FAVORIT 88060 VI

DISHWASHER

USER MANUAL

2

CONTENTS

4 SAFETY INFORMATION

6 PRODUCT DESCRIPTION

7 CONTROL PANEL

8 PROGRAMMES

10 OPTIONS

12 BEFORE FIRST USE

15 DAILY USE

18CARE AND CLEANING

19TROUBLESHOOTING

21 TECHNICAL INFORMATION

ENVIRONMENT CONCERNS

Recycle the materials with the symbol . Put the packaging in applicable containers to recycle it.

Help protect the environment and human health and to recycle waste of electrical

and electronic appliances. Do not dispose appliances marked with the symbol with the household waste. Return the product to your local recycling facility or contact your municipal office.

VISIT OUR WEBSITE FOR:

-Products

-Brochures

-User manuals

-Trouble shooter

-Service information

www.aeg.com

LEGEND

Warning - Important Safety information.

General information and tips

Environmental information

Subject to change without notice

ENGLISH 3

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

ACCESSORIES AND CONSUMABLES

In the AEG webshop, you’ll find everything you need to keep all your AEG appliances looking spotless and working perfectly. Along with a wide range of accessories designed and built to the high quality standards you would expect, from specialist cookware to cutlery baskets, from bottle holders to delicate laundry bags…

Visit the webshop at:

www.aeg.com/shop

CUSTOMER CARE AND SERVICE

We recommend the use of original spare parts.

When contacting Service, ensure that you have the following data available. The information can be found on the rating plate.

Model

PNC

Serial Number

4

SAFETY INFORMATION

Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference.

CHILDREN AND VULNERABLE PEOPLE SAFETY

WARNING!

Risk of suffocation, injury or permanent disability.

Do not let persons, children included, with reduced physical sensory, reduced mental functions or lack of experience and knowledge use the appliance. They must have supervision or instruction for the operation of the appliance by a person who is responsible for their safety. Do not let children play with the appliance.

Keep all packaging away from children. There is the risk of suffocation and injury.

Keep all detergents away from children.

Keep children and pets away from the appliance door when it is open.

INSTALLATION

WARNING!

This appliance must be installed by a qualified or competent person.

Remove all the packaging.

Do not install or use a damaged appliance.

Do not install or use the appliance where the temperature is less than 0 °C.

Obey the installation instruction supplied with the appliance.

Make sure that the appliance is installed below and adjacent to safe structures.

Water connection

Make sure not to cause damage to the water hoses.

Before you connect the appliance to new pipes or pipes not used for a long time, let the water flow until it is clean.

The first time you use the appliance, make sure that there is no leakage.

WARNING!

Dangerous voltage.

The water inlet hose has a safety valve and a sheath with an inner mains cable.

If the water inlet hose is damaged, immediately disconnect the mains plug from the mains socket. Contact Service to replace the water inlet hose.

Electrical connection

WARNING!

Risk of fire and electrical shock.

The appliance must be earthed.

Make sure that the electrical information on the rating plate agrees with the power supply. If not, contact an electrician.

Always use a correctly installed shockproof socket.

Do not use multi-plugadapters and extension cables. There is a risk of fire.

Make sure not to cause damage to the mains plug and to the mains ca-

ble. Contact Service or an electrician to change a damaged mains cable.

Connect the mains plug to the mains socket only at the end of the installation. Make sure that there is access to the mains plug after the installation.

Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.

Only for UK and Ireland. The appliance has a 13 amp mains plug. If it is necessary to change the fuse in the mains plug, use a 13 amp ASTA (BS 1362) fuse.

USE

WARNING!

Risk of injury.

Use this appliance in a household environment.

Do not change the specification of this appliance.

Put knives and cutlery with sharp points in the cutlery basket with the points down or in a horizontal position.

Do not keep the appliance door open without supervision to prevent to fall on it.

Do not sit or stand on the open door.

Dishwasher detergents are dangerous. Obey the safety instructions on the detergent packaging.

Do not drink and play with the water in the appliance.

Do not remove the dishes from the appliance until the programme is

ENGLISH 5

completed. There can be detergent on the dishes.

WARNING!

Risk of electrical shock, fire or burns.

Do not put flammable products or items that are wet with flammable products in, near or on the appliance.

Do not use water spray and steam to clean the appliance.

The appliance can release hot steam if you open the door while a programme operates.

INTERNAL LIGHT

WARNING!

Risk of injury.

Visible LED radiation, do not look directly into the beam.

The LED is CLASS 2 and agrees with IEC 60825-1:1993 + A1:1997 + A2:2001. Emission wave length: 450 nm Maximum emitted power: 548 μW

To replace the internal light, contact Service.

DISPOSAL

WARNING!

Risk of injury or suffocation.

Disconnect the appliance from the mains supply.

Cut off the mains cable and dispose of it.

Remove the door catch to prevent children and pets to get closed in the appliance.

6

PRODUCT DESCRIPTION

1

2

3

12

11

10

9

8

7

6

5

4

1

Top spray arm

7

Water hardness dial



Upper spray arm



Rinse aid dispenser

2

8



Lower spray arm



Detergent dispenser

3

9



Filters



Cutlery basket

4

10



Rating plate



Lower basket

5

11



Salt container



Upper basket

6

12

TIME BEAM

Time Beam is a light beam that shows, on the kitchen floor:

• The programme duration. It decreases with steps of one minute.

• The end of the programme (0:00).

• The time of the delay start. It decreases with steps of one hour (24h, 23h...).

• Alarm codes.

ENGLISH 7

CONTROL PANEL

1

2

3

4

5

6

7

8

9

1

On/off button

6

ÖKO PLUS touchpad



Display



Multitab touchpad

2

7



Delay touchpad



RESET touchpad

3

8



Programme touchpad



Indicators

4

9



ExtraHygiene touchpad





5













Indicators

Salt indicator. This indicator is off while the programme operates.

Rinse aid indicator. This indicator is off while the programme operates.

End indicator.

8

PROGRAMMES

Programme

Type of soil

Programme phases

Options







Type of load





1





All

Prewash

ExtraHygiene

1)

Crockery, cutlery,

Wash 45 °C or 70 °C

ÖKO PLUS

pots and pans

Rinses



















Dry



2





Heavy soil

Prewash

ÖKO PLUS

2)

Crockery, cutlery,

Wash 70 °C



pots and pans

Rinses











Dry



3





Normal soil

Prewash









Crockery and

Wash 50 °C









cutlery

Rinses



3)





Dry













4





Fresh soil

Wash 60 °C

ExtraHygiene







Crockery and

Rinse









cutlery





4)











5





Normal soil

Prewash

ExtraHygiene

5)

Crockery and

Wash 50 °C

ÖKO PLUS

cutlery

Rinses











Dry



6





Light soil

Wash 55 °C

ExtraHygiene







Crockery and

Rinses









cutlery



























7





Normal or light

Wash 45 °C

ÖKO PLUS







soil

Rinses









Delicate crockery

Dry









and glassware





8





All

Prewash



6)



















1)The appliance senses the type of soil and the quantity of items in the baskets. It automatically adjusts the temperature and quantity of the water, the energy consumption and the programme duration.

2)This programme includes the ExtraHygiene option.

3)This is the most silent washing programme. The pump works at a very low speed to decrease the level of noise. Because of the low speed, the programme duration is long.

4)With this programme you can wash a load with fresh soil. It gives good washing results in a short time.

5)This is the standard programme for test institutes. With this programme you have the most efficient use of water and energy consumption for crockery and cutlery with normal soil. Refer to the supplied leaflet for test information.

6)Use this programme to quickly rinse the dishes. This prevents the remaining food to bond on the dishes and bad odours to come out from the appliance.

Do not use detergent with this programme.

ENGLISH 9

Consumption values

Programme 1)

Duration (min)

Energy (kWh)

Water (l)

1





90

- 160

0.9 - 1.7

8 - 15













2





140 - 160

1.4 - 1.6

13 - 14













3





200 - 220

1.1 - 1.2

9 - 11











































4





30



0.8

9









































5





160 - 170

0.9 - 1.0

9 - 11















6





50

- 60

1.0 - 1.1

10 - 11











































7





70

- 80

0.8 - 0.9

11 - 12















8





14



0.1

4















1)The water pressure and temperature, the variations of the mains supply, the options and the quantity of dishes can change the programme duration and the consumption values.

10

OPTIONS

MULTITAB FUNCTION

Activate this function only when you use the combi detergent tablets. This function deactivates the flow of

rinse aid and salt. The related indicators are off.

The programme duration can increase.

Activating the multitab function

Activate or deactivate the multitab function before the start of a programme. You cannot activate or deactivate this function when a programme operates.

1.Press the on/off button to activate the appliance.

2.Make sure that the appliance is in setting mode. Refer to ‘SETTING AND STARTING A PROGRAMME'.

3.Press the multitab touchpad, the multitab indicator comes on.

The function stays on until you deactivate it. Press the multitab touchpad, the multitab indicator goes off.

If you stop to use the combi detergent tablets, before you start to use separately detergent, rinse aid and dishwasher salt, do these steps:

1.Deactivate the multitab function.

2.Set the water softener to the highest level.

3.Make sure that the salt container and the rinse aid dispenser are full.

4.Start the shortest programme with a rinsing phase, without detergent and without dishes.

5.Adjust the water softener to the water hardness in your area.

6.Adjust the released quantity of rinse aid.

ÖKO PLUS

This function decreases the temperature in the drying phase. The energy consumption decreases by 25%.

The dishes can be wet at the end of the programme. We recommend that you keep the door ajar and let the dishes dry.

EXTRAHYGIENE

This function gives better results for the hygiene. During the rinsing phase, the temperature stays at 70 °C for 10 to 14 minutes.

ACOUSTIC SIGNALS

The acoustic signals operate in these conditions:

The programme is completed.

The level of the water softener is adjusted electronically.

The appliance has a malfunction.

Factory setting: on. You can deactivate the acoustic signals.

Deactivating the acoustic signals

1.Press the on/off button to activate the appliance.

2.Make sure that the appliance is in setting mode. Refer to ‘SETTING AND STARTING A PROGRAMME’.

3.Press and hold touchpads (4) and (5) at the same time until the indicators of touchpads (3), (4), (5) and (6) flash.

4.Press touchpad (5),

The indicators of touchpads (3), (4) and (6) go off.

The indicator of touchpad (5) continues to flash.

The display shows the setting of the acoustic signals.

On

Off
