CABINET PARTS

For Models: ABB2221FEW1, ABB2221FEB1 (White) (Black)

REFRIGERATOR

10−07 Litho In U.S.A. (cjj)











1



Part No. W10169670 Rev.A

CABINET PARTS

For Models: ABB2221FEW1, ABB2221FEB1



(White)

(Black)

Illus.

Part



No.

No. DESCRIPTION

1Literature Parts W10137539 Use & Care Guide W10123457 Energy Guide W10169671 Tech Sheet

2Cabinet (Not a Servicable Part)

3Plug, Button (3) 67001130 White 67001131 Black

4B5759649 Gasket

567006118 Roller Assembly

667003868 Foot, Brake

767006744 Pin, Center Hinge

867006611 Bolt, Adjusting

(Front Roller)

967006521 Screw

10Cover, Hinge 67001014 White 67001012 Black

1167005822 Screw

1267006473 Screw

1367005064 Label, Fl Tb

Plug

1467006303 Screw

15Hinge, Center 67006960 White 67007043 Black

1612566604ED Hinge, Top

17Cover, Corner 67003484 White 67003485 Black

1867001067 Clip, Drain

1967001069 Hinge Bottom

2067006564 Screw

2167006101 Cover, Unit

22Grille Assembly (Includes Clips)

67002223 White

67002224 Black

2367001098 Cover, Fl Tb

2467001066 Tube, Drain

2567006425 Screw (9)

2667003796 Fiber, Acoustic

2767001097 Cover, Water Valve

2912479901 Plate, Cover

3067006662 Screw

31M0274057 Shim, Non Metal

3267007018 Pin, Bottom Hinge

33Cover, LWR Hinge 12561901W White

12561901B Black

3412627302 Clip, Grille

Following Parts Not Illustrated

8170942 Clamp, Tube









W10169670

2



FREEZER LINER PARTS

For Models: ABB2221FEW1, ABB2221FEB1

(White) (Black)

W10169670









3



FREEZER LINER PARTS

For Models: ABB2221FEW1, ABB2221FEB1



(White)

(Black)

Illus.

Part



No.

No. DESCRIPTION

1Liner (Not A Seviceable Part)

267001291 Gasket, Foam

367001045 Panel Fz

Control

467001285 Cover, Light

567001046 Control, Fz

6Y12570701 Socket, Light

767003420 Knob, Fz

Control

8A0282812 Bulb, Light

967001035 Housing, Frz. Light

1067005869 Cover, Evaporator

1167006425 Screw (7)

1267001286 Module, Freezer

13W10167028 Clip, Evap. Motor

1467005653 Switch, Light

1567001776 Gasket, Bottom

1613024802 Cover, Fan Shroud

17W10167023 Shroud, Evap.Fan

182169142 Blade, Fan

(Evaporator)

19W10121318 Grommet

2067003636 Motor, Evaporator

21D7753903 Funnel, Drain

22M0500703 Seal

23B8381501 Gasket

Following Parts Not Illustrated

W10130480 Harness, Lights

(Freezer)









W10169670

4



FREEZER DOOR PARTS

For Models: ABB2221FEW1, ABB2221FEB1 (White) (Black)

Illus.

Part







Illus.



Part







Illus. Part



No.

No.

DESCRIPTION





No.



No.

DESCRIPTION





No.

No.

DESCRIPTION

1



Freezer Door



3





Door Gasket,



6



Plug, Button (2)





(w/ Insulation)













Magnetic







10712401

White

W10168717

White









W10130894

White





W10153326

Black

W10168719

Black









W10130587

Black



7

67003934

Retainer

2



Handle



4





Plug, Hole



8



Bushing



67005140

White









67001130

White







67004977

White



67005125

Black



5

67001131

Black



9

67004978

Black













Stop, Door



67006831

Screw (2)















67003779

White



10

67006287

Screw (2)















67003780

Black







































































W10169670

5

REFRIGERATOR LINER PARTS

For Models: ABB2221FEW1, ABB2221FEB1 (White) (Black)

Illus. Part







Illus.



Part







Illus.

Part





No.

No.

DESCRIPTION





No.



No.

DESCRIPTION







No.

No.

DESCRIPTION



1



Liner (Not A



9

A0282812

Bulb, Light (2)



17



67002512

Knob, Damper





Serviceable Part)



10

Y12570701

Socket, Light (2)













Upfront

2

67003108

Module, Light



11

67002301

Cover



18



67003104

Logo, Light

3

67001040

Belt, Damper













Ref Light



19



67002085

Pan, Timer

4

67001034

Tensioner, Belt



12

12990514

Screw













Light Housing

5

67001036

Timer, Defrost



13

67002000

Cover, Damper

















6

C3680310

Switch, Light



14

67003803

Insulation

















7

M0310343

Plug, Button



15

67003410

Damper, Gear







Following Parts Not Illustrated





White













Assembly

















































8

67001035

Housing, Light



16

67001033

Knob, Gear











67001043

Harness, Controls































































(Refrigerator)









































































































6

W10169670

REFRIGERATOR DOOR PARTS

For Models: ABB2221FEW1, ABB2221FEB1

(White) (Black)

W10169670









7



REFRIGERATOR DOOR PARTS

For Models: ABB2221FEW1, ABB2221FEB1



(White)

(Black)

Illus.

Part



No.

No. DESCRIPTION

1Refrigerator Door (w/Liner)

67001009 White

67001008 Black

267006682 Screw

367003819 Door, Dairy

467001279 Tray, Dairy

567001021 Bucket, Medium (4)

6Plug, Handle Hole 67001130 White

67001131 Black

7Plug, Button 10712401 White 67004838 Black

8Door Gasket,

Magnetic

W10130893 White

W10131327 Black

9Door Handle 67003129 White 67003130 Black

1012528501 Nameplate

1167001280 Retainer, Ref Door

1267006287 Screw

13Bushing 67004977 White 67004978 Black

14Stop, Door 67003779 White 67003780 Black

15M0274057 Shim, Non Metal

1612248201 Screw

17Trim, Handle Btm 67005134 White

67005135 Black

18Trim, Top Handle 67005131 White

67005132 Black

1910423131 Bin, Utility









W10169670

8



UNIT PARTS

For Models: ABB2221FEW1, ABB2221FEB1 (White) (Black)

W10169670









9



UNIT PARTS







For Models: ABB2221FEW1, ABB2221FEB1



























(White)

(Black)























Illus. Part









Illus. Part













Illus.

Part

































No.

No.

DESCRIPTION







No.



No.

DESCRIPTION











No.

No.

DESCRIPTION

1

67006433

Screw



20



67001080

Tray, Drip





































Following Parts Not Illustrated

2

W10162928

Blade, Fan



21

67006737

Screw









and Optional Parts Not Included

3

67005744

Basepan





22

12001919

Evaporator



























































4

67006425

Screw



23





Dam

















978025

Valve, Access

5

67005491

Block, Condenser











67001084

Right Side

















6

W10167036

Tube, Discharge











67001083

Left Side



















(1/4")





7

W10119855

Harness, Evap.



24



67004432

Motor, Fan

















978026

Valve, Access





Heater



25

10428101

Clip, Heater



















(5/16")





8

67004713

Drain Pan



26



13060301

Harness, MC

















978027

Valve, Access

9

61004743

Grommet (3)















(Includes



















(3/8")





10

67001794

Evaporator Heater















Power Cord)

















978028

Valve, Access

11

W10136415

Clip, Capacitor



27



23178454

Drier (Service)

















(1/2")





12

W10136414

Overload



28



W10130129

Compressor

















978029

Valve, Access





(Includes Relay)



29



2264017

Capacitor



















(5/8")





13

61003210

Gasket



30



67006434

Axle, Roller

















978030

Valve, Access

14

67003426

Thermostat



31

W10153406

Shroud



















(3/4")





15

W10137529

Grommet



32

67004953

Bracket, Fan Motor















876764

Valve, Access

16

67006573

Screw



33

67004954

Screw



















(3/16")





17

67003493

Grommet (4)



34



10547003

Clip, Drier

























18

67006132

Condenser



35

67005149

Roller











REFRIGERANT CHARGE

19

67006432

Screw



36



10623002

Clip, Evap



















37



67005680

Grommet



















5.00 Ozs.



















































































(R−134A)











































































































































10
