AYP 3497A89 Parts List

Size:
178.13 Kb
Download

3497A89 (1998)

Page 1 of 24

DECALS



3497A89 (1998)



Page 2 of 24

DECALS













Ref # Part Number

Qty Description

1

162727

DECAL, LOGO



2

129212

NLA

3

146372

DECAL.GUARD.BLT.W

4

127521

NLA

5

120431X

DECAL TI

6

138546

DECAL.SHIFT.IND.

7

120075X

DECAL TI

8

110655X

NLA

9

162215

DECAL.TINE.SHIELD

11

156200

DECAL.PANEL 8 HP



162876

MANUAL.O.3497A89

3497A89 (1998)

Page 3 of 24

ENGINE, BRIGGS AND STRATTON



3497A89 (1998)



Page 4 of 24

ENGINE, BRIGGS AND STRATTON













Ref #

Part Number

Qty Description

1

495631

CYLINDER ASSEMBLY



2

495657

BUSHING, CYLINDER

3

391086

SEAL, OIL

5

214347

HEAD, CYLINDER

7

272163

GASKET, CYLINDER HEAD

8

498038

BREATHER ASSEMBLY

9

27803

GASKET, VALVE COVER

10

94621

SCREW, STEMS

11

280819

TUBE, BREATHER

12

271701

GASKET, CRANKCASE COVER 1/64"

12

27876

GASKET,CRANKCASE COVER .005"

12

27877

GASKET, CRANKCASE COVER .009"

13

94565

SCREW, CYLINDER HEAD

13A

94926

STUD, HEX DRIVE

14

93723

SCREW, CYLINDER HEAD 3"

15

94880

PLUG, OIL DRAIN, FLUSH

15

94239

PLUG, OIL DRAIN

16

495648

CRANKSHAFT

16

94388

TIMING GEAR KEY

18

496982

COVER ASSEMBLY, CRANKCASE

19

295964

BUSHING, CRANKCASE

20

391086

SEAL, OIL

21

281658

PLUG-OILFILLER

22

93585

SCREW, HEX HEAD

23

298260

FLYWHEEL, MAGNETO

24

222698

KEY, FLYWHEEL

25

499907

PISTON ASSEMBLY STANDARD

25

499908

PISTON ASSEMBLY

25

499909

PISTON ASSEMBLY

25

499910

PISTON ASSEMBLY

26

499921

RING SET, PISTON STANDARD

26

690018

SPRING, GOVERNOR

26

690019

SPRING, GOVERNED IDLE

26

690020

RING SET, PISTON

27

263181

LOCK, PISTON PIN

28

499911

PIN ASSEMBLY, PISTON STANDARD

28

499920

PIN ASSEMBLY, PISTON

29

390401

ROD ASSEMBLY, CONNECTING

29

390773

ROD ASSEROD ASSEMBLY, CONNECTING

30

222113

DIPPER, CONNECTING ROD

32

92659

SCREW, CONNECTING ROD

33

263017

VALVE, EXHAUST

34

261055

VALVE, INTAKE

35

65906

SPRING, INTAKE VALVE

37

222475

GUARD, FLYWHEEL

38

94811

SCREW, HEX HEAD

40

221596

RETAINER, INTAKE VALVE

45

260933

TAPPET, VALVE

46

214786

GEAR, CAM

50

214170

ELBOW, INTAKE

51

272708

GASKET, CARBURETOR MOUNTING

51A

272707

GASKET, INTAKE MANIFOLD

53

94778

STUD, CARB. MOUNTING

55

393576

HOUSING, REWIND STARTER

56

295871

PULLEY, REWIND STARTER

57

490179

SPRING, REWIND STARTER

58

66884

ROPE, REWIND STARTER

59

490653

INSERT, STARTER HANDLE

3497A89 (1998)



Page 5 of 24

ENGINE, BRIGGS AND STRATTON













Ref #

Part Number

Qty Description

60

490652

HANDLE, REWIND STARTER



63

260414

SPRING, RATCHET

64

281204

ADAPTER, RATCHET SPRING

65

94904

SCREW, SEMS

66

399671

CLUTCH ASSEMBLY, REWIND STARTER

67

394897

HOUSING, STARTER CLUTCH

68

63770

BALL, CLUTCH

70

298799

RATCHET, REWIND STARTER

71

394506

WASHER, CLUTCH RETAINER

73

224874

SCREEN, REWIND STARTER

74

94680

SCREW, CYLINDER SHIELD

75

225136

WASHER, SPRING

75A

495659

WASHER, SET

93

281346

BUSHING, THROTTLE SHAFT

94

496589

VALVE, IDLE ADJUSTMENT

95

94098

SCREW, THROTTLE

98

495800

SCREW, IDLE SPEED

98A

493280

SCREW ASSY SPEED ADJ

104

231789

PIN, FLOAT HINGE

105

231935

VALVE, NEEDLE

106

231856

SEAT, INLET

108

224666

VALVE, CHOKE

116

280203

O-RING,FUELVALVE

121

497581

CARBURETOR OVERHAUL KIT

123

94913

SCREW, TORX HEX

125

690011

CARBURETOR

130

224539

VALVE, THROTTLE

131

498846

SHAFT, THROTTLE

133

494381

FLOAT, CARBURETOR

137

281165

GASKET, FLOAT BOWL

138

281164

WASHER, FLOAT BOWL SCREW

141

497160

SHAST, CHOKE

142

690125

NOZZLE, CARBURETOR

142

690126

NOZZLE, CARBURETOR

161

497669

BASE, AIR CLEANER

163

273101

GASKET, AIR CLEANER

165

94692

NUTWING

186

230318

CONNECTOR, IMPULSE PUMP

186A

493496

ELBOW, FUEL PIPE

187

296004

PIPE, FUEL

187A

497029

LINE, FUEL

188

94627

SCREW, SEMS 3/4"

200

221760

GUIDE, AIR

201

263051

LINK, GOVERNOR

202

263049

LINK, THROTTLE

203

497207

LEVER, LINKAGE

209

263212

SPRING, GOVERNOR

210

492044

STRAINER, FUEL

211

263182

SPRING, GOVERNED IDLE

219

497037

GEAR GOVERNOR

220

221551

WASHER THRUST

222

499103

PLATE, GOVERNOR CONTROL

227

499096

LEVER ASSEMBLY, GOVERNOR

230

94927

WASHER, GOVERNOR LEVER

232

263020

SPRING, LINK

258

94929

SCREW, SELF-TAPPING

265

221535

CLAMP

298

261409

LOCKNUT, MUFFLER

3497A89 (1998)



Page 6 of 24

ENGINE, BRIGGS AND STRATTON













Ref #

Part Number

Qty Description

300

496127

MUFFLER, EXHAUST



304

491596

HOUSING, BLOWER

305

94786

SCREW

306

496797

SHIELD, CYLINDER

307

94930

SCREW

308

225055

COVER, CYLINDER HEAD

332

92284

NUT, FLYWHEEL

333

398811

ARMATURE, MAGNETO

334

94731

SCREW, SEMS

337

496018

SPARK PLUG

346

94896

SCREW, SEMS

353

92791

WASHERLOCK

354

94726

NUT, HEX

354A

90576

NUT, HEX

356

398838

WIRE, GROUND

356A

496868

WIRE, GROUND

358

497070

GASKET SET

363

19203

PULLER, FLYWHEEL

373

94908

NUT, HEX

383

89838

WRENCH SPARK PLUG

385

94789

SCREW, FUEL PUMP MOUNTING

387

496257

PUMP, FUEL

445

496077

CARTRIDGE, AIR CLEANER

467

280715

KNOB, CONTROL

520

93722

TERMINAL, SPADE

552

491893

BUSHING, GOVERNOR CRANK

562

94907

BOLT, GOVENOR LEVEL

592

231978

NUT, HEX

601

95162

CLAMP, FUEL LINE

608

390391

STARTER ASSEMBLY, REWIND

614

93306

COTTER, HAIR PIN

616

496818

P/N CONFLICT - CHECK WITH SUPPLIER

621

396847

SWITCH, STOP

623

231520

SCREW, SHOULDER

634

494455

SEAL, SPRING ASSY.

635

66538

ELBOW, SPARK PLUG

642

281357

COVER, AIR CLEANER

655

222598

ANCHOR, SPRING

657

94906

SCREW

676

393757

DEFLECTOR, EXHAUST, SIDE OUTLET

741

263025

GEAR, TIMING

843

280643

SLEEVE, LEVER

851

493880

TERMINAL, IGNITION CABLE

868

497656

SEAL, INTAKE VALVE

869

211661

SEAT, INTAKE AND EXHAUST VALVES

871

231218

GUIDE, INTAKE VALVE

918

497457

LINE, VACUUM

950

94642

SCREW, FUEL BOWL

956

493337

FUEL TANK ASSEMBLY

957

493988

CAP, FUEL TANK

958

399517

VALVE ASSEMBLY, FUEL SHUT-OFF

959

495664

BRACKET, FUEL TANK, UPPER

960

492990

BRACKET, FUEL TANK LOWER

961

94095

SCREW, TANK MOUNTING

965

94010

LOCKNUT, AIR CLEANER MOUNTING

969

94777

SCREW, SLOTTED HEX

975

494378

BOWL ASSEMBLY, CARBURETOR

985

398525

INSULATOR ASSEMBLY

3497A89 (1998)



Page 7 of 24

ENGINE, BRIGGS AND STRATTON











Ref # Part Number

Qty Description

987

281166

SEAL, THROTTLE SHAFT



1016

490817

SPACER

1036

499354

LABEL KIT, EMISSION

1058

273682

OWNER'S MANUAL

2500

192402-1015

REPLACEMENT ENGINE



497536

REPLACEMENT SHORTBLOCK



497578

CARBURETOR KIT



497069

CARBURETOR GASKET SET



497534

VALVE OVERHAUL GASKET SET

3497A89 (1998)

Page 8 of 24

ENGINE, BRIGGS AND STRATTON



3497A89 (1998)



Page 9 of 24

ENGINE, BRIGGS AND STRATTON













Ref #

Part Number

Qty Description

1

495631

CYLINDER ASSEMBLY



2

495657

BUSHING, CYLINDER

3

391086

SEAL, OIL

5

214347

HEAD, CYLINDER

7

272163

GASKET, CYLINDER HEAD

8

498038

BREATHER ASSEMBLY

9

27803

GASKET, VALVE COVER

10

94621

SCREW, STEMS

11

280819

TUBE, BREATHER

12

271701

GASKET, CRANKCASE COVER 1/64"

12

27876

GASKET,CRANKCASE COVER .005"

12

27877

GASKET, CRANKCASE COVER .009"

13

94565

SCREW, CYLINDER HEAD

13A

94926

STUD, HEX DRIVE

14

93723

SCREW, CYLINDER HEAD 3"

15

94880

PLUG, OIL DRAIN, FLUSH

15

94239

PLUG, OIL DRAIN

16

495648

CRANKSHAFT

16

94388

TIMING GEAR KEY

18

496982

COVER ASSEMBLY, CRANKCASE

19

295964

BUSHING, CRANKCASE

20

391086

SEAL, OIL

21

281658

PLUG-OILFILLER

22

93585

SCREW, HEX HEAD

23

298260

FLYWHEEL, MAGNETO

24

222698

KEY, FLYWHEEL

25

499907

PISTON ASSEMBLY STANDARD

25

499908

PISTON ASSEMBLY

25

499909

PISTON ASSEMBLY

25

499910

PISTON ASSEMBLY

26

499921

RING SET, PISTON STANDARD

26

690018

SPRING, GOVERNOR

26

690019

SPRING, GOVERNED IDLE

26

690020

RING SET, PISTON

27

263181

LOCK, PISTON PIN

28

499911

PIN ASSEMBLY, PISTON STANDARD

28

499920

PIN ASSEMBLY, PISTON

29

390401

ROD ASSEMBLY, CONNECTING

29

390773

ROD ASSEROD ASSEMBLY, CONNECTING

30

222113

DIPPER, CONNECTING ROD

32

92659

SCREW, CONNECTING ROD

33

263017

VALVE, EXHAUST

34

261055

VALVE, INTAKE

35

65906

SPRING, INTAKE VALVE

37

222475

GUARD, FLYWHEEL

38

94811

SCREW, HEX HEAD

40

221596

RETAINER, INTAKE VALVE

45

260933

TAPPET, VALVE

46

214786

GEAR, CAM

50

214170

ELBOW, INTAKE

51

272708

GASKET, CARBURETOR MOUNTING

51A

272707

GASKET, INTAKE MANIFOLD

53

94778

STUD, CARB. MOUNTING

55

393576

HOUSING, REWIND STARTER

56

295871

PULLEY, REWIND STARTER

57

490179

SPRING, REWIND STARTER

58

66884

ROPE, REWIND STARTER

59

490653

INSERT, STARTER HANDLE

3497A89 (1998)



Page 10 of 24

ENGINE, BRIGGS AND STRATTON













Ref #

Part Number

Qty Description

60

490652

HANDLE, REWIND STARTER



63

260414

SPRING, RATCHET

64

281204

ADAPTER, RATCHET SPRING

65

94904

SCREW, SEMS

66

399671

CLUTCH ASSEMBLY, REWIND STARTER

67

394897

HOUSING, STARTER CLUTCH

68

63770

BALL, CLUTCH

70

298799

RATCHET, REWIND STARTER

71

394506

WASHER, CLUTCH RETAINER

73

224874

SCREEN, REWIND STARTER

74

94680

SCREW, CYLINDER SHIELD

75

225136

WASHER, SPRING

75A

495659

WASHER, SET

93

281346

BUSHING, THROTTLE SHAFT

94

496589

VALVE, IDLE ADJUSTMENT

95

94098

SCREW, THROTTLE

98

495800

SCREW, IDLE SPEED

98A

493280

SCREW ASSY SPEED ADJ

104

231789

PIN, FLOAT HINGE

105

231935

VALVE, NEEDLE

106

231856

SEAT, INLET

108

224666

VALVE, CHOKE

116

280203

O-RING,FUELVALVE

121

497581

CARBURETOR OVERHAUL KIT

123

94913

SCREW, TORX HEX

125

690011

CARBURETOR

130

224539

VALVE, THROTTLE

131

498846

SHAFT, THROTTLE

133

494381

FLOAT, CARBURETOR

137

281165

GASKET, FLOAT BOWL

138

281164

WASHER, FLOAT BOWL SCREW

141

497160

SHAST, CHOKE

142

690125

NOZZLE, CARBURETOR

142

690126

NOZZLE, CARBURETOR

161

497669

BASE, AIR CLEANER

163

273101

GASKET, AIR CLEANER

165

94692

NUTWING

186

230318

CONNECTOR, IMPULSE PUMP

186A

493496

ELBOW, FUEL PIPE

187

296004

PIPE, FUEL

187A

497029

LINE, FUEL

188

94627

SCREW, SEMS 3/4"

200

221760

GUIDE, AIR

201

263051

LINK, GOVERNOR

202

263049

LINK, THROTTLE

203

497207

LEVER, LINKAGE

209

263212

SPRING, GOVERNOR

210

492044

STRAINER, FUEL

211

263182

SPRING, GOVERNED IDLE

219

497037

GEAR GOVERNOR

220

221551

WASHER THRUST

222

499103

PLATE, GOVERNOR CONTROL

227

499096

LEVER ASSEMBLY, GOVERNOR

230

94927

WASHER, GOVERNOR LEVER

232

263020

SPRING, LINK

258

94929

SCREW, SELF-TAPPING

265

221535

CLAMP

298

261409

LOCKNUT, MUFFLER
