Notebook PC
E-Manual
E7486
August 2012
COPYRIGHT INFORMATION
No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”).
ASUS PROVIDES THIS MANUAL “AS IS”WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
Products and corporate names appearing in this manual may or may not be registered trademarks or copyrights of their respective companies, and are used only for identification or explanation and to the owners’ benefit, without intent to infringe.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Copyright © 2012 ASUSTeK COMPUTER INC. All Rights Reserved.
LIMITATION OF LIABILITY
Circumstances may arise where because of a default on ASUS’ part or other liability, you are entitled to recover damages from ASUS. In each such instance, regardless of the basis on which you are entitled to claim damages from ASUS, ASUS is liable for no more than damages for bodily injury (including death) and damage to real property and tangible personal property; or any other actual and direct damages resulted from omission or failure of performing legal duties under this Warranty Statement, up to the listed contract price of each product.
ASUS will only be responsible for or indemnify you for loss, damages or claims based in contract, tort or infringement under this Warranty Statement.
This limit also applies to ASUS’ suppliers and its reseller. It is the maximum for which ASUS, its suppliers, and your reseller are collectively responsible.
UNDER NO CIRCUMSTANCES IS ASUS LIABLE FOR ANY OF THE FOLLOWING: (1) THIRDPARTY CLAIMS AGAINST YOU FOR DAMAGES; (2) LOSS OF, OR DAMAGE TO, YOUR RECORDS OR DATA; OR (3) SPECIAL, INCIDENTAL, OR INDIRECT DAMAGES OR FOR ANY ECONOMIC CONSEQUENTIAL DAMAGES (INCLUDING LOST PROFITS OR SAVINGS), EVEN IF ASUS, ITS SUPPLIERS OR YOUR RESELLER IS INFORMED OF THEIR POSSIBILITY.
SERVICE AND SUPPORT
Visit our multi-language web site at http://support.asus.com
|
Notebook PC E-Manual |
Table of Contents |
|
About this manual.............................................................................................. |
6 |
Conventions used in this manual................................................................ |
7 |
Icons ............................................................................................................... |
7 |
Typography......................................................................................................... |
7 |
Safety precautions.............................................................................................. |
8 |
Using your Notebook PC................................................................................ |
8 |
Caring for your Notebook PC........................................................................ |
9 |
Proper disposal................................................................................................ |
10 |
Chapter 1: Hardware Setup |
|
Getting to know your Notebook PC........................................................... |
12 |
Top View............................................................................................................. |
12 |
Bottom ............................................................................................................. |
16 |
Right Side........................................................................................................... |
17 |
Left Side ............................................................................................................. |
18 |
Connecting external devices (on selected models)............................. |
20 |
External display................................................................................................ |
20 |
Subwoofer (on selected models)............................................................... |
21 |
External DVD-RW drive (on selected models)...................................... |
22 |
Chapter 2: Using your Notebook PC |
|
Getting started.................................................................................................. |
24 |
Charge your Notebook PC........................................................................... |
24 |
Lift to open the display panel..................................................................... |
25 |
Press the power button................................................................................. |
25 |
Gestures for the touchpad............................................................................ |
26 |
Moving the pointer........................................................................................ |
26 |
One-finger gestures....................................................................................... |
27 |
Two-finger gestures....................................................................................... |
29 |
Three-finger gestures.................................................................................... |
30 |
Using the keyboard.......................................................................................... |
31 |
Function keys.................................................................................................... |
31 |
Function keys for ASUS Apps...................................................................... |
32 |
Windows®8 keys.............................................................................................. |
32 |
Multimedia control keys .............................................................................. |
33 |
Numeric keypad (on selected models).................................................... |
33 |
Notebook PC E-Manual |
|
Chapter 3:Working with Windows® 8 |
|
Starting for the first time................................................................................ |
36 |
Windows® 8 lock screen.................................................................................. |
36 |
Windows® UI........................................................................................................ |
37 |
Start screen........................................................................................................ |
37 |
Windows® apps................................................................................................ |
37 |
Hotspots............................................................................................................. |
38 |
Working with Windows® apps...................................................................... |
40 |
Launching apps............................................................................................... |
40 |
Customizing apps........................................................................................... |
40 |
Closing apps...................................................................................................... |
41 |
Accessing the Apps screen.......................................................................... |
42 |
Charm bar.......................................................................................................... |
44 |
Snap feature...................................................................................................... |
46 |
Other keyboard shortcuts............................................................................. |
48 |
Connecting to wireless networks............................................................... |
50 |
Wi-Fi ............................................................................................................. |
50 |
Bluetooth .......................................................................................................... |
52 |
Airplane mode.................................................................................................. |
54 |
Connecting to wired networks.................................................................... |
55 |
Configuring a dynamic IP/PPPoE network connection..................... |
55 |
Configuring a static IP network connection.......................................... |
59 |
Turning your Notebook PC off..................................................................... |
60 |
Putting your Notebook PC to sleep.......................................................... |
60 |
Chapter 4: ASUS apps |
|
Featured ASUS Apps........................................................................................ |
62 |
LifeFrame............................................................................................................ |
62 |
Power4Gear Hybrid........................................................................................ |
64 |
USB Charger+................................................................................................... |
65 |
Instant On.......................................................................................................... |
67 |
Chapter 5: Power-on Self-test (POST) |
|
The Power-on Self-test (POST)..................................................................... |
70 |
Using POST to access BIOS and Troubleshoot...................................... |
70 |
BIOS ................................................................................................................... |
70 |
Notebook PC E-Manual
Accessing BIOS................................................................................................. |
70 |
BIOS Settings.................................................................................................... |
71 |
Troubleshoot...................................................................................................... |
78 |
Refresh your PC................................................................................................ |
78 |
Reset your PC.................................................................................................... |
79 |
Advanced options........................................................................................... |
80 |
Appendices |
|
DVD-ROM Drive Information (on selected models)........................... |
84 |
Blu-ray ROM Drive Information (on selected models)....................... |
86 |
Internal Modem Compliancy...................................................................... |
87 |
Overview............................................................................................................ |
87 |
Network Compatibility Declaration.......................................................... |
87 |
Network Compatibility Declaration ......................................................... |
88 |
Non-Voice Equipment .................................................................................. |
88 |
Federal Communications Commission Statement............................. |
90 |
FCC Radio Frequency (RF) Exposure Caution Statement.................. |
92 |
Declaration of Conformity (R&TTE directive 1999/5/EC).................. |
92 |
CE Marking........................................................................................................ |
93 |
IC Radiation Exposure Statement for Canada....................................... |
93 |
Wireless Operation Channel for Different Domains........................... |
94 |
France Restricted Wireless Frequency Bands........................................ |
94 |
UL Safety Notices............................................................................................ |
96 |
Power Safety Requirement.......................................................................... |
97 |
TV Tuner Notices.............................................................................................. |
97 |
REACH ............................................................................................................. |
97 |
Nordic Lithium Cautions (for lithium-ion batteries)........................... |
97 |
Optical Drive Safety Information............................................................... |
99 |
Macrovision Corporation Product Notice............................................... |
99 |
CTR 21 Approval (for Notebook PC with built-in Modem)............ |
100 |
ENERGY STAR complied product............................................................ |
101 |
European Union Eco-label........................................................................ |
102 |
Prevention of Hearing Loss....................................................................... |
102 |
Global Environmental Regulation Compliance and Declaration 103 |
|
ASUS Recycling/Takeback Services....................................................... |
103 |
Coating Notice.............................................................................................. |
103 |
Notebook PC E-Manual
About this manual
This manual provides information about the hardware and software features of your Notebook PC, organized through the following chapters:
Chapter 1: Hardware Setup
This chapter details the hardware components of your
Notebook PC.
Chapter 2: Using your Notebook PC
This chapter shows you how to use the different parts of your Notebook PC.
Chapter 3: Working with Windows® 8
This chapter provides an overview of using Windows® 8 in your Notebook PC.
Chapter 4: ASUS Apps
This chapter features the ASUS apps included with your
Notebook PC.
Chapter 5: Power-on Self-test (POST)
This chapter shows you how to use POST to change the settings of your Notebook PC.
Appendices
This section includes notices and safety statements for your
Notebook PC.
Notebook PC E-Manual
Conventions used in this manual
To highlight key information in this manual, some text are presented as follows:
IMPORTANT! This message contains vital information that must be followed to complete a task.
NOTE: This message contains additional information and tips that can help complete tasks.
WARNING! This message contains important information that must be followed to keep you safe while performing tasks and prevent damage to your Notebook PC's data and components.
Icons
The icons below indicate the devices you can use for completing a series of tasks or procedures on your Notebook PC.
= Use the touchpad.
= Use the keyboard.
Typography
Bold |
= This indicates a menu or an item that must be selected. |
Italic |
= This indicates sections that you can refer to in this manual. |
Notebook PC E-Manual
Safety precautions
Using your Notebook PC
This Notebook PC should only be used in environments with ambient temperatures between 5°C (41°F) and 35°C (95°F).
Refer to the rating label on the bottom of your Notebook PC and ensure that your power adapter complies with this rating.
Do not leave your Notebook PC on your lap or near any part of your body to prevent discomfort or injury from heat exposure.
Do not use damaged power cords, accessories, and other peripherals with your Notebook PC.
While powered on, ensure that you do not carry or cover your Notebook PC with any materials that can reduce air circulation.
Do not place your Notebook PC on uneven or unstable work surfaces.
You can send your Notebook PC through x-ray machines (used on items placed on conveyor belts), but do not expose them to magnetic detectors and wands.
Contact your airline provider to learn about related inflight services that can be used and restrictions that must be followed when using your Notebook PC inflight.
Notebook PC E-Manual
Caring for your Notebook PC
Disconnect the AC power and remove the battery pack (if applicable) before cleaning your Notebook PC. Use a clean cellulose sponge or chamois cloth dampened with a solution of nonabrasive detergent and a few drops
of warm water. Remove any extra moisture from your Notebook PC using a dry cloth.
Do not use strong solvents such as thinners, benzene, or other chemicals on or near your Notebook PC.
Do not place objects on top of your Notebook PC.
Do not expose your Notebook PC to strong magnetic or electrical fields.
Do not use or expose your Notebook PC near liquids, rain, or moisture.
Do not expose your Notebook PC to dusty environments.
Do not use your Notebook PC near gas leaks.
Notebook PC E-Manual |
|
Proper disposal
Do not throw your Notebook PC or battery (if applicable) in municipal waste. This product has been designed to enable proper reuse of parts and recycling. The symbol of the crossed out wheeled bin indicates that the product (electrical, electronic equipment and mercury-containing button cell battery) should not be placed in municipal waste. Check local regulations for disposal of electronic products.
10 |
Notebook PC E-Manual |
Chapter 1:
Hardware Setup
Notebook PC E-Manual |
11 |
Getting to know your Notebook PC
Top View
NOTE: The keyboard's layout may vary per region or country. The top view may also vary in appearance depending on the Notebook PC model.
12 |
Notebook PC E-Manual |
Microphone
The built-in microphone can be used for video conferencing, voice narrations, or simple audio recording.
Camera indicator
The camera indicator lights up when the built-in camera is in use.
Camera
The built-in camera allows you take pictures or record videos using your Notebook PC.
Ambient light sensor
The ambient light sensor detects the amount of ambient light in your environment. It allows the system to automatically adjust the brightness of the display depending on the ambient light condition.
Display panel
The display panel provides excellent viewing features for photos, videos, and other multimedia files on your Notebook PC.
Air vents
The air vents allow cool air to enter and warm air to exit the Notebook PC.
WARNING! Ensure that paper, books, clothing, cables, or other objects do not block any of the air vents or else overheating may occur.
Notebook PC E-Manual |
13 |
Power button
Press the power button to turn your Notebook PC on or off. You can also use the power button to put your Notebook PC to sleep or hibernate mode and wake it up from sleep or hibernate mode.
In the event that your Notebook PC becomes unresponsive, press and hold the power button for about four (4) seconds until your Notebook PC shuts down.
Numeric keypad (on selected models)
The numeric keypad can be used for numeric input or as pointer direction keys.
NOTE: For more details, refer to the Numeric keypad section in this manual.
Keyboard
The keyboard provides full-sized QWERTY keys with a comfortable travel depth for typing. It also enables you to use the function keys, allows quick access to Windows®, and controls other multimedia functions.
NOTE:
•The keyboard layout differs by model or territory.
•Some selected models come with a backlit keyboard.
Touchpad
The touchpad allows the use of multi-gestures to navigate onscreen, providing an intuitive user experience. It also simulates the functions of a regular mouse.
NOTE: For more details, refer to the Gestures for the touchpad section in this manual.
14 |
Notebook PC E-Manual |
Status indicators
The status indicators help identify the current hardware status of your Notebook PC.
Drive activity indicator
This indicator lights up when your Notebook PC is accessing the internal storage drives.
Bluetooth / Wireless indicator (on selected models)
This indicator lights up when your Notebook PC’s wireless function (Bluetooth or Wi-Fi) is enabled.
Number lock indicator
This indicator lights up when the number lock function is activated. This allows you to use some of the keys on your keyboard for numeric input.
Capital lock indicator
This indicator lights up when the capital lock function is activated. Using capital lock allows you to type capitalized letters (such as A, B, C) using your Notebook PC’s keyboard.
Notebook PC E-Manual |
15 |
Bottom
NOTE: The bottom side may vary in appearance depending on model.
WARNING! The bottom of the Notebook PC can get warm to hot while in use or while charging the battery pack. When working on your Notebook PC, do not place it on surfaces that can block the vents.
IMPORTANT! Battery time varies by usage and by the specifications for this Notebook PC. The battery pack cannot be disassembled.
Audio speakers
This Notebook PC uses SonicMaster technology developed in collaboration with Bang & Olufsen ICEPower® to provide hi-fi sound quality, with richer bass sounds, straight from the builtin audio speakers.
16 |
Notebook PC E-Manual |
Right Side
Headphone output/microphone input combo jack port
This port allows you to connect your Notebook PC to amplified speakers or headphones. You can also use this port to connect your Notebook PC to an external microphone.
Memory card reader
This Notebook PC has a single built-in memory card reader slot that supports MMC, SD, and SDHC card formats.
USB 3.0 port
This Universal Serial Bus 3.0 (USB 3.0) port provides a transfer rate of up to 5 Gbit/s and is backward compatible to USB 2.0.
Mini VGA port
The mini VGA port allows you to connect your Notebook PC to a standard VGA-compatible device, such as a monitor or projector, using a VGA cable.
Subwoofer jack port
The subwoofer jack port is used to connect the subwoofer (optional) to your Notebook PC.
Power indicator
The power indicator lights up when the Notebook PC is turned on and blinks slowly when the Notebook PC is in sleep mode.
Notebook PC E-Manual |
17 |
Left Side
Power (DC) input port
Insert the bundled power adapter into this port to charge the battery pack and supply power to your Notebook PC.
WARNING! The adapter may become warm to hot while in use. Do not cover the adapter and keep it away from your body while it is connected to a power source.
IMPORTANT! Use only the bundled power adapter to charge the battery pack and supply power to your Notebook PC.
Two-color battery charge indicator
The two-color LED provides a visual indication of the battery’s charge status. Refer to the following table for details:
Color |
Status |
Solid Green |
Battery power is between 95% and |
|
100%. |
Solid Orange |
Battery power is less than 95%. |
Blinking Orange |
Battery power is less than 10%. |
Lights off |
Battery power is more than 10% |
|
and below 100%. |
18 |
Notebook PC E-Manual |
LAN port
Insert the network cable into this port to connect to a local area network (LAN).
NOTE: For more details, refer to the Connecting to wired networks section in this manual.
HDMI port
This port is for a High-Definition Multimedia Interface (HDMI) connector and is HDCP compliant for HD DVD, Blu-ray, and other protected content playback.
USB 3.0 port with USB Charger+
This USB 3.0 port with the
icon comes with the USB Charger+ feature. USB Charger+ allows you to quick-charge mobile devices and can be used even while your Notebook PC is on sleep, hibernate, or shutdown mode (on selected models).
USB 3.0 port
This Universal Serial Bus 3.0 (USB 3.0) port provides a transfer rate of up to 5 Gbit/s and is backward compatible to USB 2.0.
Notebook PC E-Manual |
19 |
Connecting external devices (on selected models)
External display
Use the bundled mini VGA to VGA adapter to connect your Notebook PC to an external display.
Mini VGA port
Mini VGA to
VGA adapter
VGA cable
External display
20 |
Notebook PC E-Manual |
Subwoofer (on selected models)
The optional subwoofer allows you to enjoy richer and deeper bass sounds using ASUS SonicMaster technology.
When using the subwoofer, ensure to connect it to the designated subwoofer jack port on your Notebook PC.
WARNING! Do not force and connect the subwoofer to audio ports other than the subwoofer jack port on your Notebook PC. Doing so may damage the subwoofer or the audio jack.
Subwoofer jack port
Subwoofer
Notebook PC E-Manual |
21 |
External DVD-RW drive (on selected models)
The bundled external optical disc drive supports disc formats such as DVDs and CDs. It also allows you to write and rewrite data to these disc formats.
USB 3.0 ports
To connect the external DVD-RW drive to your Notebook PC:
A.Connect the two USB Y-cable connectors to your Notebook PC.
B.Connect the mini USB connector to the mini USB port on the ASUS DVD-RW drive.
22 |
Notebook PC E-Manual |
Chapter 2:
Using your Notebook PC
Notebook PC E-Manual |
23 |
Getting started
Charge your Notebook PC.
A.Connect the AC power cord to the AC/DC adapter.
B.Plug the AC power adapter into a 100V~240V power source.
C.Connect the DC power connector into your Notebook PC’s power (DC) input.
Charge the Notebook PC for 3 hours before using it in
battery mode for the first time.
IMPORTANT!
•Ensure that your Notebook PC is connected to the power adapter before turning it on for the first time.
•Use only the power adapter bundled with your Notebook PC.
•Power adapter information:
-Input voltage: 100-240Vac
-Input frequency: 50-60Hz
-Rating output current: 4.74A (90W)
-Rating output voltage: 19Vdc
24 |
Notebook PC E-Manual |
Lift to open the display panel.
Press the power button.
Notebook PC E-Manual |
25 |
Gestures for the touchpad
Gestures allow you to launch programs and access the settings of your Notebook PC. Refer to the following illustrations when using hand gestures on your touchpad.
Moving the pointer
You can tap or click anywhere on the touchpad to activate its pointer, then slide your finger on the touchpad to move the pointer onscreen.
Slide horizontally
Slide vertically
Slide diagonally
26 |
Notebook PC E-Manual |
One-finger gestures
Tap/Double tap
•In the Start screen, tap an app to launch it.
•In Desktop mode, double-tap an application to launch it.
Left-click |
|
|
Right-click |
|
|
|
|
|
|
|
|
• |
In the Start screen, click an • |
|
app to launch it. |
•In Desktop mode, doubleclick an application to launch it.
•
In the Start screen, click an app to select it and launch the settings bar. You can also press this button to launch the All Apps bar.
In Desktop mode, use this button to open the rightclick menu.
NOTE: The areas inside the dotted line represent the locations of the left mouse button and the right mouse button on the touchpad.
Notebook PC E-Manual |
27 |
Drag and drop
Double-tap an item, then slide the same finger without lifting it off the touchpad. To drop the item to its new location, lift your finger from the touchpad.
Top edge swipe
•In the Start screen, swipe from the top edge to launch the All Apps bar.
•In a running app, swipe from the top edge to view its menu.
Left edge swipe |
Right edge swipe |
||
|
|
|
|
|
|
|
|
Swipe from the left edge to shuffle your running apps.
Swipe the right edge to launch the Charm bar.
28 |
Notebook PC E-Manual |
Two-finger gestures
Tap Rotate
Tap two fingers on the touchpad to simulate the right-click function.
To rotate an image, place two fingers on the touchpad then turn one finger clockwise or counterclockwise while the other stays still.
Two-finger scroll (up/down) |
Two-finger scroll (left/right) |
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Slide two fingers to scroll up or down.
Zoom out
Bring together your two fingers on the touchpad.
Slide two fingers to scroll left or right.
Zoom in
Spread apart your two fingers on the touchpad.
Notebook PC E-Manual |
29 |
Drag and drop
Select an item then press and hold the left button. Using your other finger, slide down the touchpad to drag and drop the item to a new location.
Three-finger gestures
Swipe up |
|
Swipe down |
|
|
|
Swipe three fingers upward to show all running applications.
Swipe three fingers downward to show the Desktop mode.
30 |
Notebook PC E-Manual |
Loading...
