Beko BZ30 User Manual

Size:
651.57 Kb
Download

3.4 cu.ft.

Fully Integrated Freezer

BZ30

BEKO plc



Beko House



Caxton Way



Watford



Hertfordshire



WD18 8UF



Tel: 01923 654650



Fax: 01923 819653

Printed in Turkey

e-mail:service@beko.co.uk

Part no: 48 3900 00 02



website: www.beko.co.uk

Revision no: 2

Congratulations on your choice of a quality Appliance which has been designed to give you service for many years.

WARNING !

IMPORTANT !

DO NOT connect your appliance to the electricity supply until all packing and transit protectors have been removed.

Leave to stand for at least 4 hours before switching on to allow compressor oil to settle if transported horizontally.

If you are discarding an old refrigerator with a lock or latch fitted to the door, disable the lock/latch, ensure that it is left in a safe condition to prevent the entrapment of young children.

This freezer must only be used for its intended purpose i.e the storing and freezing of edible foodstuff.

Do not dispose of the appliance on a fire. At BEKO, the care and protection of our environment is an ongoing commitment. This appliance which is among the latest range introduced is particularly environment friendly. Your appliance contains non CFC / HFC natural substances in the cooling system (Called R600a) and in the insulation (Called cyclopentane) which are potentially flammable if exposed to fire. Therefore, take care not to damage, the cooling circuit / pipes of the appliance in transportation and in use. In case of a damage do not expose the appliance to fire, potential ignition source and immediately ventilate the room where the appliance is situated.

We suggest you contact your local authority for disposal information and facilities available.

You may install your freezer in an unheated cold room ((E.g.: garage, conservatory, annex) provided it is protected from rain, moisture, excessive heat.

To obtain the best possible performance and trouble free operation from your appliance it is very important to carefully read these instructions.

On delivery, check to make sure that the product is not damaged and that all the parts and accessories are in perfect condition.

Ensure that the plug remains readily accessible. Do not use a multiple adapter bar or extension cable.

Failure to observe these instructions may invalidate your right to free service during the guarantee

period.

WARNINGKeep ventilation openings, in the appliance enclosure or in the built-instructure, clear of obstruction.

WARNINGDo not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.

WARNINGDo not damage the refrigerant circuit.

WARNINGDo not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.

• We suggest you keep these instructions in a safe place for easy reference.



Fully Integrated Freezer



BZ30





PERFORMANCE







Energy efficiency class

A





Energy consumption - Kwh/year

205

Net storage - vol fresh food ltrs (cu.ft.)

-----

Net storage - vol frozen food ltrs (cu.ft)

87 (3.1)

Total net vol - ltrs (cu.ft.)

87 (3.1)

Frozen food compartment rating

4 STAR

Conservation time from failure

19 hrs.

Freezing capacity fresh food - kg /24 hrs.

10

Climate class

SN

Operating noise level dB(A)

39

1

CONTENTS

PAGE





SAFETY FIRST / ELECTRICAL REQUIREMENTS

3





TRANSPORTATION INSTRUCTIONS

4





INSTALLATION INSTRUCTIONS

5





REPOSITIONING THE DOOR

6-7





STARTING

8





TEMPERATURE CONTROL AND ADJUSTMENT

9





STORING FROZEN FOOD

9





FREEZING FRESH FOOD

10





DEFROSTING

11





CLEANING AND CARE

12





DO'S AND DON'TS

13





PROBLEM SOLVING

13





INSTALLATION INSTRUCTIONS - DETAILED STEP BY STEP

14-19





GUARANTEE DETAILS

20





HOW TO OBTAIN SERVICE

21





2

ELECTRICAL REQUIREMENTS

Before you insert the plug into the wall socket make sure that the voltage and the frequency shown in the rating plate inside the appliance corresponds to your electricity supply. Rating label is on the left hand side of freezer inner liner.

We recommend that this appliance is connected to the mains supply via a suitable switched and fused socket in a readily accessible position.

Should the mains lead of the appliance become damaged or should it need replacing

at any time, it must be replaced by a special purpose made mains lead which can only be obtained from a BEKO Authorised Service Agent.

WARNING! THIS APPLIANCE MUST BE EARTHED

If the fitted moulded plug is not suitable for your socket, then the plug should be cut off and an appropriate plug fitted. Destroy the old plug which is cut off as a

plug with bared cord could cause a shock hazard if inserted into a socket elsewhere in the house.

The moulded plug on this appliance incorporates a 13 A fuse. Should the fuse need

to be replaced an ASTABEAB approved BS 1362 fuse of the same rating must be used. Do not forget to refit the fuse cover. In the event of losing the fuse cover the

plug must not be used until a replacement fuse cover has been fitted. Colour of the

replacement fuse cover must be the same colour as that visible on the pin face of the plug. Fuse covers are available from any good electrical store.

IMPORTANT! FITTING A DIFFERENT PLUG

As the colours of the wires in the mains lead of this appliance may

not correspond with the coloured

markings identifying the terminals in your plug proceed as follows:

(See diagram).

1.Connect the green-yellowor green (Earth) wire to the terminal in the plug marked 'E' or with the symbolor coloured green and yellow or green.

2.Connect the blue (Neutral) wire to the terminal in the plug marked 'N' or coloured black.

GREEN &













6mm.



































YELLOW

















































OR













L









GREEN

32mm.













































BROWN



6mm.























N













OR



































22mm.

RED









BLUE



































12mm.

OR





6mm.







































BLACK























































CORD GRIP







FITTED WITH BS 1362 13A FUSE ALWAYS FIT BS 1362 REPLACEMENT CARTRIDGE FUSE









FUSE





















3.Connect the brown (Live) wire to the terminal in the plug marked 'L' or coloured red.

With alternative plugs a 13 A fuse must be fitted either in the plug or adaptor or in the main fuse box.

If in doubt contact a qualified electrician.

3

TRANSPORTATION INSTRUCTIONS

1.The appliance should be transported only in a vertical upright position. The packing as supplied must be intact during transportation.

2.If during the course of transport the appliance has to be transported horizontally, it must only be laid on its left hand side when standing in the front of the appliance. After bringing it to upright position,it must not be operated for at least 4 hours to allow the system to settle.

3.Failure to comply with the above instructions could result in damage occuring to the appliance. The manufacturer will not be held responsible if these instructions are disregarded.

4.The appliance must be protected against rain, moisture and other atmospheric influences.

5.When positioning your appliance take care not to damage your flooring, pipes, wall coverings etc. Do not move the appliance by pulling by the door or handle.

IMPORTANT : Care must be taken while cleaning / carrying the appliance to avoid touching the bottom of the condenser metal support or pipework at the back of the appliance as you might injure your fingers and hands or damage your product.

IMPORTANT : This appliance is not designed for stacking with any other appliance.

Do not attempt to sit or stand on top of your appliance as it is not designed for such use. You could injure yourself or damage the appliance.

IMPORTANT : Make sure that mains cable is not caught under the appliance during and after carrying / moving the appliance, to avoid the mains cable becoming cut or damaged.

Do not allow children to play with the appliance or tamper with the controls.

Take care when installing your appliance and using it for the first time, during normal daily use, while defrosting and cleaning the interior freezer compartments not to damage cold panels and pipes and to avoid any injury. We recommend the use of a pair of gloves when cleaning the cold panels as you might injure your fingers and hands and/or damage the appliance beyond repair.

BEKO plc declines to accept any liability should the instructions not be followed.

IMPORTANT

INSTALLATION INSTRUCTIONS

1.To avoid a hazard due to instability of the appliance, it must be fixed in accordance with the instructions.

2.Do not operate this applliance unless installed to furniture.

3.The appliance should be located on a smooth surface. The four front and back feet can be adjusted as required. To ensure that, your appliance is standing upright adjust the four front and back feet by turning clockwise or anti-clockwise,until the product is in firm contact with the floor. Correct adjustment of feet avoids excessive vibration and noise.

4.Refer to "Cleaning and Care" section to prepare your appliance for use.

10 mm

To avoid any loss in performance, air suction channels should not be obstructed. (140 cm2)

Minimum distance between the wall and the appliance must be at least 10 mm.

40 mm

10 mm

40 mm



Wall

Appliance

4

5

REPOSITIONING THE DOOR

Follow the step by step instructions and the diagram below. Numbers in brackets refer to diagrams.

1

3

5 1

4

2

2

6



9





11

7

11







8

10 12

12

1.Switch off at the socket outlet and pull out the mains plug.

2.Remove all food, loose items and fittings from inside the appliance and door shelves.

3.Unscrew the bolts and remove the upper and bottom hinges from the cabinet and door.

(1) (2)

4.Unscrew the bolts and remove the furniture fixing parts from the door. (3) (4)

5.Remove stoppers. (5) (6)

6.Reposition the furniture fixing parts on the opposite side. (7) (8)

7.Fit the stoppers on the opposite side. (9) (10)

8.Reposition the upper hinge on the opposite side as bottom hinge (12)

9. Reposition the bottom hinge on the opposite side as upper hinge. (11) Locate the door and tighten the bolts fixing the door.

6

7



STARTING

Final Check

Before you start using the freezer check that:

1.The feet have been adjusted and the product is level.

2.The interior is dry and air can circulate freely at the rear.

3.Clean the interior as recommended under "CLEANING AND CARE."

4.Insert the plug into the wall socket and switch on the electricity supply. Avoid accidental disconnection by taping over the switch.

5.You will hear a noise as the compressor starts up. The liquid and gases sealed within the refrigeration system may also give rise to noise, whether the

compressor is running or not which is quite normal.

7. Front edges of the cabinet may feel warm. This is normal. These areas are designed to be warm to avoid condensation.

9. Do not load the appliance immediately it is switched on. Wait until the correct storage temperature has been reached. We recommend that you check the temperature with an accurate thermometer (see; Temperature Control and Adjustment).

Important Notes :

1.If there is a power failure do not open the door. Frozen food should not be affected if the failure lasts for less than 19 hours. If the failure is longer, then the food should be checked and either eaten immediately or cooked and then re-frozen.

2.If you find the freezer door difficult to open just after you have closed it, don't worry. This is due to the pressure difference which will equalise and allow the door to open normally after a few minutes.

3.Always wrap food using a suitable packaging material before storing in your appliance to avoid contact with the appliance surface and food remains for hygiene reasons.

8

TEMPERATURE CONTROL AND ADJUSTMENT

There are three coloured indicator lights located inside the appliance which show the operating mode of the freezer.

Green Indicator (1)

Illuminates when the appliance is connected to the mains and will glow as long as there is electricity present. The green light will not glow if the thermostat is set in the 'O' position. The green indicator does not give any indication of the temperature inside the freezer.

Amber Indicator (2)

This indicator will glow when the fast-freezeswitch (4) is on and will continue to glow until thefast-freezeswitch is turned off. The compressor will run continuously whilst thefast-freezeswitch is on.Fast-freezeoperation is for freezing fresh food (see Freezing Fresh Food, section).

Red Indicator (3) Illuminates:

a.If the pre-settemperature can not be maintained.

b.If the appliance is overloaded with fresh food.

c.If the appliance door is left open accidentally.

Thermostat knob (5)

The thermostat knob is located on the indicator light frame.

Important:

When you press the fast-freezeswitch, there may be a short delay before the compressor starts to operate. This is normal and not a compressor fault.

4

5



3

1

2













































































































































































































































































































































STORING FROZEN FOOD

Prepacked commercially frozen food should be stored in accordance with the frozen food manufacturer's instructions for a frozen food storage compartment.

The freezing area is marked with symbol on the door liner.

To ensure that the high quality achieved by the frozen food manufacturer and the food retailer is maintained the following should be remembered:

1.Put packets in the freezer as quickly as possible after purchase.

2.Do not exceed "Use By", "Best Before" dates on the packaging.

3.Please note that drawers, baskets, flaps, trays are all removable.

9

FREEZING FRESH FOOD

Freezing capacity of your appliance in a 24 hours period is 10 kg (22.1 lb). Never exceed this maximum capacity.

Fast freeze compartment (3) is shown in diagram.

Take special care not to mix already frozen food and fresh food.

If the fast freeze compartment (3) is filled with fresh food, other compartments can also be used to freeze fresh food.

1

2

2

1.Fast-freezecompartment

2.Frozen-foodcompartments

DEFROSTING

Defrost twice a year or when a frost layer of around 7 mm (1/4") has formed.

To start defrosting procedure turn the thermostat knob to zero position (Alternatively you may switch off the freezer at the socket outlet and pull out the

mains plug.)

All food should be wrapped in several layers of newspaper and stored in a cool place (e.g. fridge or larder).

Remove all freezer drawers.The special defrost collection basin collects the defrost water. Therefore defrosting can be conducted without mess.

Containers full of warm water may be placed carefully in the freezer to speed up the defrosting.

Do not use pointed or sharp edged objects such as knives, forks to remove the frost.

Never use hairdryers, electrical heaters and other similar electrical appliances for defrosting.

When defrosting has finished, sponge out any defrost water which collects at the bottom of the freezer and dry the interior thoroughly. Turn the thermostat knob to mid point. Close the freezer door. Insert the plug into the wall socket and switch on the electricity supply. Don't forget to tape over the switch to avoid accidental disconnection.

10

11

CLEANING AND CARE

**We recommend that you switch off the freezer at the socket outlet and pull out the mains plug before cleaning.

**Never use any sharp abrasive instrument, soap, household cleaner, detergent and wax polish for cleaning.

**Use luke warm water to clean the cabinet of the freezer and wipe it dry.

**Use a damp cloth wrung out in a solution of one teaspoon of bicarbonate of

soda to one pint of water to clean the interior and wipe it dry.

** Excess deposit of ice should be removed on a regular basis using the handle of a spoon. Large accumulation of ice will impair the performance of the freezer.

**If the freezer is not going to be used for a long period of time switch it off, remove all food, clean it and leave the door ajar.

**To remove a drawer, pull it as far as possible, and then tilt it upwards, and then pull it out completely.

**Check door seals regularly to ensure they are clean and free from food particles.

**Never :

Subject it to hot temperatures in any way,

Scour, rub etc., with abrasive material.

**Take care when installing your appliance and using it for the first time, during normal daily use, while defrosting and cleaning the interior freezer compartments not to damage cold panels and pipes and to avoid any injury. We recommend the use of a pair of gloves when cleaning the cold panels as you might injure your fingers and hands and/or damage the appliance beyond repair.

12

DO'S AND DON'TS

DoCheck contents of the freezer at regular intervals.

DoClean and defrost your freezer regularly (See "Defrosting")

DoKeep food for as short a time as possible and adhere to "Best Before", "Use By" dates.

DoStore commercially frozen food in accordance with the instructions given on the packets that you buy.

DoAlways choose high quality fresh food and be sure it is thoroughly clean before you freeze it.

DoPrepare fresh food for freezing in small portions to ensure rapid freezing. DoWrap all foods in aluminium foil or freezer quality polythene bags and

make sure any air is excluded.

DoWrap frozen food when you buy it and put it in to the freezer as soon as possible.

DoSeparate food in the compartments. This will enable you to find food quickly and avoid excessive door opening therefore save electricity.

DoRemove ice cream from the freezer 10-20minutes before serving. Don't- Leave the door open for long periods as this will make the freezer more

costly to run and cause excessive ice formation.

Don't- Use pointed sharp edged objeects such as knives, forks to remove the ice. Don't- Put hot food into the freezer. Let it cool down first.

Don't- Put liquid-filledbottles or sealed cans containing carbonated liquids into the freezer as they may burst.

Don't- Store poisonous or dangerous substances in the Freezer. Your freezer has been designed for the storage of edible foodstuffs only.

Don't- Exceed the maximum freezing capacity (10 kg in any 24 hours) when freezing fresh food.

Don't- Consume ice-creamand water ices direct from the freezer. The low temperature may cause 'freezer burns' on lips.

Don't- Freeze fizzy drinks.

Don't- Try to keep frozen food which has thawed, it should be eaten within 24 hours or cooked and refrozen.

Don't- Remove items from the freezer with wet hands.

Don't- Close the door before placing the fast-freezecompartment cover in its place.

Don’t- Leave frozen food at room temperature to thaw; the best way to defrost food is to put it in the fridge to thaw slowly. Make sure you avoid defrosting food or food juices drip onto other food.

PROBLEM SOLVING

If the appliance does not operate when switched on, check:

The plug is inserted properly in the socket and that the power supply is on. (To check the power supply to the socket, plug in another appliance)

The fuse has blown/circuit breaker has tripped/main distribution switch has been turned off.

The temperature control has been set correctly.

New plug is wired correctly if you have changed the fitted moulded plug.

If the appliance is still not operating after the above checks, please refer to the section on “How To Obtain Service”.

Please ensure that above checks have been made as a charge will be made if no fault is found.

13

INSTALLATION INSTRUCTIONS - DETAILED STEP BY STEP

598

595

545

A

A (mm)

813 - 863 mm

B (mm)

820 - 870 mm





C (mm)

100 - 150 mm





NOTE

1)Height of the product can be adjusted by the help of adjustable feet (front and back) to fit the furniture niche height (B).

2)Do not operate this appliance until it has been installed in the furniture.

min.



550





B

min.

C

550

C=100-150mm



600

.

min



C

600

D



C

D > 150 mm.

14

15

E = 3 mm is recommended.

Top view



A

E

E

Front view

B

1

4

2

min. 4 mm

3

40 + A

505

B

5

6

Note:

1.These dimensions are valid for products,which are hinged on right hand side.

2.When door opening direction is reversed, mirror image of this instruction should be considered. That is, dimensions should be considered for opposite sides.

16

17
