential Wood Burning Fireplace
OWNER’S OPERATION AND INSTALLATION MANUAL
F48H(I)(R), VF48H(I)(R) |
|
|
and WCM-48F |
|
|
Plantation |
|
|
48" Wood Burning |
O-TL REPORT #114-F-23-2 |
|
Fireplace |
||
|
||
with Herringbone |
|
|
Masonry Brick |
|
IF FIREPLACE IS TO BE INSTALLED DIRECTLY ON ANY COMBUSTIBLE MATERIAL, A HEARTH SPACER IS REQUIRED.
SAVE THIS BOOK
This book is valuable. In addition to instructing you on how to install and maintain your appliance, it also contains information that will enable you to obtain replacement parts or accessory items when needed. Keep it with your other important papers.
This fireplace is approved for use as a wood burning fireplace or for use with a vented gas log approved to ANS Z21.60, Z21.84 or RGA2-72 standards or for use with a ventfree gas log heater approved to ANS Z21.11.2 standard.
ThiswoodburningfireplacecomplieswithUL127-CAN/ULC-
S610-M87 standard as a FACTORY BUILT APPLIANCE.
FOR CANADA: The authority having jurisdiction (such as the municipal building department, fire department, etc.) should be contacted before installation to determine the need to obtain a permit.
INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference.
For more information, visit www.desatech.com
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury, property damage or loss of life. Refer to this manual for assistance or additional information. Consult a qualified
installer or local distributor.
Table of Contents
Safety................................................................... |
2 |
Operation and Maintenance............................... |
16 |
Specifications....................................................... |
3 |
Technical Service............................................... |
18 |
Installation............................................................ |
4 |
Replacement and Accessory Parts.................... |
18 |
IMPORTANT: Check local codes before installing this fireplace.
Before beginning the installation of the fireplace, read these instructions through completely.
•This DESA Heating, LLC fireplace and its components are safe when installed according to this installation manual. Unless you use DESA Heating, LLC components, which have been designed and tested for the fireplace system, you may cause a fire hazard.
•The DESA Heating, LLC warranty will be voided by and DESA Heating, LLC disclaims any responsibility for the following actions.
a.Modification of the fireplace, components, doors, air inlet system and damper control.
b.Use of any component part not manufactured or approved by DESAHeating, LLC in combination with a DESA Heating, LLC fireplace system.
Proper installation is the most important step in ensuring safe and continuous operation of the fireplace. Consult the local building codes as to the particular requirements concerned with the installation of all factory built fireplaces.
WARNING: Do not install a fireplaceinsertinthisboxunless the manufacturer's instructions with the insert specifically state thisfireplacehasbeentestedfor use with this insert.
This fireplace is not intended to be used as a substitute for a furnace to heat an entire home. Use for supplemental heat only.
FOR YOUR SAFETY
•Do not store or use gasoline oranyotherflammablevapors or liquids in the vicinity of this or any other appliance.
•Due to high temperatures, the appliance should be located out of traffic and away from furniture and draperies.
•Do not place clothing or other flammablematerialsonornear the appliance.
•Never leave children unattended when a fire is burning in the fireplace.
WARNING: Use solid wood or processed solid fuel fire logs only. When processed wood fuel fire logs are used, do not poke or stir the logs while they are burning. Use only fire logs that have been evaluated for the application in fireplace and refer to fire log warnings and caution markings on packaging prior to use.
2 |
www.desatech.com |
122272-01C |
Safety
Continued
WARNING:Alwaysleaveglass doorsfullyopenedorfullyclosed when operating fireplace.
WARNING: If fireplace is to be installed on combustible material, a Hearth Spacer must be used. See Replacement and Accessory Parts on page 18.
Models F48H(I)(R) and VF48H(I)(R)
ROUND TOP |
SQUARE |
|
CHASE-TOP |
||
TERMINATION |
||
TERMINATION |
||
|
||
No Combustible |
2" Chimney Airspace |
|
Material on Front |
Clearance to Combustible |
|
Face Except for |
Material |
|
Mantel Applications |
|
|
|
1.5" Airspace |
|
|
Back and Sides |
|
PLANTATION FIREPLACE |
|
|
WITH HEARTH SPACER |
|
|
(REQUIRED FOR |
|
|
COMBUSTIBLE FLOORS) |
Outside Air |
|
18" Min. to |
||
Access Location |
||
Perpendicular |
||
Gas Line |
||
Wall |
||
Access Location |
||
Hearth |
||
Hearth Spacer |
||
Extension |
||
(Required for |
||
72" X 20" |
||
Combustible Floor) |
||
|
|
|
|
42.375" |
|
0" to Bottom |
|
33.5" |
|
|
|
12" Min. |
|
|
|
|
Each Side |
|
|
|
|
|
15.625" |
|
|
|
|
|
|
|
24" |
|
|
30" |
|
|
|
|
|
14.375" |
|
|
|
|
|
|
|
|
|
48" |
|
30.31" |
|
|
|
|
60.625" |
0.625" |
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
22" |
|
|
|
|
|
71.5" |
|
|
|
|
|
65.75" |
76.25"* |
|
|
|
42" |
43.75" |
|
|
|
7.625" |
|
|
7.625" |
8.875" |
|
|
|
|
|
|
17.5" |
14.375" |
48" |
4.75" |
12.875" |
|
|
Secure Fireplace |
|||
|
|
60.625" |
1" |
||
|
|
|
To Hearth Spacer |
||
|
|
|
*With Hearth Spacer |
|
|
|
|
|
|
Using Straps |
|
|
|
|
|
|
Provided |
122272-01C |
|
|
www.desatech.com |
3 |
selecting Fireplace location
To determine the safest and most efficient location for the fireplace, you must take into consideration the following guidelines:
1.The location must allow for proper clearances (see Figures 1 and 2).
2.Consider a location where the fireplace will not be affected by drafts, air conditioning ducts, windows or doors.
3.A location that avoids the cutting of joists or roof rafters will make installation easier.
4.An outside air kit is available with this fireplace (see Optional Outside Air Kit on page 5).
Minimum clearance to combustibles
Back and sides of fireplace |
1 1/2" min.* |
Front of fireplace |
48" min. |
Floor** |
0" min. |
Perpendicular wall to opening 18" min.
Top spacers |
0" min. |
Mantel clearance |
see Mantels, |
|
page 5 |
Chimney outer pipe surface |
2" min. |
* Not required at nailing flanges ** See step 2 of Framing
WARNING: Do not pack required air spaces with insulation or other materials.
Minimum/Maximum Chimney Height
The minimum height of the chimney, measured from the base of the fireplace to the flue gas outlet of the termination, is 16 feet for straight flue or a flue with one elbow set. The maximum distance between elbows is 6 feet. For systems with two elbow sets, the minimum height is 22 feet. The maximum height of any system is 50 feet.This measurement includes the fireplace, chimney sections and the height of the termination assembly at the level of the flue gas outlet (see Figure 15, page 9).
Framing
1.Frame the opening for the fireplace using the dimensions shown in Figures 1 and 2.
2.If the fireplace is to be installed directly on carpeting, tile (other than ceramic) or any combustible material including wood flooring, the fireplace must be installed
on a hearth spacer designed for use with this fireplace (see Replacement and Accessory Parts, page 18).
3.Set the fireplace directly in front of this opening and slide the unit back until the nailing flanges touch the side framing.
4.Check the level of the fireplace and shim with sheet metal if necessary.
5.Beforesecuringfireplacetopreparedframing,theemberprotector(provided)mustbe placed between the hearth extension (not supplied) and under the bottom front edge of the fireplace to protect against glowing embers falling through. If the fireplace is to be installed on a raised platform, a Z- type ember protector (not supplied) must be fabricated to fit your required platform height.The ember protector should extend underthefireplaceaminimumof1 1/2". The ember protector should be made of galvanized sheet metal (28 gauge minimum to prevent corrosion.
6.Using screws or nails, secure the fireplace to the framing through flanges located on the sides of the fireplace.
60.875" * With Hearth Spacer
71.5" |
|
65.7" |
76.375"* |
31.625" Secure Fireplace
To Hearth Spacer Using Straps Provided (Sides and Rear)
Figure 1 - Framing Dimensions
Maintain 1 1/2"
Clearance at Sides and
Back of Fireplace
|
1 1/2" Clearance |
" |
Not Required at |
.875 |
Nailing Flanges |
78 |
|
107.3"
Figure 2 - Corner Installation
4 |
www.desatech.com |
122272-01C |
Installation
Continued
Hearth Extension
A hearth extension projecting a minimum of 20" in front of and a minimum of 12" beyond each side of the fireplace opening is required to protect combustible floor construction in front of the fireplace. Fabricate a hearth extension using a material which meets the following specifications: a layer of noncombustible, inorganic material having a thermal conductivity of K=0.84 BTU IN/FT, HR. F (or less) at 1" thick. For example, if the material selected has a K factor of 0.25, such as glass fiber, the following formula would apply:
0.25 x 1.0" = 0.30" thickness required
0.84
Thermal conductivity "K" of materials can be obtained from the manufacturer or supplier of the noncombustible material. If the hearth extension is to be covered, use noncombustible material such as tile, slate, brick, concrete, metal, glass, marble, stone, etc. Provide a means to prevent the hearth extension from shifting and seal gap between the fireplace frame and hearth extension with a noncombustible material (see Figure 3).
WARNING:Hearthextension
is to be installed only as shown
in Figure 3.
Seal Gap
Fireplace Front
Ember Protector
Fireplace Front |
|
Raised Hearth |
|
Ember Protector |
Hearth |
|
|
|
Extension |
Fireplace Front |
Seal Gap |
Elevated |
|
Ember Protector
Figure 3 - Hearth Extension
Mantels
A mantel may be installed if desired (see Figure 4). Woodwork such as wood trims, mantels or any other combustible material projecting from the front face must not be placed within 12" of the fireplace opening. Combustible materials above 12" and projecting more than 1 1/2" from the fireplace must not be placed less than 15" from the top opening of the fireplace (NFPA STD 211, Sec. 7-3.3.3).
Mantels or any other combustible material also may come up to the side edge of the black metal face of the fireplace just as long as the projection from the front face fall within the limit shown in Figure 4.
|
|
Combustible |
|
12 1/4" Ref. |
Material |
|
|
Safe |
6" |
|
Zone for |
Ref. |
33° |
Projection of |
|
Combustible |
|
|
|
|
|
3" Nom. |
Materials |
|
|
15" Min. 11/2" Max.
12" Min.
Upper
Section of
Fireplace
Fireplace Opening
Figure 4 - Mantel Clearances to
Combustible Material
Optional Outside air Kit
(Model ak4/ak4f)
Installation of an outside air kit should be performed during rough framing of fireplace due to nature of it's location. Outside combustion air is accessed through a vented crawl space (AK4F) or through a sidewall (AK4). This fireplace is equipped with a barometric damper which allow outside air to flow into fireplace automatically when needed.
122272-01C |
www.desatech.com |
5 |
Installation
Continued
CAUTION: Combustion air inlet ducts shall not terminate in attic space.
The maximum height for the air vent can not exceed 3 feet below the flue gas outlet of the termination.
Secure to Collars with Metal Tape, Screws or Straps (Min. of 1/4" x 20" in size)
|
Air Inlet |
|
Location |
|
Must Allow |
|
For Bushes |
|
or Snow |
|
Air Inlet |
|
Eyebrow |
Vented Crawl Space |
Vent Hood |
(Check Local Codes |
Required for |
Before Installing in a |
Wall Installation |
Vented Crawl Space)
Figure 5 - Outside Air Kit
Chimney Pipe
DESAHeating, LLC chimney system consists of12",18",24",36"'and48"snap-lock,double- wall pipe segments, planned for maximum adaptability to individual site requirements. Actuallengthsgainedafterfittingoverlapsmust betakenintoconsideration(linealgain)andare given in lineal gain chart (see Figure 6). Lineal gain is the actual measurable length of a part after two or more parts are connected. For Canada, use chimney parts designated "HT".
LINEAL GAIN
PART NO. |
DESCRIPTION |
GAIN (IN) |
|
48" Plantation |
Fireplace |
66 1/2" |
|
12-12DM |
Pipe Section |
10 5/8" |
|
12-12HT |
|||
18-12DM |
Pipe Section |
16 5/8" |
|
18-12HT |
|||
|
|
||
24-12DM |
Pipe Section |
23 5/8" |
|
24-12HT |
|||
|
|
||
36-12DM |
Pipe Section |
34 5/8" |
|
36-12HT |
|||
48-12DM |
Pipe Section |
46 5/8" |
|
48-12HT |
|||
|
|
||
RLT-12D |
Round |
7 3/4"* |
|
RLT-12HT |
Termination |
||
|
|||
|
Square Chase- |
|
|
STL-12D |
Top with Slip |
7" to 15"* |
|
|
Section |
|
* The lineal gain for the terminations is measured to the flue gas outlet height.
15" Galvanized
Outer Pipe
12 3/8" |
Hemmed |
Stainless |
End |
|
|
Inner Pipe |
|
Figure 6 - Lineal Gain
Assembly and installation of double wall chimney system
Each double wall chimney section consists of a galvanized outer pipe, a stainless steel inner flue pipe and a wire spacer. Pipe sections must be assembled independently as chimney is installed. When connecting chimney directly to fireplace, inner flue pipe section must be installed first with lanced side up. Outer pipe section can then be installed over flue pipe section with hemmed end up. Press down on each pipe section until lances securely engage hem on fireplace starter. Wire will assure proper spacing between inner and
WARNING: The opening in the collar around the chimney at the top of the fireplace must not be obstructed.Neveruseblowninsulation to fill the chimney enclosure.
outer pipe sections.
Continue to assemble chimney sections as outlined above, making sure both inner and outer pipe sections are locked together. When installing double wall snap-lock chimney together, it is important to assure joint between chimney sections is locked. Check by pulling chimney upward after locking. Chimney will not come apart if properly locked. It is not necessary to add screws to keep chimney together (exception, see Figure 9, page 8).
6 |
www.desatech.com |
122272-01C |
