Module No. 1632/1813

1632/1813-1





GENERAL GUIDE



If the contents of the upper part of the display seem to be continually changing, see “AUTO DISPLAY FUNCTION” for information on how to stop it.

The operational procedures for modules 1632 and 1813 are identical. All of the illustrations in this manual show module 1632.

Press M to change from mode to mode.

Press L in any mode to illuminate the display for about one second.



Timekeeping Mode

Telememo Mode





Text area





A

B A

B Press M



TIME TEL SCH VIT ALM STW

TIME TEL SCH VIT ALM STW



TIME TEL SCH VIT ALM STW

P

P















M

C M

C





LMode L



Light



[Module 1813]

[Module 1632]





Stopwatch Mode







TIME TEL SCH VIT ALM STW

TIMEKEEPING MODE

Month – Day

Mode indicator



Day of week

Year

Text area

A

B

TIME TEL SCH VIT ALM STW

P

M C

L

Hour : Minutes

Seconds

PM indicator

In addition to normal timekeeping, the Timekeeping Mode is also used to set the current time and date. You can also adjust the seconds count to “00” at any time by pressing two buttons.

To adjust the seconds count to “00”

In the Timekeeping Mode, press B and C simultaneously to adjust the seconds count to

00.

If you press B and C at the same time while the seconds count is in the range of 30 to 59, the seconds are reset to 00 and 1 is added to the minutes. If the seconds count is in the range of 00 to 29, the minutes count is unchanged.

To set the time and date

1. Hold down Awhile in the Timekeeping Mode until the seconds digits start to flash on the display. The seconds flash because they are selected.

While the seconds digits are selected (flashing), press C to reset the seconds to00.

2. Press M to change the selection in the following sequence.





Seconds





Hour





Minutes





Year





Month





Day















































































3.While any other digits (besides seconds) are selected (flashing), press C to increase the number or B to decrease it. Holding down either button changes the current selection at high speed.

While any digits are selected, press L to switch between the 12-hourand24-hourformats.

When the 12-hourformat is selected, the12H indicator appears in the text area of the display. With the12-hourformat, theP indicator appears on the display to indicate “p.m.” times. There is no indicator for “a.m.” times.

Selecting the 24-hourformat causes the24H indicator to appear in the text area, and the24 indicator to appear on the display.

4.After you set the time and date, press A to return to the Timekeeping Mode.

The day of the week is automatically set in accordance with the date.

The date can be set within the range of January 1, 1995 to December 31, 2039.

If you do not operate any button for a few minutes while a selection is flashing, the flashing stops and the watch goes back to the Timekeeping Mode automatically.

When the text in the text area of the display contains more than five characters, it automatically scrolls. Text scrolling in the text area stops moving whenever an alarm is sounding.

In any mode other than Stopwatch Mode, the watch automatically returns to the Timekeeping Mode if you do not perform any button operation for two or three minutes.

Schedule-memoMode



TIME TEL SCH VIT ALM STW

















Alarm Mode

Vital Statistics/ID Mode





TIME TEL SCH VIT ALM STW

TIME TEL SCH VIT ALM STW







BACKLIGHT









This watch features an electroluminescent (EL)

A



B

backlight that helps you easily read the face, even



in total darkness. Its Auto Light Switch function



TIME TEL SCH VIT ALM STW

automatically lights the watch face whenever you



P



turn your wrist towards your face.









M



C

Notes



LThe backlight of the watch employs an electroluminescent (EL) light, which loses illuminating power after very long use.

Frequent use of the backlight shortens the battery life.

The illumination provided by the backlight may be hard to see when viewed under direct sunlight.

The watch will emit an audible sound whenever the display is illuminated. This is caused by a transformer that vibrates when the EL panel lights up. It does not indicate malfunction of the watch.

The backlight automatically turns off whenever an alarm sounds.

To manually turn on the backlight

In any mode, press L to illuminate the display for about one second.

To turn the Auto Light Switch function on and off

In the Timekeeping Mode, hold down C for one or two seconds to turn the Auto Light Switch function on and off.



Auto Light Switch



on indicator

TIME TEL SCH VIT ALM STW

TIME TEL SCH VIT ALM STW

P

P

AUTO



ON

OFF

The Auto Light Switch on indicator is shown on the display in all modes while the Auto Light Switch function is on.

In order to protect against running down the battery, the Auto Light Switch function is automatically turned off approximately two hours after you turn it on. Repeat the above procedure to turn the Auto Light Switch function back on if you want.

Pressing L in any mode illuminates the display for about one second, regardless of the Auto Light Switch function on/off setting.

About the Auto Light Switch function

While the Auto Light Switch function is turned on, the backlight automatically lights for about one second in any mode whenever you position your wrist as described below.

Important!

Avoid wearing the watch on the inside of your wrist. Doing so causes the Auto Light Switch to operate when it is not needed, which shortens battery life.

1632/1813-2

Moving the watch to a position that is parallel to the ground and then tilting it towards you more than 40 degrees causes the backlight to illuminate.

Parallel to

More

than

ground

40°

The backlight may not illuminate if the face of the watch is more than 15 degrees off parallel as shown below. Make sure that the back of your hand is parallel to the ground.

Parallel to ground

More than 15 degrees

More than 15 degrees



too high

too low

Static electricity or magnetic force can interfere with proper operation of the Auto Light Switch function. If the backlight does not illuminate, try moving the watch back to the starting position (parallel with the ground) and then tilt it back toward you again. If this does not work, drop your arm all the way down so it hangs at your side, and then bring it back up again.

Under certain conditions the backlight may not light until about one second or less after turn the face of the watch towards you. This does not necessarily indicate malfunction of the backlight.

Warning!

Never try to read your watch when mountain climbing or hiking in areas that are dark or in areas with poor footing. Doing so is dangerous and can result in serious personal injury.

Never try to read your watch when running on a roadside or in any other location where there might be vehicular or pedestrian traffic. Doing so is dangerous and can result in serious personal injury.

Never try to read your watch when riding on a bicycle or when operating a motorcycle or any other motor vehicle. Doing so is dangerous and can result in a traffic accident and serious personal injury.

When you are wearing the watch, make sure that its Auto Light Switch function is turned off before riding on a bicycle or operating a motorcycle or any other motor vehicle. Sudden and unintended operation of the Auto Light Switch function can create a distraction, which can result in a traffic accident and serious personal injury.





TELEMEMO MODE

Mode indicator



The Telememo Mode lets you store up to 100*



pairs of name and telephone number data.









Text area



Stored data is sorted automatically into







alphabetic sequence based on the text area







text.







* The Telememo Mode shares memory with

TIME TEL SCH VIT ALM STW



the Schedule-memoMode. This means that













the maximum number of Telememo Mode







entries you can store is reduced by one each

A



B

time you store a Schedule-memoMode data



item.

Remaining

TIME TEL SCH VIT ALM STW

Whenever you enter the Telememo Mode,

memory





the text TELEPHONE scrolls across the







M



C

text area of the display once. Next, Telememo



data appears on the display. You can interrupt







scrolling of the initial text and immediately







display Telememo data at any time by pressing







A, B, or C.

See the “CHARACTER LIST” at the back of this manual for details on how the watch sorts data.

The data item that appears on the display when you enter the Telememo Mode is the same one that was displayed the last time you exited the Telememo Mode.

To input new Telememo data



Cursor

Text area

1. In the Telememo Mode, press Band Cat the



















same time to display the new data display.

A









B

If there is no Telememo data stored in memory







yet, the new data display appears as soon as





































TIME TEL SCH VIT ALM STW

you enter the Telememo Mode.





































If the messageFULL appears in the text area

M





C

of the display, it means that memory is full. To





store more data, you will first have to delete

[New

















Data Display]

some of the data stored in memory.

Number area

2.Hold down A until the flashing cursor appears in the text area of the display.

3.Input a name in the text area and a telephone number in the number area. You can input up to eight characters in the text area, and 12 digits in the

number area.

You can input only hyphens, numbers and spaces in the number area (you cannot input text).

Use Band Cto input characters, and Mto move the cursor around the display. For details, see “INPUTTING TEXT”.

4. After inputting your data, press A to store it and return to the Telememo Mode.

When you press A to store data, the message SORT appears on the display for a few seconds. After the sort operation is complete, the normal Telememo Mode display (without the cursor) appears.

To recall Telememo data

In the Telememo Mode, press C to scroll forward through stored data items or B to scroll in reverse.

Holding down either button scrolls through the data at high speed.

The new data display appears whenever scrolling reaches the beginning or the end of data currently stored in memory.

To edit Telememo data items

1.In the Telememo Mode, scroll through the data items and display the one you want to edit.

2.Hold down A until the flashing cursor appears in the text area of the display.

3.Use M to move the cursor to the character you want to change.

4.Change the character.

See “INPUTTING TEXT” for details.

5.After making the changes that you want, press Ato store them and return to the Telememo Mode.

To delete Telememo data

1.In the Telememo Mode, scroll through the data items and display the one you want to delete.

2.Hold down A until the flashing cursor appears in the text area of the display.

3.Press B and C at the same time to delete the Telememo data item.

At this time the cursor appears in the text area, ready for input.

4.Press A to return to the Telememo Mode.

SCHEDULE-MEMOMODE

Text area

Mode indicator

TIME TEL SCH VIT ALM STW

Text

AB

Remaining TIME TEL SCH VIT ALM STW

memory

P

MC

Hour : Minutes

Month – Day

Schedule-memoMode lets you store up to 100* Schedule-memodata items (appointment date and time, and text). Whenever a time you set is reached, an alarm sounds and the text you input for the data scrolls across the text area of the display.

*The Schedule-memoMode shares memory with the Telememo Mode. This means that the maximum number ofSchedule-memoMode entries you can store is reduced by one each time you store a Telememo Mode data

item.

Whenever you enter the Schedule-memoMode, the textSCHEDULE scrolls across the text area of the display once. Next,Schedule-memodata appears on the display. You can interrupt scrolling of the initial text and immediately displaySchedule-memodata at any time by pressing A, B, or C.

Notes

A Schedule-memoAlarm sounds whenever a time you set is reached. It continues for about 20 seconds or until you interrupt it by pressing any button.

The Schedule-memotext scrolls across the text area of the display only if the watch is in the Timekeeping Mode when theSchedule-memotime is reached. The text continues to scroll for about 25 seconds, or until you stop it by pressing any button after you press a button to interrupt the alarm.

Schedule-memoMode data items are automatically sorted into chronological order.

Entering the Schedule-memoMode causes data for the next scheduled appointment to appear on the display.

To input new Schedule-memodata

Text area

AB

TIME TEL SCH VIT ALM STW

MC

Number area

[New Data Display]

1.In the Schedule-memoMode, press B or C until the new data display appears.

If there is no Schedule-memodata stored in memory yet, the new data display appears as soon as you enter theSchedule-memoMode.

If the message FULL appears in the text area of the display, it means that memory is full. To store more data, you will first have to delete some of the data stored in memory.

1632/1813-3

2. Hold down A until the month setting starts to flash in the number area of the display. The month setting flashes because it is selected.

The initialSchedule-memotime setting is always midnight, which is indicated as 12:00 with the12-hourtimekeeping format and 0:00 in the24-hourformat. You can select the timekeeping format in the Timekeeping Mode.

3. Press M to change the flashing selection in the following sequence.

Month DayHourMinutesText*

*11 spaces are provided for the text. This means that if you input only five characters for the text, so you have to press M 6 times to reach the month setting.

4.While the month, day, hour or minutes is flashing, press Cto increase the selected setting or B to decrease it. Holding down either button changes the current selection at high speed.

Important!

Correct storage of Schedule-memodata is impossible if you do not input a month and date.

The date you can specify must be within one year from the current date. This means that if the current date (in the Timekeeping Mode) is June 30, 1998, you will be able to specify any date up to June 29, 1999 for a Schedule-memodate.

When setting the time using the 12-hourformat, take care to set the time correctly as morning (no indicator) or afternoon (P).

5. Input text in the text area of the display.

You can input up to 11 characters for the text.

Use Band Cto input characters, and Mto move the cursor around the display. For details, see “INPUTTING TEXT”.

6.After inputting your data, press A to store it and return to the Schedulememo Mode.

Schedule-memodata remains in memory until you delete it. Be sure to delete oldSchedule-memodata whenever you no longer need it. See “To deleteSchedule-memodata”.

To recall Schedule-memodata

In the Schedule-memoMode, press C to scroll forward through stored data items or B to scroll in reverse.

Holding down either button scrolls through the data at high speed.

The new data display appears whenever scrolling reaches the beginning or the end of data currently stored in memory.

To edit Schedule-memodata items

1.In the Schedule-memoMode, scroll through the data items and display the one you want to edit.

2.Hold down A until the month setting starts to flash in the number area.

3.Use M to move the flashing to the part of the Schedule-memodata item you want to change.

4.Use B and C to change the data.

See “To input new Schedule-memodata” for details on inputting data.

5.After making the changes that you want, press Ato store them and return to the Schedule-memoMode.

To delete Schedule-memodata

1.In the Schedule-memoMode, scroll through the data items and display the one you want to delete.

2.Hold down A until the month setting starts to flash in the number area.

3.Press Band Cat the same time to delete the Schedule-memodata item.

The message CLEAR appears for a short while. Next, the month setting starts to flash on the display, ready for input of new data.

4.Press A to return to the Schedule-memoMode.

VITAL STATISTICS/ID MODE

Mode indicator

TIME TEL SCH VIT ALM STW

Text area

A B

TIME TEL SCH VIT ALM STW

MC

Number area

Important!

The Vital Statistics/ID Mode provides a handy place to store data about your vital statistics (name, blood type, date of birth) and personal identification (ID) data (credit card number, license number, passport number, and two undefined items).

Whenever you enter the Vital Statistics/ID Mode, the text VITAL STATS./ID scrolls across the text area of the display once. Next, the name screen appears on the display. You can interrupt scrolling of the initial text and immediately display the name screen at any time by pressing A, B, or C.

The name screen always appears first whenever you enter the Vital Statistics/ID Mode.

Once you input your vital statistics, take care that the watch is not borrowed by another person. Otherwise, emergency medical personnel may assume that the data in the Vital Statistics/ID Mode applies to the person who is currently wearing the watch.

Note that storing important personal identification data in the watch’s memory runs the risk of it being misused should you lend the watch to someone or should the watch become lost or stolen. Because of this, the manufacturer strongly recommends that you input such important information in coded form that cannot be deciphered by others.

Note that CASIO COMPUTER CO., LTD. shall not be held liable to you or any third party for any losses or damages suffered through the misuse of data stored in the memory of this watch.

To recall Vital Statistics/ID data

In the Vital Statistics/ID Mode, press B or C to change the data on the display in the following sequence.









































CREDI



NAME







BLOOD













BIRTH





































(Credit card



(Name)







(Blood type)













(Date of birth)





































number)

























































Press C

















Press B



















































































































































PASSP









LICEN





















































(Passport









(License



(Undefined)







(Undefined)

































number)









number)



































































The titles of the each data item appear in the text area of the display. In the case of the undefined items, you can specify titles that appear in the text area whenever you later display that item.

To input your name



Text area

1.

In the Vital Statistics/ID Mode, display the





NAME screen.

Cursor







2.

Hold down A until the flashing cursor appears







in the text area of the display.

A

B

3.

Input your name into the text area.

You can input up to 16 characters for your name.

TIME TEL SCH VIT ALM STW









Use B and C to input characters, and M to

M

C

move the cursor around the display. For de-

tails, see “INPUTTING TEXT”.





You can clear the characters currently input for the name by pressing B and C at the same time.

4.After inputting your data, press A to store it and return to the normal NAME screen (without cursor).

To input your blood type

Rh factor

1.

In the Vital Statistics/ID Mode, display the



BLOOD screen.





A

B 2. Hold down Auntil the Rh factor setting flash in





the text area of the display.

TIME TEL SCH VIT ALM STW

3.

Use B and C to scroll through the available







Rh factor settings in the following sequence.

MC

Blood type ABO

Press C









---

R

+

R

-

Press B









4.Press M to advance to the blood type.

5.Use B and C to scroll through the available blood type settings in the following sequence.

Press C









--

A

B

O

AB

Press B









6.After inputting your data, press A to store it and return to the normal BLOOD screen (no flashing characters).

Select --- if you do not want to specify an Rh factor and-- if you do not want to select a blood type in the above sequence. When neither an Rh factor nor blood type is specified, the blood data screen shows----- on the watch’s display.

To input the date of your birth







Month – Day

1.

In the Vital Statistics/ID Mode, display the





BIRTH screen.





A

B

2.

Hold down A until the year digits start to flash



on the display. The year digits flash because



TIME TEL SCH VIT ALM STW



they are selected.









3.

Press Mto change the selection in the following

M

C



sequence.







Year

Month

Day



Year













4.Press Cto increase the selected digits and Bto decrease them. Holding down either button changes the selected digits at high speed.

The year can be set in the range of 1900 to 2039.

5.After inputting your data, press A to store it and return to the normal BIRTH screen (no flashing digits).

1632/1813-4

Personal identification data

This watch has three built-intitles for personal identification data:CREDIT (for a credit card number),LICENCE (for a license number), andPASSPORT (for a passport number). You can use thesebuilt-intitle as

they are, or append eight more characters to a built-intitle to indicate a credit card company name, for example.

In addition to the three built-intitles, you can also input your own titles up to eight characters long for the two undefined items.

You can input number up to 12 digits long for each personal identification data item.

To input personal identification data

Cursor

Text area

1.

In the Vital Statistics/ID Mode, display the



personal identification data screen where you















want to input data.

A



B

See “To recall Vital Statistics/ID data” for details

TIME TEL SCH VIT ALM STW



on how to switch between data screens.







2.

Hold down A until the flashing cursor appears









in the text area of the display.

M



C





Number area

3. Input a text in the text area if you want.

In the case of a built-intitle, you can append up to eight characters to the preset title. For the undefined data items, you can input titles up to 8 characters long.

To use a built-intitle as it is without appending text, press M eight times to move the cursor to the number area.

Use Band Cto input characters, and Mto move the cursor around the display. For details, see “INPUTTING TEXT”.

4.After you input your text, use M move the cursor to the number area and input number data.

You can input up to 12 digits in the number area.

You can input only hyphens, numbers and spaces in the number area (you cannot input text).

5.After inputting your data, press A to store it and return to the screen you started out from in step 1 of this procedure.

To edit Vital Statistics/ID Mode data

1.In the Vital Statistics/ID Mode, scroll through the data items and display the one you want to edit.

2.Hold down A until the data on the display starts to flash.

3.Use M to move the flashing to the part of the data item you want to change.

4.Use B and C to change the displayed data.

For details on inputting data, see the sections of this manual that describes input for each screen.

5.After making the changes that you want, press Ato store them and return to the screen you started out from in step 1 of this procedure.

To delete Vital Statistics/ID Mode data items

1.In the Vital Statistics/ID Mode, scroll through the data items and display the one you want to delete.

2.Hold down A until the data on the display starts to flash.

3.Press B and C at the same time to delete the data item.

4.Press A to return to the screen you started out from in step 1 of this procedure.

ALARM MODE

When the Daily Alarm is switched on, the alarm

Alarm on indicator



sounds for 20 seconds at the preset time each





















day. Press any button to stop the alarm after it











Mode

indicator starts to sound.

























When the Hourly Time Signal is switched on, the



















B

watch beeps every hour on the hour.





























A

To set the alarm time

































TIME TEL SCH VIT ALM STW



























1. Hold down Awhile in the Alarm Mode until the























M









C

hour digits start to flash on the display. The









hour digits flash because they are selected.







































This operation will switch the Daily Alarm on









Hour

















Minutes



automatically.





Hourly time signal



2. Press Mto change the selection in the following



sequence.





on indicator









































Hour



Minutes

























































3.Press C to increase the selected digits or B to decrease them. Holding down either button changes the selection at high speed.

The format (12-hourand24-hour)of the alarm time matches the format you select for normal timekeeping.

When setting the alarm time using the 12-hourformat, take care to set the time correctly as morning (no indicator) or afternoon (P).

4. After you set the alarm time, press A to return to the Alarm Mode.

To switch the Daily Alarm and Hourly Time Signal on and off

Press Cwhile in the Alarm Mode to change the status of the Daily Alarm and Hourly Time Signal in the following sequence.

[Alarm ON indicator/Hourly Time Signal ON indicator]

Both ON

Both OFF

Daily Alarm

Hourly Time





Only

Signal only

To test the alarm

Hold down B while in the Alarm Mode to sound the alarm.

STOPWATCH MODE

1/100 second Mode indicator

AB

TIME TEL SCH VIT ALM STW

M C

Hours Seconds

Minutes

The Stopwatch Mode lets you measure elapsed time, split times, and two finishes. The range of the stopwatch is 23 hours, 59 minutes, 59.99 seconds.

(a) Elapsed time measurement









C

C

C

C

B

Start

Stop

Re-start

Stop

Clear

(b) Split time measurement











C

B

B

C

B

Start

Split

Split release

Stop

Clear

(c) Split time and 1st-2ndplace times









C

B

C

B

B











Start

Split

Stop

Split release

Clear



First runner

Second runner finishes.

Record time of







finishes.

Record time of first runner.

second runner.





INPUTTING TEXT

The following describes how to input text in the Telememo Mode, Schedulememo Mode, and Vital Statistics/ID Mode.

How to input characters

Cursor

Text area

A

B

TIME TEL SCH VIT ALM STW

MC

Number area

1.When the cursor is blinking in the text area of the display, use Band Cto scroll through the available letters, numbers and symbols, in the following sequence.

Press CPress B

(space)A to Z0 to 9

)(/.-

Holding down either button scrolls through at high speed.

2.When the character you want at the cursor position is shown, press M to move the cursor to the right.

3.Repeat steps 1 and 2 until your text is complete.

You can input only hyphens, numbers and spaces in the number area. Each press of B or C changes the input at the current cursor location in the following sequence.

Press C

0 to 9



x

(space)

Press B

If you do not perform any button operation for about two or three minutes while the cursor is on the display, the watch automatically returns to the normal data display (the cursor disappears).

1632/1813-5



AUTO DISPLAY FUNCTION





The Auto Display function continually changes the





contents of the text area of the display. Note that

A



B you cannot use any of the watch’s other functions



TIME TEL SCH VIT ALM STW

(except for turning on the backlight) while the Auto









Display function is operating.



P



M



C To turn the Auto Display off

L

Hold down M for about three seconds until the watch beeps.

To turn Auto Display on

Hold down M for about three seconds until the watch beeps.

Note

The Auto Display function cannot be performed while you are making settings (i.e. while digits or other settings are flashing on the display).

ABOUT THE LOW BATTERY WARNING

BATT

TIME TEL SCH VIT ALM STW

P

Important!

The message BATT flashes on the display whenever the battery power is low. Have the battery of the watch replaced as soon as possible after this message appears. Using the watch while the battery is low can result in abnormal operation.

In order to protect data stored in memory, you will not be able to recall existing data or input new data while the BATT message is flashing on the display. Also, the alarm, hourly time signal, backlight, and other functions do not operate.

Low battery power can cause time keeping to fall behind, and it can cause the display to become difficult to read, or to clear completely.

ALWAYS LEAVE BATTERY REPLACEMENT UP TO THE DEALER WHERE YOU BOUGHT THE WATCH OR TO AN AUTHORIZED CASIO DISTRIBUTOR. BE SURE TO SHOW THE FOLLOWING INFORMATION TO THE PERSON REPLACING THE BATTERY.

Attention dealer or CASIO distributor

Be sure to use the following procedure when replacing the battery. 1. Open and remove the back cover.

IfCLOSE appears on the display when you open the back cover, replace the back cover. Wait for a few minutes and try again.

2.Remove the battery holder.

3.Remove the old battery and load a new one.

4.Replace the battery holder.

5.Touch the AC contact and the battery (+) side with metallic tweezers.

6.Close the back cover.

The message WAIT appears on the display about 15 seconds after you perform the AC (all clear) operation in step 5 of the above procedure, indicating that the watch is performing an internalself-checkfor data errors.

The WAIT indicator remains on the display for a few minutes while the watch performs an internal check of data in memory. Though you can change the time setting of the watch while theWAIT indicator is on the display, other operations are disabled.

CHARACTER LIST

1

(space)

11

J

21

T

31

3

41

(





















2

A

12

K

22

U

32

4

42

)





















3

B

13

L

23

V

33

5

























4

C

14

M

24

W

34

6

























5

D

15

N

25

X

35

7

























6

E

16

O

26

Y

36

8

























7

F

17

P

27

Z

37

9

























8

G

18

Q

28

0

38

-

























9

H

19

R

29

1

39

.

























10

I

20

S

30

2

40

/
