Bushnell 111026 User Manual

Size:
1.48 Mb
Download

Instruction

Manual

Model#: 111026

Lit. #: 98-0828/10-06

LANGUAGES

English..............

4

Français..........

20

Español..........

36

Deutsch..........

52

Italiano...........

68

Português.......

84

WARNING

Make sure you download any pictures from your camera BEFORE removing or changing batteries, unless you have been using an SD card rather than the internal memory for photo storage. We recommend you download all current photo files for safekeeping before storing the ImageView away if you are not using an SD card in the camera, in case the batteries become depleted during extended storage.

WARNING

Do NOT look directly at the sun through your binoculars.

Doing so may cause permanent eye damage.

NOTE: To reset the camera if you experience problems or if the display becomes unresponsive, remove the batteries for at least one minute, then re-installthem. This may result in the loss of all photos/videos stored in the internal memory.

ENGLISH

Congratulations on your purchase of the Bushnell ImageView® binocular! The Bushnell ImageView binocular takes the technology of digital photography and combines it with ahigh-qualitycompact binocular. This allows you to observe sporting events, wildlife, scenic vistas or anything you would normally use a binocular for, and then save the image in abuilt-inattached digital camera. You can then download these images to your computer ande-mailthem to your friends and family, print out the picture using the included software or save them in a photo album for future use. Before using the product, please read the instructions contained in this manual and take time to familiarize yourself with the different parts and features of the product.

Camera and Binocular Parts Guide

Binocular

Snap

Mode

Focus

Button Camera

Button



Lens



Remote

Card

USB

Jack

Slot

Port

Tripod

Socket

Battery

Compartment

(Slide Open In

Direction of Arrow)

SetupCAMERAandPARTSBasic Operation

1.The camera is powered by two AAA alkaline, lithium, or NiMh batteries (not included). Insert batteries into the compartment, with the springs in contact with the negative (flat) end of each battery. A power meter on the left center of the display indicates battery condition.

2.Insert an SD card ("upside down" with metal contacts facing up) in the slot if greater storage is desired. You may use SD cards (not MMC cards) up to 1 GB capacity. The camera has 8 MB of internal memory which can hold over 100 photos, so a card is not necessary. However, the internal memory contents will be lost if the batteries are removed or die-unlikephotos stored on an SD memory card. A 256 MB standard speed SD card is available in most consumer electronics or computer stores and a is good choice for your ImageView.

3.Press and hold the MODE button until the camera turns on. The camera will turn off automatically after about one minute if no buttons are pressed. Note: when the camera is connected to a computer via the supplied USB cable, the camera will power on automatically, and draw power from the computer with no battery drain.

4.Hold the ImageView steady and press SNAP to take a picture (or start/stop shooting a video, when the camera is in video mode). The camera focus is preset to take sharp photos from appoximately 35 feet to infinity.

5.When using a tripod, you can help avoid the effects of camera shake by plugging the supplied remote shutter release into the jack next to the SD card slot, and using the button on the remote rather than SNAP to take photos.

Using the Operational Modes/Setting Date & Time

The ImageView will imprint the date and time in the bottom right corner of your photos. To set the current date and time, after turning on the camera, press and hold both the MODE and SNAP buttons at the same time, until the display begins to flash. The display now shows the last two digits of the year. Press the MODE button to move the cursor to the second digit if necessary. Press the SNAP button to advance the digit to the current year ("07" for 2007, etc). Then press MODE to go to the next number, which is the month. Again, use SNAP to change this to the current month. Following the month display is: date, hour (24hr format), minute, and second-continueto set these following the same process using the MODE and then SNAP buttons. When you have completed all of the date/time settings, the display will stop flashing and return to normal. Note that you will need to reset the date/time after replacing batteries.

Your ImageView is already set to high resolution and quality right out of the box, and it is not necessary to use the MODE settings and make any changes to get good results by simply pressing the SNAP button to take photos. However, as you might want to shoot a video clip, delete one or more previous photos, or explore other options, we recommend you review the available mode options listed on the following pages. Briefly pressing the MODE button will step through these operational modes in the listed order, and you will see the icon for each mode along with its current setting on the display. Use the SNAP button to select the desired setting for any mode. If you make no changes, and the SNAP or MODE button is not pressed within 5 seconds, the camera will return to normal operation and display.

Using the Operational Modes (Bold indicates default settings)

Mode

Icon

Settings

Description









Video

Video

OFF, High

Select "Hi" (recommended) or "Lo" video resolution



Camera

(640x480 pixels

instead of "OFF" to put the camera in video mode.





per frame, 15 fps),

Wait a few seconds for the camera to automatically





Low (320x240

return to the normal display, then begin shooting by





pixels)

pressing SNAP. The counter will show elapsed time-







up to the 53 (Hi) or 132 (Lo) second maximum for







each video clip. Press SNAP again to stop shooting.







The counter will advance by one, indicating the







video file has been saved. Return to the video mode







setting and select OFF to reset the camera to still







photo mode.

Quality

Hq or Lq

High, Low

Select "Hi" (recommended) or "Lo" quality to







choose the amount of file compression, which affects







the size of the photo file. "Lo" allows more photos







to be stored in memory, but at reduced quality.









Resolution

Hi or Lo

High (640x480

Select "Hi" (recommended) or "Lo" resolution,





pixels), Low

based on your preference for better looking photos





(320x240 pixels)

(Hi) or being able to take a greater number of







photos (Lo).

Using the Operational Modes

Mode

Icon

Settings

Description









Line Frequency

60 or 50

60 Hz, 50 Hz

Set to match the AC power frequency (cycles) of







your country. This ensures that stills and videos shot







under fluorescent lighting appear normal.

Continuous

CT

OFF, 3, 5

Select 3 or 5 frames to shoot a rapid series of photos







instead of a single frame when SNAP is pressed







(in normal still photo mode). To cancel, enter this







mode again and select OFF.

Memory Access

MEM

Sto (USB Mass

Select "Sto" to access the internal or card memory





Storage), PC (USB

when the camera is connected to a computer with





Camera)

the USB cable. "PC" allows the camera to be







used as a live USB/PC camera (note that the 8x







magnification and lack of close focus capability







limits usefulness in most size rooms)

Delete Last

LSt+Trash

None-pressSNAP

Select this mode and press SNAP to delete only the



Can

to delete the last

last photo or video you took. The counter will go





photo or video

down one number.
