Bosch Remote Control

for: GWH-635-ES/635-ESO/250SX/250SXO/

2400E/2400EO/2400ES/2700ES/715ES/C800ES

6 720 606 990 (2007.01) AL

Contents

Contents

1FCC Declaration of conformity 3

2

Remote control data

4







3

Remote control Kit

4

3.1

Parts supplied

4

4Remote control installation for: GWH-635-ES/GWH-635-ESO/250SX/250SXO/2400E/

2400EO

5

4.1Remote control transceiver PCB



installation

5

4.2

Remote control activation

8

4.2.1

AF board

8

4.2.2

SU board

9

5Remote control installation for: GWH C 950 ES/GWH C800 ES/

GWH 715 ES/ GWH 2700 ES/



GWH2400ES

10

5.1Remote control transceiver PCB

installation

10

5.2Remote control activation11

6

Remote control

13

6.1

Description of the LCD

13

6.2Hot water temperature adjustment

by remote control

13

6.3"Program" button on the remote



control

13

6.4

"Priority" function

15

6.5

Error messages

16







7

Troubleshooting

16

7.1

Replacing batteries

16

7.2

Cleaning

16

7.3

Troubleshooting

16

8

Notes

19

2

6 720 606 990

Safety instructions

Safety instructions

BRead the following instructions very carefully to ensure correct operation.

B Follow safety instructions.

Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

1FCC Declaration of conformity

This device meets the requirements of FCC Directives.

Caution: The remote control can be used only in the following countries: United States of America and Canada.

Caution: the remote control is water resistant and can also be used in the shower. Nevertheless, it is not waterproof and must not be immersed in water, for instance in the bathtub.

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

6 720 606 990

3

Remote control data

2Remote control data

Remote control

for temperature

adjustment of Bosch water heaters.

Technical Data:









Battery power



Alkaline AA LR 6

supply



2 x 1.5V

Frequency



915 MHz

Type of



IP X6

protection







User range



98 ft (30 m)

Further Information:







Remote

Up to 6 remote controls

control

can

be programmed for



one single appliance.







3Remote control Kit

3.1Parts supplied

Fig. 1

Parts

1Remote control

2 Remote control transceiver PCB

3Support block (used only for GWH-635-ES/GWH-635-ESO/

250SX/250SXO)

4PCB connection cable

4

6 720 606 990

Remote control installation

4Remote control installation for: GWH- 635-ES/GWH-635-ESO/250SX/250SXO/ 2400E/2400EO

4.1Remote control transceiver PCB installation

Warning: For safety reasons, disconnect the power supply to the water heater before performing installation.

Pre-installationpreparation

B Disconnect power supply to heater.

B Remove plastic decals on front panel.

B Loosen two Philips head screws located behind plastic decals.

B Lift front cover upward and remove.

Fig. 2

B Remove the 5 screws on the front retaining bar (see Fig. 2, pos. 1 and 2) being careful not to damage the foam sealant material on it.

B Remove control unit auxiliary cover (Fig. 2, pos. 4).

B Remove the two electrical strip connectors inside the auxiliary cover (Fig. see diagram below) and then loosen the 110V power supply cord retaining nut located underneath the heater. Once loosened, the power cord can be pulled up through the heater to provide sufficient slack.

6 720 606 990

5

Remote control installation

Once auxiliary cover is off, pull off the two electrical strip connectors from the board. Once off, the wiring harness can be removed from the case by pulling their rubber seals outward.

Electrical strip connectors

BAt the ignition electrodes, pull off the 2 yellow igniter wires that come from the top of the control unit (Fig. 2, pos. 3). Then pull the complete control unit forward and out of the heater, pull up the power supply cord further if more slack is needed.

BWhile holding the unit in one hand or resting it on a flat surface, remove the front cover of the control unit by removing the 4 screws.

Remote control transceiver PCB installation

BOpen control unit top cover (Fig. 3, pos. 1).

BRemove the protective paper (Fig. 3, pos. 2) from one face of the support

and attach it to the main PCB as shown in Fig. 4.

Fig. 3

BRemove the other protective paper and attach the remote control PCB as shown in Fig. 5.

6

6 720 606 990

Remote control installation

Fig. 4 Support correct position

BUse the supplied cable to connect between the main PCB and the remote control PCB as shown in Fig. 5.

BReplace the control unit cover with the 4 Philips head screws (Fig. 3, pos. 1).

B Slide control unit back into heater.

BPlug 2 yellow electrode wires from the top of the control unit back onto the ignition electrodes. Ensure all connections are secure and tight (Fig. 2, pos. 3).

Wire polarity does not

imatter on the electrode wires.

B Pull end of power cord to take up excess slack and tighten retaining nut on the bottom of the heater.

B Reinstall the two electrical strip connectors onto the PCB. The larger connector connects to the lower connection on the PCB. Reseat the rubber seals for both connectors.

B Replace the control unit auxiliary cover. (Fig. 2, pos. 4).

BReplace front retaining bar using 5 Phillips head screws. (Fig. 2, pos 1).

Fig. 5

6 720 606 990

7

Remote control installation

4.2

Remote control



B On heater control panel press and



activation





hold

Program key

or













while turning on the power switch (I).

i

Before

the

remote

Release program key

when

LCD

control will work, it must

displays “188”.













be activated using the

LCD shows “P2”. If not, repeat



procedure

described

previous step.









below with the operator

B Select “P3” using buttons

and



standing in

front

of the





on heater.







appliance.

















B Press and hold Program key















The

remote

control

activation

or

again for 1 sec.





LCD shows one number and one

instructions vary based on the version

of control board installed in your

rotating digit. If not, repeat previous

heater.







step.









To determine

the

control board

The number

represents

the remote

control which is to be registered, the

version in the water heater:

first remote control will be registered











B Turn power switch on the water

with number “0”, the second with

heater to the off position (O).

number “1” and so on.





B When turning power switch to the

The rotating

digit shows that

the

electronics is expecting a registration.

on position, note the first two letters

If the LCD fails to show a number and

that appear on the display (should

rotating digit after repeated attempts,

be AF or SU).













double

check

the wire

connections

B If the letters are AF, follow

made in section 4.1.





section 4.2.1.

















B Hold remote control in front of the

For SU, follow section 4.2.2.

control panel on the heater and

4.2.1

AF board













simultaneously press remote control

B Connect power to heater.

buttons

and

until

the

temperature indication is shown on

B Move the power

switch on the

the remote control LCD.



appliance to the off position (0).













8

6 720 606 990

Remote control installation

B Switch power switch on the appliance to the "OFF" (0) position and then back "ON" (I).

B Press buttons orin order to reach desired temperature.

New remote control is programmed.

4.2.2 SU board

B Connect power to heater.

B Move the main switch on the appliance to the "OFF" (0) position.

BPress and hold key while at the same time turning the main switch to “ON” position (I).

LCD shows one number and one

rotating digit. If not repeat previous

step.

The number represents the remote

control which is to be registered, the

first remote control will be registered

with number “0”, the second with

number “1” and so on.

The rotating digit shows that the

electronics is expecting a registration.

If the LCD fails to show a number and

rotating digit after repeated attempts,

double check the wire connections

made in section 4.1.

B Hold remote control in front of the control panel on the heater and

simultaneously press remote control buttons anduntil the temperature indication is shown on the remote control LCD.

B Switch ON/OFF switch to “OFF” position (0) and then back on (I).

B Press buttons orin order to reach requested temperature.

New remote control is programmed.

6 720 606 990

9

Remote control installation

5Remote control installation for: GWH C 950 ES/GWH C800 ES/GWH 715 ES/ GWH 2700 ES/ GWH2400ES

BRemove the 6 screws from the back cover of the control unit, to access the electronic board (PCB) (Fig. 7, pos.2).

5.1Remote control

transceiver PCB installation

Warning: For safety

reasons, disconnect the power supply to

the water heater

Fig. 7

before performing installation.

Pre-installationpreparation

BLoosen the two Philips head screws located on bottom rear of cover.

B Lift front cover upward and remove.

BRemove the three screws from the control unit (Fig. 7, pos.1).

Fig. 6
