Breville BGR400XL User Manual

0 (0)

ikon Grill

Breville is a registered trademark of Breville Pty. Ltd.

Breville Customer Service Center

US Customers

PO Box 47170 Gardena

CA 90247



Service Center: 1 (866) BREVILLE

Email

askus@brevilleUSA.com

www.breville.com

Canada Customers

Anglo Canadian 2555, de l’Aviation

Pointe-Claire (Montréal) Québec H9P 2Z2

Service Center: 1 (866) BREVILLE

Fax

(514) 683-5554

Email

askus@breville.ca

www.breville.com

© Copyright. Breville Pty. Ltd. 2007

Due to continual improvements in design or otherwise, the product you purchase may differ slightly from the one illustrated in this booklet.

Model BGR400XL Issue 1/07 Packaging Code: AM / CN

Model BGR400XL

Contents



Page

Breville recommends safety first

4

Know your Breville ikon Grill

6

Operating your Breville ikon Grill

7

Care and Cleaning

14

Warranty

16

Recipes

18

French

24

Spanish

48

Congratulations

on the purchase of your new Breville ikon Grill

2

Breville recommends safety first

IMPORTANT SAFEGUARDS

We at Breville are very safety conscious. We design and manufacture consumer products with the safety of you, our valued customer, at the forefront of our minds. In addition, we ask that you exercise a degree of care when using any electrical appliance and adhere to the following precautions:

READ ALL INSTRUCTIONS

Remove any promotional stickers or labels before using the ikon Grill for the first time.

Do not place the ikon Grill near the edge of a bench or table during operation. Ensure that the surface is level, clean and free of water, etc.

Do not place the ikon Grill on or near a hot gas or electric burner, or where it could touch a heated oven. Use the ikon Grill well away from walls.

Provide adequate space above and on all sides of air circulation around the ikon Grill.

Do not place the ikon Grill on any surface that may be affected by heat. The use of a heat resistant mat is recommended on these surfaces.

Always ensure that the ikon Grill is properly assembled before first use.

Do not touch hot surfaces. Use the handles to lift and open the top plate. Take care when using the Adjustable Grilling Height Control.

Allow the grill to cool down before releasing the removable plates. Do not release the removable plates while the grill is being operated.

Always switch off the grill at the power outlet before releasing the removable plates.

Do not leave the ikon Grill unattended when in use.

Do not place anything on top of the ikon Grill when the lid is closed, when in use and when stored.

Always switch the ikon Grill off at the power outlet, then unplug and allow to cool , if appliance is not in use, before cleaning, before attempting to move the appliance, disassembling, assembling and when storing the appliance.

Keep the exterior housing and the non-stick cooking plates clean. Follow the cleaning instructions provided in this book.

The appliance is not intended to be operated by means of an external timer or separate remotecontrol system.

Important safeguards for all electrical appliances

To protect against electric shock, do not immerse cord, plug or appliance in water or any other liquid.

Do not let the cord hang over the edge of table or counter or touch hot surfaces, or become knotted.

Young children should be supervised to ensure that they do not play with the appliance.

It is recommended to inspect the appliance regularly. Do not use the appliance if the power supply cord, plug or appliance becomes damaged or malfunctions in any way. Return the entire appliance to the nearest authorized Breville Service Center for examination and/or repair.

Any maintenance other than cleaning should be performed at an authorized Breville Service Center.

This appliance is for household use only. Do not use this appliance for anything other than its intended use/ Do not use in moving vehicles or boats. Do not use outdoors.

Do not use harsh abrasives, caustic cleaners or oven cleaners when cleaning this appliance.

The installation of a residual current device (safety switch) is recommended to provide additional safety protection when using electrical appliances.

It is advisable that a safety switch with a rated residual operating current not exceeding 30mA be installed in the electrical circuit supplying the appliance. See your electrician for professional advice.

Close Supervision is necessary when this appliance is used by or near children.

Extreme caution must be used when moving an appliance containing hot oil or other hot liquids.

The use of accessory attachments not recommended by the manufacturer may cause injuries.

For safety reasons it is recommended you plug your Breville appliance directly into the power outlet. DO NOT use in conjunction with a power strip or extension cord.

Your grill has a short cord as a safety precaution to prevent perosnal injury or property damage resulting from pulling, tripping or becoming entangled with the cord.

If you must use a longer power cord or an extension cord are available and may be used if care is exercised in their use.

Note

If an extension cord is used:

1.The marked electrical rating of the cord or extension cord should be at least as great as the electrical rating of the appliance.

2.If the appliance is of the grounded type, the extension cord should be a grounding 3-wire cord, and

3.The longer cord should be arranged so that it will not drape over the countertop or table top where it can be pulled on by children or tripped over unintentionally.

FULLY UNWIND THE CORD FROM THE CORD STORAGE FACILITY BEFORE USE.

SAVE THESE INSTRUCTIONS FOR HOUSEHOLD USE ONLY

4

5

Breville BGR400XL User Manual

Know your Breville ikon Grill

Stylish stainless steel exterior

Floating hinged top plate

Power ‘On’ and ‘Ready’ lights

Heavy duty metal arms

1800 watt of power

Non-stick scratch resistant surface

Unique fat reducing angled grill plates

Removable drip tray

Extendable non-skid feet

Plate release buttons for easy removal

Plate Tilt control function

Variable temperature control

Cord storage

Adjustable Grilling Height Control

Additional interchangeable flat plate

Operating your Breville ikon Grill

Remove any promotional materials and packaging materials before use. Check that the cooking plates are clean and free of dust. If necessary, wipe over with a damp cloth.

When using the Breville ikon Grill for the first time you may notice a fine smoke haze. This is caused by the heating of some of the components. There is no need for concern.To use as a grill

1.Insert the plug into a 110/120 volt power outlet and switch the power ON. The Red power ‘On’ light will illuminate.

2.Ensure the Removable drip tray is correctly inserted and positioned correctly into the appliance (see Fig 1).

Fig 1

3.Ensure the top and bottom grill plates are securely locked into position (Fig 2).

4.Ensure the top plate is in the closed position for more efficient pre-heating.

5.Turn the tilt control to the ‘Angle’ position, to ensure better fat drainage.

6.Turn the variable temperature control to ‘Sear’ for fast heat up.

7.Allow the ikon Grill to preheat until the green ‘Ready’ light illuminates.

8.Place meat or foods to be cooked on the bottom cooking plate. Refer to Grilling recipes or guide for cooking times.

It is important that the ikon grill plates are securely locked into position when using the grill.

Note

8.Using the handle to close top plate. The top plate has a floating hinge system that is designed to press down evenly on the food. The Grilling Height Control on the right hand side of the top plate is used to adjust for the thickness of the food. The top plate must be fully lowered to achieve the grill marks onto the food.

9.When the selected ingredients are grilled, use the handle to open the top lid. Remove the food using a plastic spatula.

Fig 2

6

7

Operating your Breville ikon Grill continued

To use as a sandwich press

1.Insert the plug into a 110/120volt power outlet and switch the power on. The red power ‘On’ light will illuminate

2.Ensure the Removable Drip Tray is correctly inserted and positioned back into the appliance.

3.Ensure the top and bottom plates grill plates are securely locked into position.

4.Ensure the top plate is in the closed position for more efficient preheating.

5.Turn the Base Plate Tilt Dial to the Flat position.

6.Turn the variable heat control dial to the ‘Sandwich’ position.

7.Allow the ikon Grill to preheat until the green ‘READY’ light illuminates.

8.During this time, prepare the sandwich and place it onto the base cooking plate. Always place sandwiches towards the rear of the bottom cooking plate.

9.Close the top cooking plate which has a floating hinge that is designed to evenly press down the sandwich. The top plate must be fully lowered to cook sandwiches. The Grilling Height Control on the right hand side of the top plate is used to adjust for the thickness of the sandwich.

10.Toasting should take approximately 5-8 minutes. Exact toasting time will be a matter of preference. It will also depend on the type of bread and filling used.

11.When the sandwich is cooked, use the handle to open the top plate. Remove the sandwich using a plastic spatula. Never use metal tongs or a knife as these can cause damage to the non-stick coating of the cooking plates.

The green ‘READY’light will cycle on and off during the toasting process indicating that the correct temperature is being maintained.

Always allow the ikon Grill to preheat until the green ‘READY’ light illuminates.

ALWAYS ALLOW THE IKON GRILL PLATES TO COOL DOWN BEFORE RELEASING AND REMOVING.

Using the plate release feature

Your ikon Grill features as a plate “Release” button which allows you to separately remove the top and bottom grill plates. It also enables you to safely and conveniently wash grill plates.

Releasing the grill plates

1.After cooking allow the ikon Grill to cool down.

2.To remove the grill plates press the “Release” buttons located on the front on the top button panel. The plates will unlock from the front where they can then be released individually (See Fig 3).

3.Once released hold the plates and remove (See Fig 4).

Fig 3

Fig 4

Using the adjustable grilling height control feature

Your ikon Grill features an adjustable Grilling height control feature which allows you to fix the top plate to a range of positions above the bottom plate.

This allows your ikon Grill to be used as an open toaster ideal for toasting open sandwich style ‘melts’. It can also be used to grill delicate hamburger buns without squashing.

1.Allow the ikon Grill to preheat until the green ‘READY’ light illuminates.

2.Place the food to be grilled on the base plate.

3.Move the Adjustable Grill Control Slide on the right hand side of the smart ikon Grill to the desired height (see Fig 5).

Fig 5

4.Slowly lower the top plate until it rests in the appropriate position above the food.

ALWAYS ALLOW THE IKON GRILL PLATES TO COOL DOWN BEFORE RELEASING AND REMOVING.

FULLY UNWIND THE CORD FROM THE CORD STORAGE FACILITY BEFORE USE.

8

9

Operating your Breville ikon Grill continued

5.The top plate will radiate the desired heat to melt ingredients such as cheese or lightly grill foods.

6.Toasting should take approximately 3-4minutes, however, exact cooking time is a matter of preference. It will also depend on the height of the top plate.

Variable temperature control dial

The Breville ikon Grill features a Variable Temperature Control dial which allows a variety of foods to be cooked. Just select a temperature suited to the foods which are being cooked.

With the dial set on Steak Sear (see Fig 6) the temperature is correctly suited to grill meats or other foods.

With the dial set on Sandwich (see Fig 7) the temperature is correctly suited to toasting sandwiches

Fig 6

Fig 7

The Adjustable Grill Height Control can be moved to accommodate thick or thin foods by sliding the clip forwards or backwards along the arm.

Note

Hints for best results for grilling

Meat

For best Grilling results use meat cuts which are thick enough to touch the top and base plate when the ikon Grill is closed.

Recommended Cuts

Beef

Sirloin (New York), Rump,



Rib Eye (Scotch Fillet), Fillet,

Pork

Butterfly loin Steaks, Spare Ribs,



Leg Steaks, Fillets, Diced Pork.

Tougher cuts such as beef blade or topside steak can be used. To tenderize these cuts marinate them for a few hours or overnight in a marinade with wine or vinegar to help break down the connective tissue.

It is recommended to cook items with thick bones such as T-bone steaks.

No not salt meat before cooking. Salt will draw out the juices toughening the meat.

If using a marinade recipe or pre-marinated meats from your meat retailer, drain excess marinade off and dab with kitchen paper before placing on the ikon Grill. Some marinades contain high sugar levels which can scortch on the Grill plate

when cooked.

Do not over cook the meat, even pork is better served pink and juicy.

Do not pierce meat with a fork or cut meat while cooking. This will let the juices escape, resulting in a tougher dry steak. Use tongs instead.

When removing fish pieces, use a flat heat resistant plastic spatula to support the food.

Part-boiling sausages can alleviate the need to pierce sausages before cooking.

FULLY UNWIND THE CORD FROM THE CORD STORAGE BEFORE USE.

10

11

Steaming foods continued

Grilling guide

Contact Grilling is a healthy and efficient way to cook. The cooking times are approximate due to the variances in ingredient thickness.

It is not recommended to cook items with thick bones such as T-bone steaks.

Ingredient and Type

Cooking Times





Beef



sirloin steak

3 minutes for medium rare





5-6 minutes for well done

minute steak

1-2 minutes

hamburger patties

4-6 minutes





Pork



Scotch fillet

4-6 minutes

loin steaks



fillet







Lamb



loin

3 minutes

cutlets

4 minutes

leg steaks

4 minutes





Chicken



breast fillets

6 minutes or until cooked through

thigh fillets

4-5 minutes or until cooked through





Sausages



thin

3-4 minutes

thick

6-7 minutes





Sandwich or Foccacia

3-5 minutes or until golden brown





Vegetables sliced 1 cm thick



eggplant

3-5 minutes

zucchini



sweet potato







Seafood



fish fillets

2-4 minutes

fish cutlets

3-5 minutes

octopus (cleaned)

3 minutes

shrimp

2 minutes

scallops

1 minute







These times relate to when the grill is closed and on the contact position.

Note

12

13

Care and cleaning

Before cleaning, switch the power off at the power outlet and then remove the plug. Allow your smart ikon Grill to be cool before cleaning. The appliance is easier to clean when slightly warm.

Always clean your ikon Grill after each use to prevent the build up of baked-on foods.

Wipe cooking plates with a soft cloth to remove food residue. For baked on food residue follow “using the plate release feature” page 9, remove the grill plates from the grill for cleaning. Wash in hot soapy. Remove stubborn residue with a non abrasive plastic scouring pad or nylon washing brush. Rinse and dry thoroughly with a clean, soft cloth and replace.

Cleaning the drip tray

Remove and empty the Drip Tray after each use and wash the tray in warm, soapy water. Avoid the use of scouring pads or harsh detergents as they may damage the surface.

Rinse and thoroughly with a clean, soft cloth and replace.

Scratch resistant coating

Your ikon Grill features a special scratch resistant non-stick coating that makes it safe to use metal utensils when cooking.

Regardless of this fact, Breville recommends that care is taken with the non-stick coating particularly when using metal utensils.

Do not use sharp objects or cut food inside the ikon Grill. Breville will not be liable for damage to the non-stick coating where metal utensils have been misused.

Cooking on a non-stick surface minimizes the need for oil, food does not stick and cleaning is easier.

Any discoloration that may occur will only detract from the appearance of the ikon Grill and will not affect the cooking performance.

When cleaning the non-stick coating, do not use metal (or other abrasive) scourers. Wash in hot soapy water. Remove stubborn residue with a non abrasive plastic scouring pad or nylon washing brush.

DO NOT IMMERSE ANY PART OF THE BREVILLE IKON GRILL IN WATER OR IN ANY OTHER LIQUID.

Storage

To store your ikon Grill:

1.Switch off at the power outlet and unplug from the wall.

2.Allow the ikon Grill to fully cool.

3.Slide the Adjustable Grill Height Control Slide towards the front handle to the LOCK position so that the top and bottom cooking plates are locked together.

4.Click the removable drip tray into place

5.Wrap the cord in the cord storage area below the appliance.

6.Store on a flat, dry, level surface

14

15

Warranty

One year limited warranty

Breville®* warrants this Breville® appliance against defects that are due to faulty material or workmanship for a period of (1) year from the date cited on the original purchase receipt. This warranty does not cover damage from abuse, neglect, use for commercial purposes, or any other use not found in the printed “Instructions for use” booklet. Should the customer choose to tamper with, or intentionally dismantle the product, the Warranty will automatically be deemed void. There is no warranty for glass parts, glass containers, filter basket, blades and agitators. HWI Breville® expressly disclaim all responsibility for consequential damages for incidental losses caused by use of this appliance. Some states or provinces do not allow this exclusion or limitation for incidental or consequential losses, so the foregoing disclaimer may not apply to you.

ANY WARRANTY OF MERCHANTABILITY OR FITNESS WITH RESPECT TO THIS PRODUCT IS ALSO LIMITED TO THE ONE YEAR LIMITED WARRANTY PERIOD.

Some states or provinces do not allow disclaimer of the implied warranty with respect to consumer goods, so the foregoing disclaimer may not apply to you.

This warranty gives you specific legal rights and you may also have other legal rights which vary from state to state or province to province.

If this appliance should become defective within the warranty period, do not return the appliance to the store. Please contact our Customer Service Center.

Toll free phone number:

1-866- BREVILLE (1-866-273-8455)

Internet email:

AskUs@BrevilleUSA.com

AskUs@Breville.ca (in Canada)

RECEIPT IS REQUIRED FOR ALL RETURNS

*HWI Breville® products are distributed in Canada by Anglo Canadian Housewares, L.P. and in USA by Metro/Thebe Inc.

Notes

16

17

Recipes

Recipes

Page

Grill recipes

20

18

Oregano lamb kebabs

16 oz (500g) boneless lean lamb, cut into

1 inch cubes

1 tablespoon olive oil

1 tablespoon lemon juice

1 tablespoon dried oregano leaves

1 teaspoon minced garlic Freshly ground black pepper

Preheat ikon Grill until the green ‘Ready’ light illuminates.

1.Combine oil with lemon juice and garlic in a large mixing bowl. Add lamb and allow to marinate for 30 minutes before threading onto 4 kebab skewers.

2.Season each kebab generously with pepper and place on grill.

3.Allow the top plate to rest lightly on lamb. Cook for 4-5 minutes.

4.Serve with crusty bread and a Greek salad of salad leaves, black olives and crumbled feta cheese.

21

Loading...
+ 25 hidden pages
