222 D

FumeExtractorHood

InstallationandOperatingInstructions

Printed on recycled paper.

AEG – putting words into action.

2

Contents

Introduction

4

Extraction mode

4





Recirculation mode

5





Electrical connections

6

Technical details

7

Installation

8

Safety warnings for kitchen unit installer

8





Wall unit mounting

10





Wall mounting

11





Hood operation

12

Safety warnings for user

13





Maintenance and care

14

Opening the grid

14





Grease filter

14





Carbon filter

15





Changing the light bulb

16





Cleaning

16

Accessories

16

Something not working

17

Service & Spare parts

18

3

Introduction

Extraction mode

The hood is supplied as an extractor unit and can also be used with a filtering function by fitting activated carbon filters (available as an accessory).

The unit features two outlet holes, one of which A is located on the top of the unit while the other B is located on the rear.

To connect up the hose, you should first fit the bayonet-mountingflange C (Ø120 mm) on the outlet required (if using the top outlet, fix the flange in place using the screw supplied as shown in Fig. 1). Close off the unused hole using the bayonet fitting caps D.

C

D

A

A

B

B

C

D



1

Important! To use the back hole B, remove switch F from the top hole. — Fig 2.

2

4

● Move the lever L to position A — Fig. 3.

L

3

L

When connecting up the hood using a telescopic wall pipe, you should use an uninflammable outlet hose ABS 120 (120 mm Ø) available as an accessory.

Recirculation mode

The air is filtered and recirculated through the front grid.

Move the lever L to position F — Fig. 3.

You will need an original KFF activated carbon filter for filtering function. (Available as an accessory).

Summer/Winter Hood Conversion

To avoid excessive heat loss during the winter months, we recommend that the hood be converted from extraction mode to recirculation mode.

In order to convert the hood, a charcoal filter (available as an accessory) is required. Follow the instructions for operating the hood to recirculate air.

When the temperature outdoors becomes more mild (spring), the filter can be removed and the hood converted once again for to extraction. Please consult the assembly instructions for operating the hood in extraction mode.

5

Electrical connection

220-240V - using fixed power supply line with plug.

(The unit should only be connected up by an authorized electrician). Your appliance must be connectedto fixedwiring via the useofadouble pole swiched fused spur outlet with or without pilot lamp.

We strongly recommend the appliance is connected by a qualified electrician who is a member of the NICEIC who will comply with the IEE andanylocalregulations.

NOTE: the terminology “DOUBLE POLE” means that both the live andneutralsuppliesareswichedanddisconnectedatthesametime.

TheterminationslabelledSUPPLYarefortheconnectionfortheinternal house wiring and the terminations labelled LOAD are for the appliance.

IMPORTANT

The wires of the mains lead supplied with this appliance are coloured in accordance with the following code:

Blue-Neutral

Brown-Live

As the colours of the flexible cord of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The whire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red.

The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured

black.

6

Technical details

Dimensions

Height x Width x Depth (in cm)

13 x 59,9 x 51









Weight



Net:

6,9 kg

Gross:

7,8 kg





Maximum absorbed power:

205 W

Motor absorption

1 x 125 W





Lighting:

2 x 40 W





Length of the cable:

110 cm



Fan powers (speed), speed in compliance with DIN 44971

Extraction mode



Speed1

115 m3/h

Speed2

145 m3/h

Speed3

180 m3/h

Intensive speed

210 m3/h

Recirculation mode



Speed1

110 m3/h

Speed2

117 m3/h

Speed3

125 m3/h

Intensive speed

145 m3/h

Flange:120 mm Ø







7

Installation

Safety warnings for kitchen unit installer

When used as an extractor unit, the hood must be fitted with a 120mm diameter hose.

If the fumes must be forced out through the wall, you must obtain a MKZ sizable wall exhaust pipe (with external exhaust and air intake), E-Nr.-610 899 004 (Ø 120 mm) which is one of our optional parts.

When installing the hood, make sure you respect the following minimum distance from the top edge of the cooking hob/ring surfaces:

electric cookers

650 mm

gas cookers

700 mm

The hood cannot be connected to flues of other appliances that run on energy sources other than electricity.

The air outlet must not be connected to chimney flues or combustion gas ducts. The air outlet must under no circumstances be connected to ventilation ducts for rooms in which fuel-burningappliances are installed.

It is advisable to apply for authorization from the relevant controlling authority when connecting the outlet to an unused chimney flue or combustion gas duct.

The air outlet installation must comply with the regulations laid down by the relevant authorities.

When the unit is used in its extractor version, a sufficiently large ventilation hole must be provided, with dimensions that are approximately the same as the outlet hole.

National and regional building regulations impose a number of restrictions on using hoods and fuel-burningappliances connected to a chimney, such as coal or oilroom-heatersand gas fires, in the same room.

8

The national decree on fuel-burningsystems specifies a maximum depression of 0.04 bar in such rooms.

Hoods can only be used safely with appliances connected to a chimney if the room and/or flat (air/environment combination) is ventilated from outside using a suitable ventilation hole approximately 500-600cm2 large to avoid the possibility of a depression being created during operation of the hood.

If you have any doubts, contact the relevant controlling authority or building inspector’s office.

Since the rule for rooms with fuel burning appliances is “outlet hole of the same size as the ventilation hole”, a hole of 500-600cm2, which is to say a larger hole, could reduce the performance of the extractor hood.

If the hood is used in its filtering function, it will operate simply and safely in the above conditions without the need for any of the aforementioned measures.

When the hood is used in its extractor function, the following rules must be followed to obtain optimal operation:

short and straight outlet hose

keep bends in outlet hose to a minimum

never install the hoses with an acute angle, they must

always follow a gentle curve only

— keep the hose as large as possible (120 mm Ø min.).

Failure to observe these basic rules will drastically reduce the performance and increase the noise levels of the extractor hood.

9

Wall unit mounting

Make the holes on the bottom of the cupboard, using the drilling template .

From inside the cupboard, insert the 4 supplied screws and tighten them in the appropriate holes on the appliance. — Fig. 4.

4
