Owner’s manual & Installation manual Benutzerhandbuch und Installationshandbuch Mode d’emploi et manuel d’installation Manuale dell’utente e manuale d’installazione Manual de instrucciones y de instalación

VX401E

VZ 401E

2-DIN DVD MULTIMEDIA STATION WITH 6.2-inch TOUCH PANEL CONTROL 2-DIN-DVD-MULTIMEDIA-STATION MIT 6,2”- TOUCHPANEL-STEUERUNG

STATION MULTIMÉDIA DVD 2-DIN AVEC COMMANDE ÉCRAN TACTILE DE 6,2 pouces

STAZIONE MULTIMEDIALE DVD A 2 DIN CON PANNELLO DI CONTROLLO A SFIORAMENTO DA 6,2 pollici ESTACIÓN DVD MULTIMEDIA DOBLE DIN CON PANEL DE CONTROL TÁCTIL DE 6,2 pulgadas

DVD MULTIMEDIA STATION WITH 7-inch TOUCH PANEL CONTROL DVD-MULTIMEDIA-STATION MIT 7”- TOUCHPANEL-STEUERUNG

STATION MULTIMÉDIA DVD AVEC COMMANDE ÉCRAN TACTILE DE 7 pouces

STAZIONE MULTIMEDIALE DVD CON PANNELLO DI CONTROLLO A SFIORAMENTO DA 7 pollici ESTACIÓN DVD MULTIMEDIA CON PANEL

DE CONTROL TÁCTIL DE 7 pulgadas

Manual Owner’s English

2 VX401E/VZ401E



Contents



1.

FEATURES .......................................................................................................................

4



Expanding Systems ..........................................................................................................

4

2.

PRECAUTIONS ................................................................................................................

5

3.

CONTROLS ......................................................................................................................

7



Operational Panel .............................................................................................................

7



Functions of Buttons ........................................................................................................

8



Remote Control .................................................................................................................

9



Functions of Remote Control Buttons ..............................................................................

10

4.

CAUTIONS ON HANDLING .............................................................................................

12



Operation Panel ................................................................................................................

12



USB Port ...........................................................................................................................

12



Cleaning ............................................................................................................................

12



Handling Discs ..................................................................................................................

13

5.

DVD VIDEO SYSTEM ......................................................................................................

14



DVD Video Features ..........................................................................................................

14



Discs .................................................................................................................................

15



About the registered marks, etc. ......................................................................................

16

6.

OPERATIONS ...................................................................................................................

17



Basic Operations ..............................................................................................................

17



Radio Operations ..............................................................................................................

20



DVD Video Player Operations ...........................................................................................

23

7.

ACCESSORIES ................................................................................................................

31



iPod/iPhone Operations ....................................................................................................

31



USB Operations ................................................................................................................

33



Bluetooth Audio Player Operations ..................................................................................

34



Bluetooth Telephone Operations ......................................................................................

36



AUX In / AV In Operations .................................................................................................

38



Camera In Operations .......................................................................................................

38



Setup Operations ..............................................................................................................

39

8.

TROUBLESHOOTING .....................................................................................................

41

9.

ERROR DISPLAY .............................................................................................................

44

10. SPECIFICATIONS ............................................................................................................

44

INSTALLATION /WIRE CONNECTION GUIDE ..........................................................

46

Manual Owner’s English

VX401E/VZ401E 3

Manual Owner’s English

1. FEATURES

Double Din 6.2” Touch Panel Control (VX401E)

Motorized 7” Touch Panel Control (VZ401E)

OEM Steering Wheel Remote Ready

DVD Video/CD-DA/MP3/WMA Playback Capability

Built-In Bluetooth®

Compatible with iPod® / iPhone® via USB

DivX Certified® to play DivX® video

Expanding Systems

Expanding visual features

Expanding audio features

Rear monitor

Rear Vision Camera

External Power

Amplifier

iPod



USB

iPhone

Memory



Bluetooth

Telephone

NOTE:

The items listed outside the frames are the commercial products generally sold.

4 VX401E/VZ401E

2. PRECAUTIONS

WARNING

For your safety, the driver should not watch any video sources and/or operate the controls while driving. Please note that watching and operating any video sources while driving are prohibited by law in some countries. Also, while driving, keep the volume to a level at which external sounds can be heard.

Do not disassemble or modify this unit. It may cause an accident, fire, or electric shock.

Do not use this unit when a trouble exists, such as no screen content appears or no sound is audible. It may cause an accident, fire, or electric shock. For that case, consult your authorized dealer or a nearest Clarion service center.

In case of a problem, such as any material has been entered in the unit, the unit gets wet, or smoke or strange smells come out of the unit, etc., stop using this unit immediately, and consult your authorized dealer or a nearest Clarion service center.

Using it in that condition may cause an accident, fire, or electric shock.

Use a fuse with the same specification only when replacing the fuse. Using a fuse with a different specification may causes a fire.

For the installation of this unit or a change in the installation, ask your authorized dealer or a nearest Clarion service center for safety. Professional skills and experiences are required to do so.

Manual Owner’s English

VX401E/VZ401E 5

Manual Owner’s English

1.When the inside of the car is very cold and the player is used soon after switching on the heater, moisture may form on the disc (DVD/ CD) or the optical parts of the player and proper playback may not be possible. If moisture forms on the disc (DVD/CD), wipe it off with a soft cloth. If moisture forms on the optical parts of the player, do not use the player for about one hour. The condensation will disappear naturally allowing normal operation.

2.Driving on extremely bumpy roads which cause severe vibration may cause the sound to skip.

3.This unit uses a precision mechanism. Even in the event that trouble arises, never open the case, disassemble the unit, or lubricate the rotating parts.

CAUTIONS:

This appliance contains a laser system and is classified as a "CLASS 1 LASER PRODUCT". To use this model properly, read this owner's Manual carefully and keep this manual for your future reference. In case of any trouble with this player, please contact your nearest "AUTHORIZED service station". To prevent direct exposure to the laser beam, do not try to open the enclosure.

VX401E

VZ401E

6 VX401E/VZ401E

Clarion VZ401E, VX401E User Manual

3. CONTROLS

Operational Panel

MIC

[SOURCE]

[PWR]

[VOL+]

[VOL-]

RESET





















SENSOR

AUX

IN





















Manual Owner’s English

[OPEN]







[ CLOSE]





AUX IN







SENSOR MIC

[VOL-]

[SOURCE]

[VOL+] RESET





[PWR]



VX401E/VZ401E 7

Manual Owner’s English

Functions of Buttons

Note: Be sure to read this chapter while referring to front diagram “CONTROLS”.

[ SRC] Button

Press this button to turn the unit power on. The Main menu will be displayed. Scroll through the available sources such as AM/FM Tuner, DVD, USB, Camera modes, etc.

Press and hold this button for more than 2 seconds to turn the power off.

[VOL -], [VOL +] Buttons

Use these buttons to increase/decrease the volume.

[OPEN] [CLOSE] Button (VZ401E)

Use this button to open/close operation panel.

RESET Button

• Press this button to reset the unit.

SENSOR

Receiver for the remote control unit (operating range: 30 degree in all directions).

MIC

Internal microphone for use during Bluetooth phone calls. Sensitivity can be adjusted from the Settings menu.

8 VX401E/VZ401E

Remote Control

Signal transmitter







































Operating range: 30° in all directions





[MUTE]





















[OPEN]





































[



]



























[









]























SRC/POWER

























[



]







[0 - 9]























VOLUME











































[NAVI/AV]  * This button is not used









































[BAND]



for VX/VZ401E





[SRCH]





















































[SET]































[

] [



]



















































[MENU]









[BACK]





















[PIC]



























































[

] [



]























[TA]













































[ENTER]









[TITLE]





















[REPEAT]



























[ROOT]





]





[ [







]

























































[ ] [

]















[ZOOM]



























[SUB TITLE/VIDEO iPod MODE*]





















































[AUDIO]





















[ANGLE/AUDIO iPod MODE*]









































Replacing the batteries

1.Press the retention tab and pull out the battery tray and remove the old battery.

2.Insert the new CR2025 battery and slide the battery tray back in the remote control the same direction that you removed it. Please ensure the tray is inserted in the correct direction.

Note:

Using battery improperly can cause it to explode. Take note of the following points:

*Only when capable iPod/iPhone is connected

Do not short-circuit, disassemble or heat battery.

Do not dispose of battery into fire or flames.

Dispose of discharged battery properly.

WARNING

Alkaline (CR) button battery contain Perchlorate.

Dispose of discharged battery properly.

Manual Owner’s English

VX401E/VZ401E 9

Manual Owner’s English

Functions of Remote Control Buttons

You can use the remote control unit to control the VX401E and VZ401E.

Note:

The wireless remote control operation may not be optimal in direct sunlight.

Shared modes

[VOLUME] Button

Increase or decrease volume.

[MUTE] Button

Turns mute on or off.

[OPEN] Button

Press this button to OPEN or CLOSE the motorized screen (VZ401E). Please ensure there are no obstructions before starting the operation.

[SRC/POWER] Button

Short press to scroll through the available sources such as the tuner, DVD player, iPod, USB modes, etc.

Long press (over 1 second) to turn off the unit.

[MENU] Button

Press this button to access the MAIN MENU. From the main menu, you can select your desired source or change your settings.

[PIC] Button

Press this button to change monitor Brightness.

[SET] Button

Press this button to access the Audio Settings.

[BACK] Button

Press this button to exit selection and adjustment menus.

[ENTER] button

Press to fix the chosen or entered data.

TUNER Radio mode

[BAND] button

Press this button to switch reception band.

[0 - 9] Buttons

Use in the Key Pad screen to set the Radio channels.

Use to select the preset number in the Preset List screen.

[ ], [] Buttons

Press to seek the next available station up or down in the TUNER Radio mode.

[], [] Buttons

Press to manually select the next station up or down in the TUNER Radio mode.

[], [], [], [] Buttons

Press [], [] to scroll through the saved presets list in the TUNER Radio mode.

Press [], [] to scroll through the page screens in the TUNER Radio mode.

[TA] Button

Press to set TA standby mode on or off.

DVD PLAYER mode

[/] Button

Short press to play or pause the video or audio media.

Long press (over 1 second) to stop the video or audio media.

[SEARCH] Button

Press to open the direct search menu while in the DVD video mode.

[ENTER] Button

Press to select, play or pause video and audio media.

[0 - 9] Buttons

Press to enter DVD video chapters/titles in the Key Pad screen.

Press to set the track/folder number of the CD, or MP3/WMA in the Key Pad screen.

[TITLE] Button

Press to go to the title menu on the DVD.

[ROOT] Button

Press to go to the root menu on the DVD.

[], [], [], [] Buttons

Press to select button items on the menu screen of a DVD video.

Press [], [] to scroll through the pages creens in the CD and MP3/WMA modes.

10 VX401E/VZ401E

Functions of Remote Control Buttons

[ ], [] Buttons

Press to select the next chapter number up or down in DVD video media.

Press to select the next track up or down in in CD media.

[], [] Buttons

Press to perform fastforward and fastbackward. Press again to advance to higher speed reversing or forwarding such as 2x,4x, 8x and 16x. Press once more to resume normal speed playback.

[REPEAT] Button

Press to perform chapter repeat in the DVD video mode, and track repeat in CD and MP3/WMA modes.

Press again to perform title repeat in DVD video mode or folder repeat in MP3/WMA mode. In CD mode, this will activate the repeat all mode.

Press again to perform all repeat in MP3/ WMA playback mode.

[ZOOM] Button

Press to turn on and zoom in while in DVD Video mode. You can zoom in up to 3x.

[AUDIO] Button

Press to switch the AUDIO function in the DVD video mode.

[SUB-T] Button

Press to display subtitles in the DVD video mode.

[ANGLE] Button

Press to switch the ANGLE function in the DVD video mode when the Angle mark is displayed.

MAIN MENU mode

[/], [BAND] Buttons

Press to scroll through the available sources and the Settings.

[], [], [], [] Buttons

Press to scroll through the available keys.

[ENTER] Button

Press to select the menu.

Manual Owner’s English

VX401E/VZ401E 11

Manual Owner’s English

4. CAUTIONS ON HANDLING

Operation Panel

For a longer service life, be sure to read the following cautions.

The operation panel will operate properly in a temperature range of 0˚ to 60˚ C.

Do not allow any liquids on the set from drinks, umbrellas etc. Doing so may damage the internal circuitry.

Do not disassemble or modify the set in any way. Doing so may result in damage.

Subjecting the operation panel to shocks may result in breakage, deformation or other damage.

Do not let cigarettes burn the display.

If a problem should occur, have the set inspected at your store of purchase.

Do not insert objects or poke in the space between the operation panel and the main unit when the panel is tilted.

The remote control unit may not work if the remote control sensor is exposed to direct sunlight.

In extremely cold weather, the display movement may slow down and the display may darken, but this is not a malfunction. The display will work normally when the temperature increases.

Small black and shiny spots inside the liquid crystal panel are normal for LCD products.

USB Port

The USB memory stick may stick out when inserted, so it may cause danger during driving. In such cases, you can use a commercial USB extension cable, etc., but use it safely under your own judgement.

The USB memory sticks must be recognized as “USB mass storage class” to work properly. Some models may not operate correctly.

When the memorized data is lost or damaged by any chance, Clarion shall not be liable for any damage.

When using an USB memory stick, we recommend that you backup your data stored on it before by using a personal computer etc.

Data files may be broken when using USB memory sticks in the following situation: When disconnecting the USB memory stick or turning the power off during writing or reading data.

When affected by static electricity or electric noise.

Connect/disconnect the USB memory stick when it is not accessed.

Some USB memory sticks cannot be inserted to the main unit because of their shape. In such cases, use a commercial USB extension cable to connect them.

Connecting with the computer is not covered.

Music files (MP3, WMA, etc.) stored in the USB memory stick can be played back.

Cleaning

Cleaning the cabinet

Use a soft, dry cloth and gently wipe off the dirt. For tough dirt, apply some neutral

detergent diluted in water to a soft cloth, wipe off the dirt gently, then wipe again with a dry cloth.

Do not use benzene, thinner, car cleaner, etc., as these substances may damage the cabinet or cause the paint to peel.

Also, leaving rubber or plastic products in contact with the cabinet for long periods of time may cause stains.

Cleaning the liquid crystal panel

The liquid crystal panel tends to collect dust, so wipe it off occasionally with a soft cloth. The surface is easily scratched, so do not rub it with hard objects.

12 VX401E/VZ401E

Handling Discs

Handling

New discs may have some roughness around the edges. If such discs are used, the player may not work or the sound may skip. Use a ball-point pen or the like to remove any roughness from the edge of the disc.

Ball-point pen

Roughness

Storage

Do not expose discs to direct sunlight or any heat source.

Do not expose discs to excess humidity or dust.

Do not expose discs to direct heat from heaters.

Cleaning

To remove fingermarks and dust, use a soft cloth and wipe in a straight line from the center of the disc to the circumference.

Do not use any solvents, such as commercially available cleaners, antistatic spray, or thinner to clean discs.

After using special disc cleaner, let the disc dry off well before playing it.

Never stick labels on the surface of the disc or mark the surface with a pencil or pen.

Never play a disc with any cellophane tape or other glue on it or with peeling off marks. If you try to play such a disc, you may not be able to get it back out of the DVD player or it may damage the DVD player.

Do not use discs that have large scratches, are misshapen, cracked, etc. Use of such discs may cause missoperation or damage.

To remove a disc from its storage case, press down on the center of the case and lift the disc out, holding it carefully by the edges.

Do not use commercially available disc protection sheets or discs equipped with stabilizers, etc. These may damage the disc or cause breakdown of the internal mechanism.

On Discs

Exercise a good precaution when loading a disc. The operation panel will close automatically when leaving it open for a while.

Never turn off the power and remove the unit from the car with a disc loaded.

CAUTION

For your safety, the driver should not insert or eject a disc, opening the operation panel while driving.

Manual Owner’s English

VX401E/VZ401E 13

Manual Owner’s English

5. DVD VIDEO SYSTEM

DVD video is a high-quality digital video source that provides crisp and clear images. One 12 cm disc contains either one film or four hours of music.

DVD Video Features

This unit provides the following functions in addition to the high image quality and sound quality of DVD video.

Note:

The functions described in this section, for example, the recorded language, subtitles, angles, etc. differ depending on the DVD video disc.

Refer to the instructions provided with the DVD video.

Some disc functions may operate differently from described in this manual.

Multi-sound function

DVD video can store up to 8 languages for one film; select the language of your preference.

The languages stored on the disc are indicated by the icon shown below.

Subpicture (subtitles) function

A DVD video can record subtitles for up to 32 languages and you can select the language of the subtitles you wish to see.

The number of recorded subtitle languages are indicated by the icon shown below.

Multi-story function

When a DVD video contains more than one story for a film, you can select the story you wish to enjoy. The operation procedures vary with the disc; observe the instructions for selecting a story provided during playback.

Menu screens

Menu can be called up during DVD video playback to perform menu setting.

Multi-angle function

• Example showing menu display



A DVD video that is filmed from multiple



angles allows you to select the angle of



choice.



• The number of recorded angles are



indicated by the icon shown below.



14 VX401E/VZ401E

Discs

Playable discs

This DVD video player can play the following discs.

Playable discs

DVD video discs

Audio CDs

CD TEXT

Playable media files

MP3/WMA DivX

About CD Extra discs

A CD Extra disc is a disc in which a total of two sessions have been recorded. The first session is Audio session and the second session is Data session.

Your personally-created CDs with more than second data sessions recorded cannot be played on this DVD video player.

Note:

When you play a CD Extra disc, only the first session will be recognized.

About playing a CD-R/CD-RW disc (MP3, WMA)

This player can play CD-R/CD-RW discs previously recorded in music CD format (MP3, WMA).

About playing a DVD-R/RW or DVD+R/RW disc

This player cannot play DVD-R/RW and DVD+R/ RW discs previously recorded in video CD format.

However, MP3/WMA files recorded on DVD-R/ RW and DVD+R/RW discs can be played.

Discs that cannot be played back

This DVD video player cannot play back DVDAudio, DVD-RAM, Photo CDs, etc.

Note:

It may also not be possible to play back CDs recorded on a CD-R unit and CD-RW unit. (Cause: disc characteristics, cracks, dust/dirt, dust/dirt on player’s lens, etc.)

If a CD-R or CD-RW disc that has not been finalized is played, it will take a long time to start playing. Also, it may not be possible to play depending on its recording conditions.

You cannot play SuperAudio CDs Playback of the CD player is not supported even if it is a hybrid disc.

About MP3/WMA playback

This unit can play back CD-R/CD-RW, DVD-R/ RW and DVD+R/RW discs on which MP3/WMA music data have been recorded.

For a detailed information, see the section entitled “Listening to MP3/WMA”.

Note on region numbers

The DVD video system assigns a region number to DVD video players and DVD discs by sales area. DVD video players sold in Europe can play back DVD discs with the region number “ALL”, “2” or any combination of numbers that also incorporate a “2”.

The DVD video region number is marked on the disc jacket as shown below.

ALL

2

1 2

4







Manual Owner’s English

VX401E/VZ401E 15

Manual Owner’s English

About the registered marks, etc.

This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be

authorized by Rovi Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Rovi Corporation. Reverse engineering or disassembly is prohibited.

Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby Laboratories.

“Made for iPod,” and “Made for iPhone” mean that an electronic accessory has been designed to connect specifically to iPod, or iPhone, respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards.

iPhone and iPod are trademarks of Apple Inc., registered in the U.S. and other countries. iTunes® is a trademark of Apple Inc.

The Bluetooth® word mark and logos are owned by the Bluetooth® SIG, Inc. And any use of such marks by Clarion Co.,Ltd. is under license. Other trademarks and trade names are those of their respective owners.

DivX®, DivX Certified® and associated logos are registered trademarks of DivX, Inc. and are used under license.

All marks, channel names and logos are the property of their respective owners.

Covered by one or more of the following U.S. Patents: 7,295,673; 7,460,668; 7,519,274

16 VX401E/VZ401E

6. OPERATIONS

Basic Operations

Note:

Be sure to read this chapter referring to the chapter “3. CONTROLS”

CAUTION

When the unit is turned on, starting and stopping the engine with its volume raised to the maximum level may harm your hearings. Be careful about adjusting the volume.

Turning ON and OFF the Power

Note:

Start the engine before using this unit.

Be careful about using this unit for a long time without running the engine. If you drain the car’s battery too far, you may not be able to start the engine and this can reduce the service life of the battery.

1.Start the engine. The power button illumination on the unit will light up.

2. Press the [ SRC] button on the unit to turn ON the power. Or press the [SRC/POWER] button on the remote control to turn ON the power.

3. To turn OFF the power, press and hold the [ SRC] power button on the unit for more

than 2 seconds. Or press the [SRC/POWER] button on the remote control to turn OFF the power for more than 1 seconds.

Engine ON position

Opening and Closing Operational Panel

Press [OPEN] button on the unit (VZ401E). The operational panel will be open.

Press the same button again to close the panel.

CAUTION

Do not move the operation panel forcibly or apply strong force to the operation panel.

When the operation panel is operating, be careful not to get your hand or finger caught between the operation panel and main unit or its mechanical parts.

The driver should not operate the operation panel while driving.

Adjusting the Angle of the Operational Panel

Touch the settings key to enter into the Monitor Adjust to adjust the desired angle (VZ401E).

Selecting a Mode

1.Touch the desired source key you wish to change to: Tuner, Disc, USB, AUX IN, AV IN, iPod/iPhone, etc.

*External equipment not connected to this unit is not displayed.

Touch the [10:00] to display the time.

2. Press the [ ] SRC button to scroll through the available sources.

Manual Owner’s English

VX401E/VZ401E 17

Loading...
+ 38 hidden pages
